INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
GAS-FIRED DIRECT VENT INSERT
INSTALLATION AND OPERATION INSTRUCTIONS FOR:
VENTED GAS FIREPLACE HEATER
NATURAL GAS MODELS GDIZC - N
PROPANE GAS MODELS GDIZC - P
CERTIFIED UNDER CANADIANAND AMERICAN NATIONAL STANDARDS, CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
• Immediatelycallyour gassupplierfrom
aneighbour'sphone.Followthe gassup-
plier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
CERTIFIED FOR CANADAAND UNITED STATES USING ANSI / CSAMETHODS

2
W415-0223 / E / 03.05.09
Pg 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5-7 INSTALLATION
Insert Vent Connection
Chimney Connection
Wall Switch / Thermostat
Gas Pipe Installation
7-8 FINISHING
Trim Extrusion Installation
Log Placement
Door Installation
Mantle Clearances
Logo Placement
Pg 9 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
10 REPLACEMENT BLOWER
11 ADJUSTMENTS
Pilot Burner Adjustment
Vent Restrictions
Venturi Adjustments
12-13 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Terminal Kits
Accessories
14-15 TROUBLE SHOOTING GUIDE
16 SERVICE HISTORY
NOTE: changes, other than editorial, are denoted by a vertical line in the margin.
WARNING
• The fireplace insert is a vented gas-fired heater. Do not burn wood or other materials in this fireplace in-
sert.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition. Supervise young children when they are in the same room as
the fireplace insert.
• Duetohightemperatures,the fireplace insertshould be locatedout of trafficand away fromfurniture and
draperies.
• Clothing or other flammable material should not be placed on or near the fireplace insert.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace insert.
• Itis imperative that thecontrol compartments, burners andcirculating blower and itspassageway in the
fireplace insert and venting system are kept clean. The fireplace insert and its venting system should be
inspected before use and at least annually by a qualified service person. More frequent cleaning may be
required due to excessive lint from carpeting, bedding material, etc. The fireplace insert area must be kept
clear and free from combustible materials, gasoline and other flammable vapours and liquids.
• Under no circumstances should this fireplace insert be modified.
• This fireplace insert must not be connected to a chimney flue pipe serving a separate solid fuel burning
appliance.
• Do not use this fireplace insert if any part has been under water. Immediately call a qualified service tech-
nicianto inspect the fireplace insert and to replace any part of the control system and any gas control which
has been under water.
• Do not operate the fireplace insert with the glass door opened, cracked or broken. Replacement of the
glass should be done by a licensed or qualified service person.
• Do not strike or slam shut the fireplace insert glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple
supplied by Wolf Steel Ltd.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

3
W415-0223 / E / 03.05.09
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO 9001:2000 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen
who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station.
The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that you, the
customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your new NAPOLEON gas fireplace are warranted against
defects for as long as you own the fireplace. This covers: combustion chamber, heat exchanger, stainless steel
burner, phazer™ logs and embers, ceramic glass (thermal breakage only), gold plated parts against tarnishing,
porcelainized enamelled components and aluminum extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves, thermal switch,
switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are covered and NAPOLEON will
provide replacement parts free of charge during the first year of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. Repair work, however,
requires the prior approval of an authorized company official. Labour costs to the account of NAPOLEON are
based on a predetermined rate schedule and any repair work must be done through an authorized NAPOLEON
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEON warrants its products against manufacturing defects to the original purchaser only -- i.e., the individual or legal entity (registered customer) whose name appears on
the warranty registration card filed with NAPOLEON -- provided that the purchase was made through an authorized NAPOLEON dealer and is subject to the following conditions
and limitations:
This factory warranty is nontransferable and may not be extended whatsoever by any of our representatives.
The gas fireplace must be installed by a licenced, authorized service technician or contractor. Installation must be done in accordance with the installation instructions included
with the product and all local and national building and fire codes.
This limited warranty does not cover damages caused by misuse, lack of maintenance, accident, alterations, abuse or neglect and parts installed from other manufacturers will
nullify this warranty.
This limited warranty further does not cover any scratches, dents, corrosion or discolouring caused by excessive heat, abrasive and chemical cleaners nor chipping on porcelain
enamel parts, mechanical breakage of PHAZER™ logs and embers, nor any venting components used in the installation of the fireplace.
NAPOLEON warrants its stainless steel burners against defects in workmanship and material for life, subject to the following conditions: During the first 10 years NAPOLEON will
replace or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
In the first year only, this warranty extends to the repair or replacement of warranted parts which are defective in material or workmanship provided that the product has been
operated in accordance with the operation instructions and under normal conditions.
After the first year, with respect to this President's Limited Lifetime Warranty, NAPOLEON may, at its discretion, fully discharge all obligations with respect to this warranty by
refunding to the original warranted purchaser the wholesale price of any warranted but defective part(s).
After the first year, NAPOLEON will not be responsible for installation, labour or any other costs or expenses related to the reinstallation of a warranted part, and such expenses
are not covered by this warranty.
Notwithstanding any provisions contained in this President's Limited Lifetime Warranty, NAPOLEON’S responsibility under this warranty is defined as above and it shall not in any
event extend to any incidental, consequential or indirect damages.
This warranty defines the obligations and liability of NAPOLEON with respect to the NAPOLEON gas fireplace and any other warranties expressed or implied with respect to this
product, its components or accessories are excluded.
NAPOLEONneither assumes, nor authorizes any third partyto assume, on its behalf, any otherliabilities with respect to the saleof this product. NAPOLEON will not beresponsible
for: over-firing, downdrafts, spillage caused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequate vents or ventilation, excessive venting
configurations, insufficient makeup air, or negative air pressures which may or may not be caused by mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.
Any damages to fireplace, combustion chamber, heat exchanger, brass trim or other component due to water, weather damage, long periods of dampness, condensation, damag-
ing chemicals or cleaners will not be the responsibility of NAPOLEON.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized dealer. The warranty registration
card must be returned within fourteen days to register the warranty.
NAPOLEON reserves the right to have its representative inspect any product or part thereof prior to honouring any warranty claim.
ALL SPECIFICATIONS AND DESIGNSARE SUBJECTTO CHANGE WITHOUT PRIOR NOTICE DUE TO ON-GOING PRODUCT IMPROVEMENTS. NAPOLEON® IS AREGISTERED
TRADEMARK OF WOLF STEEL LTD. PATENTS U.S. 5.303.693.801 - CAN. 2.073.411, 2.082.915 & DES 417,497(12.07.1999). © WOLF STEEL LTD.

