Naxa NPB-256 User manual

32
12
31
4
678910
11 12 13
15
16
17
18 20 22
23
24
25
14
19 21
26 28 527
LOCATION OF CONTROLS
1. SPEAKERS
2. USB PORT
3. LCD DISPLAY
4. SD/MMC CARD SLOT
5. AC SOCKET
6. AUX IN JACK
7. FUNCTION SWITCH
8. FM TELESCOPIC ANTENNA
9. CD DOOR
10. HANDLE
11. FM ST. INDICATOR
12. BAND SWITCH
13. MODE BUTTON
14. TUNING CONTROL
15. VOLUME CONTROL
16. USB/CARD BUTTON
17. POWER INDICATOR
18. CD DOOR OPEN BUTTON
19. CD DOOR PUSH CLOSE AREA
20. STOP BUTTON
21. PLAY/PAUSE BUTTON
22. +10/ALBUM BUTTON
23. SKIP/SEARCH DOWN BUTTON
24. EQ/PROGRAM BUTTON
25. SKIP/SEARCH UP BUTTON
26. BATTERY COMPARTMENT
27. AC VOLTAGE SELECTOR
(OPTIONAL)
28. MAINS POWER SWITCH
(OPTIONAL)
POWER SUPPLY
BATTERY OPERATION
NOTE:
AC OPERATION
NOTE:
q
q
1. Remove the battery compartment cover gently.
2. Install 8 x 'C' size batteries (UM-2 or equivalent) taking care that the correct polarities
are observed.
3. Replace the battery compartment cover.
The AC line cord must be removed for battery operation.
To avoid damage which may result from leaking batteries, remove the batteries
when they become weak or when the unit is not to be used for long period of time.
Insert one end of the AC power cord to the socket located at the rear of the player, and
the other end to the wall outlet.
Please be sure the AC Voltage Selector is switched to your local voltage (for
dual voltage version) (optional).
=
=

PLAY THE RADIO
NOTES:
HANDLE AND MAINTAIN A COMPACT DISC.
1. Slide the FUNCTION switch to the RADIO position, the POWER Indicator will light up.
2. Select the desired band with the BAND switch.
3. Tune to the desired station by rotating the TUNING control. (Move the control back and forth
until you get the strongest clearest sound).
4. The built-in AM (MW) antenna and external FM TELESCOPIC ANTENNAare directional.
When receiving an FM broadcast, fully extend the TELESCOPIC ANTENNA and
position for the best reception.
For AM (MW) broadcasts, rotate the whole set until the best reception is heard.
5. Adjust the volume level to a comfortable listening level.
6. To turn off the radio, slide the FUNCTION switch to the OFF position.
If a particular FM (STEREO) station is weak, or you hear too much background
noise, try moving the position of the band selector switch to the FM (MONO)
position. This can often result in a much clearer reception.
When the band selector switch is set to FM STEREO and a stereo broadcast is
being received, the FM STEREO indicator will be lit.
Follow the instructions below to handle and maintain your disc in order
that long time and trouble free performance can possibly be obtained:
Ensure not to caress the rain bow side of the disc; handle the
disc by the edge.
Long time exposure to sunshine, high temperatures and
humidity will damage the disc. Keep the storage area clean.
Avoid sticking labels on both sides of a disc. Writing with pointed
articles on the disc should be strictly avoided.
Clean the disc wiping the centre and then working out to the
edge with a dry & soft cloth or a disc brush. Avoid any cleansing
lotion or chemical eradicator.
Store them in their cases when they are not to be used.
=
=
=
=
=
=
=
=
=
LOAD A DISC
NOTE:
NOTE:
REMOVE A DISC
1. Slide the FUNCTION switch to the CD/MP3 position.
If slide the FUNCTION switch to CD/MP3 position, please make sure other
external devices should be disconnected.
2. Open the CD door.
3. Insert a disc with the label side facing upward (if the disc is upside down, the display will
show "NO DISC").
4. Close the CD door by hand.
Never touch the laser lens inside the CD compartment. If it ever gets dirty, clean it
with a CD cleaner disc.
