Nederman L-PAK Series User manual

Instruction Manual, PLC
L-PAK Series
L-PAK 150/250 Advanced
50 Hz, 0 Hz
Originalinstruction manual, plc
EN INSTRUCTION MANUAL, PLC
2022-03-17 2130223 (01)

L-PAK 150/250 Advanced
Trace back information:
Workspace Main version a1
Checked in 2022-03-17
Skribenta version 5.5.018

L-PAK 150/250 Advanced
Ta le of contents
Figures ............................................................................................................................................................................. 4
1 Preface ............................................................................................................................................................................
2 Safety ..............................................................................................................................................................................
2.1 Classification of important information .........................................................................................................
3 Description .....................................................................................................................................................................
4 Unit Operation ...............................................................................................................................................................
4.1 Software with extended functionality ..........................................................................................................
4.2 Unit operation modes ........................................................................................................................................
5 PLC messages ................................................................................................................................................................. 7
5.1 Status messages ................................................................................................................................................ 7
5.1.1 L-PAK Off (Off mode) .......................................................................................................................... 7
5.1.2 L-PAK Standby (Standby mode) ....................................................................................................... 7
5.1.3 Running (Running mode) ................................................................................................................... 7
5.1.4 Idling (Idling mode) .............................................................................................................................. 8
5.1.5 Filter Cleaning ...................................................................................................................................... 8
5.1. Status report ........................................................................................................................................ 9
5.2 Warning messages ............................................................................................................................................. 10
5.2.1 Time for service ................................................................................................................................... 10
5.2.2 Warning! Fan Hi-Temp ........................................................................................................................ 10
5.3 Alarm messages ................................................................................................................................................. 10
5.3.1 Alarm! Fan Hi-Temp ............................................................................................................................ 11
5.3.2 Alarm! Motor Protector Activated .................................................................................................... 11
5.3.3 Alarm! Low-Pressure CAS .................................................................................................................. 11
PLC settings .................................................................................................................................................................... 12
.1 Find a parameter and set its value .................................................................................................................. 12
.2 Parameter settings ............................................................................................................................................ 13
.2.1 Adjust the time and date .................................................................................................................... 13
.2.2 H-Meter 1 .............................................................................................................................................. 13
.2.3 ZV-Detect ............................................................................................................................................. 13
.2.4 SSR_Time .............................................................................................................................................. 14
.2.5 DIR_Time ............................................................................................................................................... 14
.2. Weekly timer ........................................................................................................................................ 14
.2.7 OTTmr .................................................................................................................................................... 1
.2.8 PSIFC-I2 ................................................................................................................................................. 1
.2.9 FCTmr ..................................................................................................................................................... 1
.2.10 Clean cycle ............................................................................................................................................ 17
.3 Standard cleaning process ............................................................................................................................... 17
.4 Standard Pilot Signal (PS) input ....................................................................................................................... 18
.4.1 PS Input 2 .............................................................................................................................................. 18
.4.2 PS Input 8 .............................................................................................................................................. 18
.5 Warning-Alarm output Q4 ................................................................................................................................ 18
. Standby (Ready) indicator ................................................................................................................................ 18
3

L-PAK 150/250 Advanced
Figures
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK
OFF
TimeTo Service
2000 Hours
ESC OK
Hi Vacuum Unit
Standby
Wai�ng For
Pilot Signal
Mo 15:33
2018-01-22
ESC OK
Hi Vacuum Unit
IDLING
Time To StandBy
T > 12:00m
ESC OK
Hi Vacuum Unit
Running
Time 05:33 Min
DIRTm 00:00 s
OTTmr 00:00 h
ESC OK
Hi Vacuum Unit
IDLING
Time To StandBy
T= 05:33m
PS
PS
ESC OK
Hi Vacuum Unit
Running
Time 05:33 Min
DIRTm < 10:00 s
OTTmr 00:00 h
ESC OK
Hi Vacuum Unit
Running
Time 06:33 Min
DIRTm > 10:00 s
OTTmr 00:00 h
ESC OK
Hi Vacuum Unit
IDLING
Time To StandBy
T < 12:00m
PS
Running
P = -20 kPa
IDLING
P = 0 kPa
PS
PS
Pilot signal OFF
Pilot signal On
1
4

