NWH9250
802.11g Wireless Outdoor Bridge
802.11g Wireless Outdoor Bridge
Product Overview
The NWH9250 is a 2.4GHz 802.11g Wireless Outdoor Bridge
that compliant 802.11b/g standards. The NWH9250 covers a
large operating distance for Wireless LANs and broadband
Internet Access with transfer data rate up to 54Mbps. It links
two or more separate networks (typically located in different
buildings) to create a single expanded LAN quickly, simply, and
economically. The NWH9250 delivers higher transmission rates
than an E1 or T1 line, and eliminates the inconvenience of
installing an expensive leased line or fiber-optic cable. The
NWH9250 fully complies with the IEEE802.11b/g standard.
Combining superior wireless technology and advanced
features, the NWH9250 Wireless Outdoor Bridge is a reliable,
high-performance, cost-effective solution for the most
demanding wireless networking environments.
802.11g Wireless Outdoor Bridge

Point-to-point Mode
Bridges in point-to-point mode
connect two networks in
different locations through a
single wireless link. This allows
two widely separated sites to
share resources, including a
single high-speed connection
to the Internet.
Point-to-multipoint Mode
Bridges in point-to-multipoint
mode connect three or more
networks in scattered buildings
through wireless links. This
allows numerous sites in a
wide area to share resources,
including a single high-speed
connection to the Internet
Specifications
Standards Compliance IEEE802.11g, 11b
RF Spreading Method Direct Sequence Spread Spectrum (DSSS)
Transmission Rate 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps with auto fallback
22Mbps (Optional)
RF Output Power 802.11b: 17dBm (Typical)
802.11g: 14dBm (Typical)
Receive Sensitivity 54 Mbps OFDM, 10% PER, -70 dBm
48 Mbps OFDM, 10% PER, -72 dBm
36 Mbps OFDM, 10% PER, -77 dBm
24 Mbps OFDM, 10% PER, -81 dBm
22 Mbps PBCC, 10% PER, -82 dBm
18 Mbps OFDM, 10% PER, -84 dBm
12 Mbps OFDM, 10% PER, -86 dBm
11 Mbps CCK, 8% PER, -84 dBm
9 Mbps OFDM, 10% PER, -89 dBm
6 Mbps OFDM, 10% PER, -90 dBm
5.5 Mbps CCK, 8% PER, -87 dBm
2 Mbps QPSK, 8% PER, -88 dBm
1 Mbps BPSK, 8% PER, -91 dBm
Security 64/128/256-bit WEP; Wi-Fi Protected Access (WPA Q2 Support)
Software Support Kick Start (Advance discovery protocol for easy to use); Web-based Tool;
Bridge Auto Learning (Without the hassle of MAC number records); SNMP Support (Q2 Ready)
Environmental Requirements Operating Temperature: -20oto 70oC
Storage Temperature: -30oto 80oC
Humidity: 5% to 95%, non-condensing
Dimensions 165 X135 X 55 mm (6.52 X 5.34 X 2.17 in.)
Weight 1.13 kg.
Power Input voltage 12V DC; external power supply included (input voltage 100V to 240V AC)
Warranty One year, limited
* Product appearance and specifications are subject to change without prior notice.
s
s Outdoor Bridge Application Scenarios
802.11g Wireless Outdoor Bridge802.11g Wireless Outdoor Bridge
802.11g Wireless Outdoor Bridge802.11g Wireless Outdoor Bridge
NWH9250NWH9250
802.11g Wireless Outdoor Bridge Application Scenarios