1. Make sure the CD/MP3 disc is not playing. If it is, press the CD STOP button.
2. Open the CD door.
3. Gently remove the disc.
4. Close the CD door by hand.
5. Replace the disc in its protective storage box.
HANDLE DISC ONLY AS SHOWN
CLEAN FROM CENTER TO EDGE
DO NOT STORE NEAR HEAT
PLAY A CD
EQ SELECTION
SKIP TRACKS AND SEARCH FOR A SPECIFIC POINT TO PLAY
PROGRAMMED PLAY
REPEAT A SINGLE TRACK
1. Make sure the power is connected, slide the FUNCTION switch to CD/MP3 position,
POWER indicator will light.
2. Load a disc into the CD compartment. Close the CD door, the disc will begin to spin.
3. Adjust the VOLUME to the desired volume level.
4. To stop playing temporarily, press the PLAY/PAUSE button.
The elapsed time of the current track flashes and an icon of "PAUSE" appears on the
bottom of the LCD to indicate the player is in pause mode.
Resume normal play by pressing PLAY/PAUSE button again.
5. To stop playing, press the STOP button. The total tracks' number and whole playing time
with an icon "STOP" on the bottom will be shown on the display.
6. To turn off the player, slide the FUNCTION switch to OFF position.
Press EQ/Program button continuously during disc playback mode to select EQ sound
effects among NORMAL, POP, ROCK, CLASSIC, JAZZ and BASS.
1. Press once the SKIP/SEARCH up button in music play to skip to the next track. To skip
to a specific track ahead, press this button several times.
2. Press once the SKIP/SEARCH down button in music play to skip to last track. To skip to
a specific track at back, press this button several times.
3. Press +10/ALBUM button once in play to skip to the track 10 tracks ahead, twice to skip
to the track 20 tracks ahead. You can reach the last track of the disc using this button.
4. Hold the SKIP/SEARCH up button in music play to search forward at quick rate for a
Specific point to play.
5. Hold the SKIP/SEARCH down button in music play to search backward at quick rate for
a specific point to play.
Programmed play is that tracks on the disc can be edited for playback in a preferred order
with the use of PROGRAM button.
In CD stop mode, press EQ/PROGRAM button once, "PROG" shows in the LCD with a
flickering track number and the program sequence indication "P-01", select the first track to
be programmed using SKIP/SEARCH buttons, and press EQ/PROGRAM button again to
store and advance to the next programming step. The program sequence indication
changes to "P-02" waiting for your next input.
Repeat the steps above to program more tracks. A maximum of 20 tracks can be
programmed in memory in a preferred order.
Press PLAY/PAUSE button to begin programmed play in the preferred order after you are
done with programming. The player stops automatically after all programmed tracks are
played.
You may press STOP button to terminate programmed playback. In program stop mode,
press STOP button again to clear the programming; press PLAY/PAUSE button to begin
the programmed playback with the programming order identical with the previous one done.
To repeat a preferred track in playback, press MODE button once, the LCD shows the icon
for single track repeat. Then select the preferred track using SKIP/SERCH buttons or
+10/ALBUM button. The player will repeat the chosen track until you press STOP button.


45

76
REPEAT ALL TRACKS
RANDOM PLAY
INTRODUCTION PLAY
MP3-CD PLAYBACK
LOCATE A TRACK OR ALBUM AND SEARCH FOR A SPECIFIC POINT TO PLAY
REPEAT A SINGLE TRACK
To repeat all tracks, press MODE button twice in play mode,
The player will repeat all tracks until you press STOP button.
Random play is that tracks on the disc are played by the player at random. Press MODE
button three times to enter this mode during play, "RAN" shows in the LCD. Press
Play/Pause button or SKIP buttons to begin Random playback. Tracks on the disc will be
selected at random for playback and the player stops automatically after all tracks are
played. Press MODE button once more to exit random.
Introduction play is that the first ten seconds of each track are played in a sequential order.
Press MODE button four times to enter this mode during play, "INTRO" shows in the LCD.
Press Play/Pause button to begin Introduction play from Track NO.1. Press SKIP up button
to begin INTRO playback from the track immediately after the current track and SKIP down
button to begin INTRO playback from the track. Press STOP button in Intro
playback to exit Introduction play mode and press play/pause button to resume normal
music play.
This player is capable of MP3-CDs. It takes longer time for this player to read an MP3-CD
than it does CD-DA. Wait patiently while it is reading.
