NEAX 2000 IPS
SIP Trunk System Manual
TABLE OF CONTENTS
– i – NWA-011436-001 Rev.3.0
9ytoc001.fm
INTRODUCTION .................................................................................................................. 1
PURPOSE .................................................................................................................... 1
OUTLINE OF THIS MANUAL ...................................................................................... 1
TERMS IN THIS MANUAL ........................................................................................... 2
PBX SYSTEM DESIGNATION ............................................................................................. 2
REFERENCE MANUAL ............................................................................................... 3
CHAPTER 1 GENERAL INFORMATION ........................................................................... 5
SYSTEM OUTLINE ...................................................................................................... 6
SERVICE CONDITIONS .............................................................................................. 7
SERVICE FEATURES ................................................................................................. 8
CHAPTER 2 INSTALLATION ............................................................................................. 11
PRECAUTIONS ........................................................................................................... 12
Static Electricity Guard ...................................................................................................... 12
Turning Power ON .............................................................................................................. 15
Turning Power OFF ............................................................................................................ 16
REQUIRED EQUIPMENT ............................................................................................ 17
INSTALLATION PROCEDURE ................................................................................... 18
Mounting SIP Card .............................................................................................................. 19
LAN Cable Connection of SIP Card .................................................................................. 20
CHAPTER 3 SYSTEM DATA PROGRAMMING ................................................................ 21
HOW TO READ THIS CHAPTER ................................................................................ 22
PRECAUTIONS ........................................................................................................... 23
System Data Backup .......................................................................................................... 23
Office Data Conversion ...................................................................................................... 24
LEN Assignment by CM14 ................................................................................................. 25
PROGRAMMING ......................................................................................................... 26
SIP Trunk Data Assignment ............................................................................................... 27
Ringing Tone ....................................................................................................................... 54
SIP FEATURE PROGRAMMING ................................................................................. 58
Alternate Routing for a Fault Occurrence ........................................................................ 59
Caller ID Display ................................................................................................................. 61
Direct Inward Dialing (DID) ................................................................................................ 66
E.164 “+” Addition/Deletion ............................................................................................... 68
Fault Registration ............................................................................................................... 69

– ii – NWA-011436-001 Rev.3.0
9ytoc001.fm
TABLE OF CONTENTS
Fragmented IP Packet Receiving ...................................................................................... 71
Multiple CODEC Selection ................................................................................................. 72
Session Timer ..................................................................................................................... 75
NAT Support in SIP Trunk .................................................................................................. 77
Out-band DTMF ...................................................................................................................80
Source IP Address Check on SIP Trunk ........................................................................... 83
RTCP Function of SIP Trunk .............................................................................................. 89
SYSTEM DATA BACKUP ........................................................................................... 91
SYSTEM RESET .......................................................................................................... 93
CHAPTER 4 CIRCUIT CARD INFORMATION ................................................................... 95
HOW TO READ THIS CHAPTER ................................................................................ 96
MOUNTING LOCATION OF CIRCUIT CARDS ........................................................... 97
Regular PIM ......................................................................................................................... 97
PIM for Backup CPU System ............................................................................................. 98
LIST OF REQUIRED CIRCUIT CARD ......................................................................... 99
PN-8IPTA (SIP) .................................................................................................................... 100
APRIL/20/2007

INTRODUCTION
– 1 – NWA-011436-001 Rev.3.0
9ych0001.fm
INTRODUCTION
PURPOSE
This manual explains the hardware installation and the programming procedure for providing SIP trunk
system to the NEAX 2000 IPS System.
OUTLINE OF THIS MANUAL
This manual consists of four chapters. The following paragraphs summarize Chapters 1 through 4.
CHAPTER 1 GENERAL INFORMATION
This chapter explains the SIP trunk system outline, service conditions, and the
service features.
CHAPTER 2 INSTALLATION
This chapter explains the required equipment and the hardware installation
procedure to the SIP trunk system.
CHAPTER 3 SYSTEM DATA PROGRAMMING
This chapter explains the programming procedure for providing SIP trunk system.
CHAPTER 4 CIRCUIT CARD INFORMATION
This chapter explains the mounting location, meaning of lamp indications, and the
switch settings of the SIP circuit card.
PURPOSE/OUTLINE OF THIS MANUAL

INTRODUCTION
– 2 – NWA-011436-001 Rev.3.0
9ych0001.fm
TERMS IN THIS MANUAL
PBX SYSTEM DESIGNATION
PBX system is designated as “PBX” or “system” usually.
When we must draw a clear line between the PBX systems, they are designated as follows.
2000 IPS: NEAX 2000 IPS INTERNET PROTOCOL SERVER
NOTE 1: In regard to China market, we have not released NEAX 2000 IPS INTERNET PROTOCOL
SERVER but NEAX 2000 is released.
NOTE 2: In regard to the China market, we have not released NEAX 2400 IPX Internet Protocol
eXchange but NEAX 2400 is released.
TERMS IN THIS MANUAL

