[en] Instructions for installation and use
Extractor hood

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en
2
ÚTable of contents
[ en] I nst r uct i ons for installation and use
INSTRUCTION MANUAL.......................................................... 2
8Intended use................................................................... 2
(Important safety information ........................................ 3
7Environmental protection ............................................. 5
ÇOperating modes ........................................................... 5
1Operating the appliance................................................ 6
2Cleaning and maintenance ......................................... 16
3Trouble shooting ......................................................... 18
4Customer service......................................................... 18
INSTALLATION INSTRUCTIONS .......................................... 20
(Important safety information...................................... 21
KGeneral information .................................................... 23
5Installation ................................................................... 24
INSTRUCTION MANUAL
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.neff-international.com and in the online shop
www.neff-eshop.com
8Intended use
Intended use Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
The appliance can only be used safely if it is
correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly at
its installation location.
This appliance is intended for domestic use
and the household environment only. The
appliance is not intended for use outside. Do
not leave the appliance unattended during
operation. The manufacturer is not liable for
damage which is caused by improper use or
incorrect operation.
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental capacity
or by persons with a lack of experience or
knowledge if they are supervised by someone
who is responsible for their safety, or have
been instructed in how to use the appliance
safely and have understood the risks involved
in not using it properly.
Children must not play with the
appliance.Cleaning and user maintenance
must not be performed by children unless they
are over 15 years of age and are supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
This appliance is not intended for operation
with an external clock timer or a remote
control.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Important safety information en
3
(Important safety
information
Impor t ant safety informat i on :Warning
Danger of suffocation!
Packaging material is dangerous to children.
Never allow children to play with packaging
material.
:Warning
Danger of death!
Risk of poisoning from flue gases that are
drawn back in.
Always ensure adequate fresh air in the room
if the appliance is being operated in exhaust
air mode at the same time as room air-
dependent heat-producing appliance is being
operated.
Room air-dependent heat-producing
appliances (e.g. gas, oil, wood or coal-
operated heaters, continuous flow heaters or
water heaters) obtain combustion air from the
room in which they are installed and discharge
the exhaust gases into the open air through an
exhaust gas system (e.g. a chimney).
In combination with an activated vapour
extractor hood, room air is extracted from the
kitchen and neighbouring rooms - a partial
vacuum is produced if not enough fresh air is
supplied. Toxic gases from the chimney or the
extraction shaft are sucked back into the living
space.
■Adequate incoming air must therefore
always be ensured.
■An incoming/exhaust air wall box alone will
not ensure compliance with the limit.
Safe operation is possible only when the
partial vacuum in the place where the heat-
producing appliance is installed does not
exceed 4 Pa (0.04 mbar). This can be
achieved when the air needed for combustion
is able to enter through openings that cannot
be sealed, for example in doors, windows,
incoming/exhaust air wall boxes or by other
technical means.
In any case, consult your responsible Master
Chimney Sweep. He is able to assess the
house's entire ventilation setup and will
suggest the suitable ventilation measures to
you.
Unrestricted operation is possible if the vapour
extractor hood is operated exclusively in the
circulating-air mode.
:Warning
Risk of fire!
■Fatty deposits in the grease filter may catch
fire. Regularly clean the grease filter. Never
operate the appliance without a grease
filter.
Risk of fire!
■Grease deposits in the grease filter may
catch fire. Never work with naked flames
close to the appliance (e.g. flambéing). Do
not install the appliance near a heat-
producing appliance for solid fuel (e.g.
wood or coal) unless a closed, non-
removable cover is available. There must
be no flying sparks.
Risk of fire!
■Hot oil and fat can ignite very quickly. Never
leave hot fat or oil unattended. Never use
water to put out burning oil or fat. Switch off
the hotplate. Extinguish flames carefully
using a lid, fire blanket or something similar.
Risk of fire!
■When gas burners are in operation without
any cookware placed on them, they can
build up a lot of heat. A ventilation
appliance installed above the cooker may
become damaged or catch fire. Only
operate the gas burners with cookware on
them.
Risk of fire!
■Operating several gas burners at the same
time gives rise to a great deal of heat. A
ventilation appliance installed above the
cooker may become damaged or catch fire.
Never operate two gas burners
simultaneously on the highest flame for
longer than 15 minutes. One large burner of
more than 5 kW (wok) is equivalent to the
power of two gas burners.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Important safety information
4
:Warning
Risk of burns!
The accessible parts become very hot when in
operation. Never touch hot parts. Keep
children at a safe distance.
:Warning
Risk of injury!
■Components inside the appliance may have
sharp edges. Wear protective gloves.
Risk of injury!
