NEC MultiSync LCD1550M LCD1550M LCD1550M User manual

MultiSync LCD1550M
User’s Manual

English-1
English
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE. ALSO, DO NOT USETHIS UNIT’S POLARIZED PLUG WITH AN
EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS
CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE
COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK).NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This symbol warns user that uninsulated voltage within the unit may have
sufficient magnitude to cause electric shock.Therefore, it is dangerous to make
any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation
and maintenance of this unit has been included.Therefore, it should be read
carefully in order to avoid any problems.
CAUTION
WARNING
RISK OF ELECTRIC SHOCK •DO NOT OPEN
Caution:
When operating the MultiSync LCD1550M (LA-15R03 and LA-15R03-BK) with a
220-240V AC power source in Europe, use the power cord provided with the monitor.
In the UK, a BS approved power cord with a moulded plug has a Black (five Amps) fuse
installed for use with this equipment. If a power cord is not supplied with this equipment
please contact your supplier.
When operating the MultiSync LCD1550M with a 220-240V AC power source in
Australia, use the power cord provided with the monitor.
For all other cases, use a power cord that matches the AC voltage of the power outlet
and has been approved by and complies with the safety standard of your particular
country.
ENERGYSTAR is a U.S.trademark.
As an ENERGYSTAR®Partner, NEC-Mitsubishi Electronics Display of America, Inc. has
determined that this product meets the ENERGYSTAR guidelines for energy efficiency.
The ENERGYSTAR emblem does not represent EPA endorsement of any product or service.
IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of
International Business Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer Inc.
Microsoft and Windows are registered trademarks of the Microsoft Corporation.
NEC is a registered trademark of NEC Corporation.
All other trademarks or registered trademarks are property of their respective owners.

English-2
Declaration
Declaration of the Manufacturer
We hereby certify that the colour monitor
MultiSync LCD1550M (LA-15R03)
MultiSync LCD1550M (LA-15R03-BK)
is in compliance with
Council Directive 73/23/EEC:
–EN 60950
Council Directive 89/336/EEC:
–EN 55022
–EN 61000-3-2
–EN 61000-3-3
–EN 55024
and marked with
NEC-Mitsubishi Electric Visual Systems, Corp.
MS Shibaura Bldg., 13-23,
Shibaura 4-chome,
Minato-Ku, Tokyo 108-0023, Japan
Power consumption of the monitor is less
than 3W when in power-saving mode.

English-3
English
For the Customer to use in
U.S.A. or Canada
Canadian Department of Communications
Compliance Statement
DOC: This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Règlement sur le matériel brouiller du Canada.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety
Regulations according to CSA C22.2 #950.
Ce produit porte la marque ‘C-UL’et se conforme aux règlements de
sûrele Canadiens selon CAN/CSA C22.2 No. 950.
FCC Information
1. Use the attached specified cables with the MultiSync LCD1550M
colour monitor so as not to interfere with radio and television
reception.
(1)The power supply cord you use must have been approved by and
comply with the safety standards of U.S.A., and meet the following
condition.
Power supply cord Non shield type, 3-conductor
Length 1.8 m
Plug shape
(2)Shielded video signal cable. Use of other cables and adapters
may cause interference with radio and television reception.

English-4
2. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.This equipment
generates, uses, and can radiate radio frequency energy, and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
•Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced
radio/television technician for additional suggestions.The user may
find the following booklet, prepared by the Federal Communications
Commission, helpful:“How to Identify and Resolve Radio-TV
Interference Problems.”This booklet is available from the U.S.
Government Printing Office, Washington, D.C., 20402,
Stock No. 004-000-00345-4.
Declaration of Conformity
This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions. (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
U.S. Responsible party: NEC-Mitsubishi Electronics
Display of America, Inc.
Address: 1250 N. Arlington Heights Road
Itasca, Illinois 60143-1248
Tel. No.: [phone]
Type of Product: Computer Monitor
Equipment Classification: Class B Peripheral
Models: MultiSync LCD1550M
We hereby declare that the equipment specified above conforms
to the technical standards as specified in the FCC Rules.

English-5
English
Contents
Your new NEC MultiSync LCD monitor box* should contain the following:
•MultiSync LCD1550Mmonitor with tilt/swivel base
•Power Cord(s)
•Video Signal Cable
•Audio Cable
•USB Cable
•User’s Manual
•CD ROM (includes complete User’s Manual in PDF format).To see
the User’s Manual, Acrobat Reader 4.0 must be installed on your PC.
* Remember to save your original box and packing material to transport
or ship the monitor.
1550M

