Jimi JM01 User manual

User Manual

Please read this manual carefully before attempting installation and online activation.
Pictures are for indication and illustration purposes only
1 Accessories
Pictures are for indication and illustration purposes only.
NOTE: After opening the packing box, please check if the accessories are complete. If there is anything missing,
please contact your distributor.
2Interface descriptions

3LED status indicator and wiring
3.1 Red LED（power/working status indicator）
Status
Meaning
Quick flashing
Low battery
Slow flashing
Fully charged
Continuously in bright
Charging
Continuously in dark
No battery/troubleshoot
3.2 Blue LED(GPS signal indicator）
Status
Meaning
Quick flashing
Searching GPS signal
Slow flashing
GPS signal has successfully
Continuously in dark
GPS stops working
3.3 Green LED(GSM signal indicator）
Status
Meaning
Quick flashing
GSM initialization
Slow flashing
GPRS online
Continuously in dark
No GSM signal or no SIM card installed
3.4 Armed
When red/green/blue 3 LED lights are flashing twice in cycle, it means the terminal is armed.

3.5 Function of the wires
No.
Function
Color
Function Illustration
1
V+
Red
Positive pole
2
V-
Black
Negative pole
3
ACC
Orange
ACC on
4
Relay
Yellow
Relay controlled wire
5
TX
Green
Send data / for backup
6
RX
Blue
Receive data / for backup
7
GND
Purple
Ground wire
4Installation
4.1 Wiring
1：Red 2：Black 3：Orange 4：Yellow 5：Green 6：Blue 7：Purple

(1) Use multi-meter to find out the negative pole of the battery.
(2) Use multi-meter to find out the ACC wire. Method: Use the red pen to connect with the ACC wire while the
black pen connects with the ground wire. In this condition, when the ignition lock is off, the voltage is 0; when the
ignition lock is turned on, the multi-meter will show the voltage.
(3) The red line (positive pole) of the terminal cable should be connected to the positive pole of the battery.
(4) Follow the picture above to connect the wires.
(5) When the terminal is connected to external power, insert the SIM and the red indicator (power indicator)
should be normally on. When the ignition lock is turned off, the red indicator should be flashing slowly.
(6) The yellow wire of the relay control line should be connected to 86 as the picture shows.
5Power ON/OFF
5.1 Power ON
The terminal will be automatically on when you insert the SIM card. The battery will connect the internal wires
together in the terminal and the external power supply will start providing power to the device and also charging

the battery.
5.2 GSM&GPS signal searching
After the power is on, it will start searching the GSM and GPS signal. During this period, the green indicator
(GSM indicator) will be flashing while the blue indicator will be flashing quickly. When the blue indicator is
flashing slowly, it means GPS has located.
5.3 Power OFF
Pull out the SIM card, the terminal will be off.
6Parameters setting
6.1 Set APN
Please send SMS command to the number of terminal so as to set up the APN parameter. The terminal will reply
“OK” automatically after setting successfully.
Send SMS command: APN,APN’s name#
e.g: APN, internet#
NOTE: The APN of some countries have user name and password, you may need to send SMS command as
follows:
Send SMS command: APN,APN’s name, user name, password#
e.g: APN, internet, CLIENTE, AMENA#
6.2 Set DNS
Please send SMS command to the number of terminal so as to set up the DNS parameter. The terminal will reply
“OK” automatically after setting successfully.
Send SMS command: SERVER,1,DNS,Port,0#
e.g. SERVER,1,JM01.szdatasource.com,8841,0#
6.3 Set SOS Number
(1) Add SOS number Via SMS command
Send SMS command: SOS, A,number1,number2,number3 #(A means add number).
You can set 3 SOS numbers in maximum. If set successfully, the terminal will reply “ok”.
e.g. SOS,A, 13510****60,135116****6,136126****8# (set all 3 SOS numbers)
SOS,A, 13510****60# (set the first SOS number)
SOS,A, ,135116****6# (set the second SOS number)
SOS,A, , ,136126****8# (set the third SOS number)

(2) Delete SOS Numbers
Send SMS command: SOS, D,1,2,3# (D means delete SOS number)
e.g. SOS, D,1# means delete the first number
SOS, D,3# means delete the third number
If you do not know the sequence number, you can also delete the number by SMS command like this: SOS, D,
number#
e.g. SOS, D, 135278****0# means delete this SOS number directly.
It will reply “OK” if the number is deleted successfully.
(3) Add SOS numbers via platform
You can set SOS number via the platform after activating the terminal.
6.4 Set Center Number
Send SMS command from the SOS number to set the Center Number.
(1) Add Center Number:
Send SMS command: CENTER, A, number#
e.g. CENTER,A, 135278****0#
(2) Delete Center Number
Send SMS command :CENTER,D, number#
e.g. CENTER,D, 135278****0#
NOTE: Center Number can be set ONLY by SOS numbers.
6.5 Check current parameters
Send SMS command: PARAM#
The terminal will reply messages including: IMEI number, GPRS upload interval, time interval that GPS is
activated when ACC is off, SOS numbers, center number, sensor alarm interval, defense time and time zone.
6.6 Set GPS data upload interval
(1) Upload by interval
The default upload interval is 20 seconds, which means every 20 seconds the terminal will upload its location data
to the platform. The interval can be set by sending SMS command: TIMER,T1,T2# (5≤T≤18000 seconds)
e.g. TIMER,20,30#
It means when ACC is on, GPS data upload interval is 20 seconds; when ACC is off, GPS data upload interval is
30 seconds.
(2) Upload by distance
Send SMS command: DISTANCE,D# (100≤D≤10000 meters)
e.g. DISTANCE,300#