■Items placed on the appliance may fall
down. Do not place any objects on the
appliance.
Risk of injury!
■The light emitted by LED lights is very
dazzling, and can damage the eyes (risk
group 1). Do not look directly into the
switched on LED lights for longer than 100
seconds.
:Warning
Risk of injury!
Risk of trapping body parts when opening and
closing the glass front. Do not reach into the
area behind the glass panel, and keep your
fingers away from the hinges.
:Warning
Hazard due to magnetism!
Permanent magnets are inserted in the
appliance front. They may affect electronic
implants, e.g. heart pacemakers or insulin
pumps. Wearers of electronic implants must
stay at least 10 cm away from the appliance
front.
:Warning
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Causes of damage
Caution!
Risk of damage due to corrosion. Always
switch on the appliance while cooking to avoid
condensation. Condensate can produce
corrosion damage.
Always replace faulty bulbs to prevent the
remaining bulbs from overloading.
Risk of damage due to ingress of humidity into
the electronic circuitry. Never clean operator
controls with a wet cloth.
Surface damage due to incorrect cleaning.
Clean stainless steel surfaces in the direction
of the grain only. Do not use any stainless
steel cleaners for operator controls.
Surface damage due to strong or abrasive
cleaning agents. Never use strong and
abrasive cleaning agents.
Risk of damage from returning condensate.
Install the exhaust duct in such a way that it
falls away from the appliance slightly (1°
slope).
Risk of damage as a result of incorrect
loading of design elements. Do not pull design
elements.Do not place objects on the design
elements or hang objects from them.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Environmental protection en
5
7Environmental protection
En v i r o n ment al pr ot ec t i on Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■During cooking, ensure that there is a sufficient
supply of air so that the extractor hood can work
efficiently and with a low level of operating noise.
■Adjust the fan speed to the intensity of the cooking
fumes. Only use intensive mode where this is
required. A lower fan speed means that less energy
is consumed.
■If there are intensive cooking fumes, select a higher
fan speed in good time. If cooking fumes have
already spread in the kitchen, the extractor hood
must be operated for longer.
■Switch off the extractor hood if you no longer require
it.
■Switch off the lighting if you no longer require it.
■Clean and, if required, replace the filter at regular
intervals in order to increase the effectiveness of the
ventilation system and to prevent the risk of fire.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
ÇOperating modes
Oper at i ng modes Exhaust air mode
Note: The exhaust air must not be conveyed into a
functioning smoke or exhaust gas flue or into a shaft
which is used to ventilate installation rooms which
contain heat-producing appliances.
■Before conveying the exhaust air into a non-
functioning smoke or exhaust gas flue, obtain the
consent of the heating engineer responsible.
■If the exhaust air is conveyed through the outer wall,
a telescopic wall box should be used.
Circulating-air mode
Note: To bind odours in circulating-air mode, you must
install an activated carbon filter. The different options for
operating the appliance in circulating-air mode can be
found in the brochure. Alternatively, ask your dealer.
The required accessories are available from specialist
retailers, from customer service or from the Online
Shop.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
The air which is drawn in is cleaned
by the grease filters and conveyed to
the exterior by a pipe system.
The air which is drawn in is cleaned by
the grease filters and an activated
carbon filter and conveyed back into the
kitchen.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Operating the appliance
6
1Operating the appliance
Oper at i ng the appl i ance These instructions apply to several appliance variants.
It is possible that individual features are described
which do not apply to your appliance.
Note: . Switch on the extractor hood when you start
cooking and switch it off again several minutes after you
have finished cooking. This is the most effective way of
removing the kitchen fumes.
Control panel model 1
Setting the fan
Switching on
■Touch the #symbol.
The fan starts at setting ƒ.
■Touch + or - to alter the fan speed.
Switching off
Touch the #symbol.
Noise reduction function
The noise reduction function reduces the fan noise.
Switching on
Note: This function can be used at any fan setting
except fan setting ‚. The function will remain active
even after the fan is switched off.
Touch the Qsymbol.
Switching off
Touch the Qsymbol.
AirFresh function
Switching on
Touch the 3symbol.
3will be shown on the display panel.The fan runs for
approximately 5 minutes per hour at fan setting 1.
Switching off
Touch the 3symbol.
This ends the AirFresh function.
Symbol Explanation
#Fan on/off
QNoise reduction function
3AirFresh function
ADecrease fan setting
@Increase fan setting/intensive mode 1, 2
˜Intensive mode 2 shortcut
9Fan run-on
6Light on/off/dimming
Indicator/
symbol
Explanation
QNoise reduction function
1-3 Fan settings
9Fan run-on
3AirFresh function

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Operating the appliance en
7
Intensive setting
You can use the intensive setting if there is a large
build-up of odours and fumes/vapours.