L-PAK 150/250 Advanced
5

L-PAK 150/250 Advanced
1Preface
Thank you for using a Nederman product!
The Nederman Group is a world-leading supplier and
developer of products and solutions for the environ-
mental technology sector. Our innovative products
will filter, clean and recycle in the most demanding of
environments. Nederman's products and solutions will
help you improve your productivity, reduce costs and
also reduce the impact on the environment from in-
dustrial processes.
Read all product documentation and the product iden-
tification plate carefully before installation, use, and
service of this product. Replace documentation imme-
diately if lost. Nederman reserves the right, without
previous notice, to modify and improve its products
including documentation.
This product is designed to meet the requirements
of relevant EC directives. To maintain this status, all
installation, maintenance, and repair is to be done
by qualified personnel using only Nederman original
spare parts and accessories. Contact the nearest au-
thorized distributor or Nederman for advice on tech-
nical service and obtaining spare parts. If there are
any damaged or missing parts when the product is de-
livered, notify the carrier and the local Nederman rep-
resentative immediately.
2Safety
2.1Classification of important informa-
tion
This document contains important information that
is presented either as a warning, caution or note, ac-
cording to the following examples:
WARNING!Risk of personal injury
Warnings indicate a potential hazard to the
health and safety of personnel, and how that
hazard may be avoided.
CAUTION!Risk of equipment damage
Cautions indicate a potential hazard to the
product but not to personnel, and how that
hazard may be avoided.
NOTE!
Notes contain other information that is import-
ant for personnel.
3Description
WARNING!Risk of personal injury
See the User Manual.
4Unit Operation
4.1Software with extended functional-
ity
L-PAK 150/250 Advanced comes with extended soft-
ware and a standard Logo! PLC display that allows a
technician to easily set parameters and read status
messages.
NOTE!
If the software is used in a logo without a dis-
play, it is not possible to change parameter set-
tings.
4.2Unit operation modes
L-PAK 150/250 Advanced has the following four oper-
ation modes:
1 Off mode
2 Standby mode
3 Running mode
4 Idling mode
See Section5.1Status messages for more information
about each mode. How the unit moves from one op-
eration mode to another is explained below. See also
Figure 1 for a flow chart showing how the unit goes
through its four different operation modes.
When the unit is in Off mode, the unit can be put in-
to Standby mode (the unit is ready) with its motor off
and the Filter Cleaning Valve (FCV) closed by press-
ing the Standby/Running button. While the unit is in
Standby mode, the unit can be put back into Off mode
again by pressing the Standby/Running button.
NOTE!
If power is lost to the unit, for example, if there
is a power outage, and Zero voltage detection
is set to OFF, see Section .2.3ZV-Detect, the
unit goes immediately back into Standby mode
once power is resumed without having to push
the Standby/Running button.
The unit goes from Standby mode into Running
mode when it receives a pilot signal by a valve being
opened at one or more work stations (in other words,
someone starts to work). The unit’s motor is now on
and the FCV is closed. The DIR_Time and SSR_Time
timers are not started, see Section .2.5DIR_Time and
Section .2.4SSR_Time.
The unit stays in Running mode as long as there is an
active pilot signal. However, the unit can still be put
into Off mode by pressing the Standby/ Running but-
ton.
Note that if only one workstation is connected to
the unit, or if only one workstation is in use and work
stops at that one station, the pilot signal stops. If
there is more than one work station connected to the
unit, and more than one work station is in use, the pi-