4
W415-0223 / E / 03.05.09
FOR YOUR SATISFACTION, THIS FIREPLACE INSERT
HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION
AND QUALITY!
Minimum inlet gas supply pressure is 4.5 inches water col-
umn for natural gas and 11 inches water column for propane.
Maximum inlet gas pressure is 7 inches water column for
naturalgasand 13 inches watercolumnforpropane. Manifold
pressureunderflowconditionsis3.5incheswatercolumnfor
natural gas and 10 inches water column for propane. When
thefireplaceis installedatelevationsabove 4,500ft, andinthe
absenceofspecificrecommendations from the local authority
havingjurisdiction,thecertifiedhighaltitudeinputratingshall
be reduced at the rate of 4% for each additional 1,000ft.
Expansion/contractionnoisesduringheatingupandcooling
down cycles are normal and to be expected.
Maximuminputis 24,000 BTU/hr fornaturalgasand propane.
Maximum output for natural gas and propane is 20,400 BTU/
hr at an efficiency of 85% with the fan on. MaximumA.F.U.E.
(annualfuelutilizationefficiency) rating is 79% for natural gas
andpropane.This fireplaceinsertisnot approved forclosetor
recessed installations. It is approved for bathroom, bedroom
and bed-sitting room installations and is suitable for mobile
homes. The natural gas model is suitable for installation in a
mobile home that is permanently positioned on its site and
fuelled with natural gas.
This insert must be recessed into a vented noncombustible
wood-burning fireplace (prefabricated or masonry) only. The
minimum fireplace opening size in which the heater is to be
installed is:
HEIGHT 14½ inches
WIDTH 25 inches
DEPTH 11 inches
The minimum allowable chimney flue size is 6" round.
The minimum distance, from the bottom of a combustible
mantle projecting 3" maximum from the wall to the top of the
aluminium trim, is 3".
Donotuseabrasivecleanerstocleantheseparts.Bufflightly
with a clean dry cloth.
Theglassis 3/16"ceramicglassavailable fromyourNapoleon
/WolfSteel Ltd. dealer. DO NOTSUBSTITUTE MATERIALS.
Clean the glass after the first 10 hours of operation with a
recommendedgasfireplaceglasscleaner.Thereafterclean as
required. DO NOT CLEAN GLASS WHEN HOT! If the glass
isnotkeptcleanpermanentdiscolouration and / or blemishes
may result.
THIS GAS FIREPLACE INSERT SHOULD BE INSTALLED
AND SERVICED BYA QUALIFIED INSTALLER to conform
with local codes. Installation practices vary from region to
region and it is important to know the specifics that apply
to your area,
for example: in Massachusetts State:
• The fireplace damper must be removed or welded in the open
position prior to installation of a fireplace insert or gas log.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• The appliance is not approved for installation in a bedroom or
bathroom unless the unit is a direct vent sealed combustion
product.
• WARNING: This product must be installed by a licensed plumber
or gas fitter when installed within the commonwealth of
Massachusetts.
In absence of local codes, install to the current CAN1-
B149 Installation Code in Canada or to the National Fuel
Gas Code, ANSI Z223.1, and NFPA 54 in the United
States. Mobile home installation must conform with local
codes. In the absence of local codes, install to the current
standard for gas equipped mobile housing CAN/CSA Z240
MH Series in Canada or the manufactured home construc-
tion and safety standard, Title 24 CFR, part 3280, or the
Fire Safety Criteria for manufactured home installations,
Sites and Community Standard ANSI/NFPA 501A in the
United States.
Purge all gas lines with the glass door of the fireplace insert
opened. Assure that a continuous gas flow is at the burner
before closing the door.
Under extreme vent configurations, allow several minutes
(5-15) for the flame to stabilize after ignition.
The fireplace insert and its individual shutoff valve must be
disconnected from the gas supply piping system during any
pressure testing of that system at test pressures in excess
of 1/2 psig (3.5 kPa). The fireplace insert must be isolated
from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the gas
supply piping system at test pressures equal to or less than
1/2 psig (3.5 kPa).
A 1/8 inch NPT plug, accessible for test gauge connection,
must be installed immediately upstream of the gas supply
connection to the fireplace insert.
The fireplace insert must be electrically connected and
grounded in accordance with local codes. In the absence of
local codes, use the current CSA C22.1 CANADIAN ELEC-
TRICAL CODE in Canada or the ANSI/NFPA 70-1990 NA-
TIONALELECTRICALCODEinthe UnitedStates.Theblower
power cord must be connected into a properly grounded
receptacle. The grounding prong must not be removed from
the cord plug.
GENERAL INSTRUCTIONS GENERAL INFORMATION
CARE OF GLASS, AND PLATED PARTS
65.5%
GDIZC

