NavAccess E-802 User manual

1
User Manual
of
NavAccess E-802

2
Contents
Preface 4
☆Getting Started 5
1. External Components 5
1.1 Front 5
1.2 Back 6
1.3 Left 7
1.4 Top 7
1.5 Right 8
1.6 Bottom 9
2. Powering the NavAccess E-802 9
2.1 Battery Installation 9
2.2 Power On 9
2.3 Power Off 10
3. Accessories 10
3.1 AC/DC Adapter 10
3.2 Automobile Adapter 11
3.3 Mounting Accessories of NavAccess E-802 11
3.4 Installing the Cradle into the Mount 12
3.5 Mounting Instruction 12
3.6 Attaching NavAccess E-802 to Cradle 12
3.7 Dismounting the NavAccess E802 and the Mount 12
3.8 Removing the Cradle from the Mount Arm 12
☆Connecting the NavAccess E-802 to a Computer 13
1. Software Installation 13
2. Connecting to a Computer 14
3. File Format Conversion Software 15
☆Operating Instructions 16
1. Introduction 16
1.1 The Stylus 16
1.2 External Controls 17
1.3 Soft Keyboard 18
1.4 Playlist Dialog Boxes 18
1.5 Popup Menus 19
1.6 Power 20
2. Main Menu 21
3. System Setup 22
3.1 Sound Setup 23
3.2 Backlight Setup 23

3
3.3 Memory 23
3.4 Time and Date 24
3.5 Power Management 24
3.6 System Information 24
3.7 Screen Calibration 25
4. Photos 25
4.1 Browser 25
4.2 Player 26
5. Movie 28
5.1 Browser 28
5.2 Player 29
6. eBooks 30
6.1 Browser 30
6.2 Reader 31
7. Music 31
7.1 Browser 31
7.2 Player 31
8. Backlight/Volume Overlays 32
☆GPS Navigation 33
1. Usage Instructions 33
2. GPS Issues 33
3. Preventing GPS Signal Problems 34
☆Troubleshooting 35
☆Preventative Measures 37
1. General Rules 37
2. Travel Instructions 37
3. Energy-Saving Tips 38
☆Safety Precautions 39
1. Recharging 39
2. Power Adapter 39
3. Battery 39
Technical Specifications 40
PC Requirements 41

4
Preface
Precautions
For safety, we strongly recommend that you never operate the GPS navigation system
while driving.
Furthermore, attention should be paid to the following basic precautions when operating the
NavAccess E-802:
●The SD card should be removed only after you press the power button to shut down the unit.
Never pull out the SD card while the E-802 is operating.
●Never press the power button repeatedly or continuously. Otherwise, the unit could be
damaged.
●Never expose the NavAccess E-802 to strong sunlight or heat for extended periods of time.
The acceptable operating environment of the NavAccess E-802 is 0~70℃and 0~90%
humidity. The acceptable storage environment is -10~80℃and 0~90% humidity.
Also, when operating the GPS functions of the NavAccess E-802, these additional precautions
apply:
●This system functions as a reference for navigation only, and should never be used for
accurate measurements of direction, distance, location, etc.
●For GPS satellite positioning to work, stay at same location until the positioning process is
complete. It is best to stay in an open, uncovered location. This positioning process may
need more than 10 minutes.
●When the system is located in a building or a tunnel, or is close to a high obstacle, the
system may temporarily be unable to provide positioning and navigation information.
●Any radio transmitters (including mobile phones) might interfere with GPS satellite signals,
thereby resulting in incorrect positioning information.
●If your car is equipped with sheathing paper or explosion-proof plaster, these features might
interfere with the quality of the GPS signal.
●Route planning advice is for reference only. Road properties (such as one-way status and
turn restrictions) may change according to local conditions, and therefore may not be
consistent with the information given by the E-802. You should comply with all local traffic
regulations and drive as local road conditions require. When the NavAccess E-802 is placed
inside a car, it should be positioned in place by means of a car tripod. Avoid positioning the
NavAccess E-802 in the positions below
Driver’s line-of-sight Any position where it is not fixed in place
A position where an airbag is located A position where an airbag expands

5
☆Getting Started
1. External Components
1.1 Front
2
3
4
57
6
1
6
No. Component Description
(1) Zoom Out Button Decreases size of selected item (photos and maps only).
(2) Zoom In Button Increases size of selected item (photos and maps only).
(3) Back Button Returns to the previous menu.
(4) Menu Button Returns to the main menu.
(5) Navigation Buttons Used to navigate through menus, lists and other items.
The OK button is used to confirm a selection.
(6) Built-In Speakers Plays sounds when headset is not present
(7) 3.5″Touchscreen
Displays menus, lists, photos, videos and more. The
screen is touch sensitive, and the included stylus may be
used to perform the functions of many of the buttons on
the unit.