L-PAK 150/250 Advanced
lot signal only stops if work stops at all workstations
(in other words, all valves close).
When the pilot signal stops, the DIR and SSR timers
start. If work resumes at one or more work stations
within 10 seconds, the unit stays in Running mode.
The DIR and SSR timers are reset back to zero and are
stopped.
If DIR_Time is set for 10 seconds (default), and the
pause in work is longer than 10 seconds, DIR_Time
elapses. The unit then goes into Idling mode with its
motor on and the FCV open.
If a new pilot signal is sent within 12 minutes, the unit
goes back into Running mode. The DIR and SSR timers
are again reset to zero and are stopped. However,
if SSR_Time is set for 12 minutes, which is the de-
fault setting, and there is no new pilot signal within 12
minutes, SSR_Time also elapses.
The unit then goes into Standby mode until it either
receives a new pilot signal that puts the unit back
into Running mode, or the unit is turned off (in oth-
er words, put into Off mode) by the weekly timer,
see Section .2. Weekly timer, or by pressing the
Standby/Running button.
5PLC messages
The following sections show the different status, warning and alarm messages that can be seen in the PLC dis-
play.
5.1Status messages
The following status messages give information about what mode the unit is in or what routine service is being
performed.
5.1.1L-PAK Off (Off mode)
The unit is in Off mode, which is also the unit’s start menu. The unit can also go into Off mode if something is
wrong, such as if an alarm is activated. The pump motor is off, there is no vacuum, the FCV is closed, and the unit
cannot be activated by a pilot signal.
ESC OK
Nederman
Hi Vacuum Unit
L-PAK
OFF
Time To Service
2000 hours
TimeToService: The amount of time until the next scheduled service. The
default setting is 2000 hours. See Section .2.2H-Meter 1.
5.1.2L-PAK Stand y (Stand y mode)
The unit is in Standby mode and is ready. The pump motor is off, there is no vacuum, the FCV is closed, and the
unit is waiting for a pilot signal to go into Running mode.
ESC OK
Hi Vacuum Unit
Standby
Wai ng For
Pilot Signal
Mo 15:33
2018-01-22
5.1.3Running (Running mode)
The unit is in Running mode. The pump motor is on and the unit generates a vacuum. The FCV is closed.
ESC OK
Hi Vacuum Unit
Running
Time 05:33 Min
DIRTm 00:00 s
OTTmr 00:00 h
DIRTm: The amount of time before the unit goes into Idling mode. The de-
fault is 10 seconds. See also Section .2.5DIR_Time.
OTTmr: If the Overtime timer has been activated, OTTmr shows the elapsed
time since the overtime timer started.
Time: The number of minutes the fan engine has been running since the
last start.
7

L-PAK 150/250 Advanced
5.1.4Idling (Idling mode)
The unit is in Idling mode. The pump motor is on, there is no vacuum, and the FCV is open. The unit goes into
Idling mode when there has been no pilot signal for the time set in DIR_Time, see Section .2.5DIR_Time.
ESC OK
Hi Vacuum Unit
IDLING
Time To
StandBy
05:33m
Time to Standby: The amount of time until the unit goes into Standby mode.
The default setting is 12 minutes. See Section .2.4SSR_Time.
5.1.5Filter Cleaning
The unit is cleaning its filter.
ESC OK
Filter
Cleanining
Cycles 1
Elapsed 0
Clean 00:00 s
Charge 00:00 s
Cycles: How many cleaning pulses will be carried out.
Elapsed: How many cleaning pulses are made.
Clean: Remaining time for cleaning pulse.
Charge: Remaining vacuum build time; the time until cleaning pulse is activ-
ated.
8

