NEC NP01UCM Guide

ISSUED: 04-11-06 SHEET #: 055-9458-2 05-09-06
Visit the NEC Web Site at www.necsam.com
1 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
Read instruction sheet before you start installation and assembly.
Maximum Load Capacity: 50 lb (22.7 kg)
IMPORTANT! Be sure not to touch the projector while tightening the set screw on the
ball and socket mount. This may cause the image to be unaligned when you let go.
Applications:
FlushMount.................................................................................................................................................. page 7
ExtensionColumn........................................................................................................................................ page 8
Installations:
To Wood Joist Finished Ceilings,
Exposed Wood Joists, or Wood Beam Ceilings........................................................................................ page 5
To Concrete Ceilings.................................................................................................................................... page 6
IMPORTANT! Turn to the appropriate page for your ceiling installation.
• Makesurethatthesupportingsurfacewillsafelysupportthecombinedloadoftheequipmentandallattachedhardwareand
components.
WARNING
Model: NP01UCM
Installation andAssembly - Universal Ceiling Mount

ISSUED: 04-11-06 SHEET #: 055-9458-1
Visit the NEC Web Site at www.necsam.com 2 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
Compatability Chart
for NEC Projectors
Manufacturer Model Manufacturer Model
NEC HT410 NEC MT1035
NEC HT510 NEC MT1035+
NEC GT1150 NEC MT830
NEC GT2150 NEC MT830+
NEC GT5000 NEC MT1040
NEC GT6000 NEC MT1045
NEC GT6000R NEC MT840
NEC GT2000 NEC MT850
NEC GT2000R NEC MT1050
NEC GT950 NEC MT1055
NEC LT10 NEC MT1056
NEC LT140 NEC MT860
NEC LT84 NEC MT1060
NEC LT150 NEC MT1060R
NEC LT150z NEC MT1065
NEC LT75 NEC MultisyncLT245
NEC LT75z NEC NP1000
NEC LT85 NEC NP2000
NEC LT154 NEC V37
NEC LT155 NEC LT380
NEC LT156 NEC VT440
NEC LT157 NEC VT440K
NEC LT158 NEC VT540
NEC LT170 NEC VT540K
NEC LT180 NEC VT650
NEC LT220 NEC VT45
NEC LT240 NEC VT45K
NEC LT240K NEC VT46
NEC LT245 NEC VT460
NEC LT260 NEC VT465
NEC LT260K NEC V47
NEC LT265 NEC VT560
NEC LT280 NEC VT660
NEC LT35 NEC VT660K
NEC HT1000 NEC VT770
NEC HT1100 NEC VT47
NEC MT1000 NEC VT470
NEC MT1020 NEC VT480
NEC MT810 NEC VT48
NEC MT820 NEC VT570
NEC MT1030 NEC VT575
NEC MT1030+ NEC VT580
NEC VT670
NEC VT676
NEC WT600

ISSUED: 04-11-06 SHEET #: 055-9458-2 05-09-06
Visit the NEC Web Site at www.necsam.com
3 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
Parts List
Before you start check the parts list to insure all of the parts shown are included.
Description Qty. Part Number
Aball and socket mount 1 055-0016
B4 mm security allen wrench 1 560-9646
CM5 x .8 x 10 mm socket pin type F screw 1 520-2031
D#10-32 x 3/8" spade thumb screw 1 560-2107
E#10-32 x 3/8" serrated washer head socket pin screw 1 520-2151
F#14 x 2.5 phillips hex head wood screw 2 5S1-015-C04
Gceilingplate 1 580-4042
H.25" ID x .56" OD x .26 spacer 2 590-2071
Iextensioncolumn connectorwithcord management 1 580-4025
J#10-32 x 3/8" socket pin screw 2 520-2084
K#10-32 x 3/16" slotted set screw 3 520-2187
Ladapterplate 1 055-0614
MM3 x 8 mm serrated washer head socket pin screw (not shown) 4 510-2004
NM4 x 10 mm serrated washer head socket pin screw (not shown) 4 510-2060
OM5 x 10 mm serrated washer head socket pin screw (not shown) 4 510-2063
PM6 x 10 mm serrated washer head socket pin screw (not shown) 4 510-2066
Q2 mm security allen wrench 1 560-1097
Rwasher 4 540-2025
B
CE
DF
H
J
FASTENERS
K
Note: Actual parts may appear slightly different than illustrated.
AIG
R
Q
L