5
W415-0223 / E / 03.05.09
36"
15
1
/ 2 "
25"
10
9
/ 16 "
5 ½"
AIR INLET
EXHAUST
4
15
/ 16 "
15
1
/ 2 "
11
5
/ 8 "
7
3
/ 8 "
3"Ø
44
7
/ 8 "
3 SIDED BACKER PLATE
ALUMINUM TRIM
44 7/8"
36 1/2"
4 SIDED BACKER PLATE
ALUMINUM TRIM
Provide adequate ventilation air.
Provide adequate accessibility clearance for servicing
and operating the fireplace insert.
Never obstruct the front opening of the fireplace
insert.
Objects placed in front of the fireplace must be kept a
minimum of 48" away from the front face of the unit.
FIGURES 1a-c
Cleanoutashes from theinsideofthe wood-burning fireplace.
Make sure that the chimney and wood-burning fireplace
are in a clean and sound condition and constructed of non-
combustiblematerials.Ifnecessaryhaveany repairworkdone
by a qualified person before installing the insert. Remove the
existing fireplace damper or lock into an open position.
Using screws, attach the fireplace warning tag (W385-0199)
totheinsideofthefirebox of the fireplace intowhichtheinsert
is being installed.
The sheet-metal parts of the fireplace, in which the gas fire-
place insert is to be installed, must not be cut.
If the wood-burning factory-built fireplace has no gas access
hole(s) provided, an access hole of 1½ inch or less may be
drilled through the lower sides or bottom of the fireplace in
a proper workman like manner. This access hole must be
plugged with non-combustible insulation after the gas supply
line has been installed.
Ensure that existing chimney cleanouts fit properly.
Therefractory, glassdoors,screenrails,screenmesh and log
grates may be removed from the fireplace before installing
the gas fireplace insert.
Smoke shelves, shields and baffles may be removed if at-
tached by mechanical fasteners.
The ventilation openings in the fireplace may be obstructed
by the backer plates, aluminium trim etc. but these parts are
not to be applied so as to have an airtight seal.
WARNING: THIS FIREPLACE HAS BEEN CONVERTED FOR USE WITH A GAS FIREPLACE
INSERT ONLY AND CANNOT BE USED FOR BURNING WOOD OR SOLID FUELS UNLESS
ALL ORIGINALPARTS HAVE BEEN REPLACED ANDTHE FIREPLACE IS RE-APPROVED BY
THE AUTHORITY HAVING JURISDICTION.
ATTENTION: CE FOYER A ETE CONVERTI AFIN D'ETRE UTILISE SEULEMENT COMME
FOYER ENCASTREAU GAZ ET NE PEUT ETRE UTILSE POUR BRULER DU BOIS OU TOUT
AUTRE COMBUSTIBLE SOLIDE, SANS QUE TOUTES LES PIECES ORIGINALESAIENT ETE
REMPLACEES ET QUE LE FOYER SOIT APPROUVE DE NOUVEAU PAR LES AUTORITES
AYANT JURIDICTION. W385-0199
14"
15
1
/ 2 "
20
3
/ 4 "
3 SIDED BACKER PLATE - FRONT VIEW
4 SIDED BACKER PLATE - FRONT VIEW
TOP VIEW
3 & 4 SIDED BACKER PLATES - SIDE VIEWS
INSTALLATION

