NI-9918

USER MANUAL AND SPECIFICATIONS
NI 9148
Ethernet Expansion Chassis for C Series Modules
This document describes how to connect the NI 9148 to a network and how to use the NI 9148
features. This document also contains specifications for the NI 9148.
Figure 1. NI 9148 Front Panel
NI 9148
POWER
USER FPGA1
STATUS
SAFE MODE
IP RESET
INPUT
19-30 V
20 W MAX
LINK
10/
100
V
C
NC
C
DO NOT SEPARATE CABLES WHEN ENERGIZED IN HAZARDOUS LOCATIONS
2
3
4
1
1. LEDs
2. RJ-45 Ethernet Port
3. Power Connector
4. DIP Switches
Safety Guidelines
Operate the NI 9148 only as described in this document.

Caution Do not operate the NI 9148 in a manner not specified in this document.
Product misuse can result in a hazard. You can compromise the safety protection
built into the product if the product is damaged in any way. If the product is
damaged, return it to NI for repair.
Safety Guidelines for Hazardous Locations
The NI 9148 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous
locations; Class I, Zone 2, AEx nA IIC T4 and Ex nA IIC T4 hazardous locations; and
nonhazardous locations only. Follow these guidelines if you are installing the NI 9148 in a
potentially explosive environment. Not following these guidelines may result in serious injury
or death.
Caution Do not disconnect the power supply wires and connectors from the
controller unless power has been switched off.
Caution Do not disconnect I/O-side wires or connectors unless power has been
switched off or the area is known to be nonhazardous.
Caution Do not remove modules unless power has been switched off or the area is
known to be nonhazardous.
Caution Substitution of components may impair suitability for Class I, Division 2.
Caution For Division 2 and Zone 2 applications, install the system in an enclosure
rated to at least IP54 as defined by IEC/EN 60079-15.
Special Conditions for Hazardous Locations Use in Europe and
Internationally
The NI 9148 has been evaluated as Ex nA IIC T4 Gc equipment under DEMKO Certificate
No. 07 ATEX 0626664X and is IECEx UL 14.0089X certified. Each device is marked II
3G and is suitable for use in Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤
Ta ≤ 70 °C.
Caution You must make sure that transient disturbances do not exceed 140% of
the rated voltage.
Caution The system shall only be used in an area of not more than Pollution
Degree 2, as defined in IEC 60664-1.
Caution The system shall be mounted in an ATEX/IECEx-certified enclosure with
a minimum ingress protection rating of at least IP54 as defined in IEC/EN 60079-15.
Caution The enclosure must have a door or cover accessible only by the use of a
tool.
2| ni.com | NI 9148 User Manual

Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits for
electromagnetic compatibility (EMC) stated in the product specifications. These requirements
and limits provide reasonable protection against harmful interference when the product is
operated in the intended operational electromagnetic environment.
This product is intended for use in industrial locations. However, harmful interference may
occur in some installations, when the product is connected to a peripheral device or test object,
or if the product is used in residential or commercial areas. To minimize interference with
radio and television reception and prevent unacceptable performance degradation, install and
use this product in strict accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved by National
Instruments could void your authority to operate it under your local regulatory rules.
Special Conditions for Marine Applications
Some products are Lloyd’s Register (LR) Type Approved for marine (shipboard) applications.
To verify Lloyd’s Register certification for a product, visit ni.com/certification and search for
the LR certificate, or look for the Lloyd’s Register mark on the product.
Caution In order to meet the EMC requirements for marine applications, install the
product in a shielded enclosure with shielded and/or filtered power and input/output
ports. In addition, take precautions when designing, selecting, and installing
measurement probes and cables to ensure that the desired EMC performance is
attained.
Unpacking the Kit
Caution To prevent electrostatic discharge (ESD) from damaging the device,
ground yourself using a grounding strap or by holding a grounded object, such as
your computer chassis.
1. Touch the antistatic package to a metal part of the computer chassis.
2. Remove the device from the package and inspect the device for loose components or any
other sign of damage.
Caution Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the device in the antistatic package when the device is not in use.
NI 9148 User Manual | © National Instruments | 3

