INSTALLATION/OWNER'S MANUAL
8" Tower Woofer
NT308W

NT308W INSTALLATION
2
Preparation/Installation
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Use extreme caution when drilling holes to avoid damaging fuel lines, hydraulic lines
or existing wiring.
• If additional wiring is required, we recommend that you run all wires prior to mounting
your speaker in place.
• Use the highest quality connectors for a reliable installation and to minimize signal and
power loss.
• Use caution before you drill or cut! Be careful not to cut or drill into gas tanks, fuel lines,
hydraulic lines, vacuum lines or electrical wiring.
• Avoid running wires over, near, or through sharp edged surfaces. We suggest you also
use rubber grommets to protect any wires routed through metal.
Dimensions
65mm
2.5"
250.8mm
9.8"
230.5mm
9"
303mm
11.9"

NT308W INSTALLATION
3
Clamp Mounting
The included clamping system is designed to support structures that utilize round tubing.
Oval tubing and flat structures will not work with this clamp. The clamp can be used
with tube diameters from 1.5” up to 2.75”. Separate bushing sets for all tube sizes at 1/8”
increments are included. Refer to the table below to determine
optimal configuration.
T
ube
Di a m ete r
T
ube
Cir c u m fe r en c e
Cl
a
m
p
T
op
Bu s h i ng
Botto
m
Bu s h i ng
1.54 .71A 1.50 1.50
1.6255 .10A 1.63 1.63
1.75 5.50 A1 .751 .75
1.8755 .89A none 1.88
26 .28B 2.00 2.00
2.1256 .68B 2.13 2.13
2.25 7.07 B2 .252 .25
2.375 7.46 B2 .382 .38
2.57 .85B 2.50 2.50
2.6258 .25B 2.68 2.68
2.75 8.64 Bn onen one

NT308W INSTALLATION
4
Safety Cable
The included safety cable is pre-installed on the unit.
Mounting Bracket Rotation
The mounting bracket rotates 360 degrees, allowing the speaker to rotate in any direction.
Step 1
Loosen screw using the supplied tool.
Step 2
Rotate speaker to desired direction, then tighten screw to lock in place.
Step 3
Attach top bracket to bottom bracket using the four bolts. Make sure brackets are
tightened all the way so there is no movement.
1. 2. 3.

NT308W INSTALLATION
5
Connection Descriptions
SPEAKER CONNECTION (PIGTAIL)
• Tower woofers will connect to BMA500M using waterproof cables supplied with the
amplifier, use caution when screwing/tightening waterproof connector as to not strip/
break thread or damage gasket.
WARNING: ONLY USE THIS PRODUCT WITH THE BMA500M, USE WITH ANY OTHER
AFTERMARKET AMPLIFIER WILL RESULT IN DAMAGE AND WILL VOID WARRANTY.
INPUT FROM
SOURCE UNIT
NT308W
BMA500M
Ground(-)
Acc(+12V)
REQUIRES D2D/A2A
(SOLD SEPARATELY)
CONNECTING CABLE
OUTPUT CAN CONNECT TO ANY MODEL
(NS14A/NS27A/NS35A,NT65AT,BMA500M)
INPUT
OUTPUT

NT308W INSTALLATION
6
Limited One Year Warranty
This warranty gives you specific legal
rights. You may also have other rights
which vary from state to state.
arrants this product to the
original purchaser to be free from defects
in material and workmanship for a period
of one year from the date of the original
purchase.
grees, at our option, during the
warranty period,
to repair any defect in material or
workmanshiporto furnish an equal
new, renewedor comparable product
(whichever is deemed necessary)in
exchange without charges, subjectto
verificationof the defector malfunction and
proofof the date of purchase. Subsequent
replacement products are warranted for the
balance of the original warranty period.
Who is covered? This warranty is extended
to the original retail purchaser for products
purchased from an authorized NavAtlas
dealer and used in the U.S.A
What is covered? This warranty covers all
defects in material and workmanshipin this
product. The following are not covered:
software, installation/removal costs,
damage resulting from accident, misuse,
abuse, neglect, product modification,
improper installation, incorrect line voltage,
unauthorized repair or failure
to follow instructions supplied with the
product, or damage occurring during return
shipmentof the product.
What to do?
1. Before you call for service, check the
troubleshooting guide in your owner’s
manual. A slight adjustment of any
custom controls may save youaservice
call.
2. If you require service during the
warranty period, you must carefully
pack the product (preferably in the
original package) and ship it by prepaid
transportation with a copy of the original
receipt from the retailer to an
authorized service center.
3. Please describe your problem in
writing and include your name, a
return UPS shipping address (P.O. Box
not acceptable), andadaytime phone
number with your shipment.
4. For more information and for the
location of the nearest authorized
service center please contact us by one
of the following methods:
•Callus
1-562-946-7471
•E-mail us at
Exclusion of Certain Damages: This
warranty is exclusive and in lieu of any
and all other warranties, expressed or
implied, including without limitation the
implied warranties of merchantability and
fitness for a particular purpose and any
obligation, liability, right, claim or remedy
in contract or tort, whether or not arising
from the company’s negligence, actual
or imputed. No person or representative
is authorized to assume for the company
any other liability in connection with the
sale of this product. In no event shall the
company be liable for indirect, incidental or
consequential damages.
Factory defects include:
· MID/Tweeter not playing or distorting
· Glue/adhesive separating or not holding
correctly
· Tinsel leads not attached/soldered
correctly
· LED not working out-of-box
EXCHANGE ONLY ON FACTORY DEFECTS, PHYSICAL
DAMAGE IS NOT COVERED BY WARRANTY.

NT308W INSTALLATION
7
Specifications
IMPP black
(Injection molded polypropylene )
Rubber
8"
200W
400W
85dB
45Hz - 500Hz
4 Ohms
UV-resistant ABS plastic
Woofer type
Woofer surround
Woofer size
RMS Power
Peak Power
Sensitivity
Frequency response
Impedance
Enclosure type
Design and specifications subject to change without notice.

Support Line: 1-562-946-7471
9AM-5PM PST Monday-Friday
www.navatlas.com
All rights reserved.
NSA0918-V01