Switching on
Touch the ˜symbol. ˜ƒ will light up on the display.
Touch the ˜symbol again to switch back to intensive
mode ˜‚.
Note: After approx. 6 minutes, the extractor hood
automatically switches back to fan setting 3.
Switching off
If you want to end intensive mode before the preset
time expires, touch the ˜symbol.
Intermediate position for the glass front
On some appliances, the glass front can be adjusted to
an intermediate position. The intermediate position can
be used for eliminating particularly strong cooking
smells and large amounts of steam.
Take hold of the glass front in the centre and open it
carefully.
Fan run-on time
Switching on
Touch the 9symbol.
The fan will run at fan setting 1.
After approximately 10 minutes, the fan will switch itself
off automatically.
Switching off
Touch the 9symbol.
This immediately stops fan run-on.
Lighting
The lighting can be switched on and off independently
of the fan.
Touch the 6symbol.
Setting the brightness
Press and hold the 6symbol until the required
brightness is reached.
Saturation display
If the metal grease filters or activated charcoal filter are/
is saturated, the corresponding symbols will flash once
the appliance has been switched off:
■Metal grease filter: ”ª
■Activated charcoal filter: ’ª
■Metal grease filter and activated charcoal filter: ”ª
and ’ª
If you have not yet done so, the metal grease filters
should now be cleaned or the activated charcoal filter
replaced. ~"Cleaning and maintenance" on page 16
The saturation indicators can be reset while they are
flashing. To do this, touch the Asymbol.
Switching over the display for air recirculation mode
For air recirculation mode, the electronic controller must
be switched over accordingly:
■The extractor hood must be connected and switched
off.
■Touch and hold the Qsymbol and touch the @or
Asymbol until "2" lights up for air recirculation mode
(filters that cannot be regenerated). Take your finger
off the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
cannot be regenerated).
■Touch and hold the Qsymbol and touch the @or
Asymbol until "3" lights up for air recirculation mode
(filters that can be regenerated). Take your finger off
the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
can be regenerated).
■Repeatedly touching and holding the Qsymbol and
touching the @or Asymbol until "1" lights up
switches the electronic controller back over to air
extraction mode.
Audible signal
Switching on
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched off. An audible signal will sound as an
acknowledgement.
When the signal tone is activated, ‚will be lit.
Switching off
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched off. An audible signal will sound as an
acknowledgement.
When the signal tone is deactivated, ‹will be lit.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Operating the appliance
8
Control panel model 2
Setting the fan
Switching on
■Touch the #symbol.
The fan starts at setting ƒ.
■Touch + or - to alter the fan speed.
Switching off
Touch the #symbol.
Noise reduction function
The noise reduction function reduces the fan noise.
Switching on
Note: This function can be used at any fan setting
except fan setting ‚. The function will remain active
even after the fan is switched off.
Touch the Qsymbol.
Switching off
Touch the Qsymbol.
AirFresh function
Switching on
Touch the 3symbol.
3will be shown on the display panel.The fan runs for
approximately 5 minutes per hour at fan setting 1.
Switching off
Touch the 3symbol.
This ends the AirFresh function.
Fan run-on time
Switching on
Touch the Asymbol while the fan is running at fan
setting 1.
The fan will run at fan setting 1.
After approximately 10 minutes, the fan will switch itself
off automatically.
Switching off
Touch the @symbol to select a different fan setting.
This immediately stops fan run-on.
Intensive setting
You can use the intensive setting if there is a large
build-up of odours and fumes/vapours.
Switching on
Touch the ˜symbol. ˜ƒ will light up on the display.
Touch the ˜symbol again to switch back to intensive
mode ˜‚.
Note: After approx. 6 minutes, the extractor hood
automatically switches back to fan setting 3.
Switching off
If you want to end intensive mode before the preset
time expires, touch the ˜symbol.
Intermediate position for the glass front
On some appliances, the glass front can be adjusted to
an intermediate position. The intermediate position can
be used for eliminating particularly strong cooking
smells and large amounts of steam.
Take hold of the glass front in the centre and open it
carefully.
Symbol Explanation
#Fan on/off
QNoise reduction function
3AirFresh function
AReduce fan setting/fan run-on
@Increase fan setting/intensive mode 1, 2
˜Intensive mode 2 shortcut
kAmbientLight
6Light on/off/dimming
Indicator/
symbol
Explanation
QNoise reduction function
1-3 Fan settings
9Fan run-on
3AirFresh function

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Operating the appliance en
9
AmbientLight
The AmbientLight can be switched on and off
independently of the fan.
