Naxa NPB-260 User manual
MP3/CD Boombox with USB Player
NPB-260
Instruction Manual
Please read carefully before use and keep for future reference.
Page 2 Naxa Electronics
Table of Contents
Thank You ..................................................................... 3
In the Box ...................................................................... 3
Before You Start ........................................................... 4
At a Glance .................................................................... 5
Connect Power.............................................................. 9
AC Power.......................................................................................... 9
Battery Power................................................................................. 9
Basic Functions............................................................10
Turning the Unit On and Off ...................................................... 10
Changing Function Modes.......................................................... 10
Adjusting the Volume.................................................................. 10
Using the Radio............................................................10
Using the CD/MP3 Player ............................................ 11
About Compact Discs................................................................... 11
Loading a Disc................................................................................ 11
Playing a Disc.................................................................................12
Repeat Playback ...........................................................................13
Programming a Playlist ...............................................................13
Using the USB Player...................................................14
About USB Drives ........................................................................ 14
Loading a USB Stick Drive............................................................15
Playing Music from USB Drives ..................................................15
Using the AUX Input ....................................................16
Warnings and Precautions.......................................... 17
Specications ..............................................................21
Support ....................................................................... 22
www.naxa.com Page 3
Thank You
We know you have many choices when it comes to
technology; thank you for choosing us here at Naxa
Electronics. Established in 2001 in Los Angeles, Califor-
nia, we are dedicated to delivering products that en-
tertain and delight.
We trust that you will be happy with your purchase.
Please read this manual carefully and save it for refer-
ence. You may also nd the latest FAQ, documentation,
and other product material at our website. Come visit
us on the web at www.naxa.com and see all that we
have to offer!
In the Box
Please take a moment to make sure that you have ev-
erything in the list below. Although we make every ef-
fort to ensure that each Naxa device is securely packed
and sealed, we know a lot can happen in between us and
you. If anything is missing, check back with your local
retailer to get immediate assistance. If they cannot help
you, please contact our Naxa Support team at www.
naxa.com/naxa_support.
•NPB-260 portable MP3/CD/USB player
•AC power cable
•User manual
Page 4 Naxa Electronics
Before You Start
Please take note of the following before you start.
•Do not block the ventilation openings or holes.
•Avoid installing the unit in locations described be-
low:
•Places exposed to direct sunlight or close to
heat radiating appliances (such as electric
heaters, or on top of other stereo equipment
that radiate heat).
•Places lacking ventilation or dusty places.
•Places subject to constant vibration.
•Places that are humid or moist.
•Operate turning controls and switches as instruct-
ed in manual.
• Before turning on the power for the rst time, make
sure that the power cord is properly installed.
•Store your tapes or CD in a cool area to avoid dam-
age from heat.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO DOT REMOVE COVER (OR BACK). NO USER SER-
VICEABLE PARTS INSIDE, REFER SERVICING TO QUALI-
FIED SERVICE PERSONNEL.
WARNING: Remove batteries if exhausted or ifthey will
not be used again for a long period. The incorrect use
of batteries can cause electrolyte leakage and will cor-
rode the compartment or cause the batteries to burst,
therefore:
•Do not mix battery types, e.g. alkaline with zinc
carbonate.
•When inserting new batteries, replace all batteries
at the same time.
www.naxa.com Page 5
At a Glance
NPB-260
5
1 Handle Raise the handle to transport the
unit safely and easily.
2 CD compartment Load compact discs here. The label
side should face up.
3 CD door latch Press here to open/close the door of
the CD compartment [2].
Never open the compartment while
a CD is playing or spinning!
4 Antenna Extend the antenna fully and adjust
its position to optimize FM radio
reception.
5 AC power socket Connection for the included AC
power cable.
Page 6 Naxa Electronics
FM ST.
FUNCTION
FUNCTION
PROG/+10
REPEAT
PHONE
687 9
1110
6key
(Previous/
Reverse)
Previous: Press to skip to the previous
track.
Reverse: Press and hold to scan quickly in
reverse through the current track.
7key Press to stop playback.
8 / FUNC-
TION key
Play/Pause: Press to start, pause, or re-
sume playback.
FUNCTION: Press and hold to switch to
USB mode.
9key
(Next/
Forward)
Next: Press to skip to the next track.
Forward: Press and hold to scan quickly
forward through the current track.
10 PROG /
+10 key
PROG: Create a custom playlist. Press to
enter Program mode.