What You Need to Install the NI 9148
• NI 9148 Ethernet Expansion Chassis
• NI-RIO Software DVD
• C Series I/O modules
• DIN rail mount kit (for DIN rail mounting only)
• Panel mount kit (for panel mounting only)
• Two M4 or number 8 flathead screws (for mounting the chassis without one of the listed
mounting kits)
• A number 2 Phillips screwdriver
• Power supply
• Ethernet cable
Note Visit ni.com/info and enter the Info Code rdsoftwareversion to
determine which software you need to use the NI 9148.
Mounting the Chassis
You can mount the chassis in any orientation on a 35 mm DIN rail or on a panel. Use the DIN
rail mounting method if you already have a DIN rail configuration or if you need to be able to
quickly remove the chassis. Use the panel mount method for high shock and vibration
applications.
Your installation must meet the following requirements for space and cabling clearance:
• Allow 25.4 mm (1 in.) on the top and the bottom of the chassis for air circulation.
• Allow 50.8 mm (2 in.) in front of modules for cabling clearance.
Figure 2. NI 9148 Bottom View with Dimensions
29 mm
(1.14 in.)
58.9 mm
(2.32 in.)
48.4 mm
(1.91 in.)
3.3 mm
(0.13 in.)
286.4 mm
(11.28 in.)
4| ni.com | NI 9148 User Manual

Figure 3. NI 9148 Front View with Dimensions
87.3 mm
(3.44 in.)
165.1 mm
(6.50 in.)
3.1 mm
(0.12 in.)
51.1 mm
(2.04 in.)
36.4 mm
(1.43 in.)
19 mm
(0.75 in.)
NI 9148
POWER
USER FPGA1
STATUS
SAFE MODE
IP RESET
INPUT
19-30 V
20 W MAX
LINK
10/
100
V
C
NC
C
Figure 4. NI 9148 Side View with Dimensions
3XM4X0.7
25 mm
(0.98 in.)
44 mm
(1.73 in.)
23.7 mm
(0.94 in.)
63.1 mm
(2.48 in.)
44.1 mm
(1.74 in.)
The following sections give instructions for the mounting methods. Before using any of these
mounting methods, record the serial number from the back of the chassis. You will be unable
to read the serial number after you have mounted the chassis.
Caution Make sure that no I/O modules are in the chassis before mounting it.
Mounting the Chassis on a Panel
You can use the NI 9905 panel mount kit to mount the NI 9148 on a flat surface. Complete the
following steps to mount the NI 9148 on a panel.
1. Fasten the chassis to the panel mount kit using a number 2 Phillips screwdriver and two
M4 × 25 screws. National Instruments provides these screws with the panel mount kit.
NI 9148 User Manual | © National Instruments | 5

You must use these screws because they are the correct depth and thread for the panel.
Tighten the screws to a maximum torque of 1.3 N · m (11.5 lb · in.).
Figure 5. Installing the Panel Mount Accessory on the NI 9148
Figure 6. Dimensions of NI 9148 with Panel Mount Accessory Installed
31.8 mm
(1.25 in.)
15.5 mm
(0.61 in.)
9.5 mm
(0.38 in.) 28.1 mm
(1.11 in.)
63.5 mm
(2.50 in.)
88.1 mm
(3.47 in.)
311.2 mm
(12.25 in.)
330.2 mm
(13.00 in.)
NI 9148
POWER
USER FPGA1
STATUS
SAFE MODE
IP RESET
INPUT
19-30 V
20 W MAX
LINK
10/
100
V
C
NC
C
2. Fasten the NI 9905 panel to the wall using the screwdriver and screws that are
appropriate for the wall surface. The maximum screw size is M4 or number 8.
Caution Make sure that no I/O modules are in the chassis before removing it
from the panel.
Mounting the Chassis on a DIN Rail
You can order the NI 9915 DIN rail mount kit to mount the NI 9148 on a DIN rail. You need
one clip for mounting the chassis on a standard 35 mm DIN rail. Complete the following steps
to mount the chassis on a DIN rail.
6| ni.com | NI 9148 User Manual

1. Fasten the DIN rail clip to the chassis using a number 2 Phillips screwdriver and two
M4 × 16 screws. NI provides these screws with the DIN rail mount kit.
Figure 7. Installing the DIN Rail Clip on the NI 9148
2. Insert one edge of the DIN rail into the deeper opening of the DIN rail clip.
Figure 8. One Edge of the DIN Rail Inserted in a Clip
3
2
1
1. DIN Rail Clip
2. DIN Rail
3. DIN Rail Spring
3. Press down firmly on the chassis to compress the spring until the clip locks in place on
the DIN rail.
Caution Make sure that no I/O modules are in the chassis before removing it
from the DIN rail.
NI 9148 User Manual | © National Instruments | 7