After an MP3-CD is successfully read, the total number of albums and tracks show on the
LCD. And a second later, playback begins from the first track of the first album with the Mp3
icon.
1. Press once the SKIP/SEARCH up button in music play to skip to the next track. To skip
to a specific track ahead, press this button several times.
2. Press once the SKIP/SEARCH down button in music play to skip to the last track. To
skip to a specific track at back, press this button several times.
3. Press +10/ALBUM button once in play to skip to the track 10 tracks ahead, twice to skip
to the track 20 tracks ahead. You can reach the last track of the current album using this
button.
4. Hold the SKIP/SEARCH up button in music play to search forward at quick rate for a
specific point to play.
5. Hold the SKIP/SEARCH down button in music play to search backward at quick rate for
a specific point to play.
6. Hold the +10/ALBUM button, the album number will flash; press the Skip/Search button
to select the desired album, press and hold the ALBUM button again for 2 seconds to
confirm this album selection, the track number flickers for your input; select the desired
track of the chosen album using the SKIP/SEARCH buttons. Finally, press PLAY/PAUSE
button again to begin playing this chosen track.
To repeat a preferred track in playback, press MODE button once,
Then select the preferred track using SKIP/SERCH buttons. The
player will repeat the chosen track until you press STOP button.
the LCD shows the icon for all
tracks repeat.
previous
the LCD shows the icon
for single track repeat.
REPEAT ALL TRACKS
REPEAT AN ALBUM
RANDOM PLAY
INTRODUCTION PLAY
To repeat all tracks, press MODE button twice in play mode,
The player will repeat all tracks until you press STOP button.
To repeat a preferred album in playback, press MODE button thrice, the LCD shows the
icon for album repeat. Then select the preferred track using the +10/Album and Skip
buttons together. The player will repeat the chosen album until you press STOP button.
Random play is that tracks on the disc are played by the player at random. Press MODE
button four times to enter this mode during play, "RAN" shows in the LCD. Press
Play/Pause button or SKIP buttons to begin Random playback. Tracks on the disc will be
selected at random for playback and the player stops automatically after all tracks are
played. Press MODE button once more to exit random and return to normal playback from
the track it's reached.
Introduction play is that the first ten seconds of each track are played in a sequential order.
Press MODE button five times to enter this mode during play, "INTRO" shows in the LCD.
Press Play/Pause button to begin Introduction play from Track NO.1. Press SKIP up button
to begin INTRO playback from the track immediately after the current track and SKIP down
button to begin INTRO playback from the previous track. Press Play/Pause button again in
Intro playback to exit Introduction play mode and normal music play resumes.
the LCD shows the icon for all
tracks repeat.
Programmed play is that tracks on the disc can be edited for playback in a preferred order
with the use of PROGRAM button.
In MP3 stop mode, press EQ/PROGRAM button once, "PROG" shows in the LCD with a
flickering album number and the program sequence indication "P-01"; select the album
number to be programmed using SKIP/SEARCH buttons or +10/ALBUM button, and press
PROGRAM button again to store; the track number flickers waiting for your selection.
Choose the desired track with SKIP/SEARCH buttons or +10/ALBUM button. Press
PROGRAM button again to confirm the first programming and advance to the next
programming step. The program sequence indication changes to "P-02" waiting for your
next input.
Repeat the steps above to program more tracks. A maximum of 99 tracks can be
programmed in memory in a preferred order.
Press PLAY/PAUSE button to begin programmed play in the preferred order after you are
done with programming. The player stops automatically after all programmed tracks are
played.
You may press STOP button to terminate programmed playback. In program stop mode,
press STOP button again to clear the programming; press PLAY/PAUSE button to begin
the programmed playback with the programming order identical with the previous one done.
Prepare the player for external memory media operation.
Insert a USB data traveller into the USB port OR insert a SD/MMC card into the card slot;
Slide FUNCTION switch to USB/AUX mode and playback will start from the first track.
You may press the USB/CARD button to switch between USB and SD/MMC modes.
PROGRAMMED PLAY
EXTERNAL MEMORY MEDIA OPERATION (USB, SD/MMC)
NOTE:

98
VARIOUS PLAY MODES
SKIPPING TRACKS AND SEARCHING BETWEEN TRACKS
REPEAT MODES
RANDOM PLAY
INTROSCAN PLAY
Press the SKIP UP button once to skip the current track and play the next track, press this
button continuously to go to corresponding tracks ahead.