6
1.2 Back
1
2
No. Component Description
(1) Lithium-Polymer Battery [See Note 1]
(2) Reset Key Forcibly resets the NavAccess E-802 to factory default
settings
[Note 1] Specification of battery:
Dimensions 62.3mm(L)×52.5mm(H)×7.5mm(W)
Capacity 1500mAh
Weight 35g
Input voltage DC 5V
Output voltage 2.75V ~ 4.2V
Operating temperature -20°C ~ +60°C
Storage temperature -20°C ~+60°C

7
1.3 Left
2
3
1
4
No. Component Description
(1) USB Interfaces
The larger (host) interface is used to connect the
E-802 to other USB equipment.
The smaller (slave) interface is used to connect
the E-802 to a PC.
(2) Adjustment Knob Adjusts sound volume and backlight brightness
(3) Hanging Hole Used to suspend the unit
(4) Earphone Jack Connects the unit to stereo headphones
1.4 Top
1 23
No. Component Description
(1) Stylus Used to control the unit through the touch screen
(2) SD Card Slot Used to expand the memory of the unit with an SD Card
[See Note 2]
(3) Power Button Used to power the unit on and off

8
[Note 2] The NavAccess E-802 can support an SD card with a maximum capacity of 1GB.
[Inserting an SD Card]
With the card facing forward, align the card with the slot to insert it in place.
When removing the SD card, first confirm that the SD card is idle and then press its top edge
slightly to release it. Finally pull out the card.
[Notice]
●Do not place anything other than an SD card in the SD Card Slot.
●When outside the E-802, the SD card should be repacked properly to avoid dust and
humidity.
1.5 Right
1
2
No. Component Description
(1) Hold Switch Locks the touchscreen and external buttons
(2) Power Jack Connects the unit to one of its power adapters [See Note 3]
[Note 3] Specification of the AC/DC power adapter
Dimensions 71mm(L)×51mm(W)×26mm(H)
Input voltage 100V～240V
Output voltage 5V
Net weight 150 g
Gross weight 172g
Storage temperature -20°C ~ +60°C
Operating temperature 0 ~ +40°C
Relative storage humidity 45 ~ 85%
Relative working humidity 45～85%

9
1.6 Bottom
1
No. Component Description
(1) Mounting Hole Not applicable in this model
2. Powering the NavAccess E-802
2.1 Battery Installation
When using NavAccess E-802, please ensure the battery has been installed correctly.
1 2 3 4
2.2 Power On
1
To power the NavAccess E-802, press the power button (1) and wait for approximately 5
seconds. The power button will glow green. This means the unit is ready to use.

10
2.3 Power Off
1
To shut down the NavAccess E-802, press the power button (1). The unit will shut down
immediately.
3. Accessories
3.1 AC/DC Adapter
The AC/DC Adapter is used to recharge the battery of the NavAccess E-802. To use the
adapter, plug the adapter into the Power Jack of the E-802. Then plug the adapter into a
standard 100V～240V AC power outlet, as shown in the figure below.
When charging, the Power Button glows orange. Once charging starts, leave the adapter
connected until the Power Button glows green. This means that the battery is fully charged. The
charging process may need several hours.

11
3.2 Automobile Adapter
[Notice] The Automobile Adapter should not be connected to a vehicle when the vehicle is
being started. Otherwise, the instantaneous current impact might damage the E-802.
The Automobile Adapter is used to recharge the battery of the NavAccess E-802 from the power
available in vehicle cigarette lighters. To use the adapter, plug the adapter into the Power Jack
of the E-802. Then plug the adapter into a standard 12VDC vehicle cigarette lighter.
When charging, the Power Button glows orange. Once charging starts, leave the adapter
connected until the Power Button glows green. This means that the battery is fully charged. The
charging process may need several hours.
3.3 Mounting Accessories of NavAccess E-802
It contains:
1) Suction cup mount with swivel and tilt arms
2) Swivel cradle with adjustable grip mechanism
3) A base plate.
1 23
Quick release tab
Base plate
Sockets arm nut