L-PAK 150/250 Advanced
5.1.6Status report
ESC OK
Thu 10:45
2018-02-01
ESC OK
ESC + C 9/9
ESC OK
Status Report 2
CASAlarm 1
FCTmr On
Clean Puls 3
ZV Detect On
PSILFC-I2 Off
ESC OK
Status Report 1
Sn: 2180523-0-EN
Starts 0
FLT M-Prot 0
FanTempHi 0
CleanePulse 0
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK
OFF
TimeTo Service
2000 Hours
1 Press the down arrow once to show the time and date screen.
2 Press the right arrow until the arrow screen appears.
• Press Escape and the up arrow at the same time to show the Status Report screen.
• Press Escape and the up arrow at the same time to show the next Status Report screen.
Sn Software number - Revision - Language.
Starts The number of motor starts.
FLT M-Prot Number of times motor overload protector has been activated.
FanTempHi Number of times Hi-Temp Fan, the thermostat has activated fan Cooling.
CleanePulse The number of cleaning pulses by the cleaning valve.
CASAlarm How many times Compressed Air Switch has alerted for low pressure.
FCTmr If the Filter cleaning timer is activated On/Off.
Clean Puls How many cleaning pulses that is selected.
ZV Detect Auto Standby, On = Unit going to Off mode at Power on.
PSILFC-I2 Input 2 selection Off = normal PS input, On = PSILFC input.
9

L-PAK 150/250 Advanced
5.2Warning messages
If a warning is activated, there is a problem that needs to be corrected, but the unit continues to work.
When a warning is activated, Output Q4 and White lamp button “Filter Cleaning/ Test start” flash with intervals,
1 second On/3 second Off.
If the flush valve function is chosen, it disconnects Output Q4 as a warning/Alarm signal output. See Sec-
tion .5Warning-Alarm output Q4.
5.2.1Time for service
The time interval set in the ‘Service Interval Setting’ menu has expired. If this alarm is activated, the light in the
Standby/Running button is lit one second and then again in 7 seconds. This 1/7 on/off sequence continues until
the warning is reset.
Reset the alarm by first putting the unit into Off mode. Press the manual filter cleaning button for 10 seconds.
ESC OK
Hi Vacuum Unit
Time for
Service
Th 15:01
Reset OK à
5.2.2Warning! Fan Hi-Temp
The fan is overheated. The temperature is greater than 125°C, and the filter cleaning valve is open to cool the
fan. When the Fan-temperature is below 90°C, the filter cleaning valve closes and the vacuum is reestablished
again.
When the fan cooling function activates a timer start, which is shown in the display, if the fan does not cool
down when the timer elapses, the vacuum unit will stop and the Alarm message, “Alarm Fan Hi-Temp” is activ-
ated.
ESC OK
Warning!
Fan Hi Temp
Fan Cooling
Ac!vated
Time To Stop
00:00 m
Time to Stop: Remaining time until L-Pak is stopped.
5.3Alarm messages
When an Alarm is activated, Output Q4 and White lamp button “Filter Cleaning/ Test start” flash with intervals, 1
second On/1 second Off. If an alarm is activated, the unit goes into Off mode until the problem is corrected. Spe-
cific Alarm Motor Protector Activated and Alarm Fan Hi-Temp are critical alarms and need to be Acknowledged
by pressing ‘OK’.
Other Alarms such as Low-Pressure CAS, Alarm Bin Level High and Alarm Filter Clogged are not critical alarms
and do not need to be Acknowledged.
If the flush valve function is chosen, it disconnects Output Q4 as a warning/Alarm signal output. See Sec-
tion .5Warning-Alarm output Q4.
10

L-PAK 150/250 Advanced
5.3.1Alarm! Fan Hi-Temp
When the fan temperature passes above 125°C, a Warning Fan Hi-Temp message is displayed, and the filter
cleaning valve opens to let air in to cool the fan.
If the filter-cleaning valve has been open to cool the fan for more than 8 minutes, and the temperature has not
gone below 90°C. The unit shuts off and the message Alarm Fan Hi-Temp is displayed. Correct the problem, and
press ‘OK’ to reset the warning.
ESC OK
Alarm!
Fan Hi Temp
Vacuum Unit
Off
Th 11:23
Reset OK à
Th: The actual day and time when L-Pak was stopped.
5.3.2Alarm! Motor Protector Activated
The motor is overheated. Correct the problem, and press ‘OK’ to reset the warning.
ESC OK
Alarm!
Motor
Protector
Ac!vated
Th 11:23
Reset OK à
Th: The actual day and time when L-Pak was stopped.
5.3.3Alarm! Low-Pressure CAS
This alarm is only shown when the Compressed Air Switch (CAS) is installed.
The compressed air level is low. When the accurate pressure is established, No reset is required after the active
alarm message.
ESC OK
Alarm!
Compressed Air
Low Pressure
CAS<3Bar
Th 11:23
Th: The actual day and time when L-PAK was stopped.
11

