NAD C715 User manual

,!5.!-%#)62%3
#$2ECEIVER
##$!"
#$2ECEIVER
##$!"
For Orignal DAB Module up to S/N A86C71512400
Draft: March 2010

1-3
CAUTION : DO NOT ATTEMPT TO MODIFY THIS PRODUCT IN
ANY WAY. NEVER PERFORM CUSTOMIZED INSTALLATIONS
WITHOUT MANUFACTURER’S APPROVAL. UNAUTHORIZED
MODIFICATIONS WILL NOT ONLY VOID THE WARRANTY, BUT
MAY LEAD TO YOUR BEING LIABLE FOR ANY RESULTING
PROPERTY DAMAGE OR USER INJURY.
SERVICE WORK SHOULD BE PERFORMED ONLY AFTER YOU
ARE THOROUGHLY FAMILIAR WITH ALL OF THE FOLLOWING
SAFETY CHECKS AND SERVICING GUIDELINES. TO DO
OTHERWISE, INCREASES THE RISK OF POTENTIAL HAZARDS
AND INJURY TO THE USER.
WHILE SERVICING, USE AN ISOLATION TRANSFORMER FOR
PROTECTION FROM AC LINE SHOCK.
SAFETY CHECKS
AFTER THE ORIGINAL SERVICE PROBLEM HAS BEEN
CORRECTED. A CHECK SHOULD BE MADE OF THE
FOLLOWING.
SUBJECT : FIRE & SHOCK HAZARD
1. BE SURE THAT ALL COMPONENTS ARE POSITIONED IN
SUCH A WAY AS TO AVOID POSSIBILITY OF ADJACENT
COMPONENT SHORTS. THIS IS ESPECIALLY IMPORTANT
ON THOSE MODULES WHICH ARE TRANSPORTED TO AND
FROM THE REPAIR SHOP.
2. NEVER RELEASE A REPAIR UNLESS ALL PROTECTIVE
DEVICES SUCH AS INSULATORS, BARRIERS, COVERS,
SHIELDS, STRAIN RELIEFS, POWER SUPPLY CORDS, AND
OTHER HARDWARE HAVE BEEN REINSTALLED PER
ORIGINAL DESIGN. BE SURE THAT THE SAFETY PURPOSE
OF THE POLARIZED LINE PLUG HAS NOT BEEN DEFEATED.
3. SOLDERING MUST BE INSPECTED TO DISCOVER POSSIBLE
COLD SOLDER JOINTS, SOLDER SPLASHES OR SHARP
SOLDER POINTS. BE CERTAIN TO REMOVE ALL LOOSE
FOREIGN PARTICLES.
4. CHECK FOR PHYSICAL EVIDENCE OF DAMAGE OR
DETERIORATION TO PARTS AND COMPONENTS. FOR
FRAYED LEADS, DAMAGED INSULATION (INCLUDING AC
CORD). AND REPLACE IF NECESSARY FOLLOW ORIGINAL
LAYOUT, LEAD LENGTH AND DRESS.
5. NO LEAD OR COMPONENT SHOULD TOUCH A RECEIVING
TUBE OR A RESISTOR RATED AT 1 WATT OR MORE. LEAD
TENSION AROUND PROTRUDING METAL SURFACES MUST
BE AVOIDED.
6. ALL CRITICAL COMPONENTS SUCH AS FUSES,
FLAMEPROOF RESISTORS, CAPACITORS, ETC. MUST BE
REPLACED WITH EXACT FACTORY TYPES, DO NOT USE
REPLACEMENT COMPONENTS OTHER THAN THOSE
SPECIFIED OR MAKE UNRECOMMENDED CIRCUIT
MODIFICATIONS.
7. AFTER RE-ASSEMBLY OF THE SET ALWAYS PERFORM AN
AC LEAKAGE TEST ON ALL EXPOSED METALLIC PARTS OF
THE CABINET, (THE CHANNEL SELECTOR KNOB, ANTENNA
TERMINALS. HANDLE AND SCREWS) TO BE SURE THE SET
IS SAFET TO OPERATE WITHOUT DANGER OF ELECTRICAL
SHOCK. DO NOT USE A LINE ISOLATION TRANSFORMER
DURING THIS TEST USE AN AC VOLTMETER, HAVING 5000
OHMS PER VOLT OR MORE SENSITIVITY, IN THE
FOLLOWING MANNER; CONNECT A 1500 OHM 10 WATT
RESISTOR, PARALLELED BY A .15 MFD, 150V AC TYPE
CAPACITOR BETWEEN A KNOWN GOOD EARTH GROUND
(WATER PIPE, CONDUIT, ETC.) AND THE EXPOSED
METALLIC PARTS, ONE AT A TIME.
MEASURE THE AC VOLTAGE ACROSS THE COMBINATION
OF 1500 OHM RESISTOR AND .15 MFD CAPACITOR.
REVERSE THE AC PLUG AND REPEAT AC VOLTAGE
MEASUREMENTS FOR EACH EXPOSED METALLIC PART.
VOLTAGE MEASURE MUST NOT EXCEED 75 VOLTS R.M.S.
THIS CORRESPONDS TO 0.5 MILLIAMP AC ANY VALUE
EXCEEDING THIS LIMIT CONSTITUTES A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED IMMEDIATELY.
SUBJECT : GRAPHIC SYMBOLS
SUBJECT : TIPS ON PROPER INSTALLATION
1. NEVER INSTALL ANY PRODUCT IN A CLOSED-IN RECESS,
CUBBYHOLE OR CLOSELY FITTING SHELF SPACE. OVER
OR CLOSE TO HEAT DUCT, OR IN THE PATH OF HEATED
AIR FLOW.
2. AVOID CONDITIONS OF HIGH HUMIDITY SUCH AS:
OUTDOOR PATIO INSTALLATIONS WHERE DEW IS A
FACTOR, NEAR STEAM RADIATORS WHERE STEAM
LEAKAGE IS A FACTOR, ETC.
3. AVOID PLACEMENT WHERE DRAPERIES MAY OBSTRUCT
REAR VENTING. THE CUSTOMER SHOULD ALSO AVOID THE
USE OF DECORATIVE SCARVES OR OTHER COVERINGS
WHICH MIGHT OBSTRUCT VENTILATION.
4. WALL AND SHELF MOUNTED INSTALLATIONS USING A
COMMERCAL MOUNTING KIT MUST FOLLOW THE FACTORY
APPROVED MOUNTING INSTRUCTIONS A PRODUCT
MOUNTED TO A SHELF OR PLATFORM MUST RETAIN ITS
ORIGINAL FEET (OR THE EQUIVALENT THICKNESS IN
SPACERS) TO PROVIDE ADEQUATE AIR FLOW ACROSS
THE BOTTOM, BOLTS OR SCREWS USED FOR FASTENERS
MUST NOT TOUCH ANY PARTS OR WIRING. PERFORM
LEAKAGE TEST ON CUSTOMIZED INSTALLATIONS.
5. CAUTION CUSTOMERS AGAINST THE MOUNTING OF A
PRODUCT ON SLOPING SHELF OR A TILTED POSITION,
UNLESS THE PRODUCT IS PROPERLY SECURED.
6. A PRODUCT ON A ROLL-ABOUT CART SHOULD BE STABLE
ON ITS MOUNTING TO THE CART. CAUTION THE
CUSTOMER ON THE HAZARDS OF TRYING TO ROLL A CART
WITH SMALL CASTERS ACROSS THRESHOLDS OR DEEP
PILE CARPETS.
7. CAUTION CUSTOMERS AGAINST THE USE OF A CART OR
STAND WHICH HAS NOT BEEN LISTED BY UNDERWRITERS
LABORATORIES, INC. FOR USE WITH THEIR SPECIFIC
MODEL OF TELEVISION RECEIVER OR GENERICALLY
APPROVED FOR USE WITH T.V.’S OF THE SAME OR
LARGER SCREEN SIZE.
8. CAUTION CUSTOMERS AGAINST THE USE OF EXTENSION
CORDS, EXPLAIN THAT A FOREST OF EXTENSIONS
SPROUTING FROM A SINGLE OUTLET CAN LEAD TO
DISASTROUS CONSEQUENCES TO HOME AND FAMILY.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN
EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE
PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE
PRODUCT’S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO
CONSTITUTE A RISK OF ELECTRIC SHOCK.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS
INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE APPLIANCE.
PRODUCT SAFETY SERVICING GUIDELINES