Installing C Series I/O Modules in the Chassis
The following figure shows the mechanical dimensions of C Series I/O modules.
Figure 9. C Series I/O Module, Front and Side View with Dimensions
88.1 mm
(3.47 in.)
70.7 mm
(2.78 in.)
22.9 mm
(0.9 in.)
1. Make sure that no I/O-side power is connected to the I/O module. If the system is in a
nonhazardous location, the chassis power can be on when you install I/O modules.
2. Align the I/O module with an I/O module slot in the chassis as shown in the following
figure. The module slots are labeled 1 to 8, left to right.
8| ni.com | NI 9148 User Manual

Figure 10. Installing an I/O Module in the Chassis
1
2
1. Insertion Groove
2. Latch
3. Squeeze the latches and insert the I/O module into the module slot.
4. Press firmly on the connector side of the I/O module until the latches lock the I/O module
into place.
5. Repeat these steps to install additional I/O modules.
Removing I/O Modules from the Chassis
Complete the following steps to remove a C Series I/O module from the chassis.
1. Make sure that no I/O-side power is connected to the I/O module.
2. Squeeze the latches on both sides of the module and pull the module out of the chassis.
Connecting the Chassis to a Network
Connect the chassis to an Ethernet network using Ethernet port 1 on the front panel. Use a
standard Category 5 (CAT-5) or better shielded, twisted-pair Ethernet cable to connect the
chassis to an Ethernet hub or a computer.
NI 9148 User Manual | © National Instruments | 9

Caution To prevent data loss and to maintain the integrity of your Ethernet
installation, do not use a cable longer than 100 m.
If you need to build your own cable, refer to the Cabling section for more information about
Ethernet cable wiring connections.
Note You will configure the IP settings as described in the Configuring IP Settings
section, after connecting power and powering the chassis on.
The host computer communicates with the chassis over a standard Ethernet connection. If the
host computer is on a network, you must configure the chassis on the same subnet as the host
computer. If neither the host computer nor the chassis is connected to a network, you can
connect the two directly using a crossover cable.
If you want to use the chassis on a subnet other than the one the host computer is on, first
connect the chassis on the same subnet as the host computer. Use DHCP to assign an IP
address or reassign a static IP address for the subnet where you want it to be and physically
move it to the other subnet.
Wiring Power to the Chassis
The NI 9148 requires an external power supply that meets the specifications in the Power
Requirements section.
The NI 9148 filters and regulates the supplied power and provides power for all of the I/O
modules. The NI 9148 has one layer of reverse-voltage protection. Complete the following
steps to connect a power supply to the chassis.
1. Ensure that the power supply is turned off.
2. Connect the positive lead of the power supply to the V terminal of the COMBICON
power connector shipped with the NI 9148, and tighten the terminal screw. The following
figure shows the terminal screws, which secure the wires in the screw terminals, and the
connector screws, which secure the power connector on the controller.
Figure 11. COMBICON Power Connector
C
NC
C
V
2
1
2
1. Terminal Screw
2. Connector Screws
3. Connect the negative lead of the power supply to the C terminal of the power connector
and tighten the terminal screw.
10 | ni.com | NI 9148 User Manual

4. Install the power connector on the front panel of the NI 9148 and tighten the connector
screws.
5. Turn on the power supply.
Powering On the NI 9148
When you apply power to the NI 9148, the chassis runs a power-on self test (POST). During
the POST, the Power and Status LEDs turn on. The Status LED turns off, indicating that the
POST is complete. If the LEDs do not behave in this way when the system powers on, refer to
the Understanding LED Indications section.
Chassis Startup Options
The following table lists the startup options available for the NI 9148. These options determine
how the chassis behaves when it starts up in various conditions. Use the RIO Device Setup
utility to select startup options. Access the RIO Device Setup utility by selecting Start»All
Programs»National Instruments»NI-RIO»RIO Device Setup.
Table 1. NI 9148 Reset Options
Startup Options Behavior
Do Not Autoload VI Does not load the FPGA bit stream from flash memory.
Autoload VI on device
powerup
Loads the FPGA bit stream from flash memory to the FPGA
when the chassis powers on.
Autoload VI on device reboot Loads the FPGA bit stream from flash to the FPGA when
you reboot the chassis either with or without cycling power.
Configuring IP Settings
When you power on the NI 9148 for the first time, it boots into safe mode because there is no
software installed on it. This section describes how to configure the IP settings and install
software on the chassis.
1. Launch MAX on the host computer and expand Remote Systems in the MAX
configuration tree. MAX lists the NI 9148 as the model name of the chassis followed by
the serial number, for example, NI9148-XXXXXXXX.
The chassis automatically attempts to connect to the network using DHCP. If DHCP is
not available, the chassis connects to the network with a link-local IP address with the
form 169.254.x.x. You must connect the chassis directly to the host computer to
configure it in this state.
2. Select the chassis under Remote Systems to see the Network Settings tab in the middle
pane of MAX.
3. Enter a name for the chassis in the Name field.
NI 9148 User Manual | © National Instruments | 11

