NEC Express5800/B120f User manual

40.103.01-101.01
October 2014
© NEC Corporation 2014
NEC Express Server
Express5800 Series
Express5800/B120f
EXP436A
User’s Guide
Chapter 1 General Description
Chapter 2 Preparations
Chapter 3 Setup
Chapter 4 Appendix

Documents for This Product
Express5800/B120f User's Guide
2
Documents for This Product
Documents for this product are provided as booklets ( ) or electronic manuals ( )
in the EXPRESSBUILDER DVD ( ).
Safety Precautions and
Regulatory Notices
Describes points of caution to ensure the safe use of this server.
Read these cautions before using this server.
Getting Started
Describes how to use this server, from unpacking to operations.
See this guide first and read the outline of this product.
User’s Guide
Chapter 1: General Description Overviews, names, and functions of the server’s parts
Chapter 2: Preparations Installation of additional options, connection of peripheral devices,
and suitable location for this server
Chapter 3: Setup System BIOS configurations and summary of EXPRESSBUILDER
Chapter 4: Appendix Specifications and other information
Installation Guide (Windows)
Chapter 1: Installing Windows Installation of Windows and drivers, and precautions for
installation
Chapter 2: Installing Bundled
Software
Installation of bundled software, such as NEC
ESMPRO and
Universal RAID Utility
Maintenance Guide
Chapter 1: Maintenance Server maintenance and troubleshooting
Chapter 2: Useful Features The detail of system BIOS settings, RAID Configuration Utility, and
EXPRESSBUILDER
Chapter 3: Appendix Error messages and Windows Event Logs
Other documents
The detail of NEC ESMPRO, Universal RAID Utility, and other features.
PDF
PDF
PDF
PDF
PDF
EXPRESSBUILDER

Contents
Express5800/B120f User's Guide
3
Contents
Documents for This Product..................................................................................................................................2
Contents................................................................................................................................................................3
Notations Used in This Document.........................................................................................................................6
Notations used in the text ...................................................................................................................6
Optical disk drive.................................................................................................................................6
Hard disk drive....................................................................................................................................6
Removable media...............................................................................................................................6
Abbreviations of Operating Systems (Windows).................................................................................7
Trademarks...........................................................................................................................................................8
Warnings and Additions to This Document..........................................................................................................12
Latest editions...................................................................................................................................12
Precautions for Use (Be Sure to Read)...............................................................................................................13
Safety precautions............................................................................................................................13
Symbols used in this document and on warning labels.....................................................................14
Safety notes......................................................................................................................................15
Handling precautions (for proper operations)....................................................................................15
Handling precautions (for Anti-static Measures)................................................................................17
Handling precautions (Power-saving feature)...................................................................................18
Chapter 1 General Description.........................................................................................................................20
1. Introduction.....................................................................................................................................................21
2. Accessories....................................................................................................................................................22
3. Features.........................................................................................................................................................23
3.1 Overview of Blade Server..........................................................................................................25
3.2 About the Monitoring of Chassis Sensors..................................................................................26
3.3 Firmware and Software Version Management...........................................................................26
4. Names and Functions of Parts.......................................................................................................................27
4.1 CPU Blade.................................................................................................................................27
4.2 Hard Disk Drive (HDD)...............................................................................................................30
4.3 LED Indications..........................................................................................................................31
4.3.1 POWER LED..........................................................................................................31
4.3.2 STATUS LED..........................................................................................................31
4.3.3 ID LED....................................................................................................................32
4.3.4 Hard disk drive access LED ...................................................................................32

