NEC P Series
40”, 46”, 52”, 55” and 70” professional-grade, full high-definition LCD displays
ideal for digital signage applications
Large-Screen LCD
Expand your messaging options with superior screen performance.
The NEC P Series, featuring the 40” P401, 46” P461, 52” P521,
55” P551 and 70” P701, provides a first-class solution for your digital signage
applications. Its high contrast, industrial-strength design and Enhanced Digital
Signage Technology Suite (DSTS), which boasts more than 30 advanced features,
make these displays ideal for 24/7 operation in even the harshest environments.
These include airports, public information, healthcare, retail
and other areas that require a combination of dazzling images
and the highest level of display management. The built-in
expansion slot future-proofs your display investment,
allowing for seamless integration of NEC and third-party
components. Plus, the capability to easily integrate
touchscreen technology or protective glass opens
these models up to even more applications,
including wayfinding and high-traffic areas. The
P701’s massive screen turns heads in corporate
boardrooms as well as rental and staging
applications. Advantages include a wide array of
inputs, including DisplayPort, unrivaled control and
communication options and enhanced video wall
capabilities. The P551’s 120 Hz refresh rate
reduces typical blur seen in fast-moving images
and text that is noticeable at the standard 60 Hz
refresh rate. It also shows increased definition
between images, giving you more lifelike viewing.
DIGITAL SIGNAGE TECHNOLOGY SUITE
INTEGRATED THERMAL PROTECTION
SEALED PANEL DESIGN
ENHANCED VIDEO WALL CAPABILITIES
ECO-FRIENDLY FEATURES
BUILT-IN EXPANSION SLOT
EXTENSIVE CONTROL, DIAGNOSTICS & COMMUNICATION
REAL-TIME CLOCK/ROUND-THE-CLOCK SCHEDULING
CABLECOMP+™ TECHNOLOGY
BUILT-IN TUNER (-AVT MODELS)
P SERIES HIGHLIGHTS

P Series Key Features
24/7 full-HD commercial SPVA panels
The professional-grade construction of P Series panels contributes to 24/7 usage, an overall longer panel life, lower likelihood of mura
effect from localized heat, virtually no image retention and the ability to use in landscape or portrait orientations. The panel’s thermal
protection starts with an extra thermal layer on the display panel to diffuse heat, followed by multi-fan-based technology specially
designed to work in both landscape and portrait modes and be controlled locally or remotely. Internal temperature sensors control self-
protective circuits, while special self-diagnostics communicate the status of the thermal characteristics.
P Series panel construction includes:
• Thermal dissipation plate, placed behind the LCD lamps, conducts heat
equally across the plate, preventing “hot spots” on the LCD
• Backlight layer (or lamps) determines the brightness of the display but is
also a key heat component
• Wider air layer allows for increased airflow and improved heat dissipation
• Heat protection plate, located between the LCD panel and the lamps,
provides added heat protection to the panel
• Panel is sealed, preventing contaminants like dust, grease or steam from
damaging the panel*
Green technology helps lead to a lower total cost of ownership
Eco-friendly features are aplenty in the P Series, decreasing energy consumption, lowering your expenses
over the lifecycle of the display and contributing to your environmental consciousness. These include:
• Ambient light sensor ensures consistent brightness no matter the lighting conditions, while
allowing the user to set the brightness level to a pre-determined lower level in order to
automatically compensate and reduce the brightness, thus decreasing power consumption
• Carbon footprint meter helps track and calculate the conservation of green gas emissions in real time
• Real-time clock/round-the-clock scheduling allows for advanced scheduling of monitor powering up/
down, increasing panel lifetime, reducing power consumption and saving the time and expense of
finding and purchasing a third-party scheduling solution
• ENERGY STAR 5.0 is proudly offered for most P Series displays, which meet strict energy efficiency guidelines set by the U.S.
Environmental Protection Agency and the U.S. Department of Energy, helping you save money and reduce greenhouse gas emissions
• Cold cathode fluorescent lamp (CCFL) backlighting quantity has been lowered compared to predecessors, maintaining high
brightness while reducing the power consumption and increasing the life of the panel and contrast ratio
Built-in technology to support video wall configurations
Select P Series displays’ thin-bezel design and enhanced video wall capabilities allow you to expand your messaging options.
