NEC MultiSync V984Q User manual

Please find your model name in the label on the rear side of monitor.
MODEL: V754Q, V864Q, V984Q
User’s Manual
Large Format Display
MultiSync V754Q
MultiSync V864Q
MultiSync V984Q

Index
DECLARATION OF CONFORMITY..................................................................................................................................English-1
Important Information........................................................................................................................................................English-2
WARNING..........................................................................................................................................................English-2
CAUTION...........................................................................................................................................................English-2
Safety Precautions, Maintenance & Recommended Use .................................................................................................English-3
Safety Precautions and Maintenance................................................................................................................English-3
Recommended Use...........................................................................................................................................English-3
Ergonomics........................................................................................................................................................English-3
Cleaning the LCD Panel ....................................................................................................................................English-4
Cleaning the Cabinet .........................................................................................................................................English-4
Installation.........................................................................................................................................................................English-5
Attaching Mounting Accessories........................................................................................................................English-7
Parts Name and Functions................................................................................................................................................English-10
Control Panel.....................................................................................................................................................English-10
Terminal Panel...................................................................................................................................................English-11
Wireless Remote Control...................................................................................................................................English-13
Operating Range for the Remote Control..........................................................................................................English-14
Setup.................................................................................................................................................................................English-15
Connections ......................................................................................................................................................................English-17
Wiring Diagram..................................................................................................................................................English-17
Connecting a Personal Computer......................................................................................................................English-18
Connecting a Player or Computer with HDMI....................................................................................................English-18
Connecting a Computer with DisplayPort..........................................................................................................English-18
Connecting a USB device..................................................................................................................................English-19
Basic Operation.................................................................................................................................................................English-20
Power ON and OFF Modes ...............................................................................................................................English-20
Power Indicator..................................................................................................................................................English-21
Using Power Management.................................................................................................................................English-21
Aspect................................................................................................................................................................English-21
Media Player......................................................................................................................................................English-22
Displayable/playable files...................................................................................................................................English-22
File display screen.............................................................................................................................................English-24
Slideshow display ..............................................................................................................................................English-25
Media Player settings.........................................................................................................................................English-25
NETWORK & OTHER SETTINGS.....................................................................................................................English-26
Using SHARED SD card SETTINGS.................................................................................................................English-27
Using CONTENTS COPY..................................................................................................................................English-28
Using Emergency contents................................................................................................................................English-28
Information OSD................................................................................................................................................English-28
Picture Mode......................................................................................................................................................English-29
OSD (On-Screen-Display) Controls ..................................................................................................................................English-32
INPUT................................................................................................................................................................English-33
PICTURE...........................................................................................................................................................English-33
AUDIO................................................................................................................................................................English-35
SCHEDULE .......................................................................................................................................................English-36
MULTI INPUT.....................................................................................................................................................English-37
OSD...................................................................................................................................................................English-39
MULTI DISPLAY.................................................................................................................................................English-39
DISPLAY PROTECTION....................................................................................................................................English-41
CONTROL..........................................................................................................................................................English-41
OPTION.............................................................................................................................................................English-44
SYSTEM............................................................................................................................................................English-45
Remote Control Functions.................................................................................................................................................English-47
Multiple Monitors Connection............................................................................................................................................English-48
Controlling the LCD monitor via RS-232C Remote Control ..............................................................................................English-49
Controlling the LCD monitor via LAN Control.....................................................................................................................English-51
Connecting to a Network....................................................................................................................................English-51
Network Setting by Using an HTTP Browser.....................................................................................................English-51
POINT ZOOM....................................................................................................................................................................English-59
PROOF OF PLAY..............................................................................................................................................................English-60
INTELLIGENT WIRELESS DATA......................................................................................................................................English-61
MULTIPICTURE matrix.....................................................................................................................................................English-61
Video out...........................................................................................................................................................................English-68
Features............................................................................................................................................................................English-69
Troubleshooting.................................................................................................................................................................English-70
Specifications - V754Q......................................................................................................................................................English-72
Specifications - V864Q......................................................................................................................................................English-73
Specifications - V984Q......................................................................................................................................................English-74
Manufacturer’s Recycling and Energy Information............................................................................................................English-75
[Notice] About the MPEG-4 AVC, MPEG-4 Visual license included in this product...........................................................English-77

