Nauticam 37305 User manual

Current as of 2019-09-25
Instruction Manual for N100 to N120
35.5mm Port Adaptor II (for NA-A7IV)
PN# 37305
OREWORD
Thank you for your purchase of a NAUTICAM product.
At NAUTICAM, e pride ourselves in the ability to recognize the requirements
of professional as ell as amateur under ater photographers and fulfill them
through the innovative designs of our products. We strive to achieve a high
level of user-friendliness by allo ing stress-free installation and easy
operation of all important functions of the camera.
Please read this manual carefully before using the product, this ill maximize
its performance as ell as its lifetime.
W
ARRANTY
All NAUTICAM Products are arranted against any material and
manufacturing defects for t o years from the date of purchase for consumer
use. This arranty only applies to products purchased from authorized
NAUTICAM dealers and does not extend beyond the original retail purchaser.
To return your product for service, please contact your regional authorized
service center(s). Please note that this arranty only applies hen the product
is purchased in the territory here the service center is located.
NAUTICAM does not hold responsibility for damage, of any nature, to any
equipment used ith and/or placed ithin our products.
NAUTICAM accepts no liability for any loss of captured images or the inability
to capture images even if it is due to the malfunctioning of our products.
Unauthorized modifications and/or repairs of our products ill automatically
invalidate the arranty.
P
RE
-
CAUTIONS
· After installation of the port combo, please make sure the O-ring (s)
are free from debris and uneven surface issues.
· A ater-tight test ithout the camera inside the housing is highly
recommended after the changing of port and O-ring(s).
· Do not use lubricants from other brands ith the silicone rubber O-ring
on this housing, only use the lubricant provided by NAUTICAM.
· Discontinue use immediately should you notice any leakage.
· Do not open the product in a et or sandy environment. Protect the
interior from moisture and debris in order to prevent malfunction or
leakage.
· Defective products should be shipped to our distributors for service,
unauthorized disassembling and/or modifications could result in
malfunction or leakage.
I
DENTI ICATION O
P
ARTS
M
OUNT ON THE
H
OUSING
1. After install the camera body only into the housing, mount
the N100 to N120 35.5mm port adaptor II to the housing.
*Please refer to the housing manual for installing camera and
mounting port to the housing.
2. Mount the lens ( ith gears attached) on the camera.
Make sure that the knob on the adaptor is at its most
out ard position before mounting/ dismounting the lens.
The knob should be left at this
3. Lift the Port lock/ release latch on the other side of the
adaptor. Then Press and hold the RED port release safety
button, turn the port lock/release latch clock ise until it
stops.
4. Align the "I" mark on the adaptor ith the WHITE dot on
the port. Gently push the port to ards the adaptor until it
cannot go in any further.
Zoom/Focus Knob
Port alignment
index
Port alignment ‘’I’’ mark
Port
Release Safety Button
Port c
ap
Port Lock Lever

Current as of 2019-09-25
5. Turn the port anti-clock ise until the hite dot on the
adaptor aligns ith the hite dot on the port.
6. To lock the port in place, turn the port lock/release latch
anti-clock ise to the original position and then flip it do n.
7. Engage the focus gear on the lens by pushing the knob
in ards, then turn the knob both ays to check if the lens
is functioning
To unlock, reverse the above procedures.
*37305 N100 to N120 35.5mm Port Adaptor II (for NA-A7IV) is
compatible ith 37303 N100 to N120 35.5mm port adaptor ith
zoom/focus knob (for NA-A7II/A9/A7RIII), EXCEPT ith NA-A7IV.
S
PECI ICATIONS
Port Mount:
N120
Dimension:
DIA162.0×46.8
Compatible Housings:
Sony A Series Housings, such as NA
-
A7II/A9/A7RIII/A7IV
Remark: Nauticam supports only e-manuals. Please do nload corresponding
product manuals on Nauticam.com ebsite, or contact us for e-manuals