Technologies include:
• TileMatrix™ allows you to create video walls (up to 100 displays in
a 10x10 matrix)
• TileComp™ works in tandem with TileMatrix to compensate for the
bezel width and create a more seamless video wall
• Copy function allows the user to apply the settings from one
display to all others in the RS-232 daisy chain, reducing setup time
and saving money
• Individual and Group ID functions allow users to control settings for
a defined individual display or group of displays within a video wall
• Optional Display Wall Calibrator Kit
(KT-46UN-CC; pictured) provides a
quick, accurate and easy-to-use
means of automatically matching all
displays in color and brightness to
create uniformity across the video wall
*use under the environmental conditions noted in the specifications and user’s manual

Full connectivity and control with the option for expansion in every display
The P Series touts the industry’s most extensive control, diagnostics and communication, providing the highest level of remote display
management. These include:
• RS-232 enables multi-display control and daisy chain, allowing for individual and group-addressable control, and simple,
effective setup and monitoring of the display
• Ethernet connectivity adds the same RS-232 control plus automatic email notification for diagnostic purposes
• NaViSet™ software offers an intuitive graphical interface, allowing for easy adjustment of display settings via mouse and
keyboard. NaViSet Administrator provides all the advanced control to remotely located IT professionals.
• DDC/CI standard allows for PC control of the display based on the VESA command set
• CableComp+ uses a digitized signal delay circuit to automatically compensate for each red, green and blue cable’s length and
video signal delay, ensuring sharp image reproduction despite long cables and low output level*
A built-in expansion slot future-proofs your display investment, allowing for seamless integration of optional NEC and third-party
components, including:
• HD-SDI card (SB-L007KK): Achieve broadcast-grade video with this internal card that provides an HD-SDI input without using
additional space or power.
• Single board computer (NET-SBC-01/02/03)**: This option provides for a seam less internal PC solution that is both cost-efficient and
flexible. It eliminates the need for external cabling, mounting and power supply, provid ing for a clean look that simplifies installation
and reduces maintenance.
• DVI daisychain (SB-L008WU): Loop in and out a single digital video signal to up to nine displays with this option, which eliminates
the need for external distribution equipment and power supply. These benefits make the board ideal for video banners, ribbons and
walls in addition to back-to-back installations.
• Digital IP tuner (MPD-DTi): This IPTV card enables you to stream up to 1080p content directly to the display as well as
ATSC/NTSC/Clear QAM signals. Other features include auto scan, DTV signal strength, parental controls, closed caption and
network settings—all adjustable from the display.
• CAT5 receiver: Using NEC-approved third-party solutions, you’ll be able to safely send your video over longer distances.
The P Series sets the standard for connectivity. Improved input options include quick input change, customized detection and naming.
See below for the complete list of P Series input/output terminals.
RS-232 In/Out
Speaker Out
5 BNC Out (RGBHV,
DVD/HD or
Composite Video)
5 BNC In (RGBHV,
DVD/HD or Composite
Video)
HDMI In
VGA D-Sub In Audio
Mini-Jack In
BNC Composite
Video Out
RCA Component
Video In
BNC Composite Video In
DisplayPort
In
DVI-D In
RCA Audio
In/Out
RCA
Composite
Video In
S-Video
In
LAN Port
IR In/Out
*use under the environmental conditions noted in the specifications and user’s manual *use under the environmental conditions noted in the specifications and user’s manual
** Available in Summer 2010
P401: 5.5 in.
P461: 5.5 in.
P521: 5.8 in.
P551: 5.9 in.
P701: 7.8 in.
P401: 36.2 in.
P461: 41.6 in.
P521: 47.2 in.
P551: 49.2 in.
P401: 34.9 in.
P461: 40.1 in.
P521: 45.4 in.
P551: 47.6 in.
P701: 66.1 in.
P701: 61 in.

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
CableComp+, NaViSet, SpectraViewII, TileComp and TileMatrix
are trademarks of NEC Display Solutions. All other brand or
product names are trademarks or registered trademarks of their
respective holders. Product specifications subject to change.
6/10 ver. 6.