It means for every 300 meters, the terminal will upload GPS data to platform.
NOTE: if the upload interval is short, the GPRS current will add up. Please set the suitable upload interval.
6.7 Corners upload (ON as default)
The terminal will upload GPS data to the platform when the vehicle is turning (the turning angle reaches the
pre-set value).
NOTE: if the speed is too low during turning, the GPS data will be not able to upload to the platform.
Send SMS command: ANGLEREP,OFF# to turn it off.
6.8 Arm time interval
When the vehicle is turned off (ACC low) and stays off in 3 minutes(pre-set), the terminal will enter arm status.
During this status, if the terminal detects 6 vibrations (default) and the vehicle still stays off (ACC off) in 30
seconds, it will activate vibration alarm.
Send SMS command: DEFENSE,T# (1≤T≤60 minutes)
e.g. DEFENSE,15#
It means after 15 minutes the vehicle is turned off, the terminal will enter defense mode.
6.9 Reboot the terminal
Send SMS command: RESET#
When the terminal receives the command, it will reboot in 20 seconds.
7Operation
7.1 Check location
(1) Ask for coordinates
Send SMS command from SOS number to the terminal: WHERE#
Only SOS number can apply for replying longitude and latitude from the terminal. If GPS is located, it will reply
latest longitude and latitude information.
e.g. Lat:N22.571285,Lon:E113.877115,Course:42.20,Speed:0.0740,DateTime:10-11-23 22:28
If GPS is not located at all, the terminal will reply: “NO DATA!”
(2)Ask for Google link
Send SMS command from SOS number to the terminal: URL#
If GPS is located, it will reply google link of latest longitude and latitude.
e.g. Google link reply
<DateTime:10-11-23 23:42:51> http://maps. google.com/maps?q=N22.571490,E113.877103

(3) Check platform
The terminal will send position information to the platform server timely. Users can check the position on the
platform.
The platform website: www.cootrack.com
Please contact your supplier for the login methods and operations.
7.2 Vibration Alarm (ON as default)
When the vehicle is turned off (ACC low) and stays off for 3 minutes (pre-set), the terminal will enter arm status.
During this time, if the terminal detects 6 times vibrations (default) and the vehicle still stays off (ACC off) in 30
seconds, it will activate vibration alarm. The terminal will upload longitude and latitude data to the platform. Then
the platform will send the google link to SOS number.
e.g. GPS information link:
“vibration alarm: <DateTime:10-11-23 23:42:51> http://maps. google.com/maps?q=N22.571490,E113.877103”
If you do not want to receive vibration alarm messages, send SMS command: SENALM,OFF# to turn it off.
7.3 Cable cut-off Alarm (ON as default)
When the terminal cable is cut off, the cable cut-off alarm will be activated. The terminal will send the alarm to
the platform and upload longitude and latitude data. And the platform will send google link to SOS number.
e.g. GPS information link:
“Cut Power! <DateTime:10-11-23 23:42:51> http://maps. google.com/maps?q=N22.571490,E113.877103”
Send SMS command: POWERALM,OFF# to turn it off.
7.4 Low Battery Alarm (ON as default)
When the battery is low, the terminal will send SMS to SOS numbers and upload alarm information to platform.
Send SMS command: BATALM,OFF# to turn off the alarm.
7.5 Moving alarm (OFF as default)
Send SMS command: MOVING,ON,R# (100≤R≤1000 meters, 300 is recommended)
In the situation where ACC becomes low, if the vehicle is moved over 300 meters (pre-set) from the latest location,
the terminal will send moving alarm to the platform. SOS number will receive moving alarm message.
e.g.
Attention! The vehicle is moved.
<DateTime:10-11-2323:42:51>http://maps.google.com/maps?q=N22.571490,E113.877103
Send SMS command: MOVING,OFF# to turn off the alarm

7.6 Petrol cut-off
(1) Cut-off petrol
When the vehicle was stolen, you can cut off the petrol on the platform in the situation where the speed is under
20km/h. Platform password is needed. Or you can send SMS command to the device.
Send SMS command: RELAY,1# to cut off petrol.
(2) Restore petrol
You can restore petrol on the platform. Platform password is needed.
Send SMS command: RELAY,0# to restore petrol.
NOTE: Petrol cut-off and restore commands can be executed by the center number ONLY.
8Trouble shooting
If there is any problem while operating the terminal, please refer to the following table, or contact your supplier.
Common problems
Causes
Solution
Bad reception
Near the tall building or in the basement
Change to a place with good signal
The terminal cannot be
turned on
No battery power
Change a new battery
Cannot connect to the network
SIM card is not inserted correctly
Check the SIM card
The sheet mental of SIM card is
dusty
Wipe it clean
Invalid SIM card
Contact your SIM card operator
Out of GSM service area
Move back to the GSM service
covered area.
Weak signal
Try again in a strong signal area
Cannot charge
Voltage is out of charging range of the
charger
Change to the proper voltage
Poor contact
Check if the plug is in

Cannot check
address information
GPRS function is not activated
Please contact the SIM card operator
to activate GPRS
Cannot get the position data
①restart the terminal
②contact with your supplier
It is not a SOS number
set SOS number
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Warning Statements
This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other transmitter.