Touch the ksymbol.
Setting the brightness
Press and hold the ksymbol until the required
brightness is reached.
Setting the colour
1. Switch off the fan.
2. Touch the ksymbol.
The @and Asymbols will be lit for approximately
10 seconds.
3. Within this 10-second period, touch the Aor
@symbol until the colour you require is selected.
Lighting
The lighting can be switched on and off independently
of the fan.
Touch the 6symbol.
Setting the brightness
Press and hold the 6symbol until the required
brightness is reached.
Saturation display
If the metal grease filters or activated charcoal filter are/
is saturated, the corresponding symbols will flash once
the appliance has been switched off:
■Metal grease filter: ”ª
■Activated charcoal filter: ’ª
■Metal grease filter and activated charcoal filter: ”ª
and ’ª
If you have not yet done so, the metal grease filters
should now be cleaned or the activated charcoal filter
replaced. ~"Cleaning and maintenance" on page 16
The saturation indicators can be reset while they are
flashing. To do this, touch the Asymbol.
Switching over the display for air recirculation mode
For air recirculation mode, the electronic controller must
be switched over accordingly:
■The extractor hood must be connected and switched
off.
■Touch and hold the Qsymbol and touch the @or
Asymbol until "2" lights up for air recirculation mode
(filters that cannot be regenerated). Take your finger
off the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
cannot be regenerated).
■Touch and hold the Qsymbol and touch the @or
Asymbol until "3" lights up for air recirculation mode
(filters that can be regenerated). Take your finger off
the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
can be regenerated).
■Repeatedly touching and holding the Qsymbol and
touching the @or Asymbol until "1" lights up
switches the electronic controller back over to air
extraction mode.
Audible signal
Switching on
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched off. An audible signal will sound as an
acknowledgement.
When the signal tone is activated, ‚will be lit.
Switching off
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched off. An audible signal will sound as an
acknowledgement.
When the signal tone is deactivated, ‹will be lit.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Operating the appliance
10
Control panel model 3
Setting the fan
Switching on
■Touch the #symbol.
The fan starts at setting ƒ.
■Touch + or - to alter the fan speed.
Switching off
Touch the #symbol.
Noise reduction function
The noise reduction function reduces the fan noise.
Switching on
Note: This function can be used at any fan setting
except fan setting ‚. The function will remain active
even after the fan is switched off.
Touch the Qsymbol.
Switching off
Touch the Qsymbol.
AirFresh function
Switching on
Touch the 3symbol.
3will be shown on the display panel.The fan runs for
approximately 5 minutes per hour at fan setting 1.
Switching off
Touch the 3symbol.
This ends the AirFresh function.
Intensive setting
You can use the intensive setting if there is a large
build-up of odours and fumes/vapours.
Switching on
Touch the ˜symbol. ˜ƒ will light up on the display.
Touch the ˜symbol again to switch back to intensive
mode ˜‚.
Note: After approx. 6 minutes, the extractor hood
automatically switches back to fan setting 3.
Switching off
If you want to end intensive mode before the preset
time expires, touch the ˜symbol.
Intermediate position for the glass front
On some appliances, the glass front can be adjusted to
an intermediate position. The intermediate position can
be used for eliminating particularly strong cooking
smells and large amounts of steam.
Take hold of the glass front in the centre and open it
carefully.
Fan run-on time
Switching on
Touch the 9symbol.
The fan will run at fan setting 1.
After approximately 10 minutes, the fan will switch itself
off automatically.
Switching off
Touch the 9symbol.
This immediately stops fan run-on.
Symbol Explanation
#Fan on/off
QNoise reduction function
3AirFresh function
ADecrease fan setting
@Increase fan setting/intensive mode 1, 2
˜Intensive mode 2 shortcut
9Fan run-on
6Light on/off/dimming
Indicator/
symbol
Explanation
QNoise reduction function
1-3 Fan settings
9Fan run-on
3AirFresh function

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Operating the appliance en
11
Lighting
The lighting can be switched on and off independently
of the fan.
Touch the 6symbol.
Setting the brightness
Press and hold the 6symbol until the required
brightness is reached.
Saturation display
If the metal grease filters or activated charcoal filter are/
is saturated, the corresponding symbols will flash once
the appliance has been switched off:
■Metal grease filter: ”ªª
■Activated charcoal filter: ’ªª
■Metal grease filter and activated charcoal filter:
”ªª and ’ªª
If you have not yet done so, the metal grease filters
should now be cleaned or the activated charcoal filter
replaced. ~"Cleaning and maintenance" on page 16
The saturation indicators can be reset while they are
flashing. To do this, touch the Asymbol.