Contents
Express5800/B120f User's Guide
4
Chapter 2 Preparations ....................................................................................................................................33
1. Installing Internal Optional Devices ................................................................................................................34
1.1 Safety Precautions.....................................................................................................................34
1.2 Overview of Installation and Removal........................................................................................35
1.3 Installation and Removal Procedure (Common section)............................................................36
1.3.1 Removal of top cover..............................................................................................36
1.3.2 Removal of air duct.................................................................................................37
1.3.3 Removal of hard disk drive cage............................................................................38
1.3.4 Installation of top cover, air duct, and hard disk drive cage....................................39
1.4 Processor (CPU)........................................................................................................................40
1.4.1 Installation..............................................................................................................41
1.4.2 Removal.................................................................................................................45
1.5 DIMM.........................................................................................................................................46
1.5.1 Adding Order and Precautions ...............................................................................47
1.5.2 Installation..............................................................................................................47
1.5.3 Removal.................................................................................................................49
1.5.4 Using Memory RAS Feature...................................................................................49
1.6 Mezzanine Card.........................................................................................................................57
1.6.1 Notes......................................................................................................................58
1.6.2 Installation..............................................................................................................58
1.6.3 Removal.................................................................................................................59
1.7 Hard Disk Drive (HDD) / Solid State Drive (SSD)......................................................................60
1.7.1 Installation..............................................................................................................61
1.7.2 Removal.................................................................................................................62
1.7.3 Replacement..........................................................................................................63
1.8 Use of Internal Hard Disk Drives in the RAID System ...............................................................66
1.8.1 Enabling a RAID System........................................................................................66
1.8.2 Notes on setting up a RAID System.......................................................................67
1.9 LAN Riser Card..........................................................................................................................68
1.9.1 Installation..............................................................................................................69
1.9.2 Removal.................................................................................................................69
1.10 TPM (Trusted Platform Module) Kit.........................................................................................70
1.10.1 Installation ............................................................................................................71
1.10.2 Removal ...............................................................................................................71
2. Installation and Connection............................................................................................................................72
2.1 Installation..................................................................................................................................72
2.1.1 Checking MAC Address..........................................................................................73
2.2 Connecting Peripheral Devices..................................................................................................75
2.2.1 USB Connection by K410-150(00) SUV Cable.......................................................77
2.2.2 Connecting with Network........................................................................................77
2.2.3 Connecting with UPS..............................................................................................78

Contents
Express5800/B120f User's Guide
5
Chapter 3 Setup ...............................................................................................................................................79
1. Power-on of Blade Server ..............................................................................................................................80
1.1 Power ON from CPU Blade .......................................................................................................81
1.2 Power ON from Network Serial Port..........................................................................................82
1.3 Power ON from Remote Console ..............................................................................................82
1.4 Operation after Power ON.........................................................................................................82
1.5 POST.........................................................................................................................................83
1.5.1 POST Execution Flow ............................................................................................83
1.5.2 POST Error Messages ...........................................................................................84
2. BIOS Setup Utility (SETUP) ...........................................................................................................................85
2.1 Overview....................................................................................................................................85
2.2 Starting and Exiting SETUP Utility.............................................................................................85
2.3 Description on On-Screen Items and Key Usage ......................................................................86
2.4 Cases that Require Configuration..............................................................................................88
3. EXPRESSSCOPE ENGINE 3........................................................................................................................89
3.1 Overview....................................................................................................................................89
3.2 EXPRESSSCOPE ENGINE 3 Network Configuration...............................................................89
4. EXPRESSBUILDER.......................................................................................................................................91
4.1 Features of EXPRESSBUILDER...............................................................................................91
4.2 Usage of EXPRESSBUILDER...................................................................................................91
5. Installing Software Components.....................................................................................................................92
6. Device Identification.......................................................................................................................................93
7. Power-off of Blade Server ..............................................................................................................................94
Chapter 4 Appendix..........................................................................................................................................95
1. Specifications .................................................................................................................................................96
2. Interrupt Lines ................................................................................................................................................98
3. Glossary.........................................................................................................................................................99

Notations Used in This Document
Express5800/B120f User's Guide
6
Notations Used in This Document
Notations used in the text
In addition to safety-related symbols urging caution, three other types of notations are used in this document.
These notations have the following meanings.
Important
Indicates critical items that must be followed when handling hardware or operating software. If
the procedures described are not followed, hardware
failure, data loss, and other serious
malfunctions could occur
.
Note
Indicates items that must be confirmed when handling hardware or operating software.
Tips
Indicates information that is helpful to keep in mind when using this server.
Optical disk drive
This server is equipped with one of the following drives. These drives are referred to as optical disk drive in this
document.
●DVD-ROM drive
●DVD Super MULTI drive
Hard disk drive
Unless otherwise stated, hard disk drive described in this document refers to both of the following.
●Hard disk drive (HDD)
●Solid state drive (SSD)
Removable media
Unless otherwise stated, removable media described in this document refer to both of the following.
●USB flash drive
●Flash FDD

