NARDA PMM FR4003 User manual

NARDA
Safety
Test
Solutions
S.r.l. Socio Unico
Sales & Support:
Via Leonardo da Vinci, 21/23
20090 Segrate (MI) - ITALY
Tel.: [phone]
Fax: [phone]
Manufacturing Plant:
Via Benessea, 29/B
17035 Cisano sul Neva (SV)
Tel.: [phone]
Fax: [phone]
http://www.narda-sts.it
SERIAL NUMBER OF THE INSTRUMENT
You can find the Serial Number on the front panel of the instrument.
Serial Number is in the form: 0000X00000.
The first four digits and the letter are the Serial Number prefix, the last five digits are the
Serial Number suffix. The prefix is the same for identical instruments, it changes only
when a configuration change is made to the instrument.
The suffix is different for each instrument.
Document FR4003EN-80708-2.05 – Copyright © NARDA 2018
User’s Manual
PMM FR4003
FIELD RECEIVER
From 9 kHz up to 30 MHz

II Note and symbols
NOTE:
® Names and Logo are registered trademarks of Narda Safety Test Solutions GmbH and L3 Communications
Holdings, Inc. – Trade names are trademarks of the owners.
If the instrument is used in any other way than as described in this User’s Manual, it
may become unsafe.
Before using this product, the related documentation must be read with great care and fully understood to familiarize
with all the safety prescriptions.
To ensure the correct use and the maximum safety level, the User shall know all the instructions and
recommendations contained in this document.
This product is a Safety Class I instrument according to IEC classification and has
been designed to meet the requirements of EN61010-1 (Safety Requirements for
Electrical Equipment for Measurement, Control and Laboratory Use).
In accordance with the IEC classification, the power supply of this product meets requirements Safety Class II and
Installation Category II (having double insulation and able to carry out mono-phase power supply operations).
It complies with the requirements of Pollution Class II (usually only non-conductive pollution). However,
occasionally it may become temporarily conductive due to condense on it.
The information contained in this document is subject to change without notice.
EXPLANATION OF ELECTRICAL AND SAFETY SYMBOLS :
You now own a high-quality instrument that will give you many years of reliable service.
Nevertheless, even this product will become obsolete. When that time comes, please remember
that electronic equipment must be disposed of in accordance with local regulations. This product
conforms to the WEEE Directive of the European Union (2002/96/EC) and belongs to Category 9
(Monitoring and Control Instruments). You can return the instrument to us free of charge for
proper environment friendly disposal. You can obtain further information from your local Narda
Sales Partner or by visiting our website at www.narda-sts.it .
Warning, danger of electric shock
Earth
Read carefully the Operating Manual and its
instructions, pay attention to the safety
symbols.
Unit Earth Connection
Earth Protection Equipotential
EXPLANATION OF SYMBOLS USED IN THIS DOCUMENT :
The DANGER sign draws attention to a serious risk to a person’s safety,
which, if not avoided, will result in death or serious injury. All the
precautions must be fully understood and applied before proceeding.
The WARNING sign indicates a hazardous situation, which, if not avoided,
could result in death or serious injury. All the precautions must be fully
understood and applied before proceeding.
The CAUTION sign indicates a hazardous situation, which, if not avoided,
could result in minor or moderate injury.
The NOTICE sign draws attention to a potential risk of damage to the
apparatus or loss of data.
The NOTE sign draws attention to important information.