L-PAK 150/250 Advanced
6PLC settings
6.1Find a parameter and set its value
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK
OFF
TimeTo Service
2000 Hours ESC OK
Thu 10:45
2018-02-01
ESC OK
Stop >
Program >
Setup >
Network >
Diagnos!cs >
ESC OK
Set Parameter
Program Name
ESC OK
H-Meter >
ZV-Detect >
SSR_Time >
DIRTmr >
WeekTmr >
OTTmr Z
Do the following to find a parameter and set its value:
1 From the PLC status screen, press the down arrow to go to the date and time screen.
2 Press ‘Escape’ to go to the main menu.
3 Press the down arrow to go to ‘Program’. Press ‘OK’ to confirm.
4 Select ‘Set Parameter’. Press ‘OK’ to confirm.
5 Use the up or down arrows to find the parameter. Press ‘OK’ to confirm.
Use the left and right arrows to select a value.
7 Use the up or down arrows to set the value. Press ‘OK’ to confirm.
8 Press ‘Escape’ to go to the main menu.
9 Press ‘Escape’ to go to the date and time screen.
10 Press the up arrow to exit.
NOTE!
There are several other input menus on the same level as the date and time screen. If pressing the down
arrow takes the PLC to one of those menus, use the left arrow to get to the date and time screen.
NOTE!
The blinking cursor shows the current value that can be changed.
12

L-PAK 150/250 Advanced
6.2Parameter settings
The following PLC displays show the different settings that can be configured for the unit.
6.2.1Adjust the time and date
ESC OK
Thu 10:45
2018-02-01
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK
OFF
TimeTo Service
2000 Hours ESC OK
Stop >
Program >
Setup >
Network >
Diagnos!cs >
ESC OK
Msg Config >
Start Screen >
Clock >
LCD >
Menu Language >
Switch to OP ESC OK
Set Clock >
S/W !me >
Sync > Thu 10:45
2018-02-01
ESC OK
Set Clock
Do the following to adjust the time and date:
1 From a PLC status screen, press the down arrow to go to the date and time screen.
2 Press ‘Escape’ to get to the main menu.
3 Press the down arrow to go to ‘Setup’. Press ‘OK’ to confirm.
4 Press the down arrow to go to ‘Clock’. Press ‘OK’ to confirm.
5 Press the down arrow to go to ‘Set Clock’. Press ‘OK’ to confirm.
Use the left and right arrows to move to cursor to the parameter value. Press ‘OK’ to confirm.
7 Use the up or down arrows to set Time or Date. Press ‘OK’ to confirm. Weekday is automatically set by the
date.
8 Press ‘Escape’ 3 times to go to the time screen.
9 Press the up arrow to exit.
NOTE!
There are several other input menus on the same level as the date and time screen. If pressing the down
arrow takes the PLC to one of those menus, use the left arrow to get to the date and time screen.
6.2.2H-Meter 1
Menu for setting the service interval. The default value is 2000 hours.
ESC OK
H-Meter 1/1
MI =2000h:0m
OT =0h:15m
MN =1999h:45
MN Ext =2000
MI = Configured, time, between, maintenance interval
OT = Accumulated, total operating time
MN = Time left until next maintenance
MI = 2000h: The amount of time between service intervals.
MI = 2000h: The amount of time between service intervals.
6.2.3ZV-Detect
The default setting for ZV-Detect is ON. When ZV-Detect is ON or activated, and power is lost to the unit, for ex-
ample, if there is a power outage, the unit must be restarted and put into Standby (ready) mode by pressing the
Standby/Running button.
ESC OK
ZV-Detect 1/1
Switch = On
Switch = On: Default setting.
13

