Naxa VIBE 3 NAS-3082 User manual

VIBE 3 Bluetooth® Speaker and MP3 Player
NAS-3082
Instruction Manual
Please read carefully before use and keep for future reference.

Important Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous volt-
age” within the product’s enclosure that maybe of
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instruc-
tions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
WARNING: This product contains lead, a chemical known
to the State of California to cause cancer and birth defects
or other reproductive harm. Wash hands after handling.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accor-
dance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including am-
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the pro-
-
trician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
Page 2 Naxa Electronics

11. -
ufacturer.
12. Use only with the cart, stand, tripod,
-
facturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. -
ing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the ap-
paratus, the apparatus has been exposed to rain or mois-
ture, does not operate normally, or has been dropped.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must ac-
cept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
CAUTION ON MODIFICATIONS
grantee of this device may void the authority granted by the
FCC to operate the equipment.
www.naxa.com Page 3

Page 4 Naxa Electronics
At a Glance
10. USB Slot
4. USB port
LED Indicator Light
USB Port to plug in a flash drive
3.5mm AUX input
1. Indicator
Light
2. DC 5V
Power Port
DC 5V Micro USB charge port
Switch to turn the unit On/Off
6. Micro SD
input
Insert a Micro SD card to listen to
MP3 files.
5. AUX Input
3. On/O
Switch

www.naxa.com Page 5
At a Glance
7. Press to Pause or Resume Playback
Press to Answer/End a call when the
speaker is connected to a smartphone
via Bluetooth
Press and hold to turn on and off the
LED Lights on the speaker
8. M
(Mode Button)
Press to select different inputs
(Bluetooth®/FM/USB/Micro SD/AUX)
9.
10.
Press to skip to previous track.
Press and hold to decrease the volume
Press skip to the next track.
Press and hold to increase the volume.

Page 6 Naxa Electronics
Bluetooth®speaker with LED
Lights
This Naxa NAS-3082 portable Bluetooth®speaker
allows you to take your music just about anywhere
you want. Stream your music from any Bluetooth®
enabled device at a range of up to 30’ or connect
your MP3 player or smartphone using the 3.5mm
line-in audio jack. LED lighting effects give you a
light show for an added enjoyment while you listen
to your favorite music or soundtracks. The hands-
free Bluetooth®speaker has a built-in microphone
which allows you to receive an incoming call while
paired with a Bluetooth®enabled smartphone.
This lightweight speaker makes it easy for you to
take it anywhere and enjoy music on the go.
Speaker Function Parameters
Frequency response: 80-18,000 Hz.
FM frequency range: 87.05---108 MHz ( 3DB)
SNR 65DB
Bluetooth® connection distance 10M with hands-
free function.
Power input USB power of 5V-1000mA from AC
power adapter (not supplied)
Instructions for Use
Operating Instructions
Built-in battery
DC-5V (0.4-1A) USB power adapter (not supplied)
REMINDER: When charging the battery is
completed, please unplug the cable.
While the unit is charging, the indicator light will
remain on RED.
When the unit is fully charged, the light will turn
off.

www.naxa.com Page 7
Bluetooth® Mode
1. Turn ON the unit.
Your Bluetooth®speaker can wirelessly stream
audio from any Bluetooth®enabled device within
the distance of 26-33 ft. Please follow the steps
below to setup connection.
2. The LED lights will flash on the unit
indicating your speaker is powered on and in
“pairing” mode.
3. Enable Bluetooth®on your Mobile Phone,
Tablet, or Computer.
4. Scan for available devices and pair with
“NAXA NAS-3082”.
6. You will hear a voice confirming you have
paired successfully.
7. If pairing was unsuccessful, please repeat the
steps above.
5. If your device requires a password, please
enter “0000” to confirm the pairing process.
Bluetooth® Control Buttons
When the speaker is connected to a device via
Bluetooth®:
Start, Pause, or
Resume playback
Play the previous
track
Press
Press and Hold or
Press
PressPlay the next
track
Adjust the
Volume
To Do
PressAnswer/End
Call
You may also use your device to control playback.
Some devices may not support remote Bluetooth
controls.
Volume control can be adjusted on both the device
and speaker.
To Do
Call previous
number dialed
Press (2x) times quickly