©2010 NEC Display Solutions of America, Inc. All rights reserved.

MODEL P401 P461 P521 P551 P701
LCD MODULE
Viewable Size (Diagonal) 40” 46” 52” 55” 70”
Panel Technology SPVA
Native Resolution 1920 x 1080
Pixel Pitch 0.46mm 0.53mm 0.60mm 0.63mm 0.81mm
Brightness (Typical/Maximum) 500 cd/m2 / 650 cd/m2500 cd/m2 / 700 cd/m2420 cd/m2 / 600 cd/m2
Contrast Ratio (Typical) 3000:1 4000:1 2000:1 3000:1 2000:1
Active Screen Area (W x H) 34.9 x 19.6 in. / 885.6 x 498.2mm 40.1 x 22.5 in. / 1018.1 x 572.7mm 45.4 x 25.5 in. / 1152 x 648mm 47.6 x 26.8 in. / 1209.6 x 680.4mm 61 x 34.3 in. / 1549 x 871.6mm
CONNECTIVITY
Input Terminals
Digital DisplayPort, HDMI, DVI-D
Analog VGA 15-pin D-sub, 5 BNC (RGBHV, DVD/HD, or Video), RCA Composite, BNC Composite, RCA (Y, Cb/Pb, Cr/Pr) Component, S-Video
Audio RCA Audio x 2, Stereo Mini-Jack, DisplayPort Audio, HDMI Audio
External Control RS-232C, Ethernet (RJ45), IR Remote, DDC/CI
Output Terminals
Analog 5 BNC (RGBHV, DVD/HD, or Video), BNC Composite
Audio RCA Audio, External Speaker Jack x 2
External Contrel RS-232C, IR Remote
Audio Amplifier 15W Stereo
Digital Tuner P401-AVT P461-AVT P521-AVT P551-AVT P701-AVT
FEATURES
Additional Features Thin bezel (P701-standard bezel), advanced thermal capabilities, sealed professional panel, expansion slot, Ethernet Control and Communication, CableComp+, TileMatrix
(10x10), TileComp, programmable lookup tables, Plug and Play (DDC/CI, DDC2B), PIP (remote), POP, 6-axis color adjustment, multi-level programmable zoom, scheduler (w/
RTC), sharpness/softness, off-timer (countdown), screen saver, vacation switch, 10-bit gamma, AutoBright (signal input), Windows Vista-certified, IR, portrait-capable, metal
rear cabinet, handles, touch- and protective screen-ready, ambient light sensor, carbon footprint meter, color temperature adjustment (2600-10,000K)
POWER
Power Requirements 3.5 A@100-120V 1.45 A@220-240V 3.9 A@100-120V 1.6 A@220-240V 4.9 A@100-120V 2.0 A@220-240V 5.3A@100-120V 2.2A@220-240V 9.2 A@100-120V 3.7 A@220-240V
Power Consumption (Typical) 175W 210W 290W 280W 600W
Power Consumption - Standby Mode <1W
PHYSICAL SPECIFICATIONS
Bezel Width (L/R, T/B) 0.6 in./0.6 in., 0.6 in./0.6 in. ;
15.5mm/15.5mm, 15.5mm/15.5mm
0.7 in./0.7 in., 0.6 in./0.6 in. ;
17mm/17mm, 16.5mm/16.5mm
0.7 in./0.7 in., 0.7 in./0.7 in. ;
19mm/19mm, 19mm/19mm
0.8 in./0.8 in., 0.8 in./0.8 in. ;
20.3mm/20.3mm, 20.3mm/20.3mm
2.5 in./2.5 in., 2.5 in./2.5 in. ;
62.4mm/62.4mm, 63.4mm/63.4mm
Dimensions (without stand; WxHxD) 36.2 x 21 x 5.5 in. /
919.7 x 532.2 x 140mm
41.6 x 24 x 5.5 in. /
1055.4 x 608.6 x 140mm
47.2 x 27.4 x 5.8 in. /
1200 x 696 x 147.5mm
49.2 x 28.4 x 5.9 in. /
1250 x 721 x 150mm
66.1 x 39.5 x 7.8 in. /
1680 x 1004 x 198mm
Packaging Dimensions (WxHxD) 42.3 x 26.9 x 11.8 in. /
1074 x 682 x 300mm
46.5 x 30.8 x 11.8 in. /
1180 x 782 x 300mm