Notations Used in This Document
Express5800/B120f User's Guide
7
Abbreviations of Operating Systems (Windows)
Windows Operating Systems are referred to as follows.
See Chapter 1 (1.2 Supported Windows OS) in Installation Guide (Windows) for detailed information.
Notations in this document Official names of Windows
Windows Server 2012 R2 Windows Server 2012 R2 Standard
Windows Server 2012 R2 Datacenter
Windows Server 2012 Windows Server 2012 Standard
Windows Server 2012 Datacenter
Windows Server 2008 R2 Windows Server 2008 R2 Standard
Windows Server 2008 R2 Enterprise
Windows Server 2008 * Windows Server 2008 Standard
Windows Server 2008 Enterprise
* Windows Server 2008 is 32-bit(x86) only in this manual.

Trademarks
Express5800/B120f User's Guide
8
Trademarks
EXPRESSSCOPE and ExpressUpdate are registered trademarks of NEC Corporation.
Microsoft, Windows, Windows Server, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United
States and other countries. Intel, Pentium, and Xeon are registered trademarks of Intel Corporation of the United States.
AT is a registered trademark of International Business Machines Corporation of the United States and other countries.
Adaptec, its logo, and SCSISelect are registered trademarks or trademarks of Adaptec, Inc. of the United States.
Avago, LSI, and the LSI & Design logo are trademarks or registered trademarks of Avago Technologies in the United States and/or
other countries.
Adobe, the Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated.
DLT and DLTtape are trademarks of Quantum Corporation of the United States.
PCI Express is a trademark of Peripheral Component Interconnect Special Interest Group.
Linux is a trademark or registered trademark of Linus Torvalds in Japan and other countries.
Red Hat® and Red Hat Enterprise Linux are trademarks or registered trademarks of Red Hat, Inc. in the United States and other
countries.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their respective
trademark owners.

Trademarks
Express5800/B120f User's Guide
9
License Notification
Open source software of following license is included in the part of this product (system BIOS).
•EDK from Tianocore.org
•UEFI Network Stack 2
•Crypto package using WPA Supplicant
Open source software of following license is included in the part of this product (Off-line Tools).
•EDK from Tianocore.org
EDK FROM TIANOCORE.ORG
BSD License from Intel
Copyright (c) 2012, Intel Corporation
All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the
following conditions are met:
•Redistributions of source code must retain the above copyright notice, this list of conditions and the following
disclaimer.
•Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other materials provided with the distribution.
•Neither the name of the Intel Corporation nor the names of its contributors may be used to endorse or
promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT
SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED
TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR
BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN
CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY
WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Copyright (c) 2004 - 2007, Intel Corporation
All rights reserved. This program and the accompanying materials are licensed and made available under the
terms and conditions of the BSD License which accompanies this distribution. The full text of the license may be
found at http://opensource.org/licenses/bsd-license.php
THE PROGRAM IS DISTRIBUTED UNDER THE BSD LICENSE ON AN "AS IS" BASIS, WITHOUT
WARRANTIES OR REPRESENTATIONS OF ANY KIND, EITHER EXPRESS OR IMPLIED.

Trademarks
Express5800/B120f User's Guide
10
UEFI NETWORK STACK 2
OpenSSL License
-------
Copyright (c) 1998-2011 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the
following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the
following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other materials provided with the distribution.
3. All advertising materials mentioning features or use of this software must display the following
acknowledgment:
"This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.
(http://www.openssl.org/)"
4. The names "OpenSSL Toolkit" and "OpenSSL Project" must not be used to endorse or promote products
derived from this software without prior written permission. For written permission, please contact
[e-mail].
5. Products derived from this software may not be called "OpenSSL" nor may "OpenSSL" appear in their
names without prior written permission of the OpenSSL Project.
6. Redistributions of any form whatsoever must retain the following acknowledgment:
"This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit
(http://www.openssl.org/)"
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY EXPRESSED OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR
ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND
ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
This product includes cryptographic software written by Eric Young ([email protected]).
This product includes software written by Tim Hudson ([e-mail]).