Contents III
Contents
Explanation of electrical and safety symbols ……....…………………………
General safety considerations and instructions ………....………………….
EC Declaration of Conformity .............…………………………………………..
1. General Information
1.1 Documentation…………………………………………………………………..
1.2 Operating Manual changes…………………………………………………….
1.3 Introduction to PMM FR4003..…………………………………………………
1.4 Instrument Items………….……………………………………………………..
1.5 Optional accessories……………….…………………………………………...
1.6 Main Specifications……………………………………………………………..
1.7 Front Panel………………………...…………………………………………….
1.8 Rear Panel……………………………………………………………………….
1.9 Functional Description………………………………………………………….
1.10 Ultra fast measurement: a unique feature of the PMM 9010F……..……..
1.11 Emission measurement……………..………………………………………..
Page
II
VIII
IX
Page
1-1
1-1
1-2
1-3
1-3
1-4
1-6
1-7
1-8
1-8
1-9
2 Installation
2.1 Introduction………………………………………………………………………
2.2 Initial Inspection……………………………….……………….………………..
2.3 Unpacking……………………………………….…………….…………………
2.4 Preparation for Use……………………………………………………………..
2.5 Battery Charger…………………………………………………….……………
2.5.1 To replace the mains connector of the battery charger…………………..
2.5.2 To charge the internal battery..……………………………………………...
2.5.3 Indication of the battery status on the screen and with PW led………….
2.6 Environment……………………………………………………………………..
2.7 Return for Service……………………………………………………………….
2.8 Equipment Cleaning…………………………………………………………….
2.9 Equipment ventilation…………………………………………………………...
2.10 Hardware Installation………………………………………………………….
2.11 Using an Artificial Mains Network (AMN or LISN)………………………….
2.12 Using Pulse Limiter……………………………………………………………
2.13 Using Current and Voltage Probes……………………………………….….
2.14 Using Antennas and other Transducers………………………………….…
Page
2-1
2-1
2-1
2-7
2-7
2-7
2-7
2-8
2-8
2-9
2-9
2-9
2-9
2-10
2-10
2-10
2-11

IV Contents
3 9010F Fast
3.1 Introduction to PMM 9010F.……………………………………………………
3.1.1 Principle of Operation…………………………………………………………
3.2 Sweep Mode..……………………………………………………………………
Ultra Fast FFT scan….……………………………………………………………....
3.2.1 Measure….…………………………………………………………………….
3.2.1.1 Frequency..…………………………………………………………………..
3.2.1.2 Level…….…………….……………………………………………………...
3.2.1.3 Input Attenuators and Preamplifier……………………………………….
3.2.1.4 Misc………………………...…………………………………………………
3.2.1.5 RF Output Generator…………………………………………………...…..
3.2.1.6 Detector………………………………………………………………………
3.2.1.7 Conversion factor……………………………………………………...……
3.2.2 Limit…………………………………………………………………………….
3.2.3 Display…………………………………………………………………………
3.2.4 Marker………………………………………………………………………….
3.2.5 Load – Store…………………………………………………………………..
3.3 Analyzer Mode…………………………………………………………………..
3.3.1 Frequency……………………………………………………………………..
3.3.2 RBW…………………………………………………………………………….
3.3.2.1 Additional RBW Filters…….……………………………………………….
3.3.2.2 MIL-STD-461E Activation Procedure (option)…………………………..
3.3.3 Level…………………………………………………………………………….
3.3.3.1 Input Attenuators and Preamplifier………………………………………..
3.3.3.2 OVER RANGE Message……………………………………………………
3.3.3.3 Misc……………………………………………………………………………
3.3.3.3.1 Signal Generator…….…………………………………………………….
3.3.3.4 Detector………………………………………………………………………
3.3.3.5 Conversion Factor…………………………………………………………..
3.3.4 Marker…………………………………………………………………………..
3.4 Setup – Unit.……………………………………………………………………..
3.5 Manual Mode…………………………………………………………………….
3.5.1 RBW Selection………………………………………………………………..
3.5.2 MIL Filters………………………………………………………………………
3.5.3 Hold Time……………………………………………………………………….
3.6 Operating Manual Changes…………………………………………………….
Page
3-1
3-2
3-3
3-3
3-4
3-4
3-5
3-5
3-6
3-6
3-7
3-8
3-8
3-8
3-9
3-10
3-11
3-12
3-13
3-13
3-14
3-15
3-15
3-16
3-16
3-17
3-17
3-18
3-18
3-18
3-19
3-19
3-19
3-20
3-20