Switching over the display for air recirculation mode
For air recirculation mode, the electronic controller must
be switched over accordingly:
■The extractor hood must be connected and switched
on.
■Touch and hold the Qsymbol and touch the @or
Asymbol until "2" lights up for air recirculation mode
(filters that cannot be regenerated). Take your finger
off the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
cannot be regenerated).
■Touch and hold the Qsymbol and touch the @or
Asymbol until "3" lights up for air recirculation mode
(filters that can be regenerated). Take your finger off
the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
can be regenerated).
■Repeatedly touching and holding the Qsymbol and
touching the @or Asymbol until "1" lights up
switches the electronic controller back over to air
extraction mode.
Audible signal
Switching on
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched on. An audible signal will sound as an
acknowledgement.
When the signal tone is activated, ‚will be lit.
Switching off
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched on. An audible signal will sound as an
acknowledgement.
When the signal tone is deactivated, ‹will be lit.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Operating the appliance
12
Control panel variant 4
Setting the fan
Switching on
■Touch the #symbol.
The fan starts at setting ƒ.
■Touch + or - to alter the fan speed.
Switching off
Touch the #symbol.
Noise reduction function
The noise reduction function reduces the fan noise.
Switching on
Note: This function can be used at any fan setting
except fan setting ‚. The function will remain active
even after the fan is switched off.
Touch the Qsymbol.
Switching off
Touch the Qsymbol.
AirFresh function
Switching on
Touch the 3symbol.
3will be shown on the display panel.The fan runs for
approximately 5 minutes per hour at fan setting 1.
Switching off
Touch the 3symbol.
This ends the AirFresh function.
Fan run-on time
Switching on
Touch the Asymbol while the fan is running at fan
setting 1.
The fan will run at fan setting 1.
After approximately 10 minutes, the fan will switch itself
off automatically.
Switching off
Touch the @symbol to select a different fan setting.
This immediately stops fan run-on.
Intensive setting
You can use the intensive setting if there is a large
build-up of odours and fumes/vapours.
Switching on
Touch the ˜symbol. ˜ƒ will light up on the display.
Touch the ˜symbol again to switch back to intensive
mode ˜‚.
Note: After approx. 6 minutes, the extractor hood
automatically switches back to fan setting 3.
Switching off
If you want to end intensive mode before the preset
time expires, touch the ˜symbol.
Intermediate position for the glass front
On some appliances, the glass front can be adjusted to
an intermediate position. The intermediate position can
be used for eliminating particularly strong cooking
smells and large amounts of steam.
Take hold of the glass front in the centre and open it
carefully.
Symbol Explanation
#Fan on/off
QNoise reduction function
3AirFresh function
AReduce fan setting/fan run-on
@Increase fan setting/intensive mode 1, 2
˜Intensive mode 2 shortcut
kAmbientLight
6Light on/off/dimming
Indicator/
symbol
Explanation
QNoise reduction function
1-3 Fan settings
9Fan run-on
3AirFresh function

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Operating the appliance en
13
AmbientLight
The AmbientLight can be switched on and off
independently of the fan.
Touch the ksymbol.
Setting the brightness
Press and hold the ksymbol until the required
brightness is reached.
Setting the colour
1. Switch off the fan.
2. Touch the ksymbol.
The @and Asymbols will be lit for approximately
10 seconds.
3. Within this 10-second period, touch the Aor
@symbol until the colour you require is selected.
Lighting
The lighting can be switched on and off independently
of the fan.
Touch the 6symbol.
Setting the brightness
Press and hold the 6symbol until the required
brightness is reached.
Saturation display
If the metal grease filters or activated charcoal filter are/
is saturated, the corresponding symbols will flash once
the appliance has been switched off:
■Metal grease filter: ”ªª
■Activated charcoal filter: ’ªª
■Metal grease filter and activated charcoal filter:
”ªª and ’ªª
If you have not yet done so, the metal grease filters
should now be cleaned or the activated charcoal filter
replaced. ~"Cleaning and maintenance" on page 16
The saturation indicators can be reset while they are
flashing. To do this, touch the Asymbol.
Switching over the display for air recirculation mode
For air recirculation mode, the electronic controller must
be switched over accordingly:
■The extractor hood must be connected and switched
on.
■Touch and hold the Qsymbol and touch the @or
Asymbol until "2" lights up for air recirculation mode
(filters that cannot be regenerated). Take your finger
off the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
cannot be regenerated).
■Touch and hold the Qsymbol and touch the @or
Asymbol until "3" lights up for air recirculation mode
(filters that can be regenerated). Take your finger off
the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
can be regenerated).