English-1
English
DECLARATION OF CONFORMITY
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
U.S. Responsible Party: NEC Display Solutions of America, Inc.
Address: 500 Park Boulevard, Suite 1100
Itasca, Illinois 60143
Tel. No.: [phone]
Type of Product: Display Monitor
Equipment Classification: Class B Peripheral
Model: MultiSync V754Q (V754Q)
MultiSync V864Q (V864Q)
MultiSync V984Q (V984Q)
We hereby declare that the equipment specied above
conforms to the technical standards as specied in the FCC Rules.
FCC Information
1. Use the attached specified cables with this color monitor so as not to interfere with radio and television reception.
(1) Please use the supplied power cord or equivalent to ensure FCC compliance.
(2) Please use the supplied shielded video signal cable.
2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
 • Reorientorrelocatethereceivingantenna.
 • Increasetheseparationbetweentheequipmentandreceiver.
 • Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
 • Consultyourdealeroranexperiencedradio/TVtechnicianforhelp.
If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions.
The user may find the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify and
Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C.,
20402, Stock No. 004-000-00345-4.
Windows is a registered trademark of Microsoft Corporation.
NEC is a registered trademark of NEC Corporation.
OmniColor is a registered trademark of NEC Display Solutions Europe GmbH in the countries of EU and
Switzerland.
DisplayPort and DisplayPort Compliance Logo are trademarks owned by Video Electronics Standards
Association in the United States and other countries.
All other brands and product names are trademarks or registered trademarks of their respective owners.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks
or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
Trademark PJLink is a trademark applied for trademark rights in Japan, the United States of America and
other countries and areas.
microSD and microSD SDHC logos are trademarks of SD-3C, LLC.
CRESTRON and CRESTRON ROOMVIEW are trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and other countries.
GPL/LGPL Software Licenses
The product includes software licensed under GNU General Public License (GPL), GNU Lesser General Public License (LGPL),
and others.
For more information on each software, see “readme.pdf” inside the “about GPL&LGPL” folder on the supplied CD-ROM.
Adobe and the Adobe logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or
other countries.

English-2
Important Information
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT
USE THIS UNIT’S POLARIZED PLUG WITHAN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE
PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINETAS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM
WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER
CORD FROM THEAC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric
shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit has
been included. Therefore, it should be read carefully in order to avoid any problems.
CAUTION
CAUTION: Please use the power cord provided with this monitor in accordance with the table below. If a power cord is not
supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the
AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.
This equipment is designed to be used in the condition of the power cord connected to earth. If the power cord is not connected
to the earth, it may cause electric shock. Please make sure the power cord is earthed properly.
PlugType North America European
Continental U.K. Chinese Japanese
Plug Shape
Region U.S.A./
Canada Taiwan EU (except U.K.) U.K. China Japan
Voltage 120* 110 230 230 220 100
* When operating this monitor with itsAC 125-240V power supply, use a power supply cord that matches the power supply
voltage of the AC power outlet being used.
NOTE: This product can only be serviced in the country where it was purchased.
Use the power cord which has BSMI mark at both ends when you use this monitor in Taiwan.
• TheintendedprimaryuseofthisproductisasanInformationTechnicalEquipmentinanofceordomesticenvironment.
• Theproductisintendedtobeconnectedtoacomputerandisnotintendedforthedisplayoftelevisionbroadcastsignals.

English-3
English
Safety Precautions and Maintenance
FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE
FOLLOWING WHEN SETTING UPAND USING
THE MULTI-FUNCTION MONITOR:
• DO NOT OPEN THE MONITOR. There are no user
serviceable parts inside and opening or removing covers
may expose you to dangerous shock hazards or other
risks. Refer all servicing to qualified service personnel.
• Donotbend,crimporotherwisedamagethepowercord.
• Donotplaceanyheavyobjectsonthepowercord.
Damage to the cord may cause shock or fire.
• Thepowersupplycordyouusemusthavebeen
approved by and comply with the safety standards of your
country. (Type H05VV-F 3G 0.75 mm2should be used in
Europe).
• InUK,useaBS-approvedpowercordwithmolded
plug having a black (5 A) fuse installed for use with this
monitor.
• Thepowercableconnectoristheprimarymeansof
detaching the system from the power supply. The monitor
should be installed close to a power outlet, which is easily
accessible.
• Donotspillanyliquidsintothecabinetoruseyour
monitor near water.
• Donotinsertobjectsofanykindintothecabinetslots,
as they may touch dangerous voltage points, which can
be harmful or fatal or may cause electric shock, fire or
equipment failure.
• Donotplacethisproductonaslopingorunstablecart,
stand or table, as the monitor may fall, causing serious
damage to the monitor.
• Donotmountthisproductupsidedownforanextended
period of time as it may cause permanent damage to the
screen.
• Donotplaceanyobjectsontothemonitoranddonotuse
the monitor outdoors.
• Ifglassisbroken,handlewithcare.
• Temperature controlled fans are implemented in this
monitor. For reliable performance and long useful life of
this product, it is mandatory to not cover any vents on the
monitor.
• Ifmonitororglassisbroken,donotcomeincontactwith
the liquid crystal and handle with care.
• Allowadequateventilationaroundthemonitor,sothat
heat can properly dissipate. Do not block ventilated
openings or place the monitor near a radiator or other
heat sources.
• Donotputanythingontopofthemonitor.
• Handlewithcarewhentransporting.Savepackagingfor
transporting.
• Ifusingthecoolingfancontinuously,itisrecommendedto
wipe holes clean a minimum of once a month.
• To ensure the monitor’s reliability, please clean the holes
at the back side of the cabinet at least once a year to
remove dirt and dust.
• WhenusingaLANcable,donotconnecttoaperipheral
device with wiring that might have excessive voltage.
• Donotusethemonitorinhightemperature,humid,dusty,
or oily areas.
• Donotusemonitorunderrapidtemperatureandhumidity
change condition and avoid cold air from air-conditioning
outlet directly, as it may shorten the lifetime of the monitor
or cause condensation. If condensation of water has
happened, let the monitor stand unplugged until the
condensation has disappeared.
Connecting to a TV*
• Cabledistributionsystemshouldbegrounded(earthed)
in accordance with ANSI/NFPA 70, the National Electrical
Code (NEC), in particular Section 820.93, Grounding of
Outer Conductive Shield of a Coaxial Cable.
• Thescreenofthecoaxialcableisintendedtobe
connected to earth in the building installation.
Under the following conditions immediately disconnect your
monitor from the wall outlet and refer servicing to qualified
service personnel:
• Whenthepowersupplycordorplugisdamaged.
• Ifliquidhasbeenspilled,orobjectshavefallenintothe
monitor.
• Ifthemonitorhasbeenexposedtorainorwater.
• Ifthemonitorhasbeendroppedorthecabinethasbeen
damaged.
• Ifyounoticeanystructuraldamagesuchascracksor
unnatural wobbling.
• Ifthemonitordoesnotoperatenormallybyfollowing
operating instructions.
Recommended Use
• Forthemonitor’soptimumperformance,allow20minutes
for warming up.
• Restyoureyesperiodicallybyfocusingonanobjectat
least 5 feet away. Blink often.
• Positionthemonitorata90°angletowindowsandother
light sources to minimize glare and reflections.
• CleantheLCDmonitorsurfacewithalint-free,non-
abrasive cloth. Avoid using any cleaning solution or glass
cleaner!
• Adjustthemonitor’sbrightness,contrastandsharpness
controls to enhance readability.
• Avoidreproduction of still patterns on the monitor for long
periods of time to avoid image persistence (after image
effects).
• Getregulareyecheckups.
Ergonomics
To realize the maximum ergonomic benefits, we recommend
the following:
• UsethepresetSizeandPositioncontrolswithstandard
signals.
• UsethepresetColorSetting.
• Usenon-interlacedsignals.
• Donotuseprimarycolorblueonadarkbackground,as
it is difficult to see and may produce eye fatigue due to
insufficient contrast.
• Suitable for entertainment purposes at controlled
luminous environments, to avoid disturbing reflections
from the screen.
Safety Precautions, Maintenance & Recommended Use
* The product you purchased may not have this feature.