Trademarks
Express5800/B120f User's Guide
11
CRYPTO PACKAGE USING WPA SUPPLICANT
WPA Supplicant
-------
Copyright (c) 2003-2012, Jouni Malinen <[email protected]> and contributors
All Rights Reserved.
This program is licensed under the BSD license (the one with advertisement clause removed).
If you are submitting changes to the project, please see CONTRIBUTIONS file for more instructions.
License
-------
This software may be distributed, used, and modified under the terms of
BSD license:
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the
following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the
following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other materials provided with the distribution.
3. Neither the name(s) of the above-listed copyright holder(s) nor the names of its contributors may be used to
endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL
THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOTLIMITED TO, PROCUREMENT
OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR
TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Warnings and Additions to This Document
Express5800/B120f User's Guide
12
Warnings and Additions to This Document
1. Unauthorized reproduction of the contents of this document, in part or in its entirety, is prohibited.
2. This document is subject to change at any time without notice.
3. Do not make copies or alter the document content without permission from NEC Corporation.
4. If you have any concerns, or discover errors or omissions in this document, contact your sales
representative.
5. Regardless of article 4, NEC Corporation assumes no responsibility for effects resulting from your
operations.
6. The sample values used in this document are not actual values.
Keep this document for future reference.
Latest editions
This document was created based on the information available at the time of its creation. The screen images,
messages and procedures are subject to change without notice. Substitute as appropriate when content has
been modified.
The most recent version of the guide, as well as other related documents, is also available for download from
the following website.
http://www.nec.com/

Precautions for Use (Be Sure to Read)
Express5800/B120f User's Guide 13
Precautions for Use (Be Sure to Read)
The following provides information required to use your server safely and properly. For details of names in this
section, refer to Names and Functions of Parts in this document.
Safety precautions
Follow the instructions in this document for the safe use of the NEC Express server.
This User’s Guide describes hazardous parts of the server, possible hazards, and how to avoid them. Server
components with possible danger are indicated with a warning label placed on or around them (or, in some
cases, by printing the warnings on the server).
In User’s Guide or on warning labels, WARNING or CAUTION is used to indicate a degree of danger. These
terms are defined as follows:
WARNING Indicates there is a risk of death or serious personal injury
CAUTION Indicates there is a risk of burns, other personal injury, or property damage
Precautions and notices against hazards are presented with one of the following three symbols. The individual
symbols are defined as follows:
Attention This symbol indicates the presence of a hazard if
the instruction is ignored.
An image in the symbol illustrates the hazard type.
Prohibited
Action This symbol indicates prohibited actions. An image
in the symbol illustrates a particular prohibited
action.
Mandatory
Action This symbol indicates mandatory actions. An
image in the symbol illustrates a mandatory action
to avoid a particular hazard.
(Example)
(Do not disassemble)
(Example)
(Electric shock risk)
(Example)
(Disconnect a plug)

Precautions for Use (Be Sure to Read)
Express5800/B120f User's Guide
14
(A label example used in this User’s Guide)
Symbols used in this document and on warning labels
Attentions
Indicates the presence of electric shock
hazards. Indicates the presence of mechanical parts that can result in bodily injury.
Indicates the presence of a hot surface or
component. Touching this surface could
result in bodily injury.
Indicates the presence of mechanical
parts that can result in pinching or other
bodily injury.
Indicates there is a risk of explosion. Indicates the presence of laser beam that
cause blindness.
Indicates there is a risk of fire or fumes. Indicates a general notice or warning that
cannot be specifically identified.
Prohibited Actions
Do not disassemble, repair, or modify the
server. Otherwise, an electric shock or fire
may be caused.
Do not touch the server with wet hand.
Otherwise, an electric shock may be
caused.
Do not touch the component specified by
this symbol. Otherwise, an electric shock
or burn may be caused.
Do not use the server in the place where
water or liquid may pour. Otherwise, an
electric shock or fire may be caused.
Do not place the server near the fire.
Otherwise, a fire may be caused. Indicates a general prohibited action that cannot be specifically identified.
Mandatory Actions
Unplug the power cord of the server.
Otherwise, an electric shock or fire may be
caused.
Indicates a mandatory action that cannot
be specifically identified. Make sure to
follow the instruction.
Make sure equipment is properly
grounded. Otherwise, an electric shock or
fire may be caused.
WARNING
Use only the specified outlet
Use a grounded outlet with the specified voltage. Use of an improper power source
may cause a fire or a power leak.
Symbol to
draw attention Descri
p
tion of a Term indicating a degree of