4. Select settings for the chassis in the IP Settings section, then click Apply.
Note For information about configuring network settings, refer to the
Configuring Network Settings book of the MAX Remote Systems Help. In
MAX, click Help»Help Topics»Remote Systems. On the Contents tab,
browse to LabVIEW Real-Time Target Configuration»Configuring
Network Settings.
5. When you click Apply, you are prompted to reboot the chassis for the changes to take
effect. Click Yes. You can also reboot the chassis by right-clicking the name under
Remote Systems and selecting Reboot.
6. After rebooting, the chassis appears under Remote Systems with the assigned name.
Expand the chassis and select Software.
7. Click Add/Remove Software in the toolbar to launch the LabVIEW Real-Time Software
Wizard.
8. Install the Recommended Software Set that appears in the LabVIEW Real-Time Software
Wizard.
For more information about configuring the chassis in MAX, refer to the MAX Help. For
information about installing and using LabVIEW FPGA, refer to the LabVIEW FPGA Module
Release and Upgrade Notes.
Configuring DIP Switches
Both DIP switches are in the OFF position when the chassis is shipped from National
Instruments.
Figure 12. DIP Switches
1 2
OFF
SAFE MODE
IP RESET
SAFE MODE Switch
Safe mode is for troubleshooting, updating configuration, and installing software. Keep the
SAFE MODE switch in the OFF position during normal operation. If the switch is in the ON
position at startup, the NI 9148 launches only the essential services required for updating
configuration and installing software.
Push the SAFE MODE switch to the ON position if the software on the chassis is corrupted.
Even if the switch is not in the ON position, if there is no software installed on the chassis, the
chassis automatically boots into safe mode. The SAFE MODE switch must be in the ON
position to reformat the drive on the chassis. Refer to the Measurement & Automation
Explorer Help for more about installing software and reformatting the drive.
IP RESET Switch
Push the IP RESET switch to the ON position and reboot the chassis to reset the IP address
and other TCP/IP settings of the chassis to the factory defaults. Refer to the Troubleshooting
12 | ni.com | NI 9148 User Manual

Network Communication section for more information about resetting the IP address. You also
can push this switch to the ON position to unlock a chassis that was previously locked in
MAX.
Understanding LED Indications
The following figure shows the NI 9148 chassis LEDs.
Figure 13. NI 9148 LEDs
POWER
USER FPGA1
STATUS
POWER LED Indicators
The following table lists the POWER LED indicators.
Table 2. POWER LED Indicators
LED Color LED Pattern Indication
Green Solid The NI 9148 is powered on and the connected power supply is
adequate.
— Off The NI 9148 is powered off.
User LED
You can define the USER FPGA1 LED to meet the needs of your application. The following
table lists the USER FPGA1 LED indicators.
Table 3. User LEDs
LED LED Color Description
USER FPGA1 Green/Yellow Use the LabVIEW FPGA Module and NI-RIO Device
Drivers software to define the USER FPGA1 LED. Use the
USER FPGA1 LED to help debug your application or
retrieve application status. Refer to the LabVIEW Help for
information about programming this LED.
STATUS LED
The STATUS LED is off during normal operation. The NI 9148 indicates specific error
conditions by flashing the STATUS LED a certain number of times every few seconds, as
shown in the following table.
NI 9148 User Manual | © National Instruments | 13