+10 key: Press to skip 10 tracks forward.
11 REPEAT key Repeat: Press to change the repeat play-
back mode.
www.naxa.com Page 7
FM ST.
FUNCTION
FUNCTION
PROG/+10
REPEAT
PHONE
14
12
13
17
15 16
12 LCD screen Displays player status information.
13 Speakers Full-range drivers deliver powerful stereo
sound.
14 Headphone
jack
Listen to music in private from optional
headphones when connected to this
3.5mm headphone output jack. Audio
from the speakers [13] will be muted
automatically when headphones are
connected.
15 USB Port Load USB memory sticks here. The USB
port is designed for music playback from
ash memory devices. It is not designed
to charge high-power devices.
16 AUX Input jack Play audio from a device that is connected
to this 3.5mm input jack.
17 Battery
compartment
Load 6 UM-2 “C” size batteries into the
compartment for portable power.
Page 8 Naxa Electronics
VOLUME
CD MP 3 US B OF F RAD IO/ /
FUNCTION
AM FM FM S T.
BANDTUNING
18
19
20
21
18 FUNCTION
switch
Set the switch to the position of the desired
function mode.
19 Volume dial Turn to adjust the volume level.
20 Radio Tun-
ing dial
Turn the dial to tune to a radio station.
21 Band
switch
Set the switch to the desired radio band
(AM/FM/FM ST).
www.naxa.com Page 9
Connect Power
The unit can be powered by AC household power, or by
batteries.
AC Power
This unit operates on AC 120 V ~60 Hz power.
With the included AC power cable, connect the AC
power socket [5] found on the rear of the unit to a wall
power outlet that provides AC 120V ~60Hz power.
⚠⚠Do not attempt to operate the radio on any
other power source. You could cause dam-
age to the unit and void your warranty.
Please be sure the power outlet you plug
this unit into is working and receives con-
stant (unswitched) power.
Contact your local power utility if you are
not sure which type of power you have.
Battery Power
Install 6 UM-2 “C” size batteries to enjoy music wher-
ever you are.
1. Remove the lid of the battery compartment [17]
found on the bottom of the main unit.
2. Load six “C” size batteries, taking care to match the
polarities marked on the inside of the compart-
ment (+, –).
3. Replace the lid of the battery compartment [17].
⚠⚠Remove the batteries if they are exhausted
or will not be used for a long time.
Batteries contain chemicals that may be
regulated by your local government. Dispose
of them properly according to regulations.
Page 10 Naxa Electronics
Basic Functions
Turning the Unit On and O
To turn the unit on, set the FUNCTION switch [18] to the
RADIO or CD position. The LCD screen [2] will light up.
To turn the unit off, set the FUNCTION switch [18] to
the OFF position.
Changing Function Modes
Set the FUNCTION switch [18] to one of the function
positions (e.g., CD/RADIO).
⚠L To change between CD and USB modes, set
the FUNCTION switch [18] to press and hold
the key [8] while the FUNCTION switch
[18] is set to the CD position.
Adjusting the Volume
Turn the VOLUME dial [19] on the left side of the unit to
increase or decrease the volume level.
Using the Radio
Set the FUNCTION switch [18] to the RADIO position to
start using the radio.
1. Select a frequency band. Set the BAND switch [21]
to the AM, FM, or FM ST. position.
2. Turn the Radio Tuning dial [20] on the right side of
the unit to tune to a radio station.
3. Optimize radio reception:
•Fully extend the telescopic ANTENNA [4] and
adjust its orientation to optimize FM radio
reception.
•The AM antenna is built into the player. Adjust
the orientation and position of the player itself
to optimize AM radio reception.
⚠L Select the mono FM band when tuning to a
station with a weak signal. Select the ste-
reo FM ST band when the signal is strong.
The FM ST indicator will light when the
radio is tuned to an FM stereo signal.
www.naxa.com Page 11
Using the CD/MP3
Player
Set the FUNCTION switch [3] to the CD position to start
using the CD/MP3 player.
About Compact Discs
This player is compatible with all digital audio CDs,
digital audio CD-Recordable discs (CD-R) and CD-Re-
writable discs (CD-RW) that have been nalized, and
CD-DA format digital audio CDs.
This player is also compatible with MP3-CDs. These are
compact discs that contain MP3 audio les on them.
⚠L Only handle a CD by its edge. Avoid touch-
ing the label or the playable side with your
hands or any other object.
