Nav TV MFT F-CAM User manual

MFT F-CAM
Force Front Camera Module
NTV-KIT831
3950 NW 120th Ave, Coral Springs, FL 33065 TEL [phone] FAX [phone]
BHM
10/24/18
NTV-DOC298

BHM
10/24/18
NTV-DOC298
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of
its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is intended for off-road
use and passenger entertainment only.
2 | P a g e
USB cable (updates)
NTV-CAB009
Overview
The MFT F-CAM module uses OEM buttons (or wire triggers) to force an added front camera on the
OEM screen at any time, in any gear on SYNC 2 and SYNC 3 (8”) Ford infotainment systems. Forcing
OEM rear camera with this kit is also available if desired (SYNC 2 only). NOTE: This kit will NOT
program rear camera. This module is only intended for use with an existing rear camera (or one that
was added previously with NAV-TV KIT391, 392, 456 etc). NOTE: the OEM 360 surround-view camera
system is not supported with this kit.
Kit Content
DIFF Module Pin Out
MFT F-CAM
Module (KT3)
NTV-ASY256
Plug & Play T-Harness
NTV-HAR305
VSW Module (video switching)
NTV-ASY187
DIFF Module (Diff
Video Conversion)
NTV-ASY221

BHM
10/24/18
NTV-DOC298
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of
its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is intended for off-road
use and passenger entertainment only.
3 | P a g e
VSW I/O Connector Pin Out
VSW Power/Trigger Pin Out

BHM
10/24/18
NTV-DOC298
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of
its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is intended for off-road
use and passenger entertainment only.
4 | P a g e
MFT F-CAM Installation
1. Remove the 8” SYNC screen (radio). Connect the provided T-Harness (with all PCB’s connected)
between the OEM vehicle harness and the radio/screen assembly.
2. Turn the ignition ON and wait for the radio to boot fully. Test all functions for normal
functionality (including reverse camera –vehicle may have to be running).
3. Test front camera force activation before mounting camera and running
wires to kit. Press and HOLD the right-arrow button on the steering wheel (left
side) for 2 seconds –verify the screen switches (to black screen or camera
image if connected).
4. Run your front camera (or AUX video signal) to the dash location and connect
to an ACC 12v source for power (do not use a reverse signal). OUTPUT 1 (red)
from the MFT F-CAM provides 12v ACC out for convenience.
•See next page for information regarding forcing the OEM camera on at any time (requires
modifying factory LIN wire)
MFT F-CAM Module Pin Out
Pin #
Description
Color
1
12v Constant Power (+)
Yellow
2
INPUT 1 Force Rear Camera*
Red
3
INPUT 2 Force Front Camera
Blue
4
--NOT USED--
Pink
5
--NOT USED--
Gray
6
LIN (camera side)
Green
8
CAN HI (Radio Side)
Purple/Black
9
CAN HI (Vehicle Side)
White/Black
10
Ground (-)
Black
11
OUTPUT 1 ACC 12v Out
Orange
12
OUTPUT 2 Reverse 12v Out
Blue/White
13
OUTPUT 3 12v [out] follows front CAM trigger
White
14
Looped to pin 15
Yellow
15
Looped to pin 14
Yellow
16
LIN (BCM Side)
Orange/White
17
CAN LO (Radio Side)
Purple
18
CAN LO (Vehicle Side)
White
Wire side
*Forcing OEM rear camera is only
supported on SYNC 2 systems.

BHM
10/24/18
NTV-DOC298
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of
its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is intended for off-road
use and passenger entertainment only.
5 | P a g e
Forcing OEM rear camera (SYNC 2 ONLY)
5. Optional: If forced OEM reverse camera is desired, extend pins 6 & 16 (from the MFT F-CAM
module) to the passenger kick panel. Locate the BCM behind the passenger kick panel.
a. Locate the typically Blue connector (F150), remove from BCM (with ignition off)
b. Using a pick tool or small flathead, slide the inner connector out of the blue shell
c. Locate PIN 37 (LIN). This wire controls the OEM rear camera and the lines that turn with
the steering wheel. Cut the wire at PIN 37 in half leaving slack on both sides.
d. Connect your extended PIN 6 to the vehicle side of the cut wire.
e. Connect your extended PIN 16 to the BCM side of the cut wire.
A
B
C

BHM
10/24/18
NTV-DOC298
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of
its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is intended for off-road
use and passenger entertainment only.
6 | P a g e
MFT F-CAM Install Diagram Overview

BHM
10/24/18
NTV-DOC298
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of
its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is intended for off-road
use and passenger entertainment only.
7 | P a g e
MFT F-CAM Kit Operation
Toggling Cameras
This function allows the viewing of an auxiliary aftermarket camera at any time.
Additionally, if you send 12v (through a
toggle) to INPUT 1 (Red) or INPUT 2 (Blue), it
will force the rear or front camera
Forcing OEM rear camera is only supported on SYNC 2: 8” media screens. For this
feature, additional wiring must be completed to separate the LIN wire at the
same time (see page 5).
F150
Mustang
Press and HOLD (2 seconds)
To toggle front camera
Press and HOLD (2 seconds) to
toggle front camera
Press and HOLD (2 seconds)
To toggle rear camera