Table 4. STATUS LED Indicators
Number of
Flashes
Indication
1 The chassis is unconfigured. Use MAX to configure the chassis. Refer to
the Measurement & Automation Explorer Help for information about
configuring the chassis.
2 The chassis has detected an error in its software. This usually occurs
when an attempt to upgrade the software is interrupted. Reinstall
software on the chassis. Refer to the Measurement & Automation
Explorer Help for information about installing software on the chassis.
3 The chassis is in safe mode because the SAFE MODE DIP switch is in
the ON position. Refer to the Configuring DIP Switches section for
information about the SAFE MODE DIP switch.
4 The software has crashed twice without rebooting or cycling power
between crashes. This usually occurs when software on the chassis is
corrupted. Reinstall software on the chassis. If the problem persists,
contact National Instruments.
Continuous
flashing or solid
The device may be configured for DHCP but unable to get an IP address
because of a problem with the DHCP server. Check the network
connection and try again. If the problem persists, contact National
Instruments.
Troubleshooting Network Communication
If the NI 9148 cannot communicate with the network, you can perform the following
troubleshooting steps.
1. Move the IP RESET switch to the ON position.
2. Disconnect and reconnect chassis power.
3. Move the IP RESET switch to the OFF position.
4. Configure the IP and other network settings in MAX.
Restoring the BIOS Network Settings
If you are unable to fix network communication with the network settings restored, you can
restore the BIOS network settings of the chassis. Refer to the Configuring IP Settings section
for information about the BIOS network settings for different chassis revisions. Complete the
following steps to restore the BIOS network settings of the chassis.
1. Move the IP RESET and SAFE MODE switches to the ON position.
2. Disconnect and reconnect chassis power.
14 | ni.com | NI 9148 User Manual

3. Move the IP RESET and SAFE MODE switches to the OFF position.
4. Configure the IP and other network settings in MAX.
Caution If the chassis is restored to the BIOS network settings, the LabVIEW
run-time engine does not load. You must reconfigure the network settings and
restart the chassis for the LabVIEW run-time engine to load.
NI 9148 Specifications
This document lists the specifications for the NI 9148 Ethernet Expansion Chassis. The
following specifications are typical for the -40 °C to 70 °C operating temperature range unless
otherwise noted.
Caution Do not operate the NI 9148 in a manner not specified in this document.
Product misuse can result in a hazard. You can compromise the safety protection
built into the product if the product is damaged in any way. If the product is
damaged, return it to NI for repair.
Network
Network interface 10BaseT and 100BaseTX Ethernet
Compatibility IEEE 802.3
Communication rates 10 Mbps, 100 Mbps, auto-negotiated
Maximum cabling distance 100 m/segment
Reconfigurable FPGA
Type Xilinx Spartan-3 2M
Number of logic cells 46,080
Available embedded RAM 720 kbits
Power Requirements
Voltage input range 19 V to 30 V
Maximum power input 20 W maximum
Maximum power consumption 20 W maximum
Physical Characteristics
If you need to clean the NI 9148, wipe it with a dry towel.
Tip For two-dimensional drawings and three-dimensional models of the NI 9148,
visit ni.com/dimensions and search by module number.
Weight (unloaded) 929 g (32.7 oz)
NI 9148 User Manual | © National Instruments | 15

Screw-terminal wiring
Gauge 0.2 mm 2 to 2.1 mm2 (24 AWG to 14 AWG)
copper conductor wire
Wire strip length 6 mm (0.24 in.) of insulation stripped from the
end
Temperature rating 85 °C
Torque for screw terminals 0.20 N · m to 0.25 N · m (1.8 lb · in. to
2.2 lb · in.)
Wires per screw terminal One wire per screw terminal
Connector securement
Securement type Screw flanges provided
Torque for screw flanges 0.3 N · m to 0.4 N · m (2.7 lb · in. to
3.5 lb · in.)
Safety Voltages
Connect only voltages that are within the following limits:
V terminal to C terminal 35 V maximum, Measurement Category I
Measurement Category I is for measurements performed on circuits not directly connected to
the electrical distribution system referred to as MAINS voltage. MAINS is a hazardous live
electrical supply system that powers equipment. This category is for measurements of voltages
from specially protected secondary circuits. Such voltage measurements include signal levels,
special equipment, limited-energy parts of equipment, circuits powered by regulated low-
voltage sources, and electronics.
Caution Do not connect the NI 9148 to signals or use for measurements within
Measurement Categories II, III, or IV.
Note Measurement Categories CAT I and CAT O are equivalent. These test and
measurement circuits are not intended for direct connection to the MAINS building
installations of Measurement Categories CAT II, CAT III, or CAT IV.
Safety and Hazardous Locations Standards
This product is designed to meet the requirements of the following electrical equipment safety
standards for measurement, control, and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
• EN 60079-0:2012, EN 60079-15:2010
• IEC 60079-0: Ed 6, IEC 60079-15; Ed 4
16 | ni.com | NI 9148 User Manual