ISSUED: 04-11-06 SHEET #: 055-9458-1
Visit the NEC Web Site at www.necsam.com 4 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
GenericScrew
L
Mounting
hole
*
GenericProjector
Placeprojector upsidedown. Locateadapterplate (L)with notchfacingforward asclose toprojector center of
gravityas possiblewithout covering anymounting holes.Loosenchannels, andif there areonly threemounting
holesremove fourthchannel.Using onechannelfor each mountinghole,position feetofchannels overmounting
holes as shown below. Important: If projector does not have at least three mounting holes, do not use this
adapterplate.
Note:Some projectorshave feetwhichcan beremovedand thecorrespondingthreaded insertcanbe usedfora
mountinghole.
Note:Oncechannels arein positionretightenfasteners.
*Notchindicates frontofprojector.
Note:Theprojector youareinstallingmay differinappearance fromthesample illustratedbelow.
Attach adapter plate (L) to projector using one screw (M, N, O, or P) for each channel as shown below. Tighten
all screws, while keeping the center of gravity. Be sure that adapter plate (L) is straight.Adjust the feet of the
channels to keep the adapter plate level. Tighten all screws with 4 mm security allen wrench (B) or wrench
providedwith projectormount, whilekeepingthe centerof gravity.If M3screws areused,tighten using2 mm
securityallen wrench(Q).
Note: Projectors will require different size screws for mounting. Use a combination of screws (M, N, O, or P) and
foot adjustment that will result in channels of adapter plate (L) fitting tightly against projector. Important: In order
to properly engage the threads in the mounting holes, the screw must be turned at least 3 full turns.
Note:If usingscrew (M),placewasher (R)betweenscrew (M)andfoot ofchannel.
FootofChannel
L
• It is the responsibility of the installer to ensure that the
projectoris properlyventilated.Feet ofchannelsare
usedto raisethe mountoff theprojector surface.
CAUTION
Installation and assembly - Universal Adapter Plate

ISSUED: 04-11-06 SHEET #: 055-9458-2 05-09-06
Visit the NEC Web Site at www.necsam.com
5 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
F
F
G
WOOD
JOIST
CEILING
Drill two 5/32" (4 mm) dia. holes to a minimum
depth of 2.5" (64 mm). Attach ceiling plate (G)
with two #14 x 2.5" (6 mm x 65 mm) wood
screws (F) as shown using 3/8" (10 mm) socket
wrench.
Skip to step 2.
IMPORTANT: Be sure to drill holes into the
joistCENTER!
For optional Cord Management,
installtwo spacers(H)between ceiling
plate(G)andceiling.
Installation To Wood Joist Finished Ceilings,
Exposed Wood Joists, or Wood Beam Ceilings
WOOD
JOIST
CEILING
F
F
G
HH
• Tighten wood screws (F) so that wall plate (G) is firmly
attached,but donotovertighten.Overtightening can
damagethe screws,greatlyreducing theirholding
power.
• Never tighten in excess of 80 in • lb (9 N.M.).
• Make sure that mounting screws are anchored into the
center of the studs. The use of an "edge to edge" stud
finderis highlyrecommended.
WARNING
• It is the responsibility of the installer to verify that the
supportingsurface willsafelysupport thecombined
loadof allattachedhardware andcomponents.
WARNING

ISSUED: 04-11-06 SHEET #: 055-9458-1
Visit the NEC Web Site at www.necsam.com 6 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
Drill two 1/4" (6 mm) dia. holes to a minimum depth of
2.5" (64 mm). Attach ceiling plate (G) using two
concrete anchors and #14 x 2.5" wood screws (F) as
shown in Illustration A and 1, 2, and 3 (below).
Tightenallfasteners.
IMPORTANT: It is the responsibility of the installer
to verify that the ceiling will safely support the
combined load of all attached hardware and
components.
1
3
CUTAWAYVIEW
INCORRECT
concrete
metal
bracket
plaster/
drywall
CORRECT
concrete
metal
bracket
plaster/
drywall
concrete
ceiling
concrete
anchor
concrete
anchor
concrete
anchor
F
F
Illustration A
Installation to Concrete Ceilings
ACC 203 (Alligator® concrete anchors) are recommended.
2G
•FORDIRECTATTACHMENTTOLOAD BEARING
CONCRETEONLY!Concreteexpansionanchorsare
not intendedfor attachmentto concreteceilings
coveredwith alayerof plaster, drywall,orother
finishingmaterial. Ifmounting to concreteceiling
coveredwith plaster/drywall isunavoidable, plaster/
drywallmust becounterboredas shownbelow.
WARNING
F
G
CONCRETECEILING
concrete
anchor
Drill hole and insert anchor
Place ceiling plate over anchor and secure with screw
After repeating step one tighten all fasteners
• Tighten wood screws so that wall plate is firmly
attached,but donotovertighten.Overtightening can
damagethe screws,greatlyreducing theirholding
power.
• Never tighten in excess of 80 in • lb (9 N.M.).
• Make sure that mounting screws are anchored into the
center of the studs. The use of an "edge to edge" stud
finderis highlyrecommended.
WARNING
• When installing wall mounts on concrete, verify that you have a minimum of 1 5/8" of actual concrete surface in the 1/
4" diameter hole to be used for the concrete anchors. Do not drill into mortar joints! Concrete must meetASTM C-90
specifications.
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.
• Makesure thatthe supportingsurface willsafely supportthe combinedload ofthe equipment andall attachedhard-
wareand components.
• Neverexceed theMaximum LoadCapacityof 50lb (22.7kg).
WARNING