12
3.4 Installing the Cradle into the Mount
1. Align the adapter plate on one end of suction mount arm with the mounting shoe on the back
of the cradle
2. Insert and slide down the four clip buttons on the plate into the four slot holes on the shoe
until it snaps into place
3.5 Mounting Instruction:
1. For a tight grip, the mounting surface should be free of dirt and oil.
2. Place and press the suction cup against mount surface such as windshield or base plate,
while maintaining pressure turn the twist lock clockwise until the arm is secure.
3. Adjust the swivel/tilt arms by loosen the socket arm nuts and turning the swivel cradle to
obtain the best viewing and GPS reception position, then tighten the nuts to hold the arm
steady.
3.6 Attaching NavAccess E-802 to Cradle
1. Turn the swivel cradle into landscape position
2. Press the quick release tab to open up the grip arms
3. Place the device to back of cradle
4. Use hand to close both grip arms together until it grasp a good hold of the device
3.7 Dismounting the NavAccess E-802 and the Mount
1. To dismount the device from the cradle, press the quick release tab on the cradle.
2. Pull the device out of the grip arms once it is loosen the grasp.
3. To remove the suction cup from the mount surface, turn the twist lock counter-clockwise.
4. Pull on the suction release tab to break vacuum seal
3.8 Removing the Cradle from the Mount Arm
To remove the cradle from the mount arm, slide the adapter plate and the mounting shoe in a
different direction as it attached together. .
Caution: Be sure to check the adhesiveness of the suction mount every time using the
unit. Aging and temperature fluctuation inside a car will eventually loosen the seal of the suction
cup. A loosen seal could lead to the unit fall or come loose during a turn or rattle.
Windshield Mounting
See Mounting Instruction. Dashboard Mounting
See Mounting Instruction.
Note: The adhesive on back
of base plate is difficult to
r
e
m
o
v
e
o
n
ce
it i
s
m
ou
nt
ed
.

13
☆Connecting the NavAccess E-802 to a Computer
1. Software Installation
Before connecting the NavAccess E-802 to a computer, ensure that the ActiveSync program
has already been installed on the computer. If the ActiveSync program has already been
installed, proceed to the next section.
(1) Insert the enclosed software CD into a CD-ROM drive on the computer and run the
“ActiveSync 3.7” program. The system will extract the installation files. This may take a few
minutes.
(2) After extracting the setup files, the system will prepare for installation. This may also take a
few minutes.
(3) When the installation program runs, the following window will appear. Press the “Next”
button to continue.

14
(4) Press the “Next” button to continue.
(5) The installation program will update your system and the following window will display. This
may take a few minutes.
(6) The installation is complete.
2. Connecting to a Computer
(1) First, insert an SD card as shown below.
Correct insertion direction
of SD card

15
(2) Connect the included USB cable to a computer and the NavAccess E-802 as shown below.
(3) If this is the first time the NavAccess E-802 has been connected to the computer, the
computer may prompt for the installation of a device driver which is located in the
Driver/Software Folder of the included CD. If this happens, insert the included CD into a
CD-ROM drive on the computer. Then choose to install the driver from a directory and
choose the appropriate directory on the CD.
(4) When the appropriate drivers are installed and the E-802 is connected to the computer, the
ActiveSync program should run automatically and prompt for a link mode. The first option is
standard mode, which automatically synchronizes the information between the NavAccess
E-802 and the computer. The second option is user mode, which does not synchronize
information. In both modes, all media files may be copied as described in the next step.
(5) To copy media files manually, select “Explore” in ActiveSync or open “Mobile Device” in “My
Computer”. Locate the “SDMEM” folder and copy all items you want to be available on the
E-802 (such as Movie, Music, photos, e-books, etc.) to that folder.
3. File Format Conversion Software
In order for some files to play on the NavAccess E-802, they must be converted into formats that
the unit can read. To convert files, use the following steps.
(1) Refer to the “shareware reference” folder on the included CD to select a software
download website. Visit the site using a Web browser.
(2) Select and download conversion software Reference for the file formats you want to
convert (for example, converting RealMedia format to Movie or Music format).
(3) Install the downloaded software.
(4) Use the software to convert your files.
(5) Copy the converted files to the NavAccess E-802 or to SD card.
[Remark] The use of downloaded software may be restricted to a trial period. If you want to
use it for longer than this period, you should register or purchase the software.

