NEC AccuSync LCD203WXM User manual

www.necdisplay.com
General Desktop
NEC AccuSyncTM LCD Series
15" - 22" flat-panel monitors ideal for
small-to-medium businesses and educational settings
High-quality LCD monitors don’t necessarily have to be associated with high-end price tags. As flat-
panel display technology has advanced and become more mainstream, LCD monitors have become
increasingly affordable for a variety of users. NEC AccuSync LCD Series monitors have set a new
standard in value for this product category, offering you a perfect opportunity to take advantage of
the many benefits offered by flat-panel monitors without having to break your budget. The 15” NEC
AccuSync LCD52V, 17” NEC AccuSync LCD72VX and 19” NEC AccuSync LCD92VX deliver ideal
visual display solutions to small-to-medium-sized businesses and educational environments, as well
as general home users, whether you’re creating presentations, surfing the Internet or playing your fa-
vorite video game. The 15” NEC AccuSync LCD52VM, 17” NEC AccuSync LCD72VXM and 19” NEC
AccuSync LCD92VXM, which boast integrated, front-firing speakers, further expand your applica-
tion possibilities with their high-quality multimedia capabilities. The widescreen 19” NEC AccuSync
LCD193WXM, NEC AccuSync 203WXM and 22” NEC AccuSync 223WXM not only tout speakers
but provide roughly the same work area as two smaller-sized LCD screens, allowing you to simultane-
ously work in multiple application windows.
Enhanced screen performance. With contrast ratios as high as 1000:1 (typical) and brightness quality
much higher than CRTs at 300 cd/m2, outstanding LCD monitor front-of-screen visual performance
is NEC’s #1 goal. The AccuSync LCD Series delivers vibrant colors and flicker-free images that make
your time in front of the monitor more comfortable and productive. NEC’s Rapid ResponseTM technol-
ogy provides for uninterrupted display of full-motion video with response times as quick as 5ms. This
remarkably quick motion makes these models better than ever for gaming and video applications
such as presentations and streaming web video.
Wide compatibility for today and tomorrow. With Ambix® dual-input technology–which utilizes both
DVI-D and traditional 15-pin VGA connectors–you can bridge the gap between analog and digital
systems by allowing the same monitor to work seamlessly in either environment. Featured on all
models (except the AccuSync LCD52V and LCD52VM), Ambix provides compatibility with today’s
computer systems and is on the forefront of tomorrow’s digital output.
Series Features and Benefits
Exceptional screen performance provides a more
comfortable and productive visual experience
with crisp, sharp and accurate text and images
Rapid Response technology delivers virtually
uninterrupted, undistorted viewing of high-
speed, full-motion video
Wide-format screen increases productivity by
expanding your working area for multiple appli-
cation windows (LCD193WXM, LCD203WXM,
LCD223WXM)
Ambix dual-input technology allows for digi-
tal/analog compatibility with upgraded video
cards and software as well as connection to
two systems (all models except LCD52V and
LCD52VM)
Built-in, front-firing multimedia speakers
provide quality sound (LCD52VM, LCD72VXM,
LCD92VXM, LCD193WXM, LCD203WXM,
LCD223WXM)
Touch or protective glass integration-enabling
design increases application options (except
LCD193WXM, LCD203WXM and LCD223WXM)
On Screen Display (OSD®) puts you in complete
control of your screen setting adjustments
No Touch Auto AdjustTM reduces setup time
and provides optimal image settings upon initial
power-on
NaViSetTM software offers an expanded and
intuitive interface, allowing you to more easily
adjust display settings via mouse and keyboard
Wall/arm mounting capability adds flexibility
and comfort, while freeing up valuable desktop
space (using third-party product)
RoHS compliance ensures the displays are free
of lead, hex-chrome, cadmium, PBDE and PBB,
with reduced mercury
ENERGY STAR 4.0 compliance/low power
consumption reduces electrical costs and lowers
total cost of ownership
Windows® Vista certification maximizes
the monitor’s resolution capabilities (except
LCD52V and LCD52VM)
NEC Display Solutions’ quality and reliability
provide peace of mind with a 3-year limited parts
and labor warranty (including backlight) and 24/7
customer service and technical support

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
AccuSync LCD52V/VM*
15”
0.297mm
86 @ native resolution
250 cd/m2
400:1
110° Vert., 140° Hor.