1-4
SERVICING PRECAUTIONS
CAUTION : Before servicing the A/V Receiver covered by this
service data and its supplements and addends, read and follow the
SAFETY PRECAUTIONS. NOTE : if unforeseen circumstances
create conflict between the following servicing precautions and any
of the safety precautions in this publication, always follow the safety
precautions.
Remember Safety First:
General Servicing Precautions
1. Always unplug the A/V Receiver AC power cord from the AC
power source before:
(1) Removing or reinstalling any component, circuit board,
module, or any other assembly.
(2) Disconnecting or reconnecting any internal electrical plug or
other electrical connection.
(3) Connecting a test substitute in parallel with an electrolytic
capacitor.
Caution : A wrong part substitution or incorrect polarity installation
of electrolytic capacitors may result in an explosion hazard.
2. Do not spray chemicals on or near this A/V Receiver or any of its
assemblies.
3. Unless specified otherwise in this service data, clean electrical
contacts by applying an appropriate contact cleaning solution to
the contacts with a pipe cleaner, cottontipped swab, or
comparable soft applicator.
Unless specified otherwise in this service data, lubrication of
contacts is not required.
4. Do not defeat any plug/socket B+ voltage interlocks with which
instruments covered by this service manual might be equipped.
5. Do not apply AC power to this A/V Receiver and/or any of its
electrical assemblies unless all solid-state device heat sinks are
correctly installed.
6. Always connect test instrument ground lead to the appropriate
ground before connecting the test instrument positive lead. Always
remove the test instrument ground lead last.
Insulation Checking Procedure
Disconnect the attachment plug from the AC outlet and turn the
power on. Connect an insulation resistance meter(500V) to the
blades of the attachment plug. The insulation resistance between
each blade of the attachment plug and accessible conductive parts
(Note 1) should be more than 1M-ohm.
Note 1 : Accessible Conductive Parts including Metal panels, Input
terminals, Earphone jacks, etc.
Electrostatically Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by
static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical Es
devices are integrated circuits and some field effect transistors and
semiconductor chip components.
The following techniques should be used to help reduce the
incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or
semiconductor-equipped assembly, drain off any electrostatic
charge on your body by touching a known earth ground.
Alternatively, obtain and wear a commercially available
discharging wrist strap device, which should be removed for
potential shock reasons prior to applying power to the unit under
test.
2. After removing an electrical assembly equipped with ES devices,
place the assembly on a conductive surface such as aluminum
foil, to prevent electrostatic charge buildup or exposure of the
assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES
devices.
4. Use only an antistatic solder removal device. Some solder
removal devices not classified a “anti-static” can generate
electrical charges sufficient to damage ES devices.
5. Do not use freonpropelled chemicals. These can generate
electrical charge sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective
package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically
shorted together by conductive foam, aluminum foil, or
comparable conductive material).
7. lmmediately before removing the protective material from the
leads of a replacement ES device, touch the protective material to
the chassis or circuit assembly into which the device will be
installed.
Caution : Be sure no power is applied to the chassis or circuit, and
observe all other safety precautions.
8. Minimize bodily motions when handing unpackaged replacement
ES devices. (Normally harmless motion such as the brushing
together of your clothes fabric or the lifting of your foot from a
carpeted floor can generate static electricity sufficient to damage
an ES device.)