English-4
Cleaning the LCD Panel
• Whentheliquidcrystalpanelisdusty,pleasegentlywipe
with a soft cloth.
• PleasedonotrubtheLCDpanelwithhardmaterial.
• PleasedonotapplypressuretotheLCDpanelsurface.
• PleasedonotuseOAcleanerasitwillcause
deterioration or discoloration on the LCD panel surface.
Cleaning the Cabinet
• Unplugthepowersupply
• Gentlywipethecabinetwithasoftcloth
• Tocleanthecabinet,dampentheclothwithaneutral
detergent and water, wipe the cabinet and follow with a
dry cloth.
NOTE: DO NOT clean with benzene thinner, alkaline
detergent, alcoholic system detergent, glass
cleaner, wax, polish cleaner, soap powder, or
insecticide. Rubber or vinyl should not be in
contact with the cabinet for an extended period
of time. These types of fluids and materials can
cause the paint to deteriorate, crack or peel.

English-5
English
For contents, please refer to the contents sheet.
This device cannot be used or installed without the Tabletop
Stand or other mounting accessory for support. For proper
installation it is strongly recommended to use a trained,
NEC authorized service person. Failure to follow NEC
standard mounting procedures could result in damage to the
equipment or injury to the user or installer. Product warranty
does not cover damage caused by improper installation.
Failure to follow these recommendations could result in
voiding the warranty.
Mounting
DO NOT mount the monitor yourself. Please ask your
supplier. For proper installation it is strongly recommended to
use a trained, qualified technician. Please inspect the location
where the unit is to be mounted. Mounting on wall or ceiling
is the customer’s responsibility. Not all walls or ceilings are
capable of supporting the weight of the unit. Product warranty
does not cover damage caused by improper installation, re-
modeling, or natural disasters. Failure to comply with these
recommendations could result in voiding the warranty.
DO NOT block ventilated openings with mounting
accessories or other accessories.
For NEC Qualified Personnel:
To ensure safe installation, use two or more brackets to
mount the unit. Mount the unit to at least two points on the
installation location.
Please note the following when mounting
on wall or ceiling
• NECrecommendsmountinginterfacesthatcomplywith
UL1678 standard in North America.
• NECstronglyrecommends
using size M8 screws
(15-17 mm + thickness
of bracket and washers in
length). If using screws
longer than 15-17 mm,
check the depth of the hole.
(Recommended Fasten
Force:1125-1375N•cm).
Bracket hole should be under 10 mm.
• Priortomounting,inspecttheinstallationlocationto
ensure that it is strong enough to support the weight of
the unit so that the unit will be safe from harm.
• For detailed information, refer to the instructions included
with the mounting equipment.
• Makesurethatthereisnogapbetweenthemonitorand
the bracket.
• Whenusedinavideowallcongurationforalonger
time, slight expansion of the monitors may happen due to
temperature changes. Due to this it is recommended that
over one millimeter gap is kept between adjacent monitor
edges.
• When installing, do not apply pressure to the screen or
excessive force to any part of the monitor by pushing
or leaning on it. This may cause the monitor to become
distorted or damaged.
To prevent the LCD monitor from falling off from the wall or
ceiling, NEC strongly recommends using a safety wire.
Please install LCD monitor in a spot of the wall or ceiling
strong enough to support the monitor.
Prepare the LCD monitor using mounting accessories such
as hook, eyebolt or mounting parts and then secure the LCD
monitor with a wire. The safety wire must not be tight.
CAUTION: Do not attempt to hang the monitor using an
installation safety wire. The monitor must be
properly installed.
Please make sure the mounting accessories are strong
enough to support the LCD monitor before mounting it.
CAUTION: If you use handles for safety wire please refer to
Handles for safety wire below.
Handles for safety wire
:Factory set position.
:Alternate position.
Solid line: Handle placement for safety wire in landscape
position.
Dotted line: Handle placement for safety wire in portrait
position.
V754Q/V864Q
V984Q
Installation
Screw
Unit
15-17 mm
Thickness
of bracket
and washers
under
10 mm
No gap
Washers
Mounting
Bracket
No thread
4 mm