Press the SKIP DOWN button once to skip to the last track, press this button continuously
to go back to previous tracks.
Press the MODE button once in play mode to repeat the current track; the LCD shows the
icon for single track repeat.
Press the button for the twice time to repeat tracks stored on this storage media
(USB/MMC card) as a whole; the LCD shows the icon for all tracks repeat.
Press the button thrice to repeat tracks in current directory as a whole. The LCD shows the
icon for album repeat.
Press MODE button for the fourth time in play to activate random playback; the player will
pick up tracks in a random sequence for playback after PLAY/PAUSE is pressed. You may
press this button once again to exit random play mode and return to normal playback.
Press MODE button for the fifth time in play mode to activate introscan playback
immediately; the player will pick up tracks for playback of the first 10 seconds of each track
in a sequential order after PLAY/PAUSE button is pressed. You may press PLAY/PAUSE
button once again to exit introscan play mode and return to normal playback from the track
it's arrived at.
Press and hold the +10/ALBUM button for 2 seconds during play, the album number
flashes; select the desired album using the SKIP/SEARCH buttons; Press and hold the
ALBUM button again for 2 seconds to confirm this album selection, the track number
flickers for your input; select the desired track of the chosen album using the
SKIP/SEARCH buttons. Finally, press PLAY/PAUSE button again to begin playing this
chosen track.
PROGRAMMED PLAY
Take the USB programmed play as an example:
In USB, SD/MMC card mode, there is also a programmed play function. A maximum of 99
tracks can be programmed.
Discs can be edited for playback in a preferred order with the use of the PROGRAM button.
In stop mode, press the PROGRAM button once, "PROG USB" shows in the LCD with a
flickering album number and the program sequence indication "P-01"; select the album
number to be programmed using the SKIP/SEARCH or +10/ALBUM buttons, and press
PROGRAM again to store; the track number flickers waiting for your selection. Choose the
desired track with SKIP/SEARCH buttons or +10/ALBUM button. Press PROGRAM button
again to confirm the first programming and advance to the next programming step. The
program sequence indication changes to "P-02" waiting for your next input.
Hold the SKIP/SEARCH up button in music play to search forward at quick rate for a
specific point to play.
Hold the SKIP/SEARCH down button in music play to search backward at quick rate for a
specific point to play.
Repeat the steps above to program more tracks. A maximum of 99 tracks can be
programmed in memory in a preferred order.
Press the PLAY/PAUSE button to begin programmed play in the preferred order after you
are done with programming. The player stops automatically after all programmed tracks are
played.
You may press STOP to terminate programmed playback. In program stop mode, press
STOP again to clear the programming; press PLAY/PAUSE to begin the programmed
playback with the programming order identical with the previous one done.
Your player can be used as a power amplifier to playback the programs from portable radio,
TV set or MP3 player or whatever provide this appliance is so designed that audio signal
may be produced through a LINE-OUT jack or the like. Observe the following steps to
connect the player to another appliance:
1. Power the player on using the supplied AC Power Cord.
2. Slide the FUNCTION button to USB/AUX position.
3. Connect the appliance into the player's AUX in jack with LINE- OUT cable of the
appliance.
4. Power on the appliance and begin play.
At this time you will be able to hear the sound produced from the programs the connected
appliance is broadcasting.
This player is subject to any change in electronics and cosmetics without advance notice or
taking any responsibilities as we follow a policy of constant development and improvement
on this product. We are sorry if this will cause or has caused any inconvenience to you.
The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the apparatus.
When the mains plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable. To be completely disconnected the
power input, the mains plug of the apparatus or the appliance coupler shall be
disconnected from the mains completely.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
Minimum distances 2.0cm around the apparatus for sufficient ventilation. The ventilation
should not be impeded by covering the ventilation openings with items, such as
newspapers, table-cloths, curtains, etc.
The use of apparatus is in tropical and/or moderate climates.
Attention should be drawn to the environmental aspects of battery disposal.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
The marking plate is located at the back of the apparatus.
AUXILIARY IN
IMPORTANT NOTES:
IMPORTANT SAFETY INSTRUCTIONS