■Repeatedly touching and holding the Qsymbol and
touching the @or Asymbol until "1" lights up
switches the electronic controller back over to air
extraction mode.
Audible signal
Switching on
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched on. An audible signal will sound as an
acknowledgement.
When the signal tone is activated, ‚will be lit.
Switching off
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched on. An audible signal will sound as an
acknowledgement.
When the signal tone is deactivated, ‹will be lit.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Operating the appliance
14
Control panel variant 5
Setting the fan
Switching on
■Touch the #symbol.
The fan starts at setting ƒ.
■Touch + or - to alter the fan speed.
Switching off
Touch the #symbol.
Noise reduction function
The noise reduction function reduces the fan noise.
Switching on
Note: This function can be used at any fan setting
except fan setting ‚. The function will remain active
even after the fan is switched off.
Touch the Qsymbol.
Switching off
Touch the Qsymbol.
AirFresh function
Switching on
Touch the 3symbol.
3will be shown on the display panel.The fan runs for
approximately 5 minutes per hour at fan setting 1.
Switching off
Touch the 3symbol.
This ends the AirFresh function.
Fan run-on time
Switching on
Touch the Asymbol while the fan is running at fan
setting 1.
The fan will run at fan setting 1.
After approximately 10 minutes, the fan will switch itself
off automatically.
Switching off
Touch the @symbol to select a different fan setting.
This immediately stops fan run-on.
Intensive setting
You can use the intensive setting if there is a large
build-up of odours and fumes/vapours.
Switching on
Touch the ˜symbol. ˜ƒ will light up on the display.
Touch the ˜symbol again to switch back to intensive
mode ˜‚.
Note: After approx. 6 minutes, the extractor hood
automatically switches back to fan setting 3.
Switching off
If you want to end intensive mode before the preset
time expires, touch the ˜symbol.
Intermediate position for the glass front
On some appliances, the glass front can be adjusted to
an intermediate position. The intermediate position can
be used for eliminating particularly strong cooking
smells and large amounts of steam.
Take hold of the glass front in the centre and open it
carefully.
Symbol Explanation
#Fan on/off
QNoise reduction function
3AirFresh function
AReduce fan setting/fan run-on
@Increase fan settings/intensive mode 1, 2
˜Intensive mode 2 shortcut
‘Automatic air sensor
6Light on/off/dimming
Indicator/
symbol
Explanation
QNoise reduction function
1-3 Fan settings
9Fan run-on
3AirFresh function

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Operating the appliance en
15
Automatic mode
Switching on
1. Touch the #symbol.
The fan will start at setting ƒ.
2. Touch the ‘symbol.
The optimum fan setting is set using an automatic air
sensor.
Switching off
Touch the ‘or #symbol to switch off automatic mode.
The fan will switch itself off automatically if the
automatic air sensor detects no further change in the air
quality in the room.
Automatic mode can run for a maximum of 4 hours.
Sensor control
In automatic mode, an automatic air sensor in the
extractor hood detects the intensity of the cooking and
roasting odours. Depending on the setting of the
automatic air sensor, the fan automatically switches
itself to another fan setting.
Possible sensor settings:
Default sensitivity setting: †
Lowest sensitivity setting: ‹
Highest sensitivity setting: Š
If the sensor controller responds too strongly or not
enough, it can be changed accordingly:
1. Touch and hold the ‘symbol for 1 second when the
fan is switched on. The setting will be displayed.
2. The sensor controller setting can be changed by
touching the @or Asymbol.
3. Take your finger off the ‘symbol.
Lighting
The lighting can be switched on and off independently
of the fan.
Touch the 6symbol.
Setting the brightness
Press and hold the 6symbol until the required
brightness is reached.
Saturation display
If the metal grease filters or activated charcoal filter are/
is saturated, the corresponding symbols will flash once
the appliance has been switched off:
■Metal grease filter: ”ªª
■Activated charcoal filter: ’ªª
■Metal grease filter and activated charcoal filter:
”ªª and ’ªª
If you have not yet done so, the metal grease filters
should now be cleaned or the activated charcoal filter
replaced. ~"Cleaning and maintenance" on page 16
The saturation indicators can be reset while they are
flashing. To do this, touch the Asymbol.
Switching over the display for air recirculation mode
For air recirculation mode, the electronic controller must
be switched over accordingly:
■The extractor hood must be connected and switched
on.
■Touch and hold the Qsymbol and touch the @or
Asymbol until "2" lights up for air recirculation mode
(filters that cannot be regenerated). Take your finger
off the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
cannot be regenerated).