1-5
SPECIFICATIONS (C715)
AMPLIFIER SECTION
Power output Stereo Mode 25W (6 ohms within rated distortion, 1kHz)
IHF dynamic power (6 ohms) 28W
Total harmonic distortion at rated power 0.15%
Damping factor (6 ohms) >102
Input sensitivity and impedance (Tape IN) 370mV/27kΩ
Frequency response +1 dB/-3dB (Ref. 1 kHz, 10Hz – 80kHz)
Signal/noise ratio, 95dB (Ref. rated power/ 6 ohms A-WTD)
Signal/noise ratio 80dB (Ref. 1W / 6 ohms A-WTD)
TUNER SECTION
AM SECTION
Tuning range 520kHz - 1710kHz (North America version, 10kHz steps)
522kHz -1629kHz (Europe version, 9kHz steps)
Usable sensitivity 60dBuV
S/N ratio 40dB
Total Harmonic Distortion 1.5%
Selectivity 25dB
Frequency response -6dB (Ref. 400Hz, 80Hz – 2.2kHz)
FM SECTION
Tuning range 87.50MHz – 108MHz (50kHz steps)
Usable sensitivity, MONO 10dBuV
S/N Ratio MONO 60dB
S/N Ratio STEREO 55dB
Total Harmonic Distortion, MONO 0.3%
Total Harmonic Distortion, STEREO 0.5%
Frequency response -3dB (Ref. 1 kHz, 30Hz – 12kHz)
Channel Separation 35dB
RDS decode sensitivity 29dBuV
CD SECTION
Output level 1.16V
Frequency response (ref. 0dB 1kHz, 20Hz-20kHz) +1dB
Total harmonic distortion (ref. 1kHz, VIDEO OUT) 0.04%
Signal/Noise ratio (A-weighted, ref. 1kHz VIDEO OUT) 100dB
Channel balance (ref. 0dB 1kHz) 0.5dB
Dynamic range (A-WTD, VIDEO OUT) 82dB
Channel separation 78dB (1kHz)
78dB (10kHz)
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 213 x 103 x 324 mm (Net)
213 x 116 x 362 mm (Gross)
Net weight 4.5kg
Shipping weight 6.0kg
Note: Gross dimensions include feet, extended buttons and rear panel terminals.
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 715.