L-PAK 150/250 Advanced
6.2.4SSR_Time
Menu for setting the SSR timer. The SSR timer is for the amount of time before the unit goes from Idling mode to
Standby mode when the pilot signal disappears.
ESC OK
SSR_Time 1/1
T = 12:00m
Ta = 00:00
T = 12:00m: Time before SSR_Time is activated. The default setting is 12
minutes. The minimum setting is 5 minutes.
Ta = 00:00: The elapsed time since the pilot signal disappeared.
6.2.5DIR_Time
Menu for setting the DIR timer. The DIR timer is the amount of time before the unit goes from Running mode in-
to Idling mode when the pilot signal disappears.
ESC OK
DIRTmr 1/1
T = 10:00s
Ta = 00:00
T = 10:00s: Time before DIR_Time is activated. The default setting is 10
seconds The minimum setting is 5 seconds.
Ta = 00:00: The elapsed time since the pilot signal disappeared.
6.2.6Weekly timer
The weekly timer sets the unit to “Stand By” mode and “Off Mode” at preset times. If the pilot signal “PS” is act-
ive and the Vacuum unit is in Standby mode, the unit starts.
ESC OK
NEDERMAN
Hi Vacum Unit
L-PAK
OFF
TimeTo Service
2000 Hours ESC OK
Thu 10:45
2018-02-01
ESC OK
Stop >
Program >
Setup >
Network >
Diagnos!cs >
ESC OK
Set Parameter
Program Name
ESC OK
H-Meter >
ZV-Detect >
SSR_Time >
DIRTmr >
WeekTmr >
OTTmr Z ESC OK
WeekTmr 1/2
D1 = MTWTF
On1 = 00:00
Off1 = -- --
D2 = MTWTF
On2 = -- --
ESC OK
WeekTmr 2/2
Off2 = -- --
D3 = - - - - -SS
On3 = -- --
Off3 = -- --
Pulse = Off
Do the following to set the weekly timer:
1 From the PLC status screen, press the down arrow to go to the date and time screen.
2 Press ‘Escape’ to go to the main menu.
3 Press the down arrow to go to ‘Program’. Press ‘OK’ to confirm.
4 Select ‘Set Parameter’. Press ‘OK’ to confirm.
5 Use the up or down arrows to find ‘WeekTmr’. Press ‘OK’ to confirm.
Use right, left, up and down arrows to select a value and change settings. Press ‘OK’ to confirm.
14

L-PAK 150/250 Advanced
NOTE!
There are several other input menus on the same level as the date and time screen. If pressing the down
arrow takes the PLC to one of those menus, use the left arrow to get to the date and time screen.
Daily AM setting
ESC OK
WeekTmr 1/2
D1 = MTWTF
On1 = 00:00
Off1 = -- --
D2 = MTWTF
On2 = -- --
D1: = MTWTF: Default setting; Monday, Tuesday, Wednesday, Thursday and
Friday.
On1 = Time the unit is set to ‘Standby’ at chosen D1 days. Default setting is
no preset time.
Off1 = The time the unit is set to ‘Off’ on chosen D1 days. Default setting is
no preset time.
Daily PM setting
ESC OK
WeekTmr 1/2
D1 = MTWTF
On1 = 00:00
Off1 = -- --
D2 = MTWTF
On2 = -- --
D2 = MTWTF: Default setting; Monday, Tuesday, Wednesday, Thursday and
Friday.
On2 = Time the unit is set to ‘Standby’ at chosen D2 days. Default setting is
no preset time.
Off2 = The time the unit is set to ‘Off’ on chosen D2 days. Default setting is
no preset time.
Weekend or second shift setting
ESC OK
WeekTmr 2/2
Off2 = -- --
D3 = - - - - -SS
On3 = -- --
Off3 = -- --
Pulse = Off
D3 = _ _ _ _ _ SS: Default setting; Saturday and Sunday.
On3 = _ _: Default setting Time the unit set to ‘Stand By’ on chosen D3 days.
Default setting is no preset time.
Off3 = The time the unit is set to ‘Off’ on chosen D3 days. Default setting is
no preset time.
Example
D3=_ _ _ _ _ SS Saturday, Sunday
On3 = 09:00 Unit starts at 9:00 in the morning Saturday, Sunday
Off3 = 13:00 Unit stops at 13:00 in the after-
noon
Saturday, Sunday
NOTE!
Pulse = Off: The pulse parameter must always be set to Off.
NOTE!
When the timer stops the unit and a valve at a workstation is in its open position, the unit will start imme-
diately once the timer puts the unit in standby mode.
It is not necessary to use the timer function. The function can be switched off by setting the display to show
only dashes. However, it is recommended that the timer function is used, as this ensures that the unit is
switched off even when a valve remains open, for example, overnight.
NOTE!
If the weekly timer has been activated, the amount of time the unit can be used during the day before it
automatically goes into Off mode can be extended if the optional external standby button accessory is
used, see Section .2.7OTTmr.
15