Loading a Disc
1. Open the CD compartment [2]. Press down on the
CD door latch [3] to release it; the CD door will
swing up.
⚠L Lower the handle [1] before opening the CD
compartment. A raised handle will prevent
the CD compartment door from opening
completely.
2. Load a compatible disc. Place the CD into the com-
partment [2] with its label facing up.
3. Lower the door by pushing down on the CD door
latch [3]; push down until you hear the latch click
and the compartment is securely closed.
4. The player will attempt to read the disc once the
compartment is closed.
•The LCD screen [12] will show the number of
playable tracks on the disc.
•If the player cannot read the disc, make sure
that the disc is loaded properly, and that is not
damaged, dirty, or incompatible.
Page 12 Naxa Electronics
⚠L To ensure good system performance, wait
until the player recognizes and reads the
disc before proceeding.
MP3-CDs take longer to read because
they have more data on them. Please wait
patiently until the player has recognized
the disc.
Playing a Disc
With a compatible disc in the CD compartment [2]:
•Press the key [8] to start playback.
•Play will start from track 1.
•The Play indicator will light steady on the LCD
screen [12].
•To pause playback, press the key [8] while a disc
is playing.
• The track number will ash on the LCD screen
[12].
•Press the key [8] again to resume playback.
•To stop playback, press the key [7].
•To select a track to play:
•Press the key [9] to skip to the next track.
•Press the key [6] to skip back to the previ-
ous track.
•Press the PROG/+10 key [10] to skip 10 tracks
forward.
⚠L Skipping 10 tracks will only work on media
that contain more than 10 MP3s (e.g., MP3-
CDs, USB ash drives).
•To scan through a track at high speed:
•Press and hold key [9] during playback. Play
will advance quickly through the current track;
release the key to resume playback at normal
speed.
•Press and hold the key [6] during playback.
Play will reverse quickly through the current
track; release the key to resume playback at
normal speed.
www.naxa.com Page 13
Repeat Playback
You can change the order in which the tracks of a CD
are played by pressing the REPEAT key [11]. To cancel
repeat mode, press the REPEAT key [11] until all of the
Repeat indicators disappear from the LCD screen [12].
•To repeat a single track, press the REPEAT key [11]
until the “Repeat” indicator ashes on the LCD
screen [12]. The current track will replay repeatedly
until play is stopped.
•To repeat all of the tracks, press the REPEAT key
[11] until the “Repeat” indicator appears steady on
the LCD screen [12]. The player will replay all tracks
continuously until play is stopped.
Programming a Playlist
When the CD is stopped, you can select up to 20 CD
tracks to play in any order that you choose.
1. Press the key [7] to make sure that playback has
stopped.
2. Press the PROG key [10]. The Program indicator and
“01” will ash on the LCD screen [12].
3. Use the and keys [9, 6] to choose a track to
enter into the playlist.
4. Press the PROG key [10] to save the chosen track
into the playlist. The LCD display [12] will then ash
the next playlist track number (e.g., “02”).
5. Repeat steps 3 and 4 until your playlist is complete
(up to 20 tracks).
•When the last track is entered, the unit will
display for review the number of each track in
the playlist. When the review is over, the Pro-
gram indicator and “01” will ash on the LCD
display [12].
•If you nd a mistake, you can edit the playlist
while “01” is ashing. Press the PROG key [10] to
change the ashing playlist number; use the
and keys [9,6] to change the track number.
6. Press the key [8] to start program playback. Play
will start from the rst track in the playlist and
stop once all of the programmed tracks have been
played.
•During program playback, you may change the
repeat playback mode by pressing the REPEAT
Page 14 Naxa Electronics
key, or you may skip ahead in the playlist by
pressing the key [9]. The key [6] is not
available during program playback.
7. Press the key [7] to stop the programmed playl-
ist, then press the key [7] a second time to clear
the playlist from Program memory.
⚠L Opening the CD compartment [2] will also
clear the playlist from Program memory.
Using the USB Player
Connect a USB memory device to the USB port [15]
found on the front of the unit, then:
1. Set the FUNCTION switch [18] to the CD position.
2. Press and hold the / FUNCTION key [8] to switch
to USB mode. (To return to CD mode, press and hold
the / FUNCTION key [8] again.)
About USB Drives
This player can play supported audio les from USB
stick drives connected to the USB port [15].
For a list of supported audio les, please refer to the
Specications section of this manual.