1-6
SPECIFICATIONS (C715 DAB)
AMPLIFIER SECTION
Power output Stereo Mode 25W (6 ohms within rated distortion, 1kHz)
IHF dynamic power (6 ohms) 28W
Total harmonic distortion at rated power 0.15%
Damping factor (6 ohms) >102
Input sensitivity and impedance (Tape IN) 370mV/27kΩ
Frequency response +1 dB/-3dB (Ref. 1 kHz, 10Hz – 80kHz)
Signal/noise ratio, 95dB (Ref. rated power/ 6 ohms A-WTD)
Signal/noise ratio 80dB (Ref. 1W / 6 ohms A-WTD)
TUNER SECTION
AM SECTION
Tuning range 520kHz -1710kHz (North America version, 10kHz steps)
522kHz -1629kHz (Europe version, 9kHz steps)
Usable sensitivity 60dBuV
S/N ratio 40dB
Total Harmonic Distortion 1.5%
Selectivity 25dB
Frequency response -6dB (Ref. 400Hz, 80Hz – 2.2kHz)
FM SECTION
Tuning range 87.50MHz – 108MHz (50kHz steps)
Usable sensitivity, MONO 10dBuV
S/N Ratio MONO 60dB
S/N Ratio STEREO 55dB
Total Harmonic Distortion, MONO 0.3%
Total Harmonic Distortion, STEREO 0.5%
Frequency response -3dB (Ref. 1 kHz, 30Hz – 12kHz)
Channel Separation 35dB
RDS decode sensitivity 29dBuV
DAB SECTION
Tuning range Band III 174MHz – 240MHz
Maximum signal -3dBm
Sensitivity -96dBm
Adjacent Channel Rejection -35dB
Audio Output Stereo 2.5Vp-p
Optical S/PDIF 24 bit sample resolution
48kHz sample rate
CD SECTION
Output level 1.16V
Frequency response (ref. 0dB 1kHz, 20Hz-20kHz) +1dB
Total harmonic distortion (ref. 1kHz, VIDEO OUT) 0.04%
Signal/Noise ratio (A-weighted, ref. 1kHz VIDEO OUT) 100dB
Channel balance (ref. 0dB 1kHz) 0.5dB
Dynamic range (A-WTD, VIDEO OUT) 82dB
Channel separation 78dB (1kHz)
78dB (10kHz)
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 213 x 103 x 324 mm (Net)
213 x 116 x 362 mm (Gross)
Net weight 4.5kg
Shipping weight 6.0kg
Note: Gross dimensions include feet, extended buttons and rear panel terminals.
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 715 DAB.

DISASSEMBLY
REMOVAL OF TOP COVER
REMOVAL OF FRONT PANEL
1-7

EQNMSOBA
BCLDBG@MHRL GD@SRHMJ
@LOOBA
SQ@MRENQLDQ
ONVDQOBA
L@HMOBA
C@ALNCTKD
STMDQLNCTKD
EQNMSOBA
BCLDBG@MHRL GD@SRHMJ
@LOOBA
SQ@MRENQLDQ
ONVDQOBA
L@HMOBA
STMDQLNCTKD
ROD@JDQOBA
ROD@JDQOBA
PRINCIPAL PARTS LOCATION
C715DABC
C715AH & C715C
1-8
CJDKSL2130CCMZ
CJDKSL2130CCMZ
DAB Module up to S/N A86C71512400

C715AH EXPLODED VIEW (120V North American version)
1-9 1-10
CD Mechansim Sony**
Classification
Time of application
POWER PCB
POWER PCB ASS'Y
DAB MODULE
Rear Panel
Washer
Nut
CD Mechanism
Program
**Chart B C715 change LIST
C715C, C715AH, C715DABC CD Mechanism change
2008.10 Start
CJDWSL11VF Sanyo
NAD "C515/C715 FIRMWARE LOADER"
Change both mechanism and program simultaneously.
The new Sanyo mechanism will not work with a servo
which has original Sony firmware installed.

C715C EXPLODED VIEW (230V European version without DAB receiver)
1-11 1-12
CD Mechanism Sony**
Classification
Time of application
POWER PCB
POWER PCB ASS'Y
DAB MODULE
Rear Panel
Washer
Nut
CD Mechanism
Program
**Chart B C715 change LIST
C715C, C715AH, C715DABC CD Mechanism change
2008.10 Start
CJDWSL11VF Sanyo
N AD C515/C715 FIRMWARE LOADER
Change both mechanism and program simultaneously.
The new Sanyo mechanism will not work with a servo
which has original Sony firmware installed.
.