L-PAK 150/250 Advanced
6.2.7OTTmr
Menu for setting the overtime timer. If the unit needs to be used after the weekly timer has expired, the unit
can be turned on for a set number of hours by pressing the external standby button. When the OTTmr expires,
the machine goes back into Off mode.
If the unit is in Off mode and the weekly timer is not used, quickly pressing the external standby button (less
than 2 seconds) puts the unit into Standby mode for the time set in ‘T’, for example, two hours. See the figure
below.
If the unit is in Standby mode and the weekly timer is not used, quickly pressing the external standby button
(less than 2 seconds) puts the unit into Off mode after the time set in ‘T’, for example, two hours. See the figure
below.
If the weekly timer is being used, quickly pressing the external standby button (less than 2 seconds) keeps
the unit into Standby mode for an additional two hours after the closing time set in the weekly timer, see Sec-
tion .2. Weekly timer.
To reset OTTmr so that the time is not extended, press the external standby button longer than 2 seconds and
then release.
ESC OK
OTTmr 1/1
T = 02:00h
Ta = 00:00
T = 02:00h: Extra time before the unit goes into Off mode. The default set-
ting is 2 hours.
Ta = 00:00: The elapsed time since the overtime timer started.
6.2.8PSIFC-I2
Standard Pilot Signal input Terminal 13-14 is now configurable.
When the input is activated, the unit starts as usual but depends on the setting below for filter cleaning. Filter
cleaning can be done during the running mode.
Standard input
Switch = Off: It is possible to activate filter cleaning any time when the motor is running by either timer or by
manual cleaning.
PSIFC input
Switch = On: Cleaning process cannot be activated by the timer or by manual cleaning. Cleaning starts after PS =
off.
ESC OK
PSIFC-I2 1/1
Switch = Off
Switch = Off: Default setting.
6.2.9FCTmr
Menu for activating and setting time between timer-controlled filter cleaning.
ESC OK
FCTmr 1/1
Stat = ON
TH = 01:00s
TL = 60:00m
Stat =On Filter Cleaning timer activated Default is On.
TH=01:00s: Do not change the default setting of 1 second.
TL= 0:00m: Time between automatic filter cleanings. The default setting
is 0 minutes.
Ta=00:00: The elapsed time since the last automatic cleaning was activ-
ated.
1