English-6
Mounting location
• Theceilingandwallmustbestrongenoughtosupportthe
monitor and mounting accessories.
• DONOTinstallinlocationswhereadoororgatecanhit
the unit.
• DONOTinstallinareaswheretheunitwillbesubjected
to strong vibrations and dust.
• DO NOT install the monitor next to a location where the
main power supply is fed into the building.
• DO NOT install the monitor in a location where people
can easily grab and hang onto the unit or the mounting
equipment.
• Allow for adequate ventilation or provide air conditioning
around the monitor, so that heat can properly dissipate
away from the monitor and from the mounting equipment.
Mounting on ceilings
• Ensurethattheceilingissturdyenoughtosupportthe
weight of the unit and the mounting equipment over time,
against earthquakes, unexpected vibrations, and other
external forces.
• Besuretheunitismountedtoasolidstructurewithin
the ceiling, such as a support beam. Secure the monitor
using bolts, spring lock washers, washer and nut.
• DONOTmounttoareasthathavenosupportinginternal
structure. DO NOT use wood screws or anchor screws for
mounting. DO NOT mount the unit to ceiling or to hanging
fixtures.
Maintenance
• Periodicallycheckforloosescrews,gaps,distortions,
or other problems that may occur with the mounting
equipment. If a problem is detected, please refer to
qualified personnel for service.
• Regularlycheckthemountinglocationforsignsof
damage or weakness that may occur over time.
Orientation
• Whenusingthemonitorintheportraitposition,itshould
be rotated clockwise so that the left side is moved to
the top, right side is moved to the bottom. This will allow
for proper ventilation and will extend the lifetime of the
monitor. Improper ventilation may shorten the lifetime of
the monitor.
LED Indicator
Changing handles position
:Factory set position.
:Alternate position.
CAUTION: Four or more handles are required when
transporting.
V754Q
V864Q
V984Q
Changing NEC logo ornament position
When using the monitor in the portrait position, the NEC logo
ornament position can be changed.
Removing the logo ornament: unscrew the installed screw
then take off the logo ornament.
Attaching the logo ornament: make sure the holes for the
screws on the logo ornament and the holes for the screws
on the bezel are aligned. Install the logo ornament with the
screws, which are used for installing the logo ornament.
(Recommended Fasten Force: 30-40N•cm).
Screw holes
CAUTION: Do not use any other screw to install the logo
ornament.

English-7
English
Attaching Mounting Accessories
The monitor is designed for use with the VESA mounting
system.
1. Attach eyebolts (not included) for
mounting
This model is equipped with attachable eyebolts to aid in
mounting.
• Install the eyebolt brackets with the attached screws.
• Screwtheeyeboltsintoeyeboltholesin eyebolt brackets
as shown in the picture.
• Besureeyeboltsaresecure.
• Inordertomovethemonitorintoposition,usealifting
device attached to the eyebolts.
CAUTION: DO NOT mount the monitor using only the
eyebolts. Eyebolts are for tentative use only.
2. Attach Mounting Accessories
Be careful to avoid tipping the monitor when attaching
accessories.
VESA Mounting Interface (M8)
400 mm
400 mm
Mounting accessories can be attached with the monitor in
the face down position. To avoid damaging the front face,
place the protective sheet on the table underneath the LCD
monitor. The protective sheet was wrapped around the LCD
monitor in the original packaging. Make sure there is nothing
on the table that can damage the monitor.
NOTE: Prior to installation, be sure to place the monitor
on a flat area with adequate space.
NOTE: You can use 600 mm/400 mm holes for mounting.
Mounting Interface (M8)
600 mm
400 mm
3. Using an Option Board
1. Turn off the main power switch.
2. Place the monitor face down on the protective sheet.
NOTE: Be sure to place the monitor on a flat and adequate
space.
3. Remove the attached slot cover by unscrewing the
installed screws (Figure 1), sliding to right (Figure 2) and
moving up (Figure 3).
Figure 1 Figure 2
Figure 3 Figure 4
4. Insert the option board into the monitor and fix it with the
removed screws (Figure 4).
NOTE: Please contact your supplier for available option
boards.
Do not apply excessive force to manipulate the
option board before fixing it with screws.
Make sure that the board is inserted into the slot in
the correct orientation.
CAUTION: Ensure the option board is attached by the
removed screws. Otherwise, the option board
may fall out and expose you to danger.
(RecommendedFastenForce:139-189N•cm).