English-6
Quick Start
To attach the MultiSync LCD monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. Remove connector cover and cable cover. Connect the audio cable to
“AUDIO INPUT”on the back of the monitor and the other end to the
“Audio out”terminal of the computer. Place the Audio cable under
Clip B (Figure A.1).
3. For PC: Connect the 15-pin mini D-SUB of the appropriate
signal cable to the connector for the display card in your system
(Figure B.1).Tighten all screws.
For Mac: Connect the MultiSync LCD1550M Macintosh cable
adapter to the computer (Figure C.1). Attach the 15-pin mini D-SUB
end of the appropriate signal cable to the MultiSync LCD1550M
Macintosh cable adapter (Figure C.1).Tighten all screws.
4. Connect the 15-pin mini D-SUB of the video signal cable to the
appropriate connector on the back of the monitor (Figure D.1). Place
the Video Signal Cable under Clip B.
5. Headphones may be connected to the “Headphones”output on the
front of the monitor’s bezel marked “”(Figure E.1).While the
headphones are connected, the sound from the speakers will be
disabled. Headphones can be purchased from your local electronics
store.
6. Using the USB cable, connect the B type connector to the USB
upstream port on the right side of the monitor and A type connector
to the downstream part on the computer (Figure F.1). If you are using
the cord from the USB device, use one of the downstream port on
the side of the monitor (Figure G.1).
7. Connect one end of the power cord to the MultiSync LCD Series
monitor and the other end to the power outlet. Place the video signal
cable and AC power cord under the clips (Figure D.1). Replace
connector cover and cable cover.
NOTE: Adjust the position of the cable under the clips to avoid damage
for cable or monitor.
NOTE: Please refer to Caution section of this manual for proper
selection of AC power cord.

English-7
English
8. The Vacation Switch on the left side of the monitor must be turned on
(Figure H.1).Turn on the monitor with the Power Button and the
computer.
NOTE: The Vacation Switch is a true on/off switch. If this switch is on
the OFF position, the monitor cannot be turned on using the
front button DO NOT switch on/off repeatedly.
9. No-touch auto adjust automatically adjusts the monitor to optimal
settings upon initial setup for most timings.For further adjustments,
use the following OSM controls:
•Auto Adjust Contrast
•Auto Adjust
Refer to the Controls section of this User’s Manual for a full description
of these OSM controls.
NOTE: If you have any problems, please refer to the Troubleshooting
section of this User’s Manual.
Figure C.1
Macintosh
Cable
Adapter
(not included)
Macintosh G3
and G4 do not
need a
Macintosh cable
adapter
Figure B.1
Figure A.1
Clip B

English-8
Figure E.1
Figure D.1
Figure F.1
Figure G.1
Connector cover
Cable cover
Clip B
A Type
B Type

English-9
English
Tilt and Swivel
Grasp both sides of the monitor screen with your hands and adjust the
tilt and swivel as desired (FigureTS.1).
Remove Monitor Stand for Mounting
To prepare the monitor for alternate mounting purposes:
1. Remove the connector cover and cable cover (Figure R.1).
2. Disconnect all cables.
3. Place monitor face down on a non-abrasive surface (Figure R.2).
4. Remove the 4 screws connecting the monitor to the stand and lift off
the stand assembly (Figure R.2) the monitor is now ready for
mounting in an alternate manner.
5. Connect the AC cord, signal cable and audio cable to the back of the
monitor (Figure R.3).
6. Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method.When
the monitor stand is removed, the USB capabilities will be
disabled.
Vacation Switch Power Button
1550M
Figure H.1

English-10
Figure R.1
Figure R.2
FigureTS.1
Non-abrasive
surface

English-11
English
7. This LCD monitor is designed for use with a flexible arm. Please use
the attached screws (4pcs) when mounting.To meet the safety
requirements the monitor must be mounted to an arm which
guaranties the necessary stability under consideration of the weight
of the monitor.The LCD monitor shall only be used with an approved
arm (e.g. GS mark).
Figure R.3
4 SCREWS
(MAX depth: 8.6 mm)
If use other screw,
check depth of hole.
Weight of LCD assembly: 3.5kg (MAX)
Replace screws
Tighten all screws
Thickness of bracket (arm)
2.0 ~ 3.2 mm
75 mm
75 mm

English-12
Sound
VOLUME
Control the sound volume of speakers and headphone.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen
brightness.
Menu
Exits the OSM controls.
Exits to the OSM main menu.
Moves the highlighted area left/right to select control
menus.
Moves the highlighted area up/down to select one of the
controls.
Moves the bar left/right to increase or decrease the
adjustment.
Activates Auto Adjust function.
Enter the sub menu.
Moves the highlighted area of main menu right to select
one of the controls.
Resets the highlighted control to the factory setting.
When no OSM menu is shown, the speaker sound will be
muted.
Controls
OSM (On-Screen-Manager) Controls
The OSM controls on the front of the monitor function as follows:
To access OSM press any of the control buttons ( ,, -,+,NEXT).
NOTE: When RESET is pressed in the main and sub-menu, a warning
window will appear allowing you to cancel the RESET function
by pressing the EXIT button.
Control
EXIT
CONTROL /
ADJUST -/+
NEXT
RESET/MUTE