Page 8 Naxa Electronics
AUX Mode
1. Turn ON the unit.
Connect devices without Bluetooth®by using the
AUX input. A 3.5mm stereo mini patch cable
(supplied) is required to make this connection.
2. Connect your audio device using the supplied
3.5mm AUX cable and the unit will auto-
matically go to the LINE(AUX) input.
3. Select your favorite song on your source
player and begin playback.
Using USB & Micro SD Mode
1. Turn ON the unit.
Install a USB drive or MicroSD card and music
will automatically begin playback.
2. Insert a USB flash drive or a MicroSD card
in the slot and music will automatically
begin playback.
3. Short press or to switch between your
tracks.
4. Short press the Play/Pause button to Pause
or resume playback.
5. Long press the or to increase or decrease
the volume.
Listening to FM Radio
1. Turn ON the unit.
2. Short press the MODE button until you hear
the FM Tuner input.
3. Short press the button for searching and
recording preset radio stations within the
frequency range of 87.5-108Mhz. .
4. Short press the or buttons to listen to
the next and previous preset radio stations.
5. Long press the or buttons to adjust the
volume up or down.

Connecting Power
www.naxa.com Page 9
Symptom
There is no power.
Device is unable
to connect to the
speaker.
The device is
connected but
there is no sound.
Possible Cause
The power switch is set to O.
Battery dead.
Troubleshooting Guide
Solution
Make sure the switch is
set to ON.
Charge the battery.
The speaker is not in pairing
mode.
Bluetooth is disabled.
Power cycle the speaker
Enable Bluetooth mode
on your device.
The AUX connector may be in
use.
Your device may be too far
from the speaker.
Your device is not in playback
mode.
Disconnect the AUX
cable from the device.
Move your device
closer to the speaker.
Ensure your device is
operating correctly.
Start playback.
This guide lists common problems and their solutions.
solutions. Please refer to this guide before requesting
service. If you need further assistance, please contact
Naxa Technical Support @ www.naxa.com/naxa_support/
If you insert a USB drive or MicroSD card while in
Bluetooth®Mode, the unit will disconnect from
Bluetooth®and begin playback in USB or MicroSD
mode. Press the Mode button to return back to BT.
Your speaker has an integrated rechargeable
battery. Upon initial use, the battery should be
fully charged to ensure optimal performance
and battery life.
Use the included USB charging cable to connect
the speaker to a USB power source to charge the
battery.
1.
2.
Connect the USB charging cable (included)
to a DC 5V charging port of the speaker
and insert the other end into a USB port on
your computer or a similar power source.
Red LED indicator signifies that the unit is
charging. Once the unit is fully charged, the
LED indicator light will turn off.
it takes approximately 3 to 6 hours to charge the
unit fully when connected to a standard USB port.
Do not charge the unit for more than 8 hours to
optimize the lifetime performance of the battery.

Speaker Output
External Memory Support
Audio Format
Specifications are subject to change without prior
notice.
Audio Frequency Range
6W RMS (2 x 3W)
USB, Micro SD (max 32GB)
MP3
Support
If you have problems with your device, please re-
viewthe instructions in this manual. Please also visit
us on the web at www.naxa.com to get the latest
news, alerts, and documentation for your device.
For additional assistance, please contact Naxa
Technical Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
866-411-6292
http://www.naxa.com/naxa_support/
MADE IN CHINA
Radio Band
Radio Band Coverage87.5 - 108 MHz
FM
Bluetooth®, AUX (3.5mm)
Inputs
Built-in Rechargeable battery 3.7V / 1500 mAh
USB charge port 5V
Accessories
1x Bluetooth Portable Speaker
1x Owner’s Manual
1x USB Charging Cable
1x 3.5 mm AUX cable
80Hz - 18,000Hz
Page 10 NAS-3082 v1.1
Talk time: Up to 4 hours
Playback: Up to 1.5 hours
Battery Life