Precautions for Use (Be Sure to Read)
Express5800/B120f User's Guide 15
Safety notes
To use this server safely, read thoroughly the "Safety Precautions and Regulatory Notices" that comes with your
server. For symbols used in this document, refer to "Safety precautions".
Handling precautions (for proper operations)
Be sure to observe the following precautions for the proper functioning of the server. Ignoring the precautions
may cause server malfunction or failure.
●General
– Do not block air vents of the CPU blades, Blade Enclosures, power supply units, and additional fan units.
– The CPU blade and internal option devices contain precision component that is easily affected by drastic
temperature change. If the device is used after storage or relocation, make sure that the device is fully
adapted to the operating environment.
– Do not touch the CPU blade terminals or on-board components by a bare hand nor place the CPU blade
directly on the desk.
– It is recommended to use options provided by NEC. Some memory devices and solid state drives of
other vendors are designed to be available for the server. If such an option causes the server to be
defected or damaged, you will be charged for the repair within the warranty period.
– Turn off the cellular phone or pager around the server. Radio interference may cause malfunctions of the
server.
●CPU blade
– N8400-230F/231F/232F/233F/234F/236F CPU blade should be installed in the Blade Enclosure
(SIGMABLADE).
– Install or remove CPU blades one by one.
– Hold the portions covered with metal plates when a CPU blade is installed or removed. To carry a CPU
blade, put it into the case in which the CPU blade was contained at the purchase and pack it into the
package.
– Check and adjust the system clock before the operation if any of the following conditions is applicable.
After transportation
After storage
After the server is used following a period of disuse, in which storage conditions did not conform to
those that guarantee server operations (temperature: 10C to 40C; humidity: 20% to 80%).
– Check the system clock at the rough rate of once per month. When the system clock is installed in a
system requiring high time precision, it is recommended to use a time server (NTP server).
If the system clock is remarkably delayed or advanced as the passage of time in spite of adjustment,
contact your sales representative to ask maintenance.
– Store the unit under the storage condition (temperature: –10°C to 55°C, humidity: 20% to 80%, without
condensation).
– Turn on the power of each CPU blade by pressing the POWER switch or the remote power-on operation
after the period of 60 seconds or longer has passed from the supply of power (the POWER LED of the
CPU blade goes on amber). The power of the CPU blade may not be turned on if the power-on operation
is done within the period of less than 60 seconds from the supply of power. After making sure that the
power is supplied to every CPU blade, turn on the power of each CPU blade by pressing the POWER
switch.

Precautions for Use (Be Sure to Read)
Express5800/B120f User's Guide
16
– After turning off the power of a CPU blade once, turn on the power again after 30 seconds have passed
from the power-off.
– Remove a CPU blade after turning off the power of the CPU blade.
– Do not perform any of the following operation during POST (including similar operations from EM card
and external applications).
Press the POWER switch of the CPU blade.
Press the RESET switch of the CPU blade.
Remove the CPU blade from the Blade Enclosure.
Disconnect the power cord from the power unit of the Blade Enclosure.
●Hard disk drive
– Confirm the slot to which the hard disk drive is inserted. The slot for the hard disk drive to be connected
to each CPU blade is defined previously.