English-13
English
CONTRAST
Adjusts the image brightness in relation to the
background.
AUTO ADJUST
Adjusts the image displayed for non-standard
video inputs.
Auto Adjust
Automatically adjusts the Image Position, the H. Size
and Fine setting.
Position Controls
LEFT/RIGHT
Controls Horizontal Image Position within the display
area of the LCD.
DOWN/UP
Controls Vertical Image Position within the display area
of the LCD.
H. SIZE
Adjusts the horizontal size by increasing or decreasing
this setting.
FINE
Improves focus, clarity and image stability by increasing
or decreasing this setting.
Colour Control Systems
Six colour presets select the desired colour setting
(sRGB and NATIVE colour presets are standard and
cannot be changed). Colour temperature increases or
decreases in each preset.
R,Y,G,C,B,M,S
Increases or decreases Red,Yellow, Green, Cyan, Blue,
Magenta and Saturation depending upon which is
selected.The change in colour will appear on screen
and the direction (increase or decrease) will be shown
by the colour bars.

English-14
sRGB
sRGB mode dramatically improves the colour fidelity in
the desktop environment by a single standard RGB
colour space.With this colour supported environment,
the operator could easily and confidently communicate
colours without further colour management overhead in
the most common situations.
NATIVE
Original colour presented by the LCD panel that is
unadjustable.
Tools LANGUAGE
OSM control menus are available in seven languages.
OSM POSITION
You can choose where you would like the OSM control
image to appear on your screen. Selecting OSM
Location allows you to manually adjust the position of
the OSM control menu left, right, down or up.
OSMTURN OFF
The OSM control menu will stay on as long as it is use.
In the OSM Turn Off submenu, you can select how long
the monitor waits after the last touch of a button to shut
off the OSM control menu.The preset choices are 10,
20, 30, 45, 60 and 120 seconds.
OSM LOCK OUT
This control completely locks out access to all OSM
control functions.When attempting to activate OSM
controls while in the Lock Out mode, a screen will
appear indicating the OSM controls are locked out.
To activate the OSM Lock Out function, press , then
and hold down simultaneously.To de-activate the OSM
Lock Out, press , then and hold down
simultaneously.
RESOLUTION NOTIFIER
This optimal resolution is 1024 x 768. If ON is selected,
a message will appear on the screen after 30 seconds,
notifying you that the resolution is not at 1024 x 768.

English-15
English
FACTORY PRESET
Selecting Factory Preset allows you to reset all OSM
control settings back to the factory settings.The RESET
button will need to be held down for several seconds to
take effect.Individual settings can be reset by
highlighting the control to be reset and pressing the
RESET button.
Information
DISPLAY MODE
Indicates the current display resolution and frequency
setting of the monitor.
MONITOR INFO.
Indicates the model and serial numbers of your monitor.
OSM Warning
OSM Warning menus disappear with Exit button.
NO SIGNAL: This function gives a warning when there
is no signal present. After power is turned on or when
there is a change of input signal or video is inactive, the
No Signal window will appear.
RESOLUTION NOTIFIER: This function gives a
warning of use with optimized resolution.After power is
turned on or when there is a change of input signal or
the video signal doesn’t have proper resolution, the
Resolution Notifier window will open.This function can
be disabled in the TOOL menu.
OUT OF RANGE: This function gives a
recommendation of the optimized resolution and refresh
rate. After the power is turned on or there is a change of
input signal or the video signal doesn’t have proper
timing, the Out Of Range menu will appear.
CHECK CABLE: This function will advise you to check
all Video Inputs on the monitor and computer to make
sure they are properly connected.

English-16
Recommended Use
Safety Precautions and Maintenance
FOR OPTIMUM PERFORMANCE, PLEASE NOTE
THE FOLLOWING WHEN SETTING UP AND
USING THE MULTISYNC LCD COLOUR MONITOR:
•DO NOT OPENTHE MONITOR. There are no user serviceable parts
inside and opening or removing covers may expose you to dangerous
shock hazards or other risks.Refer all servicing to qualified service
personnel.
•Do not spill any liquids into the cabinet or use your monitor near water.
•Do not insert objects of any kind into the cabinet slots, as they may
touch dangerous voltage points, which can be harmful or fatal or may
cause electric shock, fire or equipment failure.
•Do not place any heavy objects on the power cord. Damage to the cord
may cause shock or fire.
•Do not place this product on a sloping or unstable cart, stand or table, as
the monitor may fall, causing serious damage to the monitor.
•Do not place any objects onto the monitor and do not use the monitor
outdoors.
•The inside of the flourescent tube located within the LCD monitor
contains mercury. Please follow the bylaws or rules of your municipality
to dispose of the tube properly.
Immediately unplug your monitor from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
•When the power supply cord or plug is damaged.
•If liquid has been spilled, or objects have fallen into the monitor.
•If the monitor has been exposed to rain or water.
•If the monitor has been dropped or the cabinet damaged.
•If the monitor does not operate normally by following operating
instructions.
•Do not bend power cord.
•Do not use monitor in high temperatured, humid, dusty, or oily areas.
•Do not cover vent on monitor.
•If monitor is broken, do not come in contact with the liquid crystal.
•If glass is broken.Handle with care.