English-8
4. Installing and removing the optional
table top stand
CAUTION: Installing and removing the stand must be done
by four or more people.
For installation, follow the instructions included with the
stand or mounting equipment. Use only those devices
recommended by the manufacturer.
NOTE: ONLY use screws which are supplied with the
optional table top stand.
When installing the LCD monitor stand, handle the unit with
care to avoid pinching your fingers.
Optional table top stand
Table
Protective Sheet
NOTE: Install the stand in the direction of the arrow
which is imprinted on the surface of the stand.
Use the ST-801.
NOTE: V984Q: DO NOT use this monitor on the floor with
the table top stand. Please use this monitor on a
table or with a mounting accessory for support.
5. PreventTipping
When using the display with the optional table top stand,
fasten the LCD to a wall using a cord or chain that can
support the weight of the monitor in order to prevent the
monitor from falling. Fasten the cord or chain to the monitor
using the provided clamps and screws that are included with
the optional table top stand.
Screw (M4)
Cord or chain Clamp
Screw Holes
Screw (M4)
Cord or chain Clamp
Screw Holes
Without eyebolt brackets
With eyebolt brackets
Before attaching the LCD monitor to the wall, make sure that
the wall can support the weight of the monitor.
Be sure to remove the cord or chain from the wall before
moving the LCD.

English-9
English
6.Ventilation Requirements
When mounting in an enclosed space or recessed area,
leave adequate room between the monitor and the enclosure
to allow heat to disperse, as shown below.
100 mm
100 mm
30 mm
100 mm
100 mm
Must be under 40 Degree Celsius.
Allow adequate ventilation or provide air conditioning around
the monitor, so that heat can properly dissipate away from
the unit and the mounting equipment; especially when you
use monitors in a multiple screen configuration.
NOTE: The sound quality of the internal speakers will be
different depending on the acoustics of the room.

English-10
Parts Name and Functions
Control Panel
APower Button ( )
Switches the power on/standby. See also page 20.
BMute Button (MUTE)
Switches the audio mute on/off.
CInput/Set Button (INPUT/SET)
INPUT: Toggle switches between below inputs.
[DisplayPort1], [DisplayPort2], [HDMI1], [HDMI2], [HDMI3],
[MP], [OPTION*]. These are available inputs only, shown as
their factory preset name.
SET: When OSD (On Screen Display) is shown, this button
acts as a “set button” when you make a selection.
*: This function depends on which option board you are using.
DPlus Button (+)
Increases the audio output level when the OSD menu is
turned off.
Acts as (+) button to increase the adjustment within the
OSD menu.
EMinus Button (-)
Decreases the audio output level when the OSD menu is
turned off.
Acts as (-) button to decrease the adjustment within the
OSD menu.
FUp Button ( )
Activates the OSD menu when the OSD menu is turned off.
Acts as button to move the highlighted area up to select
adjustment items within the OSD menu.
GDown Button ( )
Activates the OSD menu when the OSD menu is turned off.
Acts as button to move the highlighted area down to select
adjustment items within the OSD menu.
HMenu/Exit Button (MENU/EXIT)
Activates the OSD menu when the OSD menu is turned off.
Acts as a back button within the OSD to move to the previous
OSD menu.
Acts as an EXIT button to close the OSD when on the main
menu.
IRemote Control Sensor and Power Indicator
Receives the signal from the remote control (when using the
wireless remote control). See also page 14.
Glows blue when the LCD monitor is in active mode*.
Green and Amber blink alternately when the “SCHEDULE
SETTINGS” function is enabled*1.
When a component failure is detected within the monitor, the
indicator will blink red or blink a combination of red and blue.
* If “OFF” is selected in the “POWER INDICATOR”
(see page 43 ), the LED will not glow when the LCD monitor is in
active mode.
*
1
If “OFF” is selected in the “SCHEDULE INDICATOR”
(see
page 43 ), the LED will not blink.
NOTE:Please refertothePOWER INDICATOR(see page43).
JRoom Light Sensing Sensor
Detects the level of ambient light, allowing the monitor
to make automatic adjustments to the backlight setting,
resulting in a more comfortable viewing experience. Do not
cover this sensor. See page 43.

English-11
English
Terminal Panel
USB Upstream
AAC IN Connector
Connects with the supplied power cord.
BMain Power Switch
On/Off switch to turn main power ON/OFF.
CAudio IN
Audio signal input from external equipment such as a
computer or player.
DDisplayPort OUT
Output DisplayPort signals from DisplayPort IN1.
You can connect multiple monitors by using DisplayPort
daisy-chain connection. See MULTI DISPLAY (page 39) and
Video out (page 68).
EDisplayPort IN1/IN2
DisplayPort signals input.
FHDMI IN1/IN2/IN3
Digital HDMI signals input.
GRS-232C IN (D-Sub 9 pin)
Connect RS-232C input from external equipment such as a
computer in order to control RS-232C functions.
HRemote IN
Use the optional sensor unit by connecting it to your monitor.
NOTE: Do not use this connector unless specified.
ImicroSD Card Slot
Insert a microSD memory card. To use the Media Player,
please connect a microSD memory card to this port
(See page 23).
To install the microSD card slot cover, please refer to
“Installing microSD card slot cover” (See page 23).
JUSB Port
USB1: Downstream port (USB Type-A).
Connect USB devices.
USB2: Upstream port (USB Type-B).
Connect external equipment such as a computer.
To control the monitor from connected external
equipment, please use this port.
USB CM1 (2A): Power supply port.
USB CM2: Service port. Please do not connect devices.
USB MP: USB storage device port. This port is for future
software upgrades.
To use the Media Player, please connect USB
storage device to this port (See page 19).
MP is an abbreviation of Media Player.
KLAN Port 1/2 (RJ-45)
LAN connection. See page 48 and 51.
NOTE: Please give priority for use to LAN1.
LAudio OUT
Audio signal output from the AUDIO IN, DisplayPort and
HDMI to an external device (stereo receiver, amplifier, etc.).
NOTE: This connector is not a Headphone terminal.
MInternal/External Speaker Switch
: Internal speaker : External speaker.
NOTE: Please turn off the monitor’s main power when you
use the Internal/External speaker switch.
NExternal SpeakerTerminal
Audio signal output.
Red terminal is plus (+).
Black terminal is minus (-).
NOTE: This speaker terminal is for 15 W + 15 W (8 ohm)
speaker.
OInternal Speaker