C715DABC EXPLODED VIEW (230V European version with DAB receiver)
1-13 1-14
W/O F -C onne ctor
CD Mechanism Sony **
Classification C715DABC OLD (DAB 1.0 MODULE)
Time of application 2007.11 Start to A86C71512400 End
POWER PCB CUP12019Z
POWER PCB ASS'Y COP12019B
DAB MODULE HNVFS2020V172C
Rear Panel CKF3A282NK1
Washer -
Nut -
CD Mechanism CJDKSL2130CCMZ Sony
Program
NAD_c715_2007_10_13-01.hex /
NAD_c715_2008_10-02.hex
It is possible to use "C515/C715
FIRMWARE LOADER" with the old
NAD "C515/C715 FIRMWARE LOADER"
Change both mechanism and program simultaneously.
The new Sanyo mechanism will not work with a servo
which has original Sony firmware installed.
DAB 1.0 MODULE
**Chart B C715 change LIST
C715C, C715AH, C715DABC CD Mechanism change
2008.10 Start
-
-
-
-
-
-
CJDWSL11VF Sanyo
See chart B
See chart B

-/" ÊÓ
/,Ê" / /-
" / /-
)#",/#+$)!'2!-30).$%3#2)04)/.. 2
%,%#42)#!,42/5",%3(//4).''5)$%35
$)!'2!-3
£°Ê"Ê,Ê°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°
Ó°Ê7, Ê,Ê °°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°
ΰÊ-/Ê,Ê °°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°
{°Ê*, / ,1/ ",-Ê °°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°°
2-1
Ó39
Ó41
Ó43
Ó47

2-2
IC BLOCK DIAGRAMS & PIN DESCRIPTION
74HC4066D
Quad bilateral switche
handbook, halfpage
MGR257
11
4Y
12
4E
4Z
10
3Z
9
2Z
3
1Z
2
8
3Y
6
3E
4
2Y
5
2E
1
1Y
13
1E
Fig.5 Functional diagram.
handbook, halfpage
MGR258
VCC
GND
nE
nZ
nY
VCC
Fig.6 Schematic diagram (one switch).
74VHC08TTR
PIN CONNECTION AND IEC LOGIC SYMBOLS

2-3
AK4554

2-4
ST92F124V
ST92F124V1: Architectural Block Diagram
256 bytes
Register File
RAM
4 Kbytes
ST9 CORE
8/16 bits
CPU
Interrupt
Management
MEMORY BUS
RCCU
Ext. MEM.
ADDRESS
DATA
Port0
Ext. MEM.
ADDRESS
Ports
1,9
REGISTER BUS
WATCHDOG
AS
DS
RW
WAIT
NMI
DS2
RW
MISO
MOSI
SCK
SS
A[10:8]
A[21:11]
A[7:0]
D[7:0]
ST. TIMER
SPI
SDA
SCL
I
2
C BUS
FLASH
128 Kbytes
WDOUT
HW0SW1
STOUT
Fully
Prog.
I/Os
P0[7:0]
P1[7:3]
P1[2:0]
P2[7:0]
P3[7:4]
P3[3:1]
P4[7:4]
P4[3:0]
P5[7:0]
P6[5:2,0]
P6.1
P7[7:0]
P8[7:0]
P9[7:0]
MF TIMER 0
TINPA0
TOUTA0
TINPB0
TOUTB0
TINPA1
TOUTA1
TINPB1
TOUTB1
INT[6:0]
WKUP[15:0]
MF TIMER 1
E
3 TM
1 Kbyte
OSCIN
OSCOUT
RESET
CLOCK2/8
INTCLK
CK_AF
ADC
AV
DD
AV
SS
AIN[15:8]
AIN[7:0]
EXTRG
V
REG
VOLTAGE
REGULATOR
The alternate functions (Italic characters) are mapped on Port 0, Port 1, Port2, Port3, Port4, Port5, Port6, Port7,
Port8 and Port9.
ICAPA0
OCMPA0
ICAPB0
OCMPB0
EXTCLK0
ICAPA1
OCMPA1
ICAPB1
OCMPB1
EXTCLK1
EF TIMER 0
EF TIMER 1
SCI M
TXCLK
RXCLK
SIN
DCD
SOUT
CLKOUT
RTS
SCI A RDI
TDO
9