6
W415-0223 / E / 03.05.09
2" OVERLAP
EXHAUST
SEALANT
HI-TEMP
INTAKE
VENT
CONNECTION
ASSEMBLY
Move the insert close to its final position inside the wood-
burningfireplace.This unitisequippedwith6levelling screws
located as follows: two are on either side of the circulation
blower on the rear panel; four are located front and back on
eithersidebeneath the logsupport.Levelusing four ofthelev-
elling screws. See Figure 1a. Levelling the unit will eliminate
rockingorexcessivenoisewhenthefanis in operation. Once
theunitislevel,moveitpartiallyintoplace within the fireplace
to allow for all connections to be made. It is not practical to
level the insert once the it has been installed. Determine the
required depth prior to installing the unit and adjust the four
levelling screws accordingly.
Chimney installation must conform to both national and local
code requirements. The chimney must be lined with one 2"
or 3" diameter liner for intake and one 3" diameter liner for
exhaust.The minimumandmaximumventlengths are 10and
35 feet respectively. Recommended Napoleon kits come in 3
lengths: Whilethe linersmustbe continuousfromthe fireplace
to the terminal, to achieve the needed length, they may be
coupled, using an aluminium coupler, provided installation is
sealed & secured.
We recommend that exhaust vents that pass through un-
heated spaces, such as a garage or attic, be wrapped in a
protective sleeve to minimize condensation and reverse flow
symptoms. See Trouble Shooting for details.
This unit is approved for use with a 2" liner for air intake and
a 3" liner for exhaust. For best performance, however, it is
recommended to use two 3" liners.
If a 2" liner is used for the intake, it is necessary to adjust the
primary air shutter. See "Air Shutter Settings" on page 11.
1. OUTSIDE: Slip one
endofa liner aminimumof
2"overone ofthecollarsof
the terminal. Secure using
3 screws. Then seal the
jointandscrewheadswith
high temperature seal-
ant. Repeat with the other
liner.
NOTE: Werecommend that the otherendoftheexhaustliner
be marked to eliminate the exhaust liner being connected to
the intake collar at the unit.
FIGURE 3
4. Detach the two screws from the back of the firebox and
remove the panel, as illustrated.
5. Reaching in through the insert, manoeuvre the vent con-
nection assembly through the openings in the firebox top,
takingcarenottodamagethegasket.Incaseof alow ceiling
fireplace, the extension should be removed and reinstalled
after the vent connection is secured to the firebox.Attach the
restrictor plate to the centre stud and secure the assembly
using the three studs and ¼-20 hex nuts.
INSERT VENT CONNECTION
CHIMNEY CONNECTION
FIGURE 4
FIGURE5a-b
1-2" & 1-3" DOUBLE PLY ALUMINUM LINER-INLET AND EXHAUST
&
2-3" TO 2" REDUCER:
GDI-2320KT VENT KIT 20FT
GDI-2325KT VENT KIT 25FT
GDI-2335KT VENT KIT 35FT
2-3" DOUBLE PLY ALUMINUM LINER-INLET AND EXHAUST:
GDI-320KT VENT KIT 20FT
GDI-325KT VENT KIT 25 FT
GDI-335KT VENT KIT 35 FT
2. Gently stretch the liners to the required lengths and in-
sert into the chimney. Place the terminal onto the top of the
chimney cap and fit the flashing plate to suit. Make weather
tight by sealing with caulking (not supplied) and fasten to the
chimney with screws and plugs (not supplied)
3. INSIDE: Attach and secure the flex liners to the vent
connection assembly using the same procedure as before,
ensuring that the marked exhaust liner is attached to the
exhaust collar.
EXHAUST
COLLAR LABELED
INTAKE
OVERLAP
SEALANT
HI-TEMP
FLASHING
PLATE
2"
TERMINAL
GDI-223
FIGURE 2
RESTRICTO
R
PLATE
STUDS
VENT
CONNECTOR
EXTENSION

7
W415-0223 / E / 03.05.09
Forease ofaccessibility,an optional remotewall switch
or millivolt thermostat may be installed in a convenient
location. Route 2-strand solid core millivolt wire from
the gas fireplace insert to the wall switch / millivolt
thermostat. The recommended maximum lead length
depends on the wire size:
WIRE SIZE MAX. LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
Do not connect either the wall switch, thermostat
or gas valve to electricity (110 VOLTS).
To adjust the trim: If the mitre is out of alignment, open each
sideandloosenthetwoscrewsateithersidetrim hinge. Slide
the trim up or down to adjust and re-tighten screws. There is
also a very slight in/out adjustment that can be made.
Note: Since the side panels open and close, to access the
controls, a gap is necessary at the mitre joint.
The top trim piece has an adjustable securing bracket which
enables the trim to be secured to the firebox shell.
In order to close off the fireplace opening or if the opening is
largerthanthe3-or4-sidedaluminiumextrusiontrimkits,itis
recommendedtoreducetheopeningusinganoncombustible
material such as ceramic tile, marble, etc or the GIZBP6-3 or
GIZBP6-4 backer plate kits. The outside edge of the backer
plate is finished off with gold trim included in each kit. A
deluxe flashing kit complete with marquis trim may also be
used to complete the installation. These flashing and trim
combinations are available in 6 and 9 inch widths as well as
many finishes to accent any room decor. Mounting brackets,
GIZBRKT,arerequiredtoinstallthedeluxeflashing.Detailed
installation instructions are included with each kit.
If this unit is being installed into an existing wood burning,
zero clearance fireplace, then be aware of this precaution:
Any circulation air opening may be covered (with non-
combustible material) but not sealed!
The insert can be equipped
with either a 3- or 4-sided
trim kit to finish off the fire-
place opening. Slide the trim
assembly over the keyholes
(2 per side) and drop into
place.Ifinstalling theoptional
3- or 4-sided backer plate
(GIZBP6-3 or GIZBP6-4), it
mustbehungpriorto the trim
kitinstallationusing the same
keyholes.
FIGURE 8
FIRE VIEWING DOOR
FIGURE 11
FIGURE 6
The insert may now be
pushed into its final position
inside the wood-burning
fireplace. Secure the insert
to the fireplace using per-
forated strapping attached
to the two securing holes
on either side of the unit as
shown. We recommend that
the trim be installed before
theunitisplacedintoitsfinal
position.
SECURING
HOLES
FIGURE 7
FIGURE 9
VALVE
CONTROL
DOOR
Installsuitablesupplypipingconnectiontothe 3/8" flex con-
nector supplied (as per local gas codes).
FIGURE 10
LOOSEN
SCREWS
SLIDE TO
ADJUST
WALL SWITCH / THERMOSTAT GAS INSTALLATION
FINISHING
ALUMINIUM EXTRUSION TRIM KIT
INSTALLATION