Contents V
4 PMM Emission Suite software
4.1 FR4003 Operation method…………………………………………………….
4.2 Sweep mode..…………………………………………………………………...
4.2.1 Scan tab.……………………………………………………………………….
4.2.2 Frequency……………………………………………………………………...
4.2.3 Detector, Hold time and Limit..……………………………………………...
4.2.4 RBW……………………………………………………………………………
4.2.5 Min Att………………………………………………………………………….
4.2.6 Preamp…………………………………………………………………………
4.2.7 Preselector…………………………………………………………………….
4.2.8 Prompt start……………………………………………………………………
4.2.9 Ancillary………………………………………………………………………..
4.2.10 Worst…………………………………………………………………………
4.2.11 Undo…………………………………….…………………………………….
4.2.12 Factors………………………………………………………….…………….
4.2.13 HPF and HiZ receiver……………………………………………………….
4.2.14 Execute..……………………………………………………………………...
4.3. Analyzer Mode….…………………………………………………..................
4.3.1 Introduction……..……………………………………………………………..
4.3.2 Analyzer Mode Tab Settings…………………………………………………
4.3.2.1 Detector………………………………………………………………………
4.3.2.2 Frequency…..……………………………………………………………….
4.3.2.3 Marker….…………………………………………………………………….
4.3.2.4 Max Hold, Hold When Done….…………………………………………...
4.3.2.5 Tune Manual @....................................................................................
4.3.3 Analyzer Mode Global Test Settings………………………………………..
4.3.3.1 BW IF…………………………………………………………………………
4.3.3.2 Limits…………………………………………………………………………
4.3.3.3 Battery………………………………………………………………………..
4.3.3.4 Factors……………………………………………………………………….
4.3.3.5 HPF and HiZ receiver………………………………………………………
4.3.3.6 Exit……………………………………………………………………………
4.4 Manual Mode…………………………………………………………………….
4.4.1 Manual Mode Tab Settings………………………………………………….
4.4.1.1 Parameter……………………………………………………………………
4.4.1.2 Detector……………………………………………………………………..,
4.4.2 Manual Mode Global Test Settings………………………………………….
4.4.2.1 BW IF…………………………………………………………………………
4.4.2.2 Attenuator – Min Att…………………………………………………………
4.4.2.3 Over Range………………………………………………………………….
4.4.2.4 Limits…………………………………………………………………………
4.4.2.5 Battery……………………………………………………………………….
4.4.2.6 Factors………………………………………………………………………
4.4.2.7 HPF and HiZ receiver………………………………………………………
4.4.2.8 Exit……………………………………………………………………………
4.4.3 Manual Mode Graph………………………………………………………….
4.5 RMS-AVG Detector…………………………………………………………….
4.5.1 Introduction…………………………………………………………………….
4.5.2 RMS-AVG Definition………………………………………………………….
4.5.3 RMS-AVG Activation Procedure (option)…………………………………..
4.5.4 C-AVG Definition………………………………………………………………
Page
4-1
4-1
4-2
4-2
4-3
4-4
4-4
4-4
4-4
4-4
4-4
4-5
4-5
4-6
4-6
4-6
4-7
4-7
4-8
4-8
4-8
4-8
4-8
4-9
4-9
4-9
4-10
4-10
4-10
4-10
4-10
4-11
4-12
4-12
4-12
4-13
4-13
4-13
4-13
4-14
4-14
4-14
4-14
4-14
4-15
4-16
4-16
4-16
4-16
4-18
5 Utility, Calibration and Stand-Alone mode.
5.1 FR4003 Utility……………………………………………………………………
5.1.1 Connection……………………………………………………………………..
5.1.2 Preferences…………………………………………………………………….
5.1.3 Tools…………………………………………………………………………….
5.1.3.1 Internal Generator…………………………………………………………..
5.1.3.2 Cap Meter……………………………………………………………………
5.1.3.3 Auto-Calibration……………………………………………………………..
5.1.4 Information……………………………………………………………………..
5.2 Analog mode…….……………………………………………………………….
5.2.1 Front panel buttons……………………………………………………………
Page
5-1
5-2
5-3
5-3
5-4
5-4
5-7
5-8
5-10
5-11