• UL 60079-0; Ed 5, UL 60079-15; Ed 3
• CSA 60079-0:2011, CSA 60079-15:2012
Note For UL and other safety certifications, refer to the product label or the Online
Product Certification section.
Electromagnetic Compatibility
This product meets the requirements of the following EMC standards for sensitive electrical
equipment for measurement, control, and laboratory use:
• EN 61326-2-1 (IEC 61326-2-1): Class A emissions; Industrial immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions
Note In the United States (per FCC 47 CFR), Class A equipment is intended for
use in commercial, light-industrial, and heavy-industrial locations. In Europe,
Canada, Australia and New Zealand (per CISPR 11) Class A equipment is intended
for use only in heavy-industrial locations.
Note Group 1 equipment (per CISPR 11) is any industrial, scientific, or medical
equipment that does not intentionally generate radio frequency energy for the
treatment of material or inspection/analysis purposes.
Note For EMC declarations and certifications, and additional information, refer to
the Online Product Certification section.
CE Compliance
This product meets the essential requirements of applicable European Directives, as follows:
• 2014/35/EU; Low-Voltage Directive (safety)
• 2014/30/EU; Electromagnetic Compatibility Directive (EMC)
• 94/9/EC; Potentially Explosive Atmospheres (ATEX)
Online Product Certification
Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance
information. To obtain product certifications and the DoC for this product, visit ni.com/
certification, search by model number or product line, and click the appropriate link in the
Certification column.
NI 9148 User Manual | © National Instruments | 17

Hazardous Locations
U.S. (UL) Class I, Division 2, Groups A, B, C, D, T4;
Class I, Zone 2, AEx nA IIC T4
Canada (C-UL) Class I, Division 2, Groups A, B, C, D, T4;
Class I, Zone 2, Ex nA IIC T4
Europe (ATEX) and International (IECEx) Ex nA IIC T4 Gc
Environmental
Temperature (IEC 60068-2-1 and IEC 60068-2-2)
Operating -40 °C to 70 °C
Storage -40 °C to 85 °C
Caution Failure to follow the mounting instructions in the user manual can cause
temperature derating. Visit ni.com/info and enter Info Code criomounting for
more information about mounting configurations and temperature derating.
Ingress protection IP40
Operating humidity (IEC 60068-2-56) 10% RH to 90% RH, noncondensing
Storage humidity (IEC 60068-2-56) 5% RH to 95% RH, noncondensing
Pollution Degree (IEC 60664) 2
Maximum altitude 2,000 m
Indoor use only.1
Shock and Vibration
To meet these specifications, you must panel mount the chassis and affix ferrules to the ends of
the terminal wires.
Operating shock (IEC 60068-2-27) 30 g, 11 ms half sine; 50 g, 3 ms half sine;
18 shocks at 6 orientations
Operating vibration
Random (IEC 60068-2-64) 5 grms, 10 Hz to 500 Hz
Sinusoidal (IEC 60068-2-6) 5 g, 10 Hz to 500 Hz
Cabling
The following table shows the standard Ethernet cable wiring connections for both normal and
crossover cables.
1Use NI 9917 and NI 9918 industrial enclosures to protect the device in harsh, dirty, or wet
environments.
18 | ni.com | NI 9148 User Manual

Table 5. Ethernet Cable Wiring Connections
Pin Connector 1 Connector 2 (Normal) Connector 2 (Crossover)
1 white/orange white/orange white/green
2 orange orange green
3 white/green white/green white/orange
4 blue blue blue
5 white/blue white/blue white/blue
6 green green orange
7 white/brown white/brown white/brown
8 brown brown brown
Figure 14. Ethernet Connector Pinout
Connector 1 Connector 2
Pin 1 Pin 1 Pin 8Pin 8
Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible
manner. NI recognizes that eliminating certain hazardous substances from our products is
beneficial to the environment and to NI customers.
For additional environmental information, refer to the Minimize Our Environmental Impact
web page at ni.com/environment. This page contains the environmental regulations and
directives with which NI complies, as well as other environmental information not included in
this document.
NI 9148 User Manual | © National Instruments | 19