8
W415-0223 / E / 03.05.09
Positioning the logs improperly will cause flame impingement
and carboning.
PHAZERTM logs and glowing embers, exclusive to Napoleon
Fireplaces, glow when exposed to direct flame and provide
a unique and realistic glowing effect that is different in every
installation. Take the time to carefully position the glowing
embers for a maximum glowing effect. Use only certified
PHAZERTM logs available from your Napoleon / Wolf Steel
Ltd. dealer.
1. Placetherear log (#1)ontothetwo log supportsandagainst
the air intake pipe.
2. Position logs #2 and #3 against the grate posts and line up
the studs located on the burner with the holes on the bottom
of the logs. Keep slightly back of the front row of ports.
3. Fit the centre log (#4) into place behind log #3 and into the
pocket provided on the back log.
This can vary according to the mantle depth. Use the graph
to help evaluate the clearance needed.
4. Tear the glowing embers into pieces and place along the
front row of ports covering all of the burner area in front of the
logs.Careshould betakentoshred theembersintothin, small
irregular pieces as only the exposed edges of the fibre hairs
will glow. The ember material will only glow when exposed to
direct flame; however, care should be taken to not block the
burner ports. Blocked burner ports can cause an incorrect
flame pattern, carbon deposits and delayed ignition.
Log colours may vary. During the initial use of the fireplace,
thecolourswill become moreuniformascolour pigmentsburn
in during the heat activated curing process.
FIGURE 17
034 7
8
9
11
13
12 56
7
10
12
H
E
I
G
H
T
M
A
N
T
L
E
MANTLE WIDTH
FIGURE 16
LOWER DOOR BRACKET
#3
#2
#1
FIGURE 12
FIGURE 13
FIGURE 14
#4
Place the door into the two lower door brackets, and secure
at the top of the unit with two #10-24 machine screws.
FIGURE 15
GLOWING EMBERS
Remove the backing of the logo supplied and place on the
glass viewing door, as indicated.
½”
½”
LOGO
LOG PLACEMENT DOOR INSTALLATION
MANTLE CLEARANCE
LOGO PLACEMENT
FIGURE 18
3”
6” 5” 4”
6” MANTEL
5”
3”
4”

9
W415-0223 / E / 03.05.09
The on-off switch is located behind the left side control
door.
Purge all gas lines with the glass door open. Assure that a
continuous gas flow is at the burner before closing the door.
Allow several minutes (5-15) for the flame to stabilize after
ignition.
Do not operate the main burner of the insert
with the door removed.
When lit for the first time, the fireplace will emit a slight odour
for a few hours. This is a normal temporary condition caused
bythe "burn-in" of paints and lubricants used in the manufac-
turingprocessand will notoccuragain.Simplyopen a window
to sufficiently ventilate the room. After extended periods of
non-operationsuchas following avacationora warm weather
season, the fireplace may emit a slight odour for a few hours.
Thisiscausedby dust particles intheheatexchangerburning
off. Open a window to sufficiently ventilate the room.
PURGE THE GAS LINE WITH THE GLASS DOOR OPEN.
7. Turn gas knob counter-clockwise to pilot.
8. Depress slightly and hold gas knob while lighting the
pilot with the push button ignitor. Keep knob depressed for
one minute, then release. If pilot does not continue to burn,
repeat steps 3 through 7.
9. With pilotlit, depress andturngasknob counter-clockwise
to on.
10. If equipped with flame adjustment valve, push and turn
knob to high.
11. If equipped with remote on-off switch/thermostat, main
burnermay not come on when you turn valve to on.Remote
switch must be in the on position to ignite burner.
12. Turn on all electric power to the fireplace.
A. This fireplace is equipped with a pilot which must be lit by
hand. While following these instructions exactly.
B. Before operating smell all around the fireplace area for gas
and next to the floor because some gas is heavier than air
and will settle on the floor.
C. Useonlyyour hand toturnthegas controlknob.Neveruse
tools. If the knob will not turn by hand, do not try to repair
it. Call a qualified service technician. Force or attempted
repair may result in a fire or explosion.
D. Donotusethisfireplaceifanyparthasbeenunderwater.
Immediately call a qualified service technician to inspect
the fireplace and replace any part of the control system
and any gas control which has been under water.
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in
your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire depart-
ment.
When lighting and re-lighting, the gas knob cannot be turned
from pilot to off unless the knob is depressed slightly.
1. Stop! Read the above safety information on this label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise to off.
4. Wait five (5) minutes to clear out any gas. If you smell gas
including near the floor. Stop! Follow "B" in the above safety in-
formation on this label. If you don't smell gas go the next step.
5. If fireplace is equipped with flame adjustment valve turn
clockwise to off.
6. Find pilot located in front of back log.
2. Pushingascontrol knob slightly and turnclockwise
to off. Do not force.
1. Turn off all electrical power to the unit if service is to be
performed.
TURN OFF THE GAS AND UNPLUG ELECTRICAL
POWER BEFORE SERVICING THE FIREPLACE INSERT!
CAUTION: Labelallwiresprior to disconnection whenservic-
ingcontrols.Wiring errors cancauseimproper and dangerous
operation. Verify proper operation after servicing. This insert
and its venting system should be inspected before use and
at least annually by a qualified service person. The fireplace
area must be kept clear and free of combustible materials,
gasoline or other flammable vapours and liquids. The flow of
combustion and ventilation air must not be obstructed.
1. In order to properly clean the burner and pilot assembly,
remove the logs exposing both assemblies.
2. Keep the control compartment, logs, burner, air shutter
opening and the area surrounding the logs clean by vacu-
uming or brushing, at least once a year.
3. Check to see that all burner ports are burning. Clean out
any of the ports which may not be burning or are not burn-
ing properly.
4. Check to see that the pilot flame is large enough to engulf
thethermocoupleononelegand reaches toward the burner
on the other leg.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely on
all openings when the gas knob for the burner is turned on.
A5-10 second total light-up period is satisfactory. If ignition
takes longer, consult your Napoleon dealer/distributor.
7. Check that the door gasketing is not broken or missing.
Replace if necessary.
OPERATION / MAINTENANCE
WHAT TO DO IF YOU SMELL GAS:
OPERATING INSTRUCTIONS
FOR YOUR SAFETY READ BEFORE LIGHTING:
LIGHTING INSTRUCTIONS
TO TURN OFF GAS
MAINTENANCE
FIGURE 19
FIGURE 20
FLAME ADJUSTMENT
KNOB ON/OFF KNOB