VI Contents
6. Applications
6.1 How it works……………………………………………………………….…...
6.2 Power switch…………………………………………………………………...
6.3 ESD risks………………………………………………………………………..
6.4 Principles of operation……………………………………………..………….
6.5 Antenna Factor…………………………………………………………..…….
6.6 Procedure of Calibration…………………………………………………..….
6.7 Measuring the EMI Voltage………………………………………………..…
6.8 Related products …..……………………………………………………..…..
Page
6-1
6-1
6-1
6-1
6-1
6-2
6-2
6-2
7. Updating firmware and Activation code Utility
7.1 Introduction……………………………………………………………………..
7.2 System requirements ……………………………….…………………………
7.3 Preparing the Hardware…………………………….…………………………
7.4 Software installation…………………………………………………..............
7.5 To transfer data……………….……………………………………..…………
7.6 9010 WrDongle utility ...……….…….……………………………..…………
Page
7-1
7-1
7-1
7-1
7-6
7-8
8. Remote control
8.1 Introduction………………………………………………………………………
8.2 Communication………………………………………………………………….
8.3 Protocol…………………………………………………………………………..
8.4 Format……………………………………………………………………………
8.5 Remote swich-on……………………………………………………………….
8.6 Auto switch-off…………………………………………………………………..
8.7 List of commands……………………………………………………………….
8.7.1 QUERY Commands………………………………………………………….
8.7.2 SETTING Commands………………………………………………………..
8.7.3 IDLE Commands……………………………………………………………..
8.7.4 Analyzer Reply………………………………………………………………..
8.7.4.1 Reply example………………………………………………………………
8.8 Special notes for FFT method………………………………………………...
Page
8-1
8-1
8-1
8-1
8-1
8-1
8-2
8-5
8-10
8-25
8-28
8-28
8-30
9 Accessories
9.1 Introduction ….…………………………..……...……………..………………
9.2 Preliminary inspection …………………..….……………………..………….
9.3 Work environment ……....………………..……………………..……………
9.4 Return for repair …….………………..………………..................................
9.5 Cleaning ……………………………..………………………………………….
9.6 PMM TR-01A Set (optional)…..………………………………………………
9.6.1 TR-01A Set....................…………………………………………………….
9.6.2 FR4003 installation on TR-01 wooden tripod…..……….………………..
Page
9-1
9-1
9-1
9-1
9-1
9-2
9-2
9-4
10. Packaging Instruction
10.1 Introduction……………………………………………………………………
10.2 Packaging Instruction ……………………………………………………….
Page
10-1
10-1

Contents VII
Figures
Figure
1-1
1-2
1-3
1-4
2-1
2-2
3-1
3-2
4-1
4-2
4-3
4-4
9-1
9-2
9-3
9-4
9-5
Front Panel…….……………………………………………………...
Rear Panel…….……………………………………………………....
BP-02 Replaceable battery………………………………………….
PMM FR4003 Functional Block Diagram…………..……………...
PMM 9010F initial screen……………………………………………
Antenna parts and assembly………………………………………..
Sweep………………………………………………………………….
Spectrum………………………………………………………………
Operation method…………………………………………….
Sweep mode screen.…………………………………………………
Analyzer mode window………………………………………………
Manual mode window……………………………………………..…
PMM TR01 Wooden Tripod………………………………………....
Adjustable joint……………………………………………………….
Column strenghthner………………………………………………..
Soft carrying case……………………………………………………
FR4003 parts and assembly………………………………………..
Page
1-6
1-7
1-7
1-8
2-10
2-11
3-3
3-11
4-1
4-1
4-7
4-11
9-2
9-2
9-3
9-3
9-4
Tables
Table
1-1
9-1
9-2
9-3
Main Specifications……..….………………………………………
PMM TR-01 Wooden tripod with extension Specifications ……
Column strenghthner Specifications……………………………..
Soft carrying case Specifications…………………………………
Page
1-4
9-2
9-3
9-3

