Naxa NHS-2012A User manual

PLEASE READ CAREFULLY BEFORE OPERATING THIS EQUIPMENT
KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE
MODEL:NHS-2012A
32" Soundbar with Bluetooth

2
WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
WARNING: USE UNDER SUPERVISION OF AN ADULT DUE TO LONG
CORD This unit has a long cord that can be easily tripped on or pulled on,
causing injury.Please make sure it is arranged so that it will not drape over a
tabletop, etc. Where it can be pulled on by children or tripped over accidentally.
FCC NOTICE:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
DANGEROUS VOLTAGE:The lighting flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION:The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

3
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation. The antenna(s) used for this
transmitter must be installed to provide a separation distance of at least
20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
FCC WARNING:
To assure continued operation, follow the attached installation instructions and
use only shield cables when connecting to other devices. Changes or
modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Before using the unit, be sure to read all operating instruction carefully, please
note that these are general precautions and may not pertain to your unit. For
example, this unit may not have the capability to be connected to an outdoor
antenna.
(1) Read these instructions
All the safety and operating instructions should be read before the
appliance is operated.
(2) Keep these instructions
The safety and operating instructions should be kept for future reference.
(3) Heed all warnings
All warnings on the appliance and in the operating instructions should be
adhered to.
(4) Follow all instructions
All operation and use instructions should be followed.
(5) Do not use this apparatus near water
The appliance should not be used near water; for example, near a bath
tub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool.
Cancer and Reproductive Harm-www.P65Warnings.ca.gov

4
(6) Clean only with dry cloth
The appliance should be cleaned only as recommended by the
manufacturer.
(7) Do not block any ventilation openings.Install in accordance with the
manufacturer’s instructions.
Slots and openings in the cabinet and in the back or bottom are provided
for ventilation, to ensure reliable operation of the product and to protect it
from overheating. These openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or similar surface. This product should never be placed near or over a
radiator or heat source. This product should not be placed in a built-in
installation, such as a bookcase or rack unless proper ventilation is
provided or the manufacturer’s instructions have been adhered to.
(8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
(9) Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
(10) Product the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
(11) Only use attachments / accessories specified by the manufacturer.
(12) Use only with a cart, stand, tripod, bracket, or tabl
specified by the manufacturer, or sold with th
apparatus. When a cart is used, use caution whe
n
e
e
moving the cart/apparatus combination to avoid injury from tip-over.
An appliance and cart combination should be moved with care. Quick stop,
excessive force and uneven surfaces may cause the appliance and cart
combination to overturn.
(13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
To protect your product from a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent damage to the
product due to lightning and power-line surges.
(14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been
dropped.

5
(15) Power source
This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your appliance dealer or local power
company. For products intended to operate from battery power, or other
source, refer to the operation instructions.
(16) Power lines
An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it
can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be fatal.
(17) Overloading
Do not overload wall outlets and extension cords as this can result in a
risk of fire or electric shock.
(18) Object and liquid entry
Never push objects of any kind into the product through openings as they
may touch dangerous voltage points or short out parts that could result in
fire or electric shock. Never spill or spray any type of liquid on the product.
(19) Outdoor antenna grounding
If an outside antenna is connected to the product, be sure the antenna
system is grounded so as to provide some protection against voltage
surges and built up static charges. Section 810 of the National Electric
Code ANSI/ NFPA 70 provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead- in
wire to an antenna discharge product, size of grounding conductors,
location of antenna- discharge product, connection to grounding
electrodes and requirements for the grounding electrodes.
(20) Service
Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.

6
(21) Replacement parts
When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the
same characteristics as the original parts. Unauthorized substitutions may
result in fire or electric shock or other hazards.
(22) Safety check
Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in
proper operating condition.
(23) Wall or ceiling mounting
The product should be mounted to a wall or ceiling only as recommended
by the manufacturer.
(24) Damage requiring service
Unplug this product from the wall outlet and refer service to qualified
service personnel under the following conditions.
a) When the power- supply cord or plug is damaged.
b) If liquid has been spilled or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an adjustment of other controls may result in
damage and will require extensive work by a qualified technician to
restore the product to its normal operation.
e) If the product has been dropped or the cabinet has been damaged.
f
)
When the product exhibits a distinct change in performance- this
indicates a need for service.
(25) Note to CATV system installer
This reminder is provided to call the CATV system installer' s attention to
Article 820- 40 of the NEC that provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.
NOTE: Refer all servicing to qualified service personnel. Servicing is
required when the unit has been damaged in any way such as the
following: the power-supply cord or plug has been damaged, liquid has
been spilled into unit, the unit has been exposed to rain or moisture, the
unit has been dropped or the unit does not operate normally.