2-5
ST92F124V1: Pin Configuration (Top-view TQFP100)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
100999897969594939291908988878685848382818079787776
ST92F124V1
P8.4/AIN4
P8.3/AIN3
P8.2/AIN2
P8.1/AIN1/WKUP15
P8.0/AIN0/WKUP14
NC
P6.5/WKUP10/INTCLK
P6.4/NMI
P6.3/INT3/INT5
P6.2/INT2/INT4/DS2
P6.1/INT6/RW
P6.0/INT0/INT1/CLOCK2/8
P0.7/A7/D7
V
DD
V
SS
P0.6/A6/D6
P0.5/A5/D5
P0.3/A3/D3
P0.2/A2/D2
P0.1/A1/D1
P0.0/A0/D0
AS
DS
P0.4/A4/D4
P1.7/A15
A20/P9.6
WAIT/WKUP5/P5.0
WKUP6/WDOUT/P5.1
TXCLK/CLKOUT/P5.4
OCMPA1/P4.2
V
DD
A21/P9.7
WDIN/SOUT/P5.3
DCD/WKUP8/P5.6
V
SS
ICAPB1/OCMPB1/P4.3
SDA/P4.6
SIN/WKUP2/P5.2
RXCLK/WKUP7/P5.5
CLOCK2/P4.1
EXTCLK1/WKUP4/P4.4
ICAPB0/P3.1
ICAPA0/OCMPA0/P3.2
WKUP9/RTS/P5.7
ICAPA1/P4.0
EXTRG/STOUT/P4.5
WKUP1/SCL/P4.7
OCMPB0/P3.3
EXTCLK0/SS/P3.4
MISO/P3.5
P9.5/A19 P9.4/A18 P9.2/A16 HW0SW1 P7.7/AIN15/7/WKUP13 P7.4/AIN12/WKUP3 P9.3/A17 P9.0/RDI RESET P7.6/AIN14/WKUP12 P7.5/AIN13/WKUP11 P7.1/AIN9 P9.1/TDO OSCIN V
SS
P7.3/AIN11 P7.0/AIN8/CK_AF P8.7/AIN7 OSCOUT V
DD
P7.2/AIN10 AV
SS
AV
DD
P8.6/AIN6 P8.5/AIN5
MOSI/P3.6
SCK/WKUP0/P3.7
RW
TOUTA0/P2.2
V
SS
*V
TEST
V
REG
TINPB0/P2.1
TOUTB0/P2.3
V
DD
V
REG
A10/P1.2
TINPA0/P2.0 TINPB1/P2.5
TOUTB1/P2.7
A8/P1.0
A11/P1.3 A12/P1.4
TINPA1/P2.4
TOUTA1/P2.6
A9/P1.1 WKUP6
NC
A13/P1.5 A14/P1.6
* V
TEST
must be kept low in standard operating mode.