The le system of the USB drive must be formatted as FAT
or FAT32. Other le systems are not supported. The unit
willnotworkwithcomputersconnectedtotheUSBport.
External hard disks and other high-power devices
connected to the USB port must have it’s own source
of power.
www.naxa.com Page 15
⚠L There are many different USB stick types
and manufacturers. Although this player
should support most of these memory
devices, it is impossible to guarantee com-
patibility with ALL USB drives.
If your USB device can be turned on, turn it
on when using it with the player.
Loading a USB Stick Drive
1. Plug your USB memory stick drive into the USB port
[15] found on the front of the unit.
⚠⚠If you feel resistance when plugging your
USB drive in, stop! Turn it over and try
again. The USB port accepts drives in one
position only.
2. Set the FUNCTION switch [18] to the CD position.
3. Press and hold the / FUNCTION key [8] to switch
to the USB reader from the CD player. The player
will attempt to read all the compatible les on your
memory device.
•The LCD screen [12] will show the number of
playable tracks on the USB drive.
•If it cannot read from the USB drive, make sure
that the drive is plugged in securely, that it is a
compatible format, has power if it is necessary,
and that it contains compatible les.
⚠L To switch between the USB player and the CD
player, press and hold the / FUNCTION key
[8]].
Playing Music from USB Drives
Using the USB player is the same as using the CD player.
•Press the / FUNCTION key [8] to start, pause, or
resume playback.
•Press the key [7] to stop playback.
⚠L To learn more about how to control play-
back, please refer to the “Using the CD/
MP3 Player” section of this manual (“Play-
ing a Disc,” “Repeat Playback,” “Program-
ming a Playlist”).
Page 16 Naxa Electronics
Using the AUX Input
Set the FUNCTION switch [18] to the CD or RADIO posi-
tion to play devices connected to the AUX Input jack [11].
⚠L The unit will switch to AUX mode automati-
cally when a player is connected to its AUX
input jack [16].
1. Connect the audio source to the player. Use an op-
tional audio patch cable (not included) to connect
the 3.5mm headphone or line-out jack of the audio
source to the 3.5mm AUX Input jack [11] found on
the front of the player.
2. Prepare the player. Set the FUNCTION switch [18] to
the CD position. Turn the VOLUME dial [19] to lower
the volume level.
3. Prepare the audio source. Start playback on the
device. Set the volume level of the device to ap-
proximately 80% of its maximum.
4. Adjust the nal volume. Turn the VOLUME dial [19]
of the player to set the volume to a comfortable
level.
⚠L Use the audio source to control playback
(e.g., stop, play, next). Use the player to
control the volume.
Remember to disconnect the audio patch
cable from the AUX input jack [16] after use
in order to be able to listen to the radio or
CD player again.
www.naxa.com Page 17
Warnings and Precautions
The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alertthe userto the presence of uninsulat-
ed “dangerous voltage” within the product’s enclosure that may
be of signicant magnitude to constitute risk of electric shock.
The exclamation point within an equilateral triangle is intended
to alert the userto the presence of important operation and ser-
vicing instructions in the literature accompanying the appliance.
On Protection Against Laser Energy Exposure
• As the laser beam used in this product is harmful to the eyes, do not
attempt to disassemble the casing.
• Stop operation immediately if any liquid or solid object should fall
into the cabinet.
• Do not put anything in the safety slot. If you do, the laser diode will
be ON when the disc compartment door is still open.
• If the unit is not to be used for a long period of time, make sure that
all power sources are disconnected from the unit. Remove all batter-
ies from the battery compartment, and unplug the AC-DC adapter
from the wall outlet. Make it a practice to remove the AC-DC adapter
by grasping the main body and not by pulling the cord.
• This unit employs a laser. The use of controls or adjustment or per-
formance of procedures other than those specied here may result in
exposure to hazardous radiation.
CAUTION
• Do not block the ventilation openings or holes.
• Do not place any naked ames (such as lighted candles) on the ap-
paratus.
• When discarding batteries, follow all local rules and laws governing the
disposal of batteries. Consider the environmental impact of your actions!
• Invisible laser radiation when open and interlock has failed or been
defeated. Avoid direct exposure to beam.
• To prevent re or shock hazard, do not expose this appliance to rain
or moisture.
Page 18 Naxa Electronics
Important Safety Information
1. Read Instructions: All the safety and operating instructions should be
read before the product is operated.
2. Retain Instructions: The safety and operating instruction should be
retained for future reference.