10
W415-0223 / E / 03.05.09
1. Turn off the electrical power and the gas supply to the
fireplace insert.
2. Remove the fire viewing door. Remove the logs.
3. Detach the two screws from the back of the firebox and
remove the panel, as illustrated.
4. Remove the blower access door held on with the remain-
ing 8 screws. Replace the blower access door gasket when
changing the blower.
FIGURE 21
4. Disconnect the two blower wires. Remove the blower
bracket secured with one wing nut and lock washer.
Forthermodiscreplacement: Removethe "Z" shaped mount-
ingbracketsecuredtothefireboxwall to the left of the blower.
Remove the thermodisc from the bracket and replace.
5. Replace the blower using the existing bracket. Slide the
vibration reducing pad (A) into the clip (C) and up against the
threaded stud (B) at the other end. The blower must be able
to be positioned entirely onto the pad.
Slide the blower into the clip (C). Secure to the threaded stud
using the existing lock washer and wing nut. Ensure that the
blower does not touch the fireplace base or the firebox.
6. Reconnect the two wires. Holding the replacement gasket
inplace,reattachthebloweraccessdoorandpanel.Replace
the logs. Re-install the fire viewing door.
7. Turn the gas supply and electricity back on.
Becausethe bloweris thermally activated,when turned
on, it will automatically start approximately 5-15 min-
utes after lighting the fireplace insert and will run for
approximately 30-45 minutes after the fireplace insert
hasbeen turnedoff. Use ofthe fanincreases the output
of heat.
Drywall dust will penetrate into the blower bearings
causing irreparable damage and must be prevented
fromcoming into contactwith the bloweror its compart-
ment. Any damage resulting from this condition is not
covered by the warranty policy.
BLOWER
WIRES
FIGURE 24
THERMODISC
BRACKET
ASSEMBLY
FIGURE 26
FIGURE 25
A
BC
OPTIONAL BLOWER INSTALLATION
FIGURE 22
FIGURE 23
BLOWER ACCESS DOOR

11
W415-0223 / E / 03.05.09
A mirror will let you see the opening
of the air shutter without removing the
burner. Scribe a line along the venturi
tube and air shutter cap. Open or close
according to the original opening by us-
ing the scribed line as your datum.
Remove the pilot screw cap.Adjust the pilot screw to provide
properly sized flame. Turn in a clockwise direction to reduce
the gas flow. Replace the pilot screw cap.
FIGURE 27
Air shutter adjustment
must only be done by a
qualified gas installer!
FIGURE 30
This unit is approved for use with a 2" liner for air intake and
a 3" liner for exhaust. For best performance, however, it is
recommended to use two 3" liners.
Air shutter settings will differ depending on the liner system
used. Use the charts below to determine the correct air shut-
ter setting:
Some vent configurations may display a very active flame.
If this appearance is not desirable, the vent exit may be re-
stricted using the restrictor plate shown in FIGURE 6b. Bend
the flap up as shown to reduce the velocity of the exhaust
gases, slowing down the flame pattern and creating a more
traditional appearance.
FIGURE 29
Closingtheairshutterwill cause a more yellow flame, butcan
lead to carboning. Opening the air shutter will cause a more
blue flame, but can cause flame lifting from the burner ports.
Theflamemaynotappearyellowimmediately;allow15to30
minutes for the final flame colour to be established.
HELPFUL HINT:
FLAME MUST
ENVELOPE
UPPER 3/8" TO 1/2" OF
THERMOCOUPLE &
THERMOPILE
PILOT
BURNER
THERMOCOUPLE
THERMOPILE
FIGURE 28
ADJUSTMENTS
PILOT BURNER ADJUSTMENT VENTURI ADJUSTMENT
VENT RESTRICTION
3"/ 3" LINER SYSTEM
NG 1/16"
LP 3/16"
AIR SHUTTER SETTING
2"/ 3" LINER SYSTEM
NG 1/8"
LP 5/16"
AIR SHUTTER SETTING
PILOT
SCREW