Precautions for Use (Be Sure to Read)
Express5800/B120f User's Guide 17
Handling precautions (for Anti-static Measures)
This product contains static-sensitive electronic components. Follow this measures below to avoid a failure
caused by static electricity when installing or uninstalling any optional device.
●Wearing anti-static wrist strap or anti-static gloves
Wear a wrist strap on your wrist and connect the wire to the chassis. If there is no wrist strap, touch an
unpainted metal surface of the chassis connected to the ground to discharge static electricity from your body
before touching the component. Touch the metal part occasionally to discharge the static electricity while
working on the component.
●Checking the workplace
– Work on an anti-static floor or concrete floor.
– If you work on a place where static electricity is likely to be generated (e.g. carpet), be sure to provide
anti-static protection.
●Using the work table
Place the server on a mat with Electrostatic Discharge (ESD) protection.
●Clothing
– Do not wear wool or synthetic clothes.
– Wear anti-static shoes.
– Remove any kind of metal accessories such as a ring, bracelet or wrist watch.
●Handling of components
– Keep the component in an anti-static bag until you install it to the server.
– Hold the component by the edges to avoid touching any terminals or mounting parts.
– Place the component in an anti-static bag when storing or moving them.
●Handling of cables
When connecting a cable (e.g., LAN cable), static electricity may also be charged due to friction against the
floor.
Connecting the charged cable with an I/O device may cause damage to the devices in the system. It is
recommended to use a product such as electrostatic discharge kit to eliminate the static charge before
connecting the cable.
●Installing and uninstalling the optional device
– To avoid electric hazard and malfunction, be sure to turn off the power switch of the server and unplug
the power cord from the outlet before installing or uninstalling any optional device. If the device is
hot-swappable, you do not need to turn off the power switch and unplug the power cord.
– The device contains static-sensitive electronic components. When installing or uninstalling the optional
device, wear an anti-static wrist strap on your wrist to avoid a failure caused by the static electricity. To
use the strap, connect the wire to the chassis.

Precautions for Use (Be Sure to Read)
Express5800/B120f User's Guide
18
Handling precautions (Power-saving feature)
The server does not support power-saving features of OS such as Standby, Hibernate, and Sleep mode.

Precautions for Use (Be Sure to Read)
Express5800/B120f User's Guide 19
Using a computer extensively may affect different parts of your body. Here are tips you should follow while working on
a computer to minimize strain on your body.
Keep proper posture
The basic body position for using a computer is sitting straight with
your hands on the keyboard parallel with the floor, and your eyes
directed slightly downward toward the monitor. With the proper
posture described above, no unnecessary strain is applied on any
part of your body, in other words when your muscles are most
relaxed.
Working on the computer with bad posture such as hunching over or
being too close to the monitor could cause fatigue or deteriorated
eyesight.
Adjust the angle of your display
Most display units are designed for adjustment of the horizontal and
vertical angles. This adjustment is important to prevent the screen
from reflecting bright lights and to make the display contents easy to
see. Working without adjusting the display to a comfortable angle
makes it difficult for you to maintain a proper posture and you will
get tired easily. Adjust the viewing angle before use.
Adjust the brightness and contrast of the display
Display screens have functions to control brightness and contrast.
The most suitable brightness/contrast depends on age, individuals,
and environment, so adjust it to suit your preferences. A too bright
or too dark display is bad for your eyes.
Adjust the angle of keyboard
Some keyboards are ergonomically designed, which allow the angle
to be adjusted. Adjusting the angle of the keyboard is effective to
reduce tension on your shoulders, arms, and fingers.
Clean your equipment
Keeping your equipment clean is important not only for the appearance but also for functional and safety reasons. A
dusty monitor makes it difficult to see the display contents, so clean it regularly.
Take rest breaks
When you feel tired, take a break. Light exercise is also
recommended.
Tips for your health and safety

Express5800/B120f User's Guide
20
NEC Express5800 Series
Express5800/B120f
General Description
This chapter describes the features of the server and bundled software, and precautions on installation.
1. Introduction
2. Accessories
Describes your server's accessories.
3. Standard Features
Describes standard features of the server and system management utilities.
4. Names and Functions of Parts
Describes the name of each part contained in this server.
