Nassar AS2 User manual

SINCE 1973
ALTERNATING RELAY
MODEL AS2
www.nassarelectronics.com
The best solutions for
automation and protection
User Manual

www.nassarelectronics.com 2
AS2 ALTERNATING RELAY MANUAL
Features
ŸAlternating and Duplexing.
ŸIsolated 10A output contacts.
ŸIsolated input control, intrisically safe.
ŸIsolated input voltage.
ŸOmit switch.
ŸLEDs indicate operation.
ŸDual Voltage 120/220 VAC.
ŸSurface mounting or 35 mm DIN rail.
Duplex Alternating Relay AS2 is used in special
applications where the optimization of load usage is
required by equalizing the run time of two loads. A
control switch initiates this alternating action. A
control switch can be: a oat, manual, or pressure
switch, a timing relay, or any other isolated contact.
Each time the initiating switch is closed, the output
relay contacts will change state, thus alternating the
two loads. Two LED indicators show the status of each
output relay.
The AS2 relay can also be used where additional
ca pacit y is requi red in case of excess load
requirements. Not only it will alternate between two
lo ads, but it also al lows both lo ads to r un
simultaneously when the lead and lag switches are
closed, thus providing a way for both loads to operate
when running just one does not provide enough
capacity.
This version has a three-position selector switch that
allows the unit to alternate the two loads normally, or
omit the relay to one load or the other. By locking the
Alternating Relay to one load, the other load can be
removed for service without rewiring the rst load,
allowing continuous operation.
Description
Operation
Alternating: When the switch is in the “Normal”
position, alternating operation of Load B1 and Load B2
ocure each time the contact S1 LEAD is closed. The
LEDs indicate which load is operating.
Simultaneous operation: When the switch is in the
“Normal” position, both loads run simultaneously
when the S1 and S2 LAG switches are closed.
To operate only one load, place the switch on position
“Omit B1” in order to lock Load B2 or “Omit B2” in order
to lock Load B1.
T1 T 1
T2 T 2
T3 T 3
INPUT
220 VAC
INPUT
120 VAC
SUPPLY VOLTAGE
OUTPUT CONTACTS
B1
C
B2
B1
B2
L1 L2
B2
B1
ALTERNATING
RELAY
Model AS2
B1 C B2 S
A
T1 T3 TCT2
Om it B1
Om it B2
Normal
S1
S2
Control switch inputs are low voltage / low current and
are electronically isolated from the input voltage and
output contacts.
The dual input voltage 120/220 VAC and the output
relays are also isolated.
DO NOT APPLY VOLTAGE BETWEEN TERMINALS TC, A,
AND S SINCE THE ALTERNATING RELAY CAN BE
DAMAGED

AS2 ALTERNATING RELAY MANUAL
WARRANTY
These products are warranted to be free from defects in workmanship or material under normal service and use for a period of one
(1) year from date of manufacture. Nassar Electronics shall, at its option, repair or replace F.O.B. point of manufacture the portion of
the product found by Nassar Electronics to be defective. All replacements or repairs necessitated by inadequate maintenance,
normal wear and usage, unsuitable power sources or environmental conditions, accident, misuse, improper installation,
modification, repair, use of unauthorized replacement parts, storage or handling, or any other cause not the fault of Nassar
Electronics are not covered by this limited warranty, and shall be at the buyer's expense. All costs of dismantling, reinstallation and
freight, and the time and expenses shall be borne by the buyer.
LIMITATION OF REMEDY AND LIABILITY
NASSAR ELECTRONICS SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE. THE REMEDIES OF THE BUYER
SET FORTH IN THIS AGREEMENT ARE EXCLUSIVE. IN NO EVENT, REGARDLESS OF THE FORM OF THE CLAIM OR CAUSE OF ACTION
(WHETHER BASED IN CONTRACT, INFRINGEMENT, NEGLIGENCE, STRICT LIABILITY, OTHER TORT OR OTHERWISE), SHALL NASSAR
ELECTRONIC'S LIABILITY TO THE BUYER AND/OR ITS CUSTOMERS EXCEED THE PRICE TO THE BUYER OF THE SPECIFIC GOODS
MANUFACTURED OR SERVICES PROVIDED BY NASSAR ELECTRONICS GIVING RISE TO THE CLAIM OR CAUSE OF ACTION. THE BUYER
AGREES THAT IN NO EVENT SHALL NASSAR ELECTRONIC'S LIABILITY TO THE BUYER AND/OR ITS CUSTOMERS EXTEND TO INCLUDE
INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES. THE TERM “CONSEQUENTIAL DAMAGES” SHALL INCLUDE, BUT NOT BE
LIMITED TO, LOSS OF ANTICIPATED PROFITS, REVENUE OR USE AND COSTS INCURRED INCLUDING WITHOUT LIMITATION FOR
CAPITAL, FUEL AND POWER, AND CLAIMS OF THE BUYER'S CUSTOMERS.
Specifications
VOLTAGE ON TERMINALS A, S , TC
INSOLATION
INPUT SUPPLY VOLTAGE
POWER REQUIRED
CONTACT RATING
LIFE
STORAGE TEMPERATURE
OPERATION TEMPERATURE
WEIGHT
LED INDICATORS
5 V.D.C. max. 0.15 mA
2500 V Input to Output
120 / 220 V.A.C. ± 10 % , 50/60 Hz
3 Watts
10 Amp. Max. @ 220 V.A.C. Resistive load
7 6
Mechanical - 1 x 10 Electrical - 1 x 10
-4 to + 158 °F (-20 to + 70 °C)
14 to + 122 °F (-10 to + 50 °C)
11 Oz. (390 g)
2 operation indicators, one for each load
*Specifications subject to change without notice.
Nassar Electronics
J. M. Salas 124 Pte.
64290 Monterrey, N. L. México
email: [email protected]
Ph.+ 52 (81)-8351-0006
Dimensions
In. (mm)
1.77(45)
3
(77)
4.44(113)
4.68(119)
DANGER!
Potentially hazardous voltages are present. Electrical
shock can cause death or serious injury.
Installation should be done by qualified personnel
following all National, State & Local Codes.
BE SURE TO REMOVE ALL POWER SUPPLYING THIS
EQUIPMENT BEFORE CONNECTING OR DISCONNECTING
THE WIRING.
READ THE INSTRUCTIONS BEFORE INSTALLING OR
OPERATING THIS DEVICE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