INTRODUCTION
– 3 – NWA-011436-001 Rev.3.0
9ych0001.fm
REFERENCE MANUAL
During installation, refer also to the manuals below:
System Manual:
Contains the system description, hardware installation procedure and the programming procedure for
the NEAX 2000 IPS System.
Command Manual:
Contains Customer Administration Terminal (CAT) operation, command functions and data re-
quired for programming the system, and Resident System Program.
Feature Programming Manual:
Contains procedure for programming each business and hotel feature.
Office Data Programming Manual:
Contains the Customer Specifications Sheets and the Office Data Programming Sheets.
Maintenance Manual:
Contains the programming procedure for maintenance service features and the recommended trou-
bleshooting procedure.
Installation Procedure Manual:
Contains the installation procedure for the PBX system.
REFERENCE MANUAL

– 4 – NWA-011436-001 Rev.3.0
9ych0001.fm
THIS PAGE LEFT BLANK INTENTIONALLY.

– 5 – NWA-011436-001 Rev.3.0
9ych1001.fm
CHAPTER 1
GENERAL INFORMATION
This chapter explains the SIP trunk system outline, service conditions, and
the service features.
SYSTEM OUTLINE .................................................................... 6
SERVICE CONDITIONS ............................................................ 7
SERVICE FEATURES ............................................................... 8
CHAPTER 1 GENERAL INFORMATION

CHAPTER 1 GENERAL INFORMATION
– 6 – NWA-011436-001 Rev.3.0
9ych1001.fm
SYSTEM OUTLINE
This system provides the IP phone service by TopLink with mounting SIP trunk on PBX.
System Outline
PSTN/
GSTN
TopLink (IP)
Router
PBX
SIP trunk
SYSTEM OUTLINE

CHAPTER 1 GENERAL INFORMATION
– 7 – NWA-011436-001 Rev.3.0
9ych1001.fm
SERVICE CONDITIONS
(1) SIP trunk system is available for Series 3600 software or later.
(2) The maximum number of the SIP card to be mounted is 8 per system including the CCH, CCT, IPT,
and virtual IPT.
(3) Setting of alternate routing to C.O. line is required in this system. Refer to “Alternate Routing for a
Fault Occurrence” on Page 59.
(4) Maximum 8 channels (trunks) are available per PN-8IPTA card. Maximum 32 channels (trunks) are
available with mounting PZ-24IPLA card on PN-8IPTA card. However, the number of channels
(trunks) for SIP trunk use is restricted up to 64 per system.
(5) Maximum 8 of PN-8IPTA cards can be mounted in per PIM. However, the number of channels
(trunks) for SIP trunk use is restricted maximum 64 per system.
(6) PN-8IPTA occupies 1 time slot per 1 channel.
(7) The maximum number of AP port use per one card is as follows. However, The number of AP port
use can be changed with setting the office data programming.
PN-8IPTA: Maximum 8 port per one card
PN-8IPTA + PZ-24IPLA: Maximum 32 port per one card
(8) PN-8IPTA can be used only at Main Site.
(9) The total number of voice channel of the following trunk is maximum 127.
•SIP
• CCIS Virtual IPT
• CCIS IPT Port (Point-to-Multi point connection)
SERVICE CONDITIONS

CHAPTER 1 GENERAL INFORMATION
– 8 – NWA-011436-001 Rev.3.0
9ych1001.fm
SERVICE FEATURES
The following is the features to be provided via SIP trunk for IP phone service.
Alternate Routing
Caller ID Display
Direct Inward Dialing (DID)
E.164 “+” Addition/Deletion
Fault Registration
Fragmented IP Packet Receiving
Multiple CODEC Selection
Session Timer
Listed from next page are the service features provided by NEAX 2000 IPS. According to that some of
these service features are not available depending on the terminal, set the service features based on the list.
For the further information, refer to the IPS System Manual and Feature Programming Manual.
Please note that the manuals above are not covered about the following.
Terminating System (translation method of called number) NOTE
(a) Terminated via Tie line
PBX defines the termination destination with Dial Number Development assuming that the
called number was originated from Tie line.
- Station/Attendant Console/trunk (at tandem connection) can be specified as a destination.
- When PBX defines to send to station, the last 1 to 8 digits of the number can be handled as the
station number.
- When PBX defines to send to trunk, the number can be deleted/added with LCR number de-
velopment. (Delete: Maximum 10 digits/Add: Maximum 32 digits)
(b) Terminated via DID
- The last 1 to 8 digits of the called number is handled as the DID number.
- The number can be converted into the following Terminating System with DID Number
Development.
•Station
•TAS
• Automated Attendant
•DISA
- Maximum 1000 DID numbers can be handled.
- DID number which is not registered is treated as Tie Line termination.
SERVICE FEATURES

