Nady Audio ProPower PFW12 Instruction manual

C
Co on ng gr ra at tu ul la at ti io on ns s! !
You have just purchased one of the finest speakers on the market
today. The ProPower Series™ was developed using the expertise
of professional sound engineers and working musicians. You will
find your new NADY AUDIO speaker has superior perform-
ance and greater flexibility than any other speaker in its price
range.
We recommend that you read this instruction sheet
carefully to get the most out of your new unit. Thanks
for selecting NADY AUDIO and the PFW12 as your
choice in speakers.
Ruggedly built, exceptional sound, most affordably priced
– the ProPower Series™ from Nady Audio delivers the best value
in small PA speakers
• 2-way floor wedge monitor speaker with 12” woofer, 4”x10.5” horn
• Program power rating: 400W
• All horns with high compression piezo drivers
• Durable black carpet cover
• Heavy duty plastic protective corners
• Impedance: 8Ω
• Binding post (banana jack) and two 1/4” (6.3 mm) jack inputs
• Sensitivity (1W/1M): 90dB
• Weight: 35 lbs (15.9 Kg)
• Dimensions (WHD): 16.5"x 26"x 19.1" (41.9 x 66 x 48.5 cm)
WARNINGS
• Read all instructions before using the product.
• This product may be capable of producing sound levels that could cause
permanent hearing loss. Do not operate for a long period of time at a high
volume level or at a level that is uncomfortable. If you experience any hear-
ing loss or ringing in the ears, you should consult an audiologist.
• To avoid damage to the drivers, never overload the speaker.
• To avoid the risk of fire, do not ever expose the speaker to a source of
naked flames. Also, it should be located away from heat sources such as
radiators, heat vents, or other devices (including amplifiers) that produce
heat.
• The product should be positioned so that proper ventilation is maintained.
• This speaker is designed for indoor use only. Do not expose to weather or
high humidity, rain, etc.
• Care should be taken so that objects do not fall into, and liquids are not
spilled through, the enclosure’s openings. Do not place containers of liquids
on the speaker.
• Don’t place any heavy appliance or object (>130lbs/60kg) on the speaker
enclosure.
• This unit is to be installed by qualified personnel only.
• This speaker is only to be used with power amplifiers complying with the
safety requirement of EN or IEC60065.
• The maximum input peak voltage to this speaker should always be less than
50V.
• This product should be serviced by qualified service personnel if:
A. Objects have fallen into, or liquid has been spilled onto the product.
B.The product has been exposed to rain.
C.The product does not appear to operate normally or exhibits
a marked change in performance.
D. The product has been dropped, or the enclosure damaged.
• Do not attempt to service this unit. All servicing should be referred to quali-
fied service personnel.
IMPORTANT SAFETY INSTRUCTIONS
When using this speaker, basic precautions should always be taken, including the following:
Pantone 185 Red/Black/Cool Gray 40%
BLACK
FEATURES
AND SPECIFICATIONS
PFW12
Two-Way Speaker
P
Pr ro oP Po ow we er rS Se er ri ie es s™ ™S Sp pe ea ak ke er rs s
Features, Instructions
& Technical Data

(U.S.) Should your NADY AUDIO product require service, please contact the Nady Service Department via telephone at (510) 652-
2411 or e-mail at [e-mail].
(International) For service, please contact the NADY AUDIO distributor in your country through the dealer from whom you purchased
this product.
SERVICE
FOR YOUR NADY AUDIO PRODUCT
NADY SYSTEMS, INC. • 6701 SHELLMOUND STREET, EMERYVILLE, CA 94608
Tel: [phone] • Fax: [phone] • www.nady.com
SPECIFICATIONS
TECHNICAL DATA
IMPEDANCE RESPONSE & PARAMETERS
MLS ANALYSIS IMPEDANCE RESPONSE