NAD C715_MCU_Port Table Date : 2007/12/22
1 A20/P9.6 I/O O VFD-CE VFD chip enable pin
2 A21/P9.7 I/O NC
3 WAIT/WKUP5/P5.0 I/O I DAB-DI DAB data in
4 WKUP6/WDOUT/P5.1 I/O I/O DAB-CLK DAB clock
5 SIN/WKUP2/P5.2 I/O I/O DAB-DO DAB data out/update port
6 WDIN/SOUT/P5.3 I/O I DAB-ON update port
7 TXCLK/CLKOUT/P5.4 I/O I update port
8 RXCLK/WKUP7/P5.5 I/O I/O STANBY Standby LED on (active "H")/update port
9 DCD/WKUP8/P5.6 I/O O F-MUTE System mute (active "H")
10 WKUP9/RTS/P5.7 I/O O TCC-CE TCC760 chip enable(USB host I.C)
11 ICAPA1/P4.0 I/O I Option FM frequency step (low : 50kHz, high : 100 kHz)
12 CLOCK2/P4.1 I/O I Option AM frequency step (low : 10kHZ, high : 9kHZ)
13 OCMPA1/P4.2 I/O I Option RDS on,off (low : off, high : on)
14 VSS GND GND
15 VDD VDD +5V
16 ICAPB1/OCMPB1/P4.3 I/O I Option Real time mode(low : 12 hours, high : 24 hours)
17 EXTCLK1/WKUP4/P4.4 I/O I/O R/T SDA Real time i.c serial data
18 EXTRG/STOUT/P4.5 I/O I/O R/T SCL Real time i.c serial clock
19 SDA/P4.6 I/O I R/T IRQ Real time i.c interrupt output
20 WKUP1/SCL/P4.7 I/O O F-STB Function i.c strobe output
21 ICAPB0/P3.1 I/O I Option DAB on,off (low : off, high : on)
22 ICAPA0/OCMPA0/P3.2 I/O I Option RESERVED
23 OCMPB0/P3.3 I/O O TCC-RST TCC760 i.c reset(USB host I.C), active"L"
24 EXTCLK0/SS/P3.4 I/O I GND GND
25 MISO/P3.5 I/O O TCC-DI TCC760 i.c data in
26 MOSI/P3.6 I/O I TCC-DO TCC760 i.c data out
27 SCK/WKUP0/P3.7 I/O I/O TCC-SCLK TCC760 i.c serial clock
28 VREG VREG Stabilization capacitor(s) for internal voltage regulator
29 RW NC
30 TINPA0/P2.0 I/O I PROTECT Protect in, active "L"
31 TINPB0/P2.1 I/O O SP-ON Speaker on, active "H"
32 TOUTA0/P2.2 I/O I H/P-IN Headphone in, active "L"
33 TOUTB0/P2.3 I/O NC
34 TINPA1/P2.4 I/O O T-MUTE Tuner mute, active "H"
35 TINPB1/P2.5 I/O O V-CLK VFD clock pin
36 TOUTA1/P2.6 I/O O V-DATA VFD serial data
37 TOUTB1/P2.7 I/O I BACK-UP Back-up, active "L"
38 VSS GND GND
39 VDD VDD +5V
40 VREG VREG Stabilization capacitor(s) for internal voltage regulator
41 VTEST GND Must be kept low in standard operating mode
42 A8/P1.0 I/O O CD-OPEN-M CD open motor pin
43 A9/P1.1 I/O NC
44 A10/P1.2 I/O O CD-CCE communication chip enalbe with CD DSP
45 A11/P1.3 I/O O CD-BUCK communication clock with CD DSP
46 WKUP6 NC
47 NC NC
48 A12/P1.4 I/O NC
49 A13/P1.5 I/O O CD-POWER optical out change of DAB and CD
50 A14/P1.6 I/O O MT-STBY Motor drive i.c standby pin
51 P1.7/A15 I/O O CD-RST CD dsp reset pin
52 DS NC
53 AS NC
54 P0.0/A0/D0 I/O I/O CD-BUS0 receive data or send command for CD DSP
55 P0.1/A1/D1 I/O I/O CD-BUS1 receive data or send command for CD DSP
56 P0.2/A2/D2 I/O I/O CD-BUS2 receive data or send command for CD DSP
57 P0.3/A3/D3 I/O I/O CD-BUS3 receive data or send command for CD DSP
58 P0.4/A4/D4 I/O I CD-OPEN-SW CD open switch pin
59 P0.5/A5/D5 I/O I CD-CLOSE-SW CD close switch pin
60 P0.6/A6/D6 I/O I CD-LIMIT-SW CD inner switch pin
61 VSS GND GND
62 VDD VDD +5V
63 P0.7/A7/D7 I/O O CD-CLOSE-M CD close motor pin
64 P6.0/INT0/INT1/CLOCK2/8 I/O NC
65 P6.1/INT6/RW I/O I REMOTE Remote in pin
66 P6.2/INT2/INT4/DS2 I/O I RDS-CLK RDS serial clock
67 P6.3/INT3/INT5 I/O I MP3-REQ Request pin for MP3 DSP
68 P6.4/NMI I/O O MP3-STBY 1Mb sram standby pin
69 P6.5/WKUP10/INTCLK I/O NC
70 NC NC
71 P8.0/AIN0/WKUP14 I/O I KEY2 Key input 2
72 P8.1/AIN1/WKUP15 I/O I KEY1 Key input 1
Name Note
pin
No Port Name I/O use
2-6

73 P8.2/AIN2 I/O NC
74 P8.3/AIN3 I/O I JOG1 Volume encoder in +
75 P8.4/AIN4 I/O I JOG2 Volume encoder in -
76 P8.5/AIN5 I/O NC
77 P8.6/AIN6 I/O NC
78 P8.7/AIN7 I/O NC
79 AVDD VDD +5V
80 AVSS GND GND
81 P7.0/AIN8/CK_AF I/O O POWER-H Power on pin, active "H"
82 P7.1/AIN9 I/O O P/F-DATA Tuner and function i.c serial data
83 P7.2/AIN10 I/O O P/F-CLK Tuner and function i.c serial clock
84 P7.3/AIN11 I/O I PLL-DI Tuner data in pin
85 P7.4/AIN12/WKUP3 I/O O PLL-CE Tuner enable pin
86 P7.5/AIN13/WKUP11 I/O I TUNED-IN Tuned in pin, active"L"
87 P7.6/AIN14/WKUP12 I/O I STEREO-IN Stereo in pin, active"L"
88 P7.7/AIN15/WKUP13 I/O I RDS-DATA RDS serial data
89 VSS GND GND
90 VDD VDD +5V
91 OSCIN I I OSCIN Oscillator in
92 OSCOUT O O OSCOUT Oscillator out
93 RESET I I RESET Reset, active "L"
94 HW0SW1 I I HW0SW1 watchdog HW/SW enabling selection, acitve "H"
95 P9.0/RDI I/O NC
96 P9.1/TDO I/O NC
97 P9.2/A16 I/O NC
98 P9.3/A17 I/O O VFD-DI VFD serial data out
99 P9.4/A18 I/O O VFD-CLK VFD serial clock out
100 P9.5/A19 I/O O VFD-RST VFD reset, active "L"
2-7