L-PAK 150/250 Advanced
6.2.10Clean cycle
Menu for setting the opening and closing times for the “FCV” Filter Cleaning Valve.
FCV cleaning cycle repeats X times depending on the value of parameter ‘On’.
This function is always active when filter cleaning takes place.
ESC OK
Clean Cyc 1/1
Tch = 05:00s
Tpu = 01:00s
On = 3
Cnt = 0
Tch = Vacuum Building time (Charge Time): Default is 5 seconds.
Tpu = Clean pulse time. Default is 1 second.
On = Number of cleaning pulses. Default is 3 pulses.
Cnt = 0: Elapsed cleaning pulses.
NOTE!
For the parameter ‘On’, the minimum value = 1.
NOTE!
If On is set to 0, No filter cleaning is performed.
Time duration for a cleaning cycle below:
Example: 1 Cleaning pulse
On=1, Tch=5, Tpu=1 → On * (Tch + Tpu) = 1*(5+1) = s where Tch=05:00s and Tpu=01:00s.
The default time for a complete cleaning cycle is seconds.
Example: 2 Cleaning pulses
On=2, Tch=5, Tpu=1 → On * (Tch + Tpu) = 2*(5+1) =12s where Tch=05:00s and Tpu=01:00s.
The default time for a complete cleaning cycle is 12 seconds
6.3Standard cleaning process
The filter cleaning process is always activated after the pilot signal (PS) or (PSIFC) has disappeared and DIR Time
has elapsed.
The filter cleaning valve opens and the filter cleaning process generates a preset number of cleaning pulses.
The unit then goes into Idle mode keeping the cleaning valve open.
See function in Section .2.10Clean cycle to set numbers of pulses and related parameters.
See function in Section .2.9FCTmr to activate Timer controlled Filter cleaning.
The Filter cleaning process can be interrupted by Pilot Signal Interlocking functions, PSIFC = Pilot Signal Inter-
locking Filter Cleaning.
See Section .4Standard Pilot Signal (PS) input.
17

L-PAK 150/250 Advanced
6.4Standard Pilot Signal (PS) input
6.4.1PS Input 2
Input 2, terminals 13 and 14 are for the standard pilot signal input. It is possible to set this input into 2 state
Standard or PSIFC mode.
Standard mode
Switch = Off: Filter cleaning by timer or manual cleaning is possible any time when PS is activated.
PSIFC mode
Switch = On: Filter cleaning by timer or manual cleaning is not possible when PS is activated.
Cleaning starts after PS = off.
ESC OK
PSIFC-I2 1/1
Switch = Off
Switch = off: Default setting.
6.4.2PS Input 8
Default Advanced PSIFC (Pilot Signal Interlock Filter Cleaning)
L-PAK Advanced models are configured with Input 8 as a pilot signal input for the PSIFC filter cleaning process.
Input 8, terminals 11 and 17 act as pilot signal inputs and interlock the cleaning process. When this input is used
as a pilot signal input, filter cleaning cannot be activated until this PS input is deactivated. If this input activates
during a filter cleaning sequence, the filter sequence stops immediately and the unit establishes a vacuum.
Input 8 can be combined with input 2.
Example: Input 2 = (PSIFC-I2 = Off)
When PS Input 2 is used the filter cleaning can proceed any time but if Input 8 is activated the input will interlock
all filter cleaning attempts “Input 8 has the highest priority”.
6.5Warning-Alarm output Q4
Potential free output Terminal X1:33-34.
When an alarm is activated, Output Q4 and White lamp button on the control box side flash with interval 1
second on / 1 second off.
Warning -Alarm Output Q4, switch with an interval 1 second on / 1 second off if one or more of the alarms listed
below are active:
• The fan temperature is over 125°C, see Section5.3.1Alarm! Fan Hi-Temp.
• The motor is overheated, see Section5.3.2Alarm! Motor Protector Activated.
• The compressed air level is low, see Section5.3.3Alarm! Low-Pressure CAS.
Warning -Alarm Output Q4, switch with an interval 1 second on /3 seconds off if one or more of the warnings lis-
ted below are active:
• Warning Fan Hi-Temp, see Section5.2.2Warning! Fan Hi-Temp.
6.6Stand y (Ready) indicator
The H1 lamp/Output DO1 acts as a Standby (unit ready) indicator. The H1 Lamp/DO1 is activated when the unit
is in Standby mode or the fan is running. The H1 lamp/Output DO1 is available on terminals X1:3 and X1:4 for re-
mote indication.
18

www.nederman.com
