Easy-Read Dual Alarm Clock Radio
with Jumbo Display & USB Charge
NRC-166
Instruction Manual
Please read carefully before use and keep for future reference.
Important Safety
Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that maybe of suf-
cient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instruc-
tions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accor-
dance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including am-
pliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the pro-
vided plug does not t into your outlet, consult an elec-
trician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specied by the man-
ufacturer.
Page 2 Naxa Electronics
12. Use only with the cart, stand, tripod,
bracket, or table specied by the manu-
facturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servic-
ing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the ap-
paratus, the apparatus has been exposed to rain or mois-
ture, does not operate normally, or has been dropped.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must ac-
cept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the
grantee of this device may void the authority granted by the
FCC to operate the equipment.
www.naxa.com Page 3
Page 4 Naxa Electronics
1CLK/MEM button
2MIN/TUN− button
3HOUR/TUN+ button
4DIMMER button
5AL2/− button
6AL1/+ button
7SOURCE/AL OFF button
8SNOOZE button
9LED display
10 Alarm 1 buzzer indicator
11 Alarm 1 radio indicator
12 Alarm 2 buzzer indicator
13 Alarm 2 radio indicator
14 PM indicator
15 Speaker
16 USB port
17 DC jack
18 FM wire antenna
19 Battery compartment
At a Glance
www.naxa.com Page 5
Connecting the Unit
to Power
Before plugging in the AC power cord to the AC
wall outlet, make sure that the voltage of your
electricity supply is same as that indicated on
the rating plate.
Battery Backup
Battery backup will preserve the current time,
alarm settings, and stored radio stations in the
case of power failure or interrupted AC power.
Insert two UM-4 batteries (AAA) into the bat-
tery compartment. Be sure to observe the
proper polarity (the “+” and “-” signs) as indi-
cated inside the battery compartment.
Setting the Clock
1. With the unit in CLOCK mode (i.e., the ra-
dio is off), press and hold the CLK/MEM
button for about 1 second. The time will
begin to ash on the display.
2. Press the HOUR/TUN+ button to adjust
the hour; press the MIN/TUN− button to
adjust the minute.
3. When the correct time is set, press the
CLK/MEM button again to conrm.
Page 6 Naxa Electronics
Setting the Alarms
1. With the unit in CLOCK mode (i.e., the ra-
dio is off), press the AL1/+ button to set
Alarm 1 (or press AL2/− to set Alarm 2).
The ALARM time will begin to ash on the
display.
2. Press the HOUR/TUN+ button to adjust
the alarm hour; press the MIN/TUN− but-
ton to adjust the alarm minute.
3. When the desired alarm time is set, press
the AL1/+ button to conrm (or AL2/−).
4. Press the AL1/+ button (or AL2/−) to tog-
gle between “wake to buzzer” or “wake
to radio” modes. The current alarm wake
mode is indicated on the display.
Snooze Function
1. Whenever the alarm (radio or buzzer) ac-
tivates, it can be temporarily suspended
9 minutes by pressing the SNOOZE/SLEEP
button once.
2. The buzzer or radio will then sound again
automatically after 9 minutes. This pro-
cedure can be repeated for up to approxi-
mately one hour.
Turning o the Alarm
Press the SOURCE/AL.OFF button to turn the
alarm off when it sounds.
www.naxa.com Page 7
Listening to the FM
Radio
1. Press the SOURCE/AL.OFF button to se-
lect the FM radio band.
2. Press the HOUR/+ or MIN/− button to
manually tune to a radio station.
3. Press and hold the HOUR/+ or MIN/− but-
ton for approximately 1 second to scan to
the next station with a strong signal. Sta-
tions with a weak signal can only be tuned
in manually.
4. To turn off the radio, press and hold the
SOURCE/AL.OFF button for approximately
1 second.
Saving a Radio Station to
Memory
1. Tune the radio to the desired station.
2. Press and hold the CLK/MEM button to save
the current station to the next preset station
number. The display will show PXX (where XX
is a preset station number from 01 to 10).
3. Up to 10 FM radio stations can be stored
in memory.
To Listen to a Saved Radio
Station
1. Press the SOURCE/AL.OFF button to se-
lect the FM radio band.
2. Press the CLK/MEM button to skip to tune
to the next preset station.
Page 8 Naxa Electronics
Turning O the Radio
While in radio mode, press and hold the
SOURCE/AL OFF button for approximately 1
second.
Sleep to Music Function
Place the radio on a timer so that you can lis-
ten to music as you fall asleep.
1. Press the SNOOZE/SLEEP button. The
display will show the default sleep time
of 90 minutes.
2. Continue to press the SNOOZE/SLEEP
button to toggle through the timer length
options (90-80-70-60-50-40-30-20-10
min. or OFF).
3. The radio will turn off automatically after
the set time has elapsed.
Charging Your De-
vices
Connect the standard end of a USB cable (not
included) to the USB port on the rear of the
unit and connect the other end to the charg-
ing port of your device. USB cables may dif-
fer by manufacturer, so be sure to use the one
provided with your device.
Some devices may not support
USB charging or may require a
higher power rating than this
product provides. Observe the
charging status on your device, or
refer to the manufacturer’s spec-
ications. There are many differ-
ent devices with different power
requirements; we cannot guaran-
www.naxa.com Page 9
tee charge support for all devices.
Ensure that your device is work-
ing properly before attempting to
charge it.
Dimmer Control
Press the DIMMER button to adjust the bright-
ness of the display.
Specications
Frequency Range FM 87.5 – 108 MHz
Power Supply AC 100-240V ~ 60/50 Hz
USB Charge Output DC 5V, 1A
Back-Up Battery 2 pc. UM-4 (AAA)
Specications are subject to change without
prior notice.
Support
If you have problems with your device, please consult the instructions in this manual. Please
also visit us on the web at www.naxa.com to get up to the minute news, alerts, and documenta-
tion for your device. For additional assistance, please contact Naxa Technical Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