(55U/55D/70L/70R)
(CR>5)
Rapid Response (16ms)
More than 16 million
31.5-60 KHz (Analog)
56.0-76.0 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level
(Positive/Negative)
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1024 x 768 @ 75 Hz
Thin-frame (bezel), tilt,
No Touch Auto Adjust,
touch screen compat-
ible, cable management,
digital smoothing, digital
controls, AccuColor
color control, On Screen
Manager user controls,
NaViSet software, DDC/
CI, Plug and Play (VESA
DDC2B), VESA DPMS
power management, ISO
13406-2 Class II
Designed for integration
AC 100-120V /
AC 220-240V
21 W
<2 W
13.6 x 13.9 x 6.5 in./
344.6 x 352.7 x 165.0mm
13.6 x 11.2 x 2.3 in./
344.6 x 285.0 x 57.5mm
7.1 lbs./3.2 kg
6.2lbs./2.8 kg
100 x 100mm
5-35° C/41-95° F
10-80%
3048m/10,000 ft.
-10-60° C/14-140° F
10-85%
12,192m/40,000 ft.
3 year parts and labor,
including backlight
24 hours/7 days
AccuSync LCD72VX/VXM**
17”
0.264mm
96 @ native resolution
270 cd/m2
600:1
170° Vert., 170° Hor.
(85U/85D/85L/85R)
(CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 KHz (Analog)
31.5-81.1 KHz (Digital)
56.0-76.0 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level
(Positive/Negative)
DVI-D and
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Thin-frame (bezel), tilt,
No Touch Auto Adjust,
touch screen compat-
ible, cable management,
digital smoothing, digital
controls, AccuColor
color control, On Screen
Manager user controls,
NaViSet software, DDC/
CI, Plug and Play (VESA
DDC2B), VESA DPMS
power management, ISO
13406-2 Class II, Win-
dows Vista-certified
Designed for integration
AC 100-120V /
AC 220-240V
30 W
<2 W
14.8 x 15.3 x 7.1 in./
375.4 x 389.0 x 180.0mm
14.8 x 12.9 x 2.4 in./
375.4 x 326.5 x 61.0mm
10.1 lbs./4.6 kg
9.3 lbs./4.2 kg
100 x 100mm
5-35° C/41-95° F
10-80%
3048m/10,000 ft.
-10-60° C/14-140° F
10-85%
12,192m/40,000 ft.
3 year parts and labor,
including backlight
24 hours/7 days
Model
Display
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Input
Resolutions Supported
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Dimensions (W x H x D)
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Net (without stand)
VESA Hole Configuration
Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
Ambix and OSD are registered trademarks, and
AccuSync, NaViSet, No Touch Auto Adjust and Rap-
id Response are trademarks of NEC Display Solutions.
All other brand or product names are trademarks or
registered trademarks of their respective holders.
Product specifications subject to change. 6/07 ver. 11.
©2007 NEC Display Solutions of America, Inc.
All rights reserved.
AccuSyncLCD92VX/VXM***
19”
0.294mm
86 @ native resolution
270 cd/m2
600:1
170° Vert., 170° Hor.
(85U/85D/85L/85R)
(CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 KHz (Analog)
31.5-81.1 KHz (Digital)
56.0-76.0 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level
(Positive/Negative)
DVI-D and
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Thin-frame (bezel), tilt,
No Touch Auto Adjust,
touch screen compat-
ible, cable management,
digital smoothing, digital
controls, AccuColor
color control, On Screen
Manager user controls,
NaViSet software, DDC/
CI, Plug and Play (VESA
DDC2B), VESA DPMS
power management, ISO
13406-2 Class II, Windows
Vista-certified
Designed for integration
AC 100-120V /
AC 220-240V
37 W
<2 W
16.5 x 16.8 x 7.9 in./
418.0 x 427.8 x 199.5mm
16.5 x 14.6 x 2.7 in./
418.0 x 369.8 x 68.0mm
14.3 lbs./6.5 kg
12.1 lbs./5.5 kg
100 x 100mm
5-35° C/41-95° F
10-80%
3048m/10,000 ft.
-10-60° C/14-140° F
10-85%
12,192m/40,000 ft.
3 year parts and labor,
including backlight
24 hours/7 days
AccuSync LCD193WXM
19”
0.284mm
89 @ native resolution
300 cd/m2
1000:1
176° Vert., 176° Hor.