English-12
POption Board Slot
Slot 2 type accessory is available. Please contact your
supplier for detailed information.
NOTE: Please contact your supplier for available option board.
QSecurity Slot
Security and theft protection lock compatible with
Kensington security cables/equipment.
For products, visit Kensington’s website,
http://www.kensington.com/
RRating Label
SIntelligent Wireless Data Sensor
Sensor for wireless communication of monitor for information
and settings.
TOption Speaker Mounting Hole
NOTE: Please contact your supplier for available optional
speaker.

English-13
English
Wireless Remote Control
APOWER ON/STANDBY Button
Switches the power on/standby.
BINPUT Button
Selects the input signal.
Input signal for the MEDIA PLAYER is shown as MP.
COPTION MENU Button
DKEYPAD
Press the buttons to set and change passwords, change
channel and set REMOTE ID.
Below buttons are used for CEC (Consumer Electronics
Control) (See page 44) and the Media Player function
(See page 22): 1 , 2 , 3 , 5 , 6 .
EENT Button
Confirm the AUTO PLAY FOLDER in Media Player.
FDISPLAY Button
Turns on/off the information OSD. See page 28.
If you lock remote control buttons using the IR LOCK
SETTINGS function, you can unlock the buttons by holding
down this DISPLAY button for more than 5 seconds.
GMENU Button
Turns on/off the menu mode.
HAUTO SET UP Button (This button does not work)
IEXIT Button
Returns to the previous menu within the OSD menu.
JUP/DOWN Button ( / )
Acts as button to move the highlighted area up or down
to select adjustment items within the OSD menu.
When using PIP (picture in picture), moves the small screen
up or down.
KMINUS/PLUS (-/+) Button
Increases or decreases the adjustment level within the OSD
menu settings.
When using PIP (picture in picture), moves the small screen
left or right.
LSET/POINT ZOOM Button
SET: When OSD is shown, this button acts as “set button”
when you make a selection.
POINT ZOOM: When OSD is not shown, this button acts as
“point zoom button”.
MVOLUME UP/DOWN Button (VOL +/-)
Increases or decreases the audio output level.
NCH/ZOOM UP/DOWN Button (CH/ZOOM +/-)*1
Increases or decreases the POINT ZOOM level.
Please refer to POINT ZOOM (See page 59).
OGUIDE Button*1
PMUTE Button
Turns on/off the mute function.
QPICTURE MODE Button
Selects the picture mode, [HIGHBRIGHT], [STANDARD],
[sRGB], [CINEMA], [CUSTOM1], [CUSTOM2],
[SVE-(1-5) SETTINGS]. See page 31.
HIGHBRIGHT: For moving images such as DVD.
STANDARD: For images.
sRGB: For text based images.
CINEMA: For movies.
CUSTOM1 and CUSTOM2: Custom setting.
SVE-(1-5) SETTINGS: For images and movies.
RASPECT Button
Selects the picture aspect, [FULL], [WIDE]*, [DYNAMIC]*,
[1:1], [ZOOM] and [NORMAL]. See page 21.
* HDMI1, HDMI2, HDMI3 inputs only.
SAUDIO INPUT Button
Selects the audio input source [IN], [HDMI1], [HDMI2],
[HDMI3], [DisplayPort1], [DisplayPort2], [OPTION]*1, [MP].
TSTILL Button
ON/OFF button: Activates/deactivates still picture mode.
CAPTURE button: Captures still picture.
NOTE: This function deactivates when selecting MULTI
PICTURE MODE, TEXT TICKER, SCREEN SAVER, POINT
ZOOM, IMAGE FLIP except for NONE, SUPER in INPUT
CHANGE, TILE MATRIX.
If input signal is OPTION, this button’s actions depend on
which option board you are using.
*1:This button’s action depends on which option board you are using.