■Touch and hold the Qsymbol and touch the @or
Asymbol until "3" lights up for air recirculation mode
(filters that can be regenerated). Take your finger off
the Qsymbol. This will switch the electronic
controller over to air recirculation mode (filters that
can be regenerated).
■Repeatedly touching and holding the Qsymbol and
touching the @or Asymbol until "1" lights up
switches the electronic controller back over to air
extraction mode.
Audible signal
Switching on
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched on. An audible signal will sound as an
acknowledgement.
When the signal tone is activated, ‚will be lit.
Switching off
Touch and hold the #and Qsymbols at the same
time for approximately 3 seconds when the fan is
switched on. An audible signal will sound as an
acknowledgement.
When the signal tone is deactivated, ‹will be lit.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Cleaning and maintenance
16
2Cleaning and maintenance
Cl eani ng and mai nt enance :Warning
Risk of burns!
The appliance becomes hot during operation. Allow the
appliance to cool down before cleaning.
:Warning
Risk of electric shock!
Penetrating moisture may result in an electric shock.
Clean the appliance using a damp cloth only. Before
cleaning, pull out the mains plug or switch off the circuit
breaker in the fuse box.
:Warning
Risk of electric shock!
Do not use any high-pressure cleaners or steam
cleaners, which can result in an electric shock.
:Warning
Risk of injury!
Components inside the appliance may have sharp
edges. Wear protective gloves.
:Warning
Risk of injury!
Risk of trapping body parts when opening and closing
the glass front. Do not reach into the area behind the
glass panel, and keep your fingers away from the
hinges.
Cleaning agents
To ensure that the different surfaces are not damaged
by using the wrong cleaning product, follow the
instructions in the table. Do not use any of the following:
■Harsh or abrasive cleaning agents, e.g. scouring
powder or liquid scouring cleaner,
■Cleaning products with a high alcohol content,
■Hard scouring pads or cleaning sponges,
■Pressure washers or steam cleaners,
■Cleaning products that dissolve limescale,
■Aggressive all-purpose cleaning products,
■Oven spray.
Note: Wash new sponge cloths thoroughly before use.
Note: Follow all instructions and warnings included with
the cleaning products.
--------
Removing metal grease filter
1. Open the glass front slowly and fully. Hold the glass
front in the centre when doing so, gripping it firmly.
2. Open the lock and swing down the metal grease
filter. When you do this, take hold of the metal
grease filter from underneath with your other hand.
3. Take the metal grease filter out of the holder.
Notes
– Fat may accumulate in the bottom of the metal
grease filter.
– Hold the metal grease filter level to prevent
grease from dripping out.
Area Cleaning products
Stainless steel Hot soapy water:
Clean with a dish cloth and then dry with a
soft cloth.
Clean stainless steel surfaces in the direction
of the grain only.
Special stainless steel cleaning products are
available from our after-sales service or from
specialist retailers.Apply a very thin layer of
the cleaning product with a soft cloth.
Painted surfaces Hot soapy water:
Clean using a damp dish cloth and then dry
with a soft cloth.
Do not use stainless steel cleaner.
Aluminium and plastic Hot soapy water:
Clean with a soft cloth.
Glass Glass cleaner:
Clean with a soft cloth. Do not use a glass
scraper.
Controls Hot soapy water:
Clean using a damp dish cloth and then dry
with a soft cloth.
Risk of electric shock caused by penetrating
moisture.
Risk of damage to the electronics caused by
penetrating moisture. Never clean controls
with a wet cloth.
Do not use stainless steel cleaner.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Cleaning and maintenance en
17
Cleaning the metal mesh grease filters
These instructions apply to several appliance variants. It
is possible that individual features are described which
do not apply to your appliance.
:Warning
Risk of fire!
Fatty deposits in the grease filter may catch fire.
Regularly clean the grease filter. Never operate the
appliance without a grease filter.
Notes
■Do not use aggressive, acidic or alkaline cleaning
products.
■We recommend cleaning the grease filters every 2
months.
■When cleaning the metal grease filters, also clean
the metal grease filter holder in the appliance using
a damp cloth.
■The metal grease filters can be cleaned in the
dishwasher or by hand.
By hand:
Note: You can use a special degreaser to remove
stubborn dirt. This can be ordered from the online shop.
■Soak the metal grease filters in hot soapy water.
■Clean the filters with a brush and then rinse them
thoroughly.
■Leave the metal grease filters to drain on an
absorbent material.
In the dishwasher:
Note: Slight discolouration may occur if the metal
grease filters are cleaned in the dishwasher. This
discolouration has no effect on the performance of the
metal grease filters.