7
1. Placing the device on table - Ventilation
When placing the Sound Bar on an entertainment center, bookshelf, or any type of
enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar for
ventilation. If the Sound Bar is enclosed in a tight space, without ventilation, heat
generated from the Sound Bar could produce a potential heat hazard.
PLACEMENT AND MOUNTING

2.1 Mountingto a wooden wall
A. Mark the position of the mounting screws on the wall using a pencil.
C. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
2.2 Mountingto a brick wall
27.6 inches
27.6 inches
B. Drill the screws directly into the marks that you have made on the wall and
leave approx. 0.3 inches length to hook the sound bar.
(screws not included)
(screws and plastic fixing plugs are not included)
A. Mark the position of the mounting screws on the wall using a pencil.
E. Put the sound bar onto the mounting screws. Make sure they are firm and stable.
6
C. Insert the fixing plug and hammer into the holes.
D. Secure the screws into the fixing plug and leave approx. 0.3 inches length
to hook the sound bar.
B. Drill 2 holes on wall with a powerful electric drill.
8

Vol+Vol-
Standby
/Source
Play
/Pause
FrontView
Top View
1. Indicator
2. Remote Sensor
3. Speaker 3. Speaker
4. AUX IN Jack 5. DC IN Jack
6. Standby/Source
Button
7. Play/Pause Button 8. Volume Down Button
9. Volume Up Button
Rear View
9
LOCATION OF CONTROLS
A U X I N
DC 9 V

10
S ANDB
1
2
3
4
5
8
6
7
STANDBY Button
(Mute) Button
(Previous) Button
4.
5.
6.
7.
8.
(Play/Pause) Button
VOL - (Volume Down) Button
2.
1.
3. SOURCE Button
(Next) Button
VOL + (Volume Up) Button
REMOTE CONTROL
NHS-2012A

●Remove and discard the insulation as figure on the right.
1. Push and slide out the battery holder as figure 1 below.
2. Replace the battery with a new CR2025 button cell as the polarity
markings on the rear of the Remote Control.
3. Close the battery holder.
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the battery
compartment, a reserved battery may cause damage to the device.
3. Do not mix different types of batteries together ( e.g: Alkaline and Carbon -zinc )
or old batteries with fresh ones.
4. If the batteries in the device are consumed or the device is not to be used for a long period of time,
remove the batteries to prevent damage or injury from possible leakage.
5. Do not try to recharge the battery not intended to be recharged; it can overheat and rupture.
( Follow battery manufacturer’s instructions.)
6. The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
7. Clean the battery contacts and also those of the device prior to battery installation.
8. The remote control supplied with a coin/button
cell battery. If the coin button cell battery is
swallowed, it can cause severe internal burns in
just 2 hours and can lead to death. Keep new
and used battery away from children. If the
Battery compartment does not close securely,
stop using the product and keep it away from
children. If you think batteries might have been
swallowed or placed any part of the body, seek
immediate medical attention.
CR2025
CAUTION
●Danger of explosion if the battery is incorrectly replaced.
●Replace only with the same or equivalent type.
film
11
BATTERY INSTALLATION OF REMOTE CONTROL
RELEASE
PUS H
OPE N
R202 5
C
+
SN
Fig.1 Fig.2 Fig.3
●
●When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong light
shines on the REMOTE SENSOR of the unit, the operation of the remote may be unstable.
When there is an obstacle between the transmitter and the unit, the unit may not operate.
USING AT FIRST TIME
REPLACING BATTERY
BATTERY PRECAUTIONS
REMOTE CONTROL OPERATION