English-14
Operating Range for the Remote
Control
Point the top of the remote control toward the LCD monitor’s
remote control sensor during button operation.
Use the remote control within a distance of about 7 m (23 ft.)
from the remote control sensor, or at a horizontal and
verticalangleofwithin30°andwithinadistanceofabout
3.5 m (10 ft.).
IMAGE FLIP Button
Toggleswitchesbetween[HFLIP],[VFLIP],[180°ROTATE]
and [NONE]. See page 35.
ACTIVE PICTURE Button
Selects active picture.
MULTI PICTURE Button
ON/OFF Button: Toggle switches between ON and OFF.
MODE Button: Selects a mode from PIP (picture in picture)
or PBP (picture by picture).
CHANGE Button: Swaps images between two pictures.
PICTURE ASPECT Button: Selects active picture frame
aspect.
NOTE: Enable to change each multi picture size by pressing
SET/POINT ZOOM button during multi picture mode.
REMOTE ID Button
Activates the REMOTE ID function. See page 47.
MTS Button*1
*1:This button’s action depends on which option board you are using.
Refer to the option board’s user’s manual for further information.
NOTE: The buttons with no explanation do not function.
Caution: Important, the remote control
system may not function when
direct sunlight or strong
illumination strikes the
remote control sensor, or
when there is an object in
the path.
Handling the remote control
• Donotexposetostrongshock.
• Donotallowwaterorotherliquidto
splash on the remote control. If the
remote control gets wet, wipe it dry immediately.
• Avoidexposuretoheatandsteam.
• Excepttoinstallthebatteries,donotopentheremote
control.

English-15
English
1. Determine the installation location
CAUTION: Installing your LCD monitor must be done by a
qualified technician. Contact your supplier for
more information.
CAUTION: MOVING OR INSTALLING THE LCD MONITOR
MUST BE DONE BY FOUR OR MORE PEOPLE.
Failure to follow this caution may result in injury if
the LCD monitor falls.
CAUTION: Do not mount or operate the monitor upside
down.
CAUTION: This LCD monitor has internal temperature
sensors and cooling fans, including a fan for the
option board.
If the LCD monitor becomes too hot, the cooling
fans will turn on automatically.
The option board’s fan is active although the
temperature is lower than normal operating
temperature for cooling the option board. If the
LCD monitor becomes overheated while the
cooling fan is running, a “Caution” warning will
appear. If the “Caution” warning appears, stop
using the unit and allow it to cool. Using the
cooling fans will reduce the likelihood of early unit
failure and may help reduce image degradation
and “Image Persistance”.
If the LCD monitor is used in an enclosed area
or if the LCD panel is covered with a protective
screen, please check the inside temperature of
the monitor by using the “HEAT STATUS” control
in the OSD (see page 41). If the temperature is
higher than the normal operating temperature,
please turn the cooling fan to ON within the FAN
CONTROL menu within the OSD (see page 41).
IMPORTANT: Lay the protective sheet beneath the
monitor, so as not to scratch the LCD panel.
The protective sheet was wrapped around the
monitor when it was packaged.
2. Install the remote control batteries
The remote control is powered by two 1.5V AAA batteries.
To install or replace batteries:
A. Press and slide to open the cover.
B. Align the batteries according to the (+) and (–) indications
inside the case.
C. Replace the cover.
CAUTION: Incorrect usage of batteries can result in leaks or
bursting.
NEC recommends the following battery use:
• Place“AAA”sizebatteriesmatchingthe(+)and(-)signs
on each battery to the (+) and (-) signs of the battery
compartment.
• Donotmixbatterybrands.
• Donotcombinenewandoldbatteries.Thiscanshorten
battery life or cause liquid leakage of batteries.
• Removedeadbatteriesimmediatelytopreventbattery
acid from leaking into the battery compartment.
• Donottouchexposedbatteryacid,itmayinjureyourskin.
NOTE: If you do not intend to use the Remote Control for
a long period of time, remove the batteries.
3. Connect external equipment
(See pages 17, 18 and 19)
• Toprotecttheexternalequipment,turnoffthemainpower
before making connections.
• Refertothe user’s manual of your equipment for further
information.
NOTE: Do not connect/disconnect cables when turning
on the monitor or other external equipment, as this
may result in a loss of the monitor image.
4. Connect the supplied power cord
• Theequipmentshouldbeinstalledclosetoaneasily
accessible power outlet.
• FastenthepowercordtotheLCDmonitorbyattaching
the screw and clamp.
• Fullyinserttheprongsintothepoweroutletsocket.
A loose connection may cause image degradation.
NOTE: Please refer to the “Safety Precautions and
Maintenance” section of this user’s manual for
proper selection of an AC power cord.
(RecommendedFastenForce:139-189N•cm).
Screw Clamp
Setup

English-16
5. Switch on the power of all the attached
external equipment
When connected with a computer, switch on the power of the
computer first.
6. Operate the attached external equipment
Show the signal on the screen from the desired input source.
7. Adjust the sound
Make volume adjustments when required.
8. Adjust the image (See page 33)
Make adjustments such as backlight or contrast when
required.
9. Recommended Adjustments
To reduce the risk of the “Image Persistence”, please adjust
the following items based on the application being used:
“SCREEN SAVER”, “SIDE BORDER COLOR” (See page 41),
“DATE & TIME” (See page 36), “SCHEDULE SETTINGS”
(See page 36).
It is recommended that the “FAN CONTROL” setting
(See page 41) be checked ON also.