English-17
English
CAUTION
•Allow adequate ventilation around the monitor so that
heat can properly dissipate. Do not block ventilated
openings or place the monitor near a radiator or other
heat sources. Do not put anything on top of monitor.
•The power cable connector is the primary means of
detaching the system from the power supply.The
monitor should be installed close to a power outlet which
is easily accessible.
•Handle with care when transporting. Save packaging for
transporting.
CORRECT PLACEMENT AND ADJUSTMENT OF
THE MONITOR CAN REDUCE EYE, SHOULDER
AND NECK FATIGUE. CHECK THE FOLLOWING
WHENYOU POSITION THE MONITOR:
•For optimum performance, allow
20 minutes for warm-up.
•Adjust the monitor height so that the top of
the screen is at or slightly below eye level.
Your eyes should look slightly downward
when viewing the middle of the screen.
•Position your monitor no closer than 40 cm
and no further away than 70 cm from your
eyes.The optimal distance is 53 cm.
•Rest your eyes periodically by focusing on
an object at least 6 m away. Blink often.
•Position the monitor at a 90°angle to windows and other light sources to
minimize glare and reflections. Adjust the monitor tilt so that ceiling lights
do not reflect on your screen.
•If reflected light makes it hard for you to see your screen, use an
antiglare filter.
•Clean the LCD monitor surface with a lint-free, non-abrasive cloth. Avoid
using any cleaning solution or glass cleaner!
•Adjust the monitor’s brightness and contrast controls to enhance
readability.
•Use a document holder placed close to the screen.
•Position whatever you are looking at most of the time (the screen or
reference material) directly in front of you to minimize turning your head
while you are typing.

English-18
•Avoid displaying fixed patterns on the monitor for long periods of time to
avoid image persistence (after-image effects).
•Get regular eye checkups.
Ergonomics
To realize the maximum ergonomics benefits, we recommend the following:
•Use the preset Size and Position controls with standard signals.
•Use the preset Colour Setting.
•Use non-interlaced signals with a vertical refresh rate between
60-75 Hz.
•Do not use primary colour blue on a dark background, as it is difficult to
see and may produce eye fatigue to insufficient contrast.

English-19
English
16,777,216
31.5 kHz to 60.0 kHz
56.2 Hz to 75.1 Hz
720 x 400*1:VGA text
640 x 480*1at 60 Hz to 75 Hz
800 x 600*1at 56 Hz to 75 Hz
832 x 624*1at 75 Hz
1024 x 768*2at 60 Hz to 75 Hz
304 mm/12 inches
228 mm/9.0 inches
AC 100-120 V/220-240 V 50/60 Hz
0.9 A @ 100-120 V, 0.5 A @ 220-240 V
Monitor Specifications
LCD Module Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
Display Colours Analog input:
Synchronization Range Horizontal:
Vertical:
Resolutions Supported
Active Display Horizontal:
Area Vertical:
Power Supply
Input Signal Video:
Sync:
Current Rating
MultiSync LCD1550M Monitor
38 cm/15 inches
38 cm/15 inches
1024 x 768
ANALOG 0.7 Vp-p/75 Ohms
Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Notes
Active matrix; thin film
transistor (TFT) liquid
crystal display (LCD);
0.30 mm dot pitch;
300cd/m2white luminence,
typical; 450:1 contrast ratio,
typical.
Depends on display card
used.
Automatically
Automatically
Some systems may not
support all modes listed.
Dependent upon signal
timing.
Specifications
Viewing Angle Left/Right:
Up/Down: ± 75°
+ 50°/- 60°
345.2 mm (W) x 362.6 mm (H) x 162.0 mm (D)
13.6 inches (W) x 14.3 inches (H) x 6.4 inches (D)
5 °C to 35 °C
30% to 80%
0 to 3,000 m
-10 °C to +60 °C
10% to 85%
0 to 9,500 m
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Altitude:
Storage Temperature:
Humidity:
Altitude:
4.5 kg (9.9 lbs)
USB Specification Revision 1.1
Upstream 1
Downstream 4
Maximum 0.5A per port
USB HUB I/F:
Port:
Load Current:
Speakers Practical Audio Output 1.0W + 1.0W