12
1. Connect the AC/DCadapter to theunit and wall outlet. The red indicatorwill
~ Press the ( Mute ) button on the Remote Control to turn off the sound. Press
again to resume.
Violet (blue+red).................................................................................AUX Mode
Blue............................................................................................Bluetooth Mode
2. Press and hold the Standby/Source button on the unit or press the STANDBY
3. During Playback:
light and the unit is in standby mode.
button on remote control to turn on the unit. Press the Standby/Source button
on the unit or press the SOURCE button on remote control repeatedly to switch
to desired mode. The color of indicator will turn to :
4. When finishing listening, press and hold the Standby/Source button on the unit
or press the STANDBY
button on remote control to put the unit in standby
mode.
GENERAL OPERATION
~ Press the Vol- or Vol+ button on unit or remote control to adjust the volume.

13
For first time use or re-pairing, pair the unit to an external Bluetooth (BT) device
~ Press the
2. Press the Standby/Source button on the unit or press the SOURCE button
~
on remote control repeatedly until the indicator turns Blue, and a voice tone
sounds "Bluetooth Mode".
When appears, select it and start pairing.
After paired, the indicator will stop blinking and a voice tone sounds "Paired".
4. During playing:
~ Press the or button on remote control to skip tracks.
~
~ Press the Vol- or Vol + button to adjust volume level.
Normal operation after first pairing:time
1. Power on the unit and select the Bluetooth mode, as stated above.
2. Activate the Bluetooth function on external Bluetooth device.
4. Play the music, as stated above.
3. Wait a few seconds until the unit automatically connected to the external
Bluetooth device.
BLUETOOTH PAIRING AND CONNECTION
" NAXA NHS-2012A "
button on remote control or the Play/Pause button on the unit to
pause. Press again to resume normal playing.
as below:
1. Power on the unit as previously explained.
3. Power on the external Bluetooth device and set Bluetooth to searching mode.
(For details on pairing procedures, please refer to the user's manual of your
Bluetooth device.)

A U X I N
14
An external (Auxiliary) audio source (ie.,personal CD player or MP3 player) can
be connected to this unitandheard throughthe speakers.
3. Power on the unit, aspreviously explained.
Audio
Player
To Audio Out Jack
1. Plug one end of the Aux In cable into the AUX IN jack on the rear of the unit.
on the Remote Control repeatedlyuntil the color of Indicator turns to
4. Press the Standby/Source button on the unit or press the SOURCE button
Violet (blue + red), and a voice tone sounds "AUX Mode".
2. Plug the otehr end of the Aux In cable into the AUX OUT or LINE OUT jack
of the external audio source.
5. Power on the connected external player and start playing as usual.
LISTEN THROUGH AUX IN
A U X I N
LR
(Cable not included)
(Cable included)
TV
or

15
not connected Connect the power AC/DC adapter to the unit or wall outlet.
Standby mode.
The paired/connected device is not in Play music/movie in the paired/
connected device as usual and make
sure the volume level of it is in high
level.
on the unit or SOURCE button on the
Remote Control repeatedly to set the
input source to the desired mode.
Reduce the volume level of the
paired/connected device.
Bluetooth
reception failure The external device is too far from the unit Put the external BT device close to the unit.
Have not paired Pair the unit with the BT Device as the
procedures stated in this manual.
Input source incorrect Press the Standby/Source button
The unit is in standby mode
playing mode
Press and hold Standby/Source button
on the unit or press button on remote
control to turn on the unit from
SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION
No sound Volume in minimum position Raise volume by pressing the
Remote control
not working The battery is weak Replace with new battery
No power Power AC/DC Adapter
Sound distortion
TROUBLESHOOTING
Vol+ button.
the Vol- button.
Volume level too high Reduce the volume level by pressing

16
Bluetooth Effective Range in Open Area.........................................Up to 32 feet
Remote Effective Range..................................................................Up to 16 feet
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE
is a trademark on a registered trademark of Bluetooth
SIG Inc. All other trademarks and trade names are
those of their respective owners.
Power Source.........................................................DC9V 1300mA
Audio Power..............................................................................................2X3W
1 x AC/DC Adapter
1 x Remote Control
1 x User's Manual
ACCESSORIES
SPECIFICATIONS
1 x 3.5mm AUX to RCA Cable