VIII Contents
SAFETY RECOMMENDATIONS AND INSTRUCTIONS
This unit has been designed, produced and tested in Italy, according to IEC 348 standard and has left
the manufacturer’s premises in a state fully complying with the safety standards; in order to maintain the
unit in a safe state and to ensure safe operation, the following instructions must be reviewed and fully
understood before operation.
•When the unit is to be permanently cabled, first connect an uninterruptible protective earth ground
conductor before making any other connections.
•If the unit is to be connected to other equipment or accessories, prior to energizing either units, verify
that a common ground exists between them.
•For permanently cabled unit without built-in fuses, automatic circuit breakers or similar protective
facilities, the power supply line shall be provided with fuses or protections rated to the unit.
•Verify that the unit is set to match the available mains voltage and correct fuse rating is installed
before applying power.
•The Safety Class I units provided with disconnectible AC supply cable and plug, may only be
operated from a power socket with protective earth ground connection.
•Any interruption or loosening of the protective earth ground conductor, either inside or outside the
unit or in an extension cable will cause a potential shock hazard that could result in personal injury.
•The protective earth ground conductor shall not be interrupted intentionally.
•To avoid electrical shock do not remove protections or covers of the unit , refer to qualified NARDA
Servicing Center for maintenance of the unit.
•To maintain adequate protection against fire hazard, replace fuses only with others of the same type
and rating;
•Observe safety regulations and rules and also the additional safety instructions specified in this
manual for prevention of accidents.

Contents IX
Dichiarazione di Conformità
EC Declaration of Conformity
In accordo alla Decisione 768/2008/EC, conforme alle direttive EMC 2014/30/UE, Bassa Tensione 2014/35/UE e
RoHS 2011/65/UE, ed anche alle norme ISO/IEC 17050-1 e 17050-2.
In accordance with the Decision 768/2008/EC, compliant to the Directives EMC 2014/30/UE, Low Voltage 2014/35/UE and
RoHS 2011/65/EU, also compliant to the ISO/IEC standard 17050-1 and 17050-2
Il costruttore
The manufacturer narda Safety Test Solutions S.r.l. Socio Unico
Indirizzo
Address Via Benessea, 29 / B
I-17035 Cisano sul Neva (SV) - Italy
sulla base delle seguenti norme europee armonizzate, applicate con esito positivo:
based on the following harmonized European Standards, successfully applied:
EMC - Emissioni:
EMC - Emission: EN 61326-1 (2013)
EMC - Immunità:
EMC - Immunity: EN 61326-1 (2013)
Sicurezza:
Safety: CEI EN 61010-1 (2010)
dichiara, sotto la propria responsabilità, che il prodotto:
declares, under its sole responsibility, that the product:
Descrizione
Description
FIELD RECEIVER
Modello
Model PMM FR4003
è conforme ai requisiti essenziali delle seguenti Direttive:
conforms with the essential requirements of the following Directives:
Bassa Tensione
Low Voltage 2014/35/EU
Compatibiltà Elettromagnetica
EMC 2014/30/EU
RoHS
RoHS 2011/65/EU
Cisano sul Neva, 03 May 2017 Egon Stocca
General Manager

X Contents
This page has been intentionally left blank

General Information 1-1
1 – General Information
1.1 Documentation
Enclosed with this manual are:
•a service questionnaire to send back to NARDA in case an equipment
service is needed.
•an accessories checklist to verify all accessories enclosed in the
packaging.
1.2 Operating
Manual Changes
Instruments manufactured after the printing of this manual may have a
serial number prefix not listed on the title page; this indicates that
instruments with different Serial Number prefix may be different from those
documented in this manual.
Document FR4003EN-80708-2.05 - © NARDA 2018

1-2 General Information
1.3 Introduction
to PMM FR4003
PMM FR4003 is not only a simple Rod Antenna but incorporates also a
powerful EMI receiver, fully CISPR 16-1-1, to measure conducted and
radiated interferences from 9 kHz up to 30 MHz, and can increase its
performances when matched with PMM 9010F units (optional). All
measurements performed by the PMM FR4003 are according to the most
accepted standards like: IEC, CISPR, EN (EuroNorm), FCC, VDE, MIL-
STD, RTCA/DO etc.
Thanks to its built-in tracking generator, PMM FR4003 is also able to
perform a self-calibration procedure and to check its good operation at any
time.
It is, at the same time, a traditional active Rod Antenna, with a RF analog
output, and a versatile EMI receiver, already internally matched to the
antenna itself.
The PMM FR4003 has been designed adopting an innovative philosophy
made possible only in the recent years by the availability of superior
technology components. This equipment is fully digital but the input
preselector and attenuator – and, of course, the output stage of the internal
reference tracking generator - and therefore combines into a pure EMI
Receiver and Signal Analyzer the precision and accuracy of a numeric
approach, with flexibility and user friendly approach typical of a modern
instrument.