12
W415-0223 / E / 03.05.09
31* W690-0001 MILLIVOLT THERMOSTAT
32* W660-0010 REMOTE CONTROL - ADVANTAGE
32* W660-0011 REMOTE CONTROL - ADVANTAGE PLUS
33* GD660 REMOTE WALL SWITCH C/W20FT WIRE
34 GI-790KT DECORATIVE BRICK PANELS
35* W175-0162 CONVERSION KIT - NG-LP
35* W175-0192 CONVERSION KIT - LP-NG
36* GIZBP6-3 3 SIDED BACKER PLATE C/WACCENT TRIM
37* GIZBP6-4 4 SIDED BACKER PLATE C/WACCENT TRIM
38* GIZTRM3 ALUMINIUM EXTRUSION - MATTE BLACK
38* GIZTRM3-K ALUMINIUM EXTRUSION - POLISHED BLACK
38* GIZTRM3-B ALUMINIUM EXTRUSION - POLISHED BRASS
39 GIZTRM4 ALUMINIUM EXTRUSION - MATTE BLACK
39 GIZTRM4-K ALUMINIUM EXTRUSION - POLISHED BLACK
39 GIZTRM4-B ALUMINIUM EXTRUSION - POLISHED BRASS
40 GIZUT-B UPPER DOOR TRIM - BRASS
40 GIZUT-G UPPER DOOR TRIM - GOLD
41 GI-900K6 6" DELUXE FLASHING WMARQUIS TRIM - BLACK
41 GI-900B6 6" DELUXE FLASHING WMARQUIS TRIM - POLISHED BRASS
41 GI-900AB6 6" DELUXE FLASHING WMARQUIS TRIM - ANTIQUE BRASS
41 GI-900SS6 6" DELUXE FLASHING WMARQUIS TRIM - BRUSHED STAINLESS STEEL
41 GI-909S6 6" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN ALMOND
41 GI-909K6 6" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN BLACK
41 GI-909F6 6" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN GREEN
41 GI-900K9 9" DELUXE FLASHING WMARQUIS TRIM - BLACK
41 GI-900B9 9" DELUXE FLASHING WMARQUIS TRIM - POLISHED BRASS
41 GI-900AB9 9" DELUXE FLASHING WMARQUIS TRIM - ANTIQUE BRASS
41 GI-900SS9 9" DELUXE FLASHING WMARQUIS TRIM - BRUSHED STAINLESS STEEL
41 GI-909S9 9" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN ALMOND
41 GI-909K9 9" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN BLACK
41 GI-909F9 9" DELUXE FLASHING WMARQUIS TRIM - PORCELAIN GREEN
42* GIZBRKT MOUNTING BRACKETS (REQUIRED FOR THE 900 SERIES FLASHING KITS)
43 CISK-A CAST IRON SURROUND KIT - PAINTED BLACK
43 CISKK-A CAST IRON SURROUND KIT - PORCELAIN ENAMEL BLACK
43 CISKN-A CAST IRON SURROUND KIT - PORCELAIN ENAMEL MAJOLICA BROWN
43 CISKF-A CAST IRON SURROUND KIT - PORCELAIN ENAMEL MAJOLICA GREEN
44* AK-4 ADAPTOR KIT FOR CAST IRON SURROUND
45 ANI-K ANDIRON - PAINTED BLACK
45 ANI-G ANDIRON - GOLD PLATED
1. MODEL & SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. PART NUMBER
4. DESCRIPTION OF PART
5. FINISH
Contactyourdealer forquestionsconcerningprices andavail-
abilityofreplacementparts.Normally all partscanbeordered
through your Napoleon dealer or distributor.
When ordering replacement parts always give the following
information:
1 W725-0039 RBT SHAW VALVE - NG
1 W725-0040 RBT SHAW VALVE - LP
2 W100-0068 BURNER
3 W455-0017 #42 BURNER ORIFICE - NG
3 W455-0059 #53 BURNER ORIFICE - LP
4 W010-0800 PILOTASSEMBLY - LP
4 W010-0801 PILOTASSEMBLY - NG
5 W455-0069 PILOT INJECTOR - NG
5 W455-0067 PILOT INJECTOR - LP
6 W680-0005 THERMOCOUPLE
7 W680-0004 THERMOPILE
8* W573-0008 HIGH TEMPERATURE SEALANT
9* W357-0001 PIEZO IGNITOR
10 GL-631 LOG SET
11 W135-0136 REAR LOG
12 W135-0138 RIGHT LOG
13 W135-0137 LEFT LOG
14 W135-0139 CENTER LOG
15* W361-0016 GLOWING EMBERS
16 GZ552 BLOWER
17* W385-0245 NAPOLEON LOGO
18* W010-0804 DOOR GLASS C/WGASKET
19* W225-0095 DOOR FRAME
20 W010-0802 DOOR C/WGLASS
21* W290-0063 BLOWER ACCESS GASKET
22* W430-0013 MAGNETIC CLOSURE
23* W660-0009 ON/OFF SWITCH
24* W690-0002 THERMODISC
25* W380-0002 VARIABLE SPEED SWITCH KNOB
26* KB35 VARIABLE SPEED SWITCH
27 W080-0451 RESTRICTOR BRACKET
28 GDI-223 TERMINAL KIT
REPLACEMENTS
FOR WARRANTY REPLACEMENT PARTS, APHOTOCOPY OF THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM.
REPLACEMENT PARTS
TERMINAL KITS
ACCESSORIES:
1-2" & 1-3" DOUBLE PLY ALUMINUM LINER-INLET AND
EXHAUST & 2-3" TO 2" REDUCER:
29* GDI-2320KT VENT KIT 20FT
29* GDI-2325KT VENT KIT 25FT
29* GDI-2335KT VENT KIT 35FT
2-3" DOUBLE PLY ALUMINUM LINER-INLET AND EX-
HAUST:
30* GDI-320KT VENT KIT 20FT
30* GDI-325KT VENT KIT 25 FT
30* GDI-335KT VENT KIT 35 FT
VENT KITS
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR NAPOLEON
DEALER.