3. Heed Warnings: All warnings on the product and in the operating in-
structions should be adhered to.
4. Follow Instructions: All operating and usage instructions should be
followed.
5. Cleaning: Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6. Attachments: Use only attachments recommended by the manufac-
turer. Use of other attachments may be hazardous.
7. Water and Moisture: Do not use this product near water (e.g., near a
bathtub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
8. Accessories: Do not place this product on an unstable cart, stand,
tripod, bracket, or table. Use only with carts, stands, tripods, brack-
ets, or tables recommended by the manufacturer or
sold with the product. Any mounting of the product
should follow the manufacturer’s instructions and
should use a mounting accessory recommended
by the manufacturer. A product and cart com-
bination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the
product and cart combination to overturn.
9. Ventilation: Slots and openings in the cabinet are provided for ven-
tilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer in-
structions have been adhered to.
10. Power Sources: This product should be operated only from the type of
power source indicated on the rating label. If you are not sure of the
type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
11. Grounding or Polarization: This product may be equipped with a po-
larized alternating-current line plug that has one blade wider than
the other. This plug will only t into the power outlet in one direction.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the direction of the plug. If the plug should
still fail to t, contact an electrician to replace the obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
12. Power-Cord Protection: Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, conve-
nience receptacles, and at the point which they exit from the product.
13. Protective Attachment Plug: The product may be equipped with an at-
tachment plug with overload protection. This is a safety feature. See
the operating instructions for replacement or directions to reset the
protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same over-
load protection as the original plug as specied by the manufacturer.
14. Outdoor Antenna Grounding: If an outside antenna is connected to
the product, be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANS/NFPA70 provides in-
formation with regard to proper grounding of the mast and support-
www.naxa.com Page 19
ing structure,grounding of the lead-in wire to an antenna-discharge
unit, size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements for the
grounding electrode (see gure).
15. Lightning: For added protection for this product, unplug it from the
wall outlet and disconnect the antenna or cable system during a
lightning storm or when it is left unattended and unused for long pe-
riods of time. This will prevent damage to the product due to lightning
or power-line surges.
16. Power Lines: An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power cir-
cuits, or where it can fall into such power lines or circuits. When in-
stalling an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits, as contact with them
might be fatal.
17. Overloading: Do not overload wall outlets, extension cords, or inte-
gral convenience receptacles as this can result in a risk of re or elec-
tric shock.
18. Object and Liquid Entry: Never push objects of any kind into this prod-
uct through openings as they may touch dangerous voltage points or
shout-out parts that could result in a re or electric shock. Never spill
liquid of any kind on the product.
19. Servicing: Do not attempt to service this product yourself as open-
ing or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualied service personnel.
20. Damage Requiring Service: Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the follow-
ing conditions: a) when the power-supply or plug is damaged; b) if
liquid has been spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as
improper adjustment of other controls may result in damage and will
often require extensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or
damaged in any way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
21. Replacement Parts: When replacement parts are required, be sure
that your service technician has used replacement parts specied
by the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in re, electric shock, or
other hazards.
22. Safety Check: Upon completion of any service or repairs to this
product,ask the service technician to perform safety checks to ensure
that the product is in proper operating condition.
Page 20 Naxa Electronics
23. Wall or Ceiling Mounting: The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
24. Heat: The product should be situated away from heat sources such as
radiators,heat registers, stoves, or other products (including ampli-
ers) that produce heat.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be de-
termined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the grantee of
this device may void the authority granted by the FCC to operate the
equipment.
WARNING
This product contains lead, a chemical known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash hands
after handling.
CAUTION
This product is equipped with a polarized plug (one blade is widerthan the
other blade) as a safety feature to reduce the risk of electrical shock. This
plug will t into a polarized outlet only one way. This is a safety feature.
If you are unable to insert the plug into the electrical outlet, try reversing
the plug. If the plug still does not t, contact a qualied electrician. Never
use the plug with an extension cord unless the plug can be fully inserted
into the extension cord. Do not alter the plug. Do not attempt to defeat
the safety purpose of the polarized plug.
NEC NATIONAL ELECTRICAL CODE
Dot not apply oil or petroleum products to this product.
GRAPHIC SYMBOLS WITH SUPPLEMENTARY MARKINGS ARE LOCATED ON
THE BOTTOM OF THE UNIT. USE OF ANY CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE HEREIN SPECIFIED
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
Table of contents
Other Naxa CD Player manuals