General Information 1-3
1.4 Instrument Items
PMM FR4003 includes the following items:
•Field Receiver from 9 kHz up to 30 MHz
•1000mm Rod;
•600 x 600 mm counterpoise;
•4 pieces Pan head machine screw X shaped M5x12mm;
•BP-02 Li-ion battery pack;
•External power supply/battery charger;
•Intern. AC plug adapters (Australia, UK, USA);
•Italian AC plug adapter;
•50 Ωto Rod capacitance fixture for CISPR calibration;
•15 pF fixture for capacitance meter calibration;
•MIL-STD 40mm Rod extension;
•10 m plastic optic fiber for PC;
•USB-OC Optical Converter;
•Carrying case;
•Reversible screwdriver;
•Operating manual;
•PMM FR4003 Utility Software on Software Media;
•Certificate of Calibration;
•Return for Repair Form.
1.5 Optional
accessories
PMM FR4003 can be used with several optional accessories, the most
common being the following:
•9010/FO-20 High speed fiber optic cable (20 m)
•9010/FO-50 High speed fiber optic cable (50 m)
•9010/FO-100 High speed fiber optic cable (100 m)
•Plastic fiber optic for PC (10 m)
•Plastic fiber optic for PC (20 m)
•Plastic fiber optic for PC (40 m)
•USB-fiber optic adapter
•TR-01A set (TR01 60-180 cm wooden column extendable tripod,
column strengthener, soft carrying case)
•BP-02 Li-Ion battery pack

1-4 General Information
1.6 Main
Specifications
Table 1-1 lists the PMM FR4003 performance specifications.
The following conditions apply to all specifications:
•The ambient temperature shall be -10°C to 60°C
TABLE 1-1 Main Specifications
Frequency range
Resolution
Frequency accuracy
9 kHz to 30 MHz
1 Hz
< 1 ppm
RF input
Attenuator
HPF
Preamplifier
High impedance N f.
Built-in 0 dB to 30 dB (10 dB steps)
Built-in 9 kHz or 150 kHz HPF (selectable)
Built-in 20 dB gain (selectable)
Max input level
100/104 cm rod
(Preamp OFF, Att 30 dB)
N input (50 Ωterm. Preamp OFF, Att 10 dB)
BNC analog output (1dB compression point @
1MHz)
(SD Spectral Density)
380 V/m CW
137 dBµV/m/MHz SD
137 dBµV CW
103 dBµV/MHz SD
Internally processed signal
(SD Spectral Density with Preselector ON)
38 V/m CW
128 dBµV/m/MHz SD
117 dBµV CW
94 dBµV/MHz SD
Damage level 500 V/m CW (Min. Att. 20 dB)
Noise level
Preamp ON, Att 0 dB, 10 kHz RBW
Manual Mode, Tune 1 MHz
100/104 cm rod
13 dBµV/m PK 2 dBµV/m AVG
DANL -38 dBµV/m(Hz)
N input (50 Ωterm)
-1 dBµV PK -12 dBµV AVG
DANL -52 dBµV(Hz)
Spurious response < -10 dBµV (Att 0 dB, 50 Ωtermination AVG, Hold time 10 ms, RBW auto)
Measurement accuracy 9 kHz to 30 MHz ± 0,8 dB
Preselector
Two Bandpass filters: 9 kHz to 30 MHz 150 kHz to 30 MHz
Five bandpass filters: 9 kHz to 5,67 MHz 5,67 MHz to 11,19 MHz
11,19 MHz to 16,71 MHz 16,71 MHz to 22,23 MHz
22,23 MHz to 30 MHz
Internal Receiver Fully digital. Operates both in conjunction with 9010F receiver and in stand-alone.
IF bandwidth
6 dB bandwidth
3, 10, 30, 100, 300 kHz
200 Hz, 9 kHz (CISPR 16-1-1)
1, 10 kHz (MIL-STD-461)
Level measuring time
(Hold time)
CISPR 16-1-1 as default.
0,2 ms to 120 s
Detectors Peak, Quasi-Peak, Average, RMS, RMS-Average (Optional), C-Average
Smart Detector function
Sweep time
9 kHz to 150 kHz (RBW 200 Hz CISPR)
10 kHz to 150 kHz (RBW 1 kHz MIL)
150 kHz to 30 MHz (RBW 9 kHz CISPR)
150 kHz to 30 MHz (RBW 10 kHz MIL)
FFT mode
Analyzer hold time lowest Receiver hold time
1s
1,1s 7s
0,4s 4s
2,8s 22s
2,8s 22s
Swept mode
Analyzer hold time lowest Receiver hold time
1s
110s 1600s
6s 595s
23s 6200s
46s 12400s
Antenna Factor
At BNC auxiliary analog output
0 dB/m (Att 0dB, PreAmp ON)