13
W415-0223 / E / 03.05.09
*WARNING: This is a fast acting thermocouple. It is an integral safety component. Replace only
with a fast acting thermocouple supplied by Wolf Steel Ltd.

14
W415-0223 / E / 03.05.09
PILOT
BURNER
THERMOCOUPLE
THERMOPILE
Main burner goes out;
pilot stays on. Pilotflameis notlargeenoughor
not engulfing the thermopile.
Thermopile shorting
Remote wall switch wire is too
long, too much resistance in the
system
Faulty thermostat or switch
- turn up pilot flame.
- replace pilot assembly.
- clean thermopile and thermopile connection to valve.
- shorten wire to correct length or wire gauge.
- replace
Gas piping is undersized.
Pilot goes out while
standing; Main burner
is in 'OFF' position.
- turn on all gas appliances and see if pilot flame flutters, di-
minishes or extinguishes, especially when main burner ignites.
Monitor supply pressure.
- check if supply piping size is to code. Correct all undersized
piping.
Pilotburning;no gas to
main burner; gas knob
is on 'HI'; wall switch /
thermostat is on.
Main burner orifice is plugged.
Faulty thermopile.
Faulty themostat or switch.
- remove stoppage in orifice.
- replace.
- connect a jumper wire across the wall switch terminals; if main
burner lights, replace thermostat.
- disconnect the switch wires & connect a jumper wire across ter-
minals 1 & 3; if the main burner lights, check the wires for defects
and / or replace wires.
Faulty valve. - replace.
- check that the manual valve is turned on.
- check the pilot orifice for blockage.
- replace the valve.
- call the gas distributor.
No gas at the pilot burner
- fill the tank.
Out of propane gas.
Pilot will not light. - check if pilot can be lit by a match
- check that the wire is connected to the push button ignitor.
- check if the push button ignitor needs tightening.
- replace the push button ignitor.
No spark at pilot burner
Spark gap is incorrect - spark gap should be 0.150" to 0.175" (5/32" to 11/64" approx.)
from the electrode tip and the pilot burner.
Pilot flame is not large enough
- turn up the pilot flame.
Pilot flame is not engulfing the
thermocouple. - turn up pilot flame. - replace pilot assembly.
Thermocouple shorting.
Faultly thermocouple.
Faulty valve.
System is not correctly purged. - purge the gas line with the glass door open.
- fill the tank.
Out of propane gas
Pilot goes out when
the gas knob is re-
leased.
- loosen and tighten thermocouple.
- clean thermocouple and valve connection.
- replace thermocouple.
- replace valve.
- replace.
- replace.
TROUBLE SHOOTING GUIDE
BEFORE ATTEMPTING TO TROUBLESHOOT, PURGE YOUR UNIT AND INITIALLY LIGHT THE PILOT AND THE MAIN BURNER WITH THE GLASS DOOR REMOVED.
SYMPTOM PROBLEM TEST SOLUTION

15
W415-0223 / E / 03.05.09
Exhaustfumessmelled
in room, headaches. - check all seals.
Fireplace is spilling.
Carbon is being de-
positedonglass,logs
or combustion cham-
ber surfaces. Flame is impinging on the logs
or combustion chamber. - check that the logs are correctly positioned. - open air shutter to increase the primary air.
- check the input rate: check the manifold pressure and orifice
size as specified by the rating plate values.
- check that the door gasketing is not broken or missing and that
the seal is tight.
- check that both vent liners are free of holes and well sealed at
all joints.
Air shutter has become
blocked - ensure air shutter opening is free of lint or other obstructions.
White / grey film
forms. Sulphur from fuel is being de-
posited on glass, logs or com-
bustion chamber surfaces.
- clean the glass with a recommended gas fireplace glass
cleaner. DO NOT CLEAN GLASS WHEN HOT.
If deposits are not cleaned off regularly, the glass may become
permanently marked.
Main burner goes out;
pilot goes out. REFER TO "MAIN BURNER GOES OUT; PILOT STAYS ON"
Thermocouple shorting or
faulty.
Vent re-circulating - check joint seals and installation.
- loosen and tighten thermocouple
- clean thermocouple and valve connection.
- replace thermocouple.
- replace valve.
Vent is reversing - check all venting and insert seals.
- checkthatdoorisproperlysealed.Ifthe insert is allowed to burn
with the door off when purging the unit, exhaust products may
escapethroughtheairintakepipeandreversetheventingaction.
Let the unit cool down to correct the reversed venting action.
Mainburnerflameis a
blue,lazy, transparent
flame.
Blockage in vent. - remove blockage. In really cold conditions, ice buildup may
occur on the terminal and should be removed as required.
- vent liners are reversed. Refer to Figure 2.
- check all venting and insert seals.
Incorrect installation.
SYMPTOM PROBLEM TEST SOLUTION

16
W415-0223 / E / 03.05.09
Appliance Service History
This heater must be serviced annually depending on usage.
Date Service Technician
Name Service Performed Special ConcernsDealer Name
43.1