(88U/88D/88L/88R)
(CR>5)
Rapid Response (5ms)
More than 16 million
31.5-81.1 KHz (Analog)
31.5-81.1 KHz (Digital)
56.0-76.0 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level
(Positive/Negative)
DVI-D and
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-76 Hz
1280 x 768 @ 60-75 Hz
1152 x 864 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-76 Hz
1360 x 768 @ 60 Hz
1440 x 900 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
Thin-frame (bezel),
widescreen format, tilt,
integrated speakers,
No Touch Auto Adjust,
cable management, digital
smoothing, digital controls,
AccuColor color control,
On Screen Manager user
controls, NaViSet software,
DDC/CI, Plug and Play
(VESA DDC2B), VESA
DPMS power manage-
ment, ISO 13406-2 Class II,
Windows Vista-certified
No
AC 100-120V /
AC 220-240V
39 W
<2 W
17.6 x 14.7 x 7.7 in./
447.3 x 374.6 x 196.2mm
17.6x 12.4 x 2.3 in./
447.3 x 314.4 x 58.8mm
12.1 lbs./5.5 kg
9.5 lbs./4.3 kg
100 x 100mm
5-35° C/41-95° F
30-80%
4572m/15,000 ft.
-10-60° C/14-140° F
10-85%
12,192m/40,000 ft.
3 year parts and labor,
including backlight
24 hours/7 days
* Aside from integrated speakers, LCD52VM specs are identical to those of the LCD52V
** Aside from integrated speakers, LCD72VXM specs are identical to those of the LCD72VX
*** Aside from integrated speakers, LCD92VXM specs are identical to those of the LCD92VX
AccuSync LCD223WXM
22”
0.282mm
84 @ native resolution
300 cd/m2
1000:1
176° Vert., 176° Hor.
(88U/88D/88L/88R)
(CR>5)
Rapid Response (5ms)
More than 16 million
31.5-82.3 KHz
(Analog/Digital)
56-75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level
(Positive/Negative)
DVI-D and
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-76 Hz
1152 x 864 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1440 x 1050 @ 60-75 Hz
1680 x 1050 @ 60-75 Hz
1680 x 1050 @ 60 Hz
Thin-frame (bezel),
widescreen format, tilt,
integrated speakers,
No Touch Auto Adjust,
cable management, digital
smoothing, digital controls,
AccuColor color control,
On Screen Display user
controls, NaViSet software,
DDC/CI, Plug and Play
(VESA DDC2B), VESA
DPMS power management,
ISO 13406-2 Class II,
Windows Vista-certified
No
AC 100-120V /
AC 220-240V
55 W
<2 W
20 x 15.7 x 7.7 in./
506.1 x 398.1 x 196.2mm
20 x 14 x 2.5 in./
506.1 x 354.7 x 64.3mm
14.3 lbs./6.5 kg
11.7 lbs./5.3 kg
100 x 100mm
5-35° C/41-95° F
30-80%
4572m/15,000 ft.
-10-60° C/14-140° F
10-85%
12,192m/40,000 ft.
3 year parts and labor,
including backlight
24 hours/7 days
AccuSync LCD203WXM
20.1”
0.258mm
89 @ native resolution
300 cd/m2
1000:1
170° Vert., 170° Hor.
(85U/85D/85L/85R)
(CR>5)
Rapid Response (5ms)
More than 16 million
31.5-82.3 KHz
(Analog/Digital)
56-75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level
(Positive/Negative)
DVI-D and
VGA 15 pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-76 Hz
1152 x 864 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1440 x 1050 @ 60-75 Hz
1680 x 1050 @ 60-75 Hz
1680 x 1050 @ 60 Hz
Thin-frame (bezel),
widescreen format, tilt,
integrated speakers,
No Touch Auto Adjust,
cable management, digital
smoothing, digital controls,
AccuColor color control,
On Screen Display user
controls, NaViSet software,
DDC/CI, Plug and Play
(VESA DDC2B), VESA
DPMS power management,
ISO 13406-2 Class II,
Windows Vista-certified
No
AC 100-120V /
AC 220-240V
49 W
<2 W
18.9 x 15.2 x 7.7 in./
478.9 x 386.8 x 196.2mm
18.9 x 13 x 2.5 in./
478.9 x 330.1 x 64.3mm
13.4 lbs./6.1 kg
10.8 lbs./4.9 kg
100 x 100mm
5-35° C/41-95° F
30-80%
3048m/10,000 ft.
-10-60° C/14-140° F
10-85%
12,192m/40,000 ft.
3 year parts and labor,
including backlight
24 hours/7 days