General Information 1-5
Analog output. 50 ΩBNC f.
Internal generator
Frequency range
Frequency resolution
Level range
Level resolution
Level accuracy
Tracking & CW generator (for auto calibration, capacitance meter and field source)
9 kHz to 30 MHz
1 Hz
65 to 95 dBµV
1 dB
0,3 dB
Internal capacitance meter
Range
Resolution
Calibration
0 to 100 pF
0,01 pF
Automatic (Calibration fixtures included)
Auto test Automatic at power on
Auto calibration Through internal generator and matching network
Optic Fiber connection RP-02 series serial optical interface 115 kbaud
9010F series high speed optical interface
PC softwares PMM Emission suite – PMM FR4003 Utility
Display units
With PMM Emission Suite SW
dBm, dBµV, dBµA, dBpW, dBµV/m, dBµA/m, dBpT
80 to 200 dB selectable dynamic range
Standard conformity
CISPR 16-1-1, MIL-STD 461G full compliant on board receiver.
CISPR 12, CISPR 25, MIL-STD 461G, DO-160 full compliant rod antenna
FW updating Through the optical link via USB
Power supply 7,4 V – 7,8 Ah Li-Ion rechargeable & interchangeable battery (8h avg. Operating time 4h avg. Charging
time)
100 - 240 Vac / 50 – 60 Hz to 12 Vdc – 2.5 A universal adapter/charger.
Recommended calibration
interval
24 months (calibration data stored in the internal EEPROM)
Operating temperature -10° to 60°C
Storage temperature -30° to 75°C
Operating humidity 0 to 98% (Without condensation)
Tripod support Threaded insert UNC ¼“
Dimensions and weights
(Overall WxDxH)
Receiver 134 x 285 x 84 mm 2,40 kg
Counterpoise 600 x 600 x 1,5 mm 4,15 kg
Rod (Ø20 x 1000mm) φ29 x 1020 mm 0,50 kg
Rod extension (40mm) φ20 x 47 mm 0,05 kg
TOTAL (w rod ext.) 600 x 600 x 1122 mm 7,10 kg
Standard accessories 50 Ωto rod capacitance fixture for CISPR calibration; 15 pF fixture for capacitance meter calibration;
MIL-STD 40mm rod extension, 600x600 mm counterpoise, battery pack; AC adapter/charger; PC
softwares; 20 m high speed optic fiber for 9010F receiver; 10 m plastic optic fiber for PC; USB-optical
adapter; carrying case; certificate of calibration; operating manual.

1-6 General Information
1.7 Front Panel
Fig. 1-1 Front Panel
Legend from left to right:
- ON Push Button Power On Led; indicates the power status
- ATT Push Button Attenuator Led; indicates the attenuator status
It is off when the attenuator has been set to 0 dB
it blinks shortly when the attenuator has been set to 10 dB
it blinks half on and half off when set to 20 dB and
it is permanently ON when set to 30 dB
- PRE Push Button Preamplifier Led; indicates the preamplifier status
- HPF Push Button HPF Led; indicates the 150 kHz high pass filter status
- REMOTE LED Remote Led; indicates the remote control status
- LINK 1 The RP-02 connector for the plastic optic fiber, for PC connection
- LINK 2 The connector for PMM 9010F fast optic fiber connection
-Product Label and Serial Number