ISSUED: 04-11-06 SHEET #: 055-9458-2 05-09-06
Visit the NEC Web Site at www.necsam.com
7 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
Screw ball and socket mount (A) into ceiling plate (G).Align the notch with one of the four holes of the ceiling plate
(G) and secure ball and socket mount (A) with a M5 x 10 mm socket pin screw (C) using security allen wrench (B)
as shown in detail 1.
Note: Slotted set screw (K) is used to jam against the threads of the ball and socket mount to prevent any excess
movementof theballand socketmount(A). Donotovertighten screw;overtighteningscrew willdamagethreads
making it difficult to separate the products.
Skip to step 3.
Flush Mount Application
DETAIL 1
A
G
A
C
WOOD
CEILING
NOTCH
G
K

ISSUED: 04-11-06 SHEET #: 055-9458-1
Visit the NEC Web Site at www.necsam.com 8 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
Screw extension column to ceiling plate (G).
Align the notch with one of the four holes in
the ceiling plate (G) and secure extension
column with a M5 x 10 mm socket pin
screw(C) usingsecurityallen wrench(B).
See detail 4.
Screw extension column connector (I) to
extension column. Align slot in extension
column with one of the top holes in
extensioncolumn connector(I).Insertand
tighten one #10-32 x 3/8" socket pin screw
(J)throughextensioncolumnconnector(I)
into slot on extension column using security
allen wrench (B). See detail 5.
Screw ball and socket mount (A) to
extension column connector (I). Align slot in
ball and socket mount (A) to one of the
bottom holes in extension column connector
(I). Insert and tighten one #10-32 x 3/8"
socket pin screw (J) through extension
column connector into slot in ball and
socket mount (A) using security allen
wrench (B). See detail 6.
Note: Slotted set screws (K) are used to
jam against the threads of each connecting
jointtoprevent anyexcessmovement.Do
notovertightenscrews;overtightening
screws will damage threads making it
difficultto separatethe products.
DETAIL 6
SLOT
SLOT
G
I
DETAIL 5
DETAIL 4
EXTENSION
COLUMN
C
G
Installation to
Extension Column
A
K
A
EXTENSION
COLUMN
SLOT
I
J
EXTENSION
COLUMN
SLOT
IJ
K
K
EXTENSIONCOLUMN
(UL Listed EXT orADJ
Series)
Sold Separately

ISSUED: 04-11-06 SHEET #: 055-9458-2 05-09-06
Visit the NEC Web Site at www.necsam.com
9 of 9 For customer care call 1-800-729-0307 or 708-865-8870.
To adjust roll, pitch, and yaw loosen the set screw
(shown below) using security allen wrench (B) or
standard 4 mm allen wrench. You should be able to
just slightly loosen the screw so that your adjustments
can be set without having to hold the projector. Move
projector to desired position and slowly tighten set
screw.
Note: Be sure not to touch the projector while
tightening the set screw. This may cause the image
to be unaligned when you let go.
IMPORTANT:Allen wrench is your key for projector
removal. Store it in a safe place.
Note: The projector adapter plate and projector you are installing may differ in appearance from the sample
illustrated below.
Attach projector, with adapter plate already on it, to the
ball and socket mount (A) by inserting the ball and
socket mount (A) into the adapter plate connection and
twisting until the adapter plate will no longer turn
(about 75°). The spring loaded captive screw should
line up with a corresponding hole on the adapter plate
(this should line up automatically when the two are
connected). Push down and tighten the spring loaded
captive screw to secure the adapter plate to the mount.
If not using the optional security feature, fasten thumb
screw (D) in the hole opposite the spring loaded
captive screw.
OPTIONAL: For security, insert serrated washer head
socket pin security screw (E) in the hole opposite the
spring loaded captive screw. Tighten with security
allen wrench (B). This will prevent the projector from
being removed.
Note: Be sure to only use the #10-32 x 3/8" screw (E)
(or the thumb screw (D)) opposite the spring loaded
captive screw.
WOOD
JOIST
CEILING
• Do not lift more weight than you can handle! Use
additionalman powerormechanicallifting equipment
tosafely handleplacementof theprojector!
WARNING
ED
CAPTIVE
SCREW
WOOD
JOIST
CEILING
2
CUTAWAY VIEW OF
CEILINGPLATE (G)
A
1PROJECTOR ADAPTERPLATE
PROJECTOR
SETSCREW
PROJECTOR
