Key Features and Benefits
Superior Coverage and High Speed
Transmission
Data rates up to 54Mbps, 5 times of 802.11b product
Features rugged construction and a weatherproof housing
proven in outdoor installations exposed to wind, rain, and
snow
Offers multiple mounting options for flexible placement to
achieve the best possible alignment or coverage
Easy to Use Network Management Tools
Easy to Use Network Management Tools
Kick Start: If the DHCP server fails or the device is on a
different subnet, the Advanced Discovery Protocol allows the
NWH9250 to be found and configured.
Bridge Auto Learning: The NWH9250 can intelligently detect
its peer bridges' MAC addresses via the advanced wireless
technology, saving the user the hassle of entering MAC
addresses.
Auto IP address assignment - the NWH9250 will automatically
assign itself a new IP address should the DHCP server fail.
On-line firmware upgradability: allows the bridge's firmware to
be upgraded via Web-based tool from a remote station without
stopping the network.
DHCP client support: automatically obtains a new IP address
from a DHCP server.
Remote Configuration
Remote Configuration
Allows administrators to manage the bridge from anywhere on
the network. All that is required is that the bridge be on the
same logical IP subnet as the management station.
SSecurity Protection
ecurity Protection
WEP (Wired Equivalent Privacy): 64, 128 and 256-bit WEP
encryption for secure wireless LAN data transmissions.
DDetachable Antenna (Optional)
etachable Antenna (Optional)
The detachable antenna design allows such options as
connecting a high-gain antenna for better signal quality over a
wider coverage area.
OOutdoor Protection Solution for Harsh Weather
utdoor Protection Solution for Harsh Weather
The Outdoor Protection Package bridge to be located
outdoors, where it may be subjected to wind, rain, and snow.
PPower Over Ethernet
ower Over Ethernet
PoE reduces power-cable expenses and increases location
options by carrying both data and power to the bridge through
a single Ethernetcable.
Maximizing the Convenience of Networking
NWE9251
802.11g Wireless Outdoor Bridge
802.11g Wireless Outdoor Bridge
Product Overview
The NWE9251 is a 2.4GHz 802.11g Wireless Outdoor Bridge
that compliant 802.11b/g standards. The NWE9251 covers a
large operating distance for Wireless LANs and broadband
Internet Access with transfer data rate up to 54Mbps. It links
two or more separate networks (typically located in different
buildings) to create a single expanded LAN quickly, simply, and
economically. The NWE9251 delivers higher transmission rates
than an E1 or T1 line, and eliminates the inconvenience of
installing an expensive leased line or fiber-optic cable. The
NWE9251 fully complies with the IEEE802.11b/g standard.
Combining superior wireless technology and advanced
features, the NWE9251 Wireless Outdoor Bridge is a reliable,
high-performance, cost-effective solution for the most
demanding wireless networking environments.
802.11g Wireless Outdoor Bridge

Point-to-point Mode
Bridges in point-to-point mode
connect two networks in
different locations through a
single wireless link. This allows
two widely separated sites to
share resources, including a
single high-speed connection
to the Internet.
Point-to-multipoint Mode
Bridges in point-to-multipoint
mode connect three or more
networks in scattered buildings
through wireless links. This
allows numerous sites in a
wide area to share resources,
including a single high-speed
connection to the Internet
Specifications
Standards Compliance IEEE802.11g, 11b
RF Spreading Method Direct Sequence Spread Spectrum (DSSS)
Transmission Rate 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps with auto fallback
22Mbps (Optional)
RF Output Power 802.11b: 23dBm (Typical)
802.11g: 20dBm (Typical)
Receive Sensitivity 54 Mbps OFDM, 10% PER, -75dBm
48 Mbps OFDM, 10% PER, -77dBm
36 Mbps OFDM, 10% PER, -82dBm
24 Mbps OFDM, 10% PER, -86dBm
11 Mbps CCK, 8% PER, -90dBm
1 Mbps BPSK, 8% PER, -98dBm
Security 64/128/256-bit WEP; Wi-Fi Protected Access (WPA Q2 Support)
Software Support Kick Start (Advance discovery protocol for easy to use); Web-based Tool;
Bridge Auto Learning (Without the hassle of MAC number records); SNMP Support (Q2 Ready)
Environmental Requirements Operating Temperature: -20o to 70oC
Storage Temperature: -30o to 80oC
Humidity: 5% to 95%, non-condensing
Dimensions 237x152x55 mm
Weight 1.4 kg.
Power Input voltage 24zV DC; external power supply included (input voltage 100V to 240V AC)
Warranty One year, limited
* Product appearance and specifications are subject to change without prior notice.
s
s Outdoor Bridge Application Scenarios
802.11g Wireless Outdoor Bridge802.11g Wireless Outdoor Bridge
802.11g Wireless Outdoor Bridge802.11g Wireless Outdoor Bridge
NWH9250NWE9251
802.11g Wireless Outdoor Bridge Application Scenarios
P/N D-NWH9250 E01-0404