General Information 1-7
1.8 Rear Panel
Fig. 1-2 Rear Panel
Legend from left to right:
- A OUT Analog Output, BNC female connector, 50 Ω
- Batt Rechargeable Battery, PMM BP-02, with charger connector.
The battery can be easily replaced or charged separately from the unit.
- Power Supply Power Supply input to charge the battery.
Fig. 1-3 BP-02 Replaceable Battery

1-8 General Information
1.9 Functional
Description
The PMM FR4003 features a completely new receiver architecture based
on the most recent DSP and RSP technology, as shown on the diagram
below.
The PMM FR4003 diagram is shown in Fig. 1-4
Fig. 1-4 PMM FR4003 Functional BLOCK Diagram
1.10 Ultra fast
measurement: a
unique feature of
the PMM 9010F
In the CISPR band A (9 ÷ 150 kHz), the standards requires the use of a
200 Hz filter that is, by nature, a filter that implies a long measurement
time: a complete scan may require even more than 10 minutes, depending
on the detector in use.
Also the B band takes a long time since it involves many frequency steps.
Thanks to its architecture and to the large internal memory capability, the
combination of PMM FR4003 and 9010F can take a “snapshot” of the
whole band in just one second and, using a true built-in FFT capability,
perfectly show the complete band in all its details. Later on will be then
possible to make the QuasiPeak evaluation of all the frequencies of
interest after the measurements will been taken.
This feature is not only useful to greatly increase the productivity of the test
lab, but also to make better and more comprehensive analysis in case the
disturbance to be evaluated is somehow intermittent and with an irregular
repetition rate; its analysis with a traditional receiver could be hardly made
in a proper way (even if an FFT capability is available: this feature needs a
very comprehensive design), as irregular pulses could be lost during a
usual sweep.
To be noted that during the FFT analysis the PMM FR4003 and 9010F
make use of internal standard Gaussian filters, compliant to the standards,
while in other cases it uses filters mathematically modelled to the
perfection using a FIR technique.

General Information 1-9
1.11 Emission
measurements
All electric and electronic devices are potential generators of Electro-
Magnetic Interference (EMI).
The term EMI thus refers to the electromagnetic energy emitted by a
device which propagates itself along cables or through the air and couples
with other devices that are present in the surroundings.
These electromagnetic fields (conducted or radiated interferences) may
generate interfering currents and voltages into nearby equipment and
therefore can cause possible malfunctions.
In order to prevent and control such interferences there are nowadays a
number of national and international standards, like IEC and CISPR, which
specifies limits and methods of tests. Moreover, within the European Union
the application of several European Norms on Electromagnetic
Compatibility is enforced by law and therefore the commercialization and
use of all the electric and electronic equipment is subject to the
measurement of the EMC characteristics, which must be within well
defined limits.
The design approach adopted for the PMM FR4003 is that the instrument
shall be innovative, full compliant with all the relevant standards and at the
same time simple and reliable to use, to be the base building block for any
possible emission system to measure and evaluate any electric or
electronic device from the very first design stages to the final certification.
The need to precisely measure the conducted and radiated EMI noises
forces the equipment manufactures to use reliable equipment to verify the
limits imposed by the relevant standards and/or enforced by local rules.
In this view the PMM FR4003 Field Receiver is the ideal solution from
prototype debugging to final certification, as it fully meets all the
performance criteria dictated by these standards, although it remains
small, lightweight and very easy to use.
The PMM FR4003 Utility control software permits an immediate use of the
instrument without any training or special difficulties: the operator can
concentrate just on analyzing the measurement results.
Moreover, the PMM FR4003 software has also been designed for a fast
and easy installation on any PC with the Windows™operating system and
with at least one free USB (or Serial Port).
The device under test (DUT) must be installed according to the procedures
indicated in the constructor’s manual and normal operating conditions
respected.
Be sure not to overload PMM FR4003: the input signal should not
exceed the maximum level indicated in the main specifications in
chapter 1.
Also do not apply any signal to the rear RF output connector.

1-10 General Information
This page has been intentionally left blank