CHAPTER 1 GENERAL INFORMATION
– 9 – NWA-011436-001 Rev.3.0
9ych1001.fm
Method of origination operation
PBX originates a call with LCR Number Development.
Holding/Transferring features
Holding/Transferring features are not available with SIP method.
Setting Ringing Tone
The ringing tone for SIP transmission can be set by CM08>649.
NOTE: All the types of the called numbers are handled similarly on the PBX. When you want to dis-
criminate between the called numbers which are recognized as representative numbers on such
an upper SIP server and the called numbers which are recognized as DID numbers, assign an
appropriate terminating system to each called number. E.g. Fragmented IP packet receiving for
representative numbers, Direct Inward Dialing (DID) for station terminating.
SERVICE FEATURES

CHAPTER 1 GENERAL INFORMATION
– 10 – NWA-011436-001 Rev.3.0
9ych1001.fm
List of PBX Service Features
×: Available –: Not available ∆: Out of Target
SERVICE FEATURES Dterm SLT PHS Dterm
IP
Dterm
SP30 REMARKS
Hot Line-OUTSIDE ×××××
Call Hold ×××××
Speed Calling-Station
(Station Speed Dialing)
×××××
Speed Calling-System
(System Speed Dialing)
×××××
Last Number Call
(Last Number Redial)
××–××
Toll Restriction ×××××
Direct Inward Dialing (DID) ××××∆
DID Name Display ×–××∆
Station Camp-On (Camp-On) ××××∆
Music on Hold ××∆×∆
Group Diversion ××××∆
DAY/NIGHT MODE Change by
System Clock
×××××
Queue Limit For TAS ×××××
Distinctive Ringing ×∆∆×∆
Automated Attendant ×××××
Remote Access to System
(Direct Inward System Access)
×××××
Call Forwarding Set by DISA ×××××
Day/Night Mode Change by
Station Dialing
×××××
Night Connection-Fixed
Night Connection-Flexible
×××××
SERVICE FEATURES

– 11 – NWA-011436-001 Rev.3.0
9ych2001.fm
CHAPTER 2
INSTALLATION
This chapter explains the required equipment and the hardware installation
procedure to the SIP trunk system.
PRECAUTIONS ......................................................................... 12
REQUIRED EQUIPMENT .......................................................... 17
INSTALLATION PROCEDURE ................................................. 18
CHAPTER 2 INSTALLATION

CHAPTER 2 INSTALLATION
– 12 – NWA-011436-001 Rev.3.0
9ych2001.fm
PRECAUTIONS
Static Electricity Guard
You must wear a grounded wrist strap to protect circuit cards from static electricity.
Static Electricity Guard
• WHEN PLUGGING/UNPLUGGING A CIRCUIT CARD
• WHEN HOLDING A CIRCUIT CARD
Continued on next page
FRAME GROUND SCREW
PBX
WRIST STRAP
NEVER TOUCH THE COMPONENTS OR
SOLDERED SURFACE WITH BARE HANDS.
CARD FRONT
PRECAUTIONS

CHAPTER 2 INSTALLATION
– 13 – NWA-011436-001 Rev.3.0
9ych2001.fm
Static Electricity Guard
• WHEN MAKING A SWITCH SETTING ON A CIRCUIT CARD
• WHEN CARRYING A CIRCUIT CARD
The mark shown below is attached to the sheet for the work in which circuit cards are handled. When
engaging in such work, the installer must be careful not to cause damage by static electricity.
WEAR A WRIST STRAP AND PERFORM
THE WORK ON A GROUNDED
CONDUCTIVE WORK SURFACE.
CIRCUIT
CARD
WHEN CARRYING A CIRCUIT
CARD AROUND, KEEP THE
CARD IN A CONDUCTIVE
POLYETHYLENE BAG.
CIRCUIT
CARD
CONDUCTIVE
POLYETHYLENE
BAG
ATTENTION
Contents
Static Sensitive
Handling
Precautions Required
PRECAUTIONS

CHAPTER 2 INSTALLATION
– 14 – NWA-011436-001 Rev.3.0
9ych2001.fm
CAUTION
1. You must hold the edge of a circuit card when plugging or unplugging the circuit card.
If you touch another area, you may be exposed to hazardous voltages.
2. You must wait for 30 seconds before plugging the circuit card again when unplugging the
circuit card while the operating power is being supplied.
CARD FRONT
NEVER TOUCH THE COMPO-
NENTS OR SOLDERED SUR-
FACE WITH BARE HANDS.
PBX
APRIL/20/2007
PRECAUTIONS