2-8
FS2020 (Venice) HW Spec 1.2
Serial
Flash
Band III
RF
External
DAC or
CODEC
SDRAM
(optional)
USB
I/face
Audio
DAC
S/PDIF
& RDI
I/faces
384KB
RAM
Serial
I/Faces
FS1010
(Chorus)
Keypad
/Rotary
encode
LCD
5V
Figure 1 - Venice module block diagram (functions in white are on board, in grey are external)
The pin-out for CN1 is as follows:
Pin Description Pin Description
1 5V 23 AUD_SCLK
2 5V 24 AUD_MCLK
3 Audio Left Out 25 LCD DAT 0
4 Audio Ground 26 LCD DAT 1
5 Audio Right Out 27 LCD DAT 2
6 GND 28 LCD DAT 3
7 GND 29 LCD DAT 4
8 USB DM 30 LCD DAT 5
9 USB DP 31 LCD DAT 6
10 GND 32 LCD DAT 7
11 GND 33 LCD_F
12 SPDIF Out 34 LCD_LRS
13 GND 35 LCD_M
14 GND 36 LCD_PE
15 S1_DIN 37 SPDIF In
16 S1_DOUT 38 RDI Out
17 3.3V 39 SCP_CLK
18 3.3V 40 SCP_DAT
19 3.3V 41 PDM Out
20 GND 42 AUD_SDOUT1
21 AUD_SFR 43 AUD_SDOUT2
22 AUD_SDOUT0 44 AUD_SDIN

2-9
HY57V161610ET
PIN CONFIGURATION
VSS
DQ15
DQ14
VSSQ
DQ13
DQ12
VDDQ
DQ11
DQ10
VSSQ
DQ9
DQ8
VDDQ
NC
UDQM
CLK
CKE
NC
A9
A8
A7
A6
A5
A4
VSS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
VDD
DQ0
DQ1
VSSQ
DQ2
DQ3
VDDQ
DQ4
DQ5
VSSQ
DQ6
VDDQ
/WE
/CAS
/RAS
/CS
A11
A10
A0
A1
A2
A3
VDD
50pin TSOP II
400mil x 825mil
0.8mm pin pitch
27
26
DQ7
LDQM
VSS
DQ15
DQ14
VSSQ
DQ13
DQ12
VDDQ
DQ11
DQ10
VSSQ
DQ9
DQ8
VDDQ
NC
UDQM
CLK
CKE
NC
A9
A8
A7
A6
A5
A4
VSS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
VDD
DQ0
DQ1
VSSQ
DQ2
DQ3
VDDQ
DQ4
DQ5
VSSQ
DQ6
VDDQ
/WE
/CAS
/RAS
/CS
A11
A10
A0
A1
A2
A3
VDD
50pin TSOP II
400mil x 825mil
0.8mm pin pitch
27
26
DQ7
LDQM
PIN PIN NAME DESCRIPTION
CLK Clock The system clock input. All other inputs are referenced to the SDRAM on the rising
edge of CLK.
CKE Clock Enable Controls internal clock signal and when deactivated, the SDRAM will be one of the
states among power down, suspend or self refresh.
CS Chip Select Command input enable or mask except CLK, CKE and DQM
BA Bank Address Select either one of banks during both RAS and CAS activity.
A0 ~ A10 Address Row Address : RA0 ~ RA10, Column Address : CA0 ~ CA7
Auto-precharge flag : A10
RAS, CAS, WE
Row Address Strobe,
Column Address Strobe, Write
Enable
RAS, CAS and WE define the operation.
Refer function truth table for details
LDQM, UDQM Data Input/Output Mask DQM control output buffer in read mode and mask input data in write mode
DQ0 ~ DQ15 Data Input/Output Multiplexed data input / output pin
VDD/VSS Power Supply/Ground Power supply for internal circuit and input buffer
VDDQ/VSSQ Data Output Power/Ground Power supply for DQ
NC No Connection No connection
PIN DESCRIPTION