16
Operating Instructions☆
1. Introduction
1.1 The Stylus
The included stylus functions a mouse. You can use it to click and write on the screen. This
stylus is designed in two sections. After taking the stylus out of its slot in the NavAccess E-802,
it can be extended for convenience. To store the stylus, collapse it if it was previously extended
and store it back in the slot.
The stylus can be used in the following ways:
●Click
Clicking the stylus once on an item opens or selects that item.
●Click and hold
Clicking the stylus on an item and holding it down opens a popup menu that displays all
functions that can be performed for the item (as shown in the figure below).
【Notice】To avoid damage to the screen, never use any sharp object to touch the screen. If the
tip of the stylus is damaged, discontinue using it and purchase a new stylus.

17
1.2 External Controls
SU
SD
SP
K1 K2
K3
K4
KU
KR
KE
KD
KL
Code Name Function
SU Adjustment Knob (up) Increases volume or backlight brightness
SD Adjustment Knob (down) Decreases volume or backlight brightness
SP Adjustment Knob (press) Changes between volume and brightness
adjustment
K1 Zoom Out
(Depends on current application) Usually
de-magnifies
K2 Zoom In
(Depends on current application) Usually
magnifies
K3 Back Returns to the previous menu
K4 Menu Returns to the main menu
KL Left
(Depends on current application) Usually moves
left
KR Right
(Depends on current application) Usually moves
right
KU Up
(Depends on current application) Usually moves
up
KD Down
(Depends on current application) Usually moves
down
KE OK
(Depends on current application) Usually
selects/opens
In the remainder of this manual, the term “navigation buttons” refers to the keys labeled KU, KD,
KL, KR and KE in the figure above. These keys may be used for up, down, left and right
movement and selection. They are available for single-handed operation.
Holding down a directional navigation button will cause movement to continue in that direction.

18
1.3 Soft Keyboard
When an action requires text to be entered (such as with renaming a file or adding a new
category) the following screen will appear. You may use the stylus or navigation buttons to
“type” the letters, numbers or symbols needed.
1.4 Playlist Dialog Boxes
When editing an item in a playlist, the following screen will appear. This screen contains two
text fields. The first contains the name of the item as it appears in the playlist and the second
contains the path to the file in the internal filesystem. In general, you should only change the
first field unless you are sure you know what you are doing. Text entry for both fields is
performed in the same way as outlined in the previous section.

19
1.5 Popup Menus
Many of the functions of the NavAccess E-802 have file-browsing capabilities. On a browsing
screen, pressing and holding the stylus on an item will bring up a popup menu listing all of the
operations that can be performed on the file. These functions may include: Copy, Cut, Delete,
Paste and Rename.
Use the popup menus as follows:
●Click and hold the stylus on an item to activate the popup menu.
●Click the appropriate item in the menu to perform the function you want.
●Click the icon at the top right corner of the menu to close it.
Popup menu
To paste a copied
or cut item, press
and hold the pen
in an empty slot
after the end of
the file list. In the
resulting popup
menu, choose
“paste”.

20
Pasted file
1.6 Power
Notes on power in the E-802:
Software data is saved to FLASH memory in real time to avoid data loss when the unit is
powered off.
The clock on the NavAccess E-802 requires power to continue operating. This power
comes from the battery or a power adapter, even when the rest of the unit is powered off. If
no power source is available (because the unit is not connected to an adapter and the
battery is missing or completely discharged) the clock will pause, possibly resulting in
significant time errors.
A fully charged battery can work 3-5hrs. However, the actual time will vary with conditions.
Some operations (such as playing an Movie file) may drain the battery more quickly.
When a battery has insufficient charge remaining, the screen will display a low battery
message. When this happens, save any unsaved data immediately, and then connect the
unit to a power adapter to recharge. If the battery is not recharged, the NavAccess E-802 will
enter a protection state automatically when the battery charge falls below an acceptable
lower limit. If this happens, the system can only be powered on if it is connected to a power
adapter to recharge. Note that if the unit enters the protection state, data stored in RAM
might be lost. However, setup or other data saved in FLASH memory should remain intact.