58.3 x 34.9 x 13.1 in. /
1481 x 886 x 334mm
60.5 x 37.1 x 13.1 in. / 1537 x
942 x 334mm
78 x 49.6 x 22 in. /
1980 x 1260 x 560mm
Net Weight (without stand) 51.8 lbs. / 23.5 kg 62.8 lbs. / 28.5 kg 83.3 lbs. / 37.8 kg 88.2 lbs. / 40 kg 211.6 lbs. / 96 kg
Gross Weight (with box) 66.1 lbs. / 30 kg 82.2 lbs. / 37.3 kg 110.2 lbs. / 50 kg 110.2 lbs. / 50 kg 253.5 lbs. / 115 kg
VESA Hole Configuration 300 x 300mm (4 hole) 400 x 400mm (4 hole)
ENVIRONMENTAL CONDITIONS
Operating Temperature 5-40°C / 41-104°F
Operating Humidity 20-80%
ACCESSORIES
Included Power cord, 15-pin D-sub cable, setup sheet, wireless remote control, batteries, main switch cover, CD-ROM (user manual)
Optional
NEC Tilt wall mount kit (WMK-3257), stand (ST-4020/ST-4620), speakers
(SP-P4046), internal HD-SDI card (SB-L007KK), DVI daisychain (SB-
L008WU), DisplayWall Calibrator Kit (KT-46UN-CC), SpectraViewII
Color Calibration Kit (SVII-PRO-KIT), digital IP tuner (MPD-DTi),
internal single board computer (NET-SBC-01/02/03)*, external single
board computer (TNETPC-ION)*
Stand (ST-5220), speaker (SP-
PS52), tilt wall mount kit (WMK-
3257), display wall calibrator
kit (KT-46UN-CC), SpectraViewII
color calibration kit (SVII-PRO-
KIT), NEC internal DVI daisy
chain (SB-L008WU), NEC internal
HD/SDI card (SB-L007KK), digital
IP tuner (MPD-DTi), internal
single board computer (NET-
SBC-01/02/03)*, external single
board computer (TNETPC-ION)*
Stand (ST-5220), rear-mounted
speaker (SP-RM1), tilt wall mount
kit (WMK-3257), display wall
calibrator kit (KT-46UN-CC),
SpectraViewII color calibration
kit (SVII-PRO-KIT), NEC internal
DVI daisy chain (SB-L008WU),
NEC internal HD/SDI card
(SB-L007KK), digital IP tuner
(MPD-DTi), internal single board
computer (NET-SBC-01/02/03)*,
external single board computer
(TNETPC-ION)*
Stand (ST-701), rear-mounted
speaker (SP-RM1), display wall
calibrator kit (KT-46UN-CC),
SpectraViewII color calibration
kit (SVII-PRO-KIT), NEC internal
DVI daisy chain (SB-L008WU),
NEC internal HD/SDI card
(SB-L007KK), digital IP tuner
(MPD-DTi), internal single board
computer (NET-SBC-01/02/03)*,
external single board computer
(TNETPC-ION)*
Third Party TTUFF single board computer (APE-20HD-NEC; DPE-80HD-NEC), TTUFF media player (DMD-80HD-NEC),
Magenta CAT5 receiver (NEC600), and Minicom CAT5 receiver (360’: 0VS51010NEC, 1000’: 0VS51001NEC)
Chief wall mount kit (XSMU),
Peerless universal wall mounts
(SF670; ST670 [tilt]), TTUFF sin-
gle board computer (APE-20HD-
NEC; DPE-80HD-NEC), TTUFF
media player (DMD-80HD-
NEC), Magenta CAT5 receiver
(NEC600), and Minicom CAT5
receiver (360’: 0VS51010NEC,
1000’: 0VS51001NEC)
WARRANTY/SERVICE
Limited Warranty 3 years parts and labor, including backlight**
Specifications for P401/P461/P521/P551/P701
* Available in Summer 2010
** Warranty restrictions apply. Contact your representative for details.