■Use normal domestic dishwashing detergents.
■Do not clean heavily soiled metal grease filters
together with cookware.
■Place the metal grease filters in the dishwasher,
leaving plenty of space around them. Do not trap the
metal grease filters.
■Select a temperature of no more than 50 °C.
Installing the metal mesh grease filter
:Warning
Risk of injury!
Components inside the appliance may have sharp
edges. Wear protective gloves.
Note: Clean all accessible parts of the housing.
1. Insert the metal grease filter and lock it in place.
When you do this, take hold of the metal grease filter
from underneath with your other hand.
Note: Make sure that the metal grease filter is
positioned correctly.
2. If the metal grease filter has not been inserted
correctly, open the lock and reinsert the metal
grease filter correctly.

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
en Trouble shooting
18
3Trouble shooting
Tr oubl e shoot i ng Malfunctions often have simple explanations. Please
read the following notes before calling the after-sales
service.
:Warning
Risk of electric shock!
Incorrect repairs are dangerous. Repairs may only be
carried out and damaged power cables replaced by
one of our trained after-sales technicians. If the
appliance is defective, unplug the appliance from the
mains or switch off the circuit breaker in the fuse box.
Contact the after-sales service.
Malfunction table
--------
LED lights
Defective LED lights may be replaced by the
manufacturer, their customer service or a qualified
technician (electrician) only.
:Warning
Risk of injury!
The light emitted by LED lights is very dazzling, and can
damage the eyes (risk group 1). Do not look directly
into the switched on LED lights for longer than 100
seconds.
4Customer service
Cu s t o mer ser vi ce When calling us, please quote the product number (E
no.) and the production number (FD no.) so that we can
provide you with the correct advice. These numbers can
be found on the rating plate on the top of the appliance.
You can make a note of the numbers of your appliance
and the telephone number of the after-sales service in
the space below to save time should it be required.
Please be aware that a visit by an after-sales engineer
will be charged if a problem turns out to be the result of
operator error, even during the warranty period.
Please find the contact data of all countries in the
enclosed customer service list.
To book an engineer visit and product advice
Rely on the professionalism of the manufacturer. You
can therefore be sure that the repair is carried out by
trained service technicians who carry original spare
parts for your appliances.
Problem Possible cause Solution
The appliance
does not work
The plug is not
plugged in.
Connect the appliance to the
electricity supply
Power cut Check whether other kitchen
appliances are working
Faulty fuse Check in the fuse box to make
sure that the fuse for the
appliance is OK
The lighting does
not work.
The LED lights
are defective.
Call the after-sales service.
The button illumi-
nation does not
work.
The control unit is
faulty.
Call the aftersales service.
E no. FD no.
After-sales serviceO
GB 0344 892 8989
Calls charged at local or mobile rate.
IE 01450 2655
0.03 € per minute at peak. Off peak 0.0088 €
per minute.
Z-Nr:FD:E-Nr:
Type:

ImportAppliances.com
THE EASIEST WAY TO SELF-IMPORT APPLIANCES DIRECT FROM EUROPE.
Customer service en
19
Accessories
(not included in the scope of delivery)
Note: These instructions apply to several appliance
models. It may be the case that an optional accessory
that is listed does not apply for your appliance.
Note: Observe the installation instructions in the
accessory.
--------
Accessories Order number
Starter set for air-recirculation mode (flat hood
with chimney)
Easy-change filter for starter set
Z51AFU0X0
Z51AFA0X0
Starter set for air-recirculation mode (flat hood
without chimney)
Easy-change filter for starter set
Z51AFT0X0
Z51AFA0X0
Starter set for air-recirculation mode (angled hood
with chimney)
Easy-change filter for starter set
Z51AIU0X0
Z51AIA0X0
Starter set for air-recirculation mode (angled hood
without chimney)
Easy-change filter for starter set
Z51AIT0X0
Z51AIA0X0
Starter set for air-recirculation mode with filter
that can be regenerated (flat hood with chimney)
Z51AFS0X0
Starter set for air-recirculation mode with filter
that can be regenerated (angled hood with chim-
ney)
Z51AIS0X0
Starter set for air-recirculation mode with filter
that can be regenerated (flat hood without chim-
ney)
Z51AFR0X0
Starter set for air-recirculation mode with filter
that can be regenerated (angled hood without
chimney)
Z51AIR0X0
CleanAir air-recirculation module
Easy-change filter for CleanAir air-recirculation
module (cannot be regenerated)
Z51AXC0N0
Z5170X1
Easy-change filter for CleanAir air-recirculation
module (can be regenerated)
Z50XXP0X0