English-17
English
Connections
NOTE: Do not connect or disconnect cables when turning on the monitor’s main power or other external equipment’s power,
as this may result in a loss of the monitor image.
NOTE: Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor turns down the sound.
Before making connections:
* First turn off the power of all the attached equipment and make connections.
* Refer to the user’s manual included with each separate piece of equipment.
* We strongly recommend connecting or disconnecting a USB storage device or a microSD memory card to the monitor when
the monitor’s main power is off.
Wiring Diagram
USB1
USB2
USB CM1 (2A)
USB CM2
USB MP
Dotted lines = other signal
Solid lines = video signal
Dashed lines = audio signal
USB storage device
Stereo Amplifier
USB port
(Type-A)
USB devices
such as
USB camera or
USB memory
Devices that
require power
supply:
Ex:
MultiPresenter
Stick
USB port
(Type-B)
USB cable
Computer (USB)*1
AV Amplifier
DVD Player
(HDMI)
DVD Player or
Computer
DVD Player (HDMI) or
Computer (HDMI)
DVD Player
(HDMI) AV Amplifier
Computer (DisplayPort)
Computer (DisplayPort)
Second monitor*
Computer
DVD Player Stereo Amplifier
VCR player or DVD player
*: Multiple monitors that are daisy-chained have a limit to the connectable monitors.
*1: The device connected to USB2 can control the device connected to USB1.

English-18
Connecting a Personal Computer
Connecting your computer to your LCD monitor will enable you to reproduce your computer’s video signal output.
Some display cards may not be able to support the required resolution for proper image reproduction.
Your LCD monitor shows proper image by adjusting the factory preset timing signal automatically.
<Typical factory preset signal timing>
Resolution Scanning frequency HDMI DisplayPort
Horizontal Vertical MODE1 MODE2 1.1a 1.2
640 x 480 31.5 kHz 60 Hz Yes Yes Yes Yes
800 x 600 37.9 kHz 60 Hz Yes Yes Yes Yes
1024 x 768 48.4 kHz 60 Hz Yes Yes Yes Yes
1280 x 720 45.0 kHz 60 Hz Yes Yes Yes Yes
1280 x 768 47.8 kHz 60 Hz No No Yes Yes
1280 x 800 49.7 kHz 60 Hz Yes Yes Yes Yes
1280 x 1024 64 kHz 60 Hz Yes Yes Yes Yes
1360 x 768 47.7 kHz 60 Hz No No Yes Yes
1366 x 768 47.7 kHz 60 Hz No No Yes Yes
1400 x 1050 65.3 kHz 60 Hz Yes Yes Yes Yes
1440 x 900 55.9 kHz 60 Hz Yes Yes Yes Yes
1600 x 1200 75.0 kHz 60 Hz Yes Yes Yes Yes
1680 x 1050 65.3 kHz 60 Hz Yes Yes Yes Yes
1920 x 1080 67.5 kHz 60 Hz Yes Yes Yes Yes
1920 x 1200 74.6 kHz 60 Hz Yes Yes Yes Yes
1920 x 2160 133.3 kHz 60 Hz Yes Yes Yes Yes
3840 x 2160 65.7 kHz 30 Hz No No Yes*1Yes
3840 x 2160 67.5 kHz 30 Hz Yes*1Yes No No
3840 x 2160 133.3 kHz 60 Hz No Yes No Yes*1, *2
3840 x 2160 135.0 kHz 60 Hz No Yes*1No Yes*2
4096 x 2160*354.0 kHz 24 Hz Yes Yes No No
4096 x 2160*3135.0 kHz 60 Hz No Yes No No
*1: Recommended resolution.
*2: Only HBR2 is set.
*3: Compressed image.
Connecting a Player or Computer with HDMI
• PleaseuseanHDMIcablewiththeHDMIlogo.
• Itmaytakeamomentforthesignaltoappear.
• Somedisplaycardsordriversmaynotdisplayanimagecorrectly.
• WhenyouuseacomputerwithHDMI,pleasesetOVERSCANto“AUTO”or“OFF”(seepage 34).
• Please check display card when image is compressed with 3840 x 2160.
• To output HDMI audio, set [HDMI1], [HDMI2] or [HDMI3] at AUDIO INPUT in the OSD or choose [HDMI1], [HDMI2] or
[HDMI3] by the remote control AUDIO INPUT button.
• If the input resolution is 3840 x 2160 (60 Hz) and 4096 x 2160 (60 Hz), please set MODE2 at HDMI in TERMINAL
SETTINGS (See page 38).
• If the monitor’s main power is turned on after a connected computer is turned on, sometimes images are not displayed.
In this case, please turn off the computer then turn it on again.
Connecting a Computer with DisplayPort
• PleaseuseaDisplayPortcablewiththeDisplayPortcompliancelogo.
• To use the DisplayPort out connector, please refer to Video out (See page 68).
• Itmaytakeamomentforthesignaltoappear.
• WhenconnectingaDisplayPortcabletoacomponentwithasignalconversionadapter,animagemaynotappear.
• SelectDisplayPortcablesfeaturealockingfunction.Whenremovingthiscable,holddownthetopbuttontoreleasethelock.
• To output DisplayPort audio, set [DisplayPort1] or [DisplayPort2] at AUDIO INPUT in the OSD or choose [DisplayPort1] or
[DisplayPort2] by the remote control AUDIO INPUT button.
• To display individual images at each connected monitors with the DisplayPort out connector, please set DisplayPort1.2 and
MST at DisplayPort in the TERMINAL SETTINGS (See page 38).
• If the monitor’s main power is turned on after a connected computer to the monitor is turned on, sometimes images are not
displayed. In this case, please turn off the computer then turn it on again.
