nekos NRS1 User manual

INSTRUCTION MANUAL
HEATED RAIN SENSOR
Electrical feeding 24V
NEKOS S.r.l. -
Via Capitoni, 7/5
[phone]
E
N
4420068 – Rev. 2003
NRS1
INSTRUCTION MANUAL
HEATED RAIN SENSOR
Electrical feeding 24V
Via Capitoni, 7/5
- 36064 Colceresa (VI)
–
[phone]
–  [phone] - www.nekos.it -
[e-mail]
–
ITALY
[email protected]
2
USER INSTRUCTIONS
CAUTION. Carefully observe all the following installation
instructions to ensure personal safety.
The device is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lacking
experience and knowledge. Do not allow children to play with the
fixed controls and keep any remote-control units out of their reach.
Have installation checks performed periodically by qualified
personnel from a service centre authorised by the manufacturer. Do
not use if repair or adjustment is required.
CAUTION: if the power cable is damaged, it must be replaced by
qualified personnel from a service centre authorised by the
manufacturer.
CAUTION. Disconnect the power supply during cleaning or
maintenance operations. Do not use solvents or jets of water to
wash the appliance; the appliance should not be submerged in
water.
In the event of fault or malfunction, switch off the device at the main
switch. All repairs and adjustments (e.g. setting the stroke) must
only be performed by qualified personnel from a service centre
authorised by the manufacturer.
Always request exclusive use of original spare parts. Failure to
respect this condition could compromise safety and invalidate the
benefits contained in the warranty for the appliance. In the event of
any problems or queries, consult your agent or contact the
manufacturer directly.
The A-weighted sound pressure level is less than 70dB(A).
Carefully preserve these instructions after installation.

INSTALLER INSTRUCTIONS
nekos
products have been manufactured in accordance with safety standards and conforms to
the stipulations of current standards in force.
When correctly assembled, installed and used according to the present instructions, they will not
generate any danger for
persons, animals or items.
Symbols used in the manual
DANGER
Contents
1. Safety indications
................................
1.1. General notes
................................
1.2.
Notes for functioning and use
2.
Technical and constructional information
3. Technical data
................................
4. Id plate and marking data
................................
5. Technical information
................................
6.
Advices and instruction for mounting
7. Electrical connections
................................
7.1.
Replace P2 rain sensor on N series units
8. Dip-switches selection
................................
9. Led signals
................................
10. Environmental protection
................................
11. Recall to main prin
ciples of warranty certificate
12. Declaration of conformity
................................
3
INSTALLER INSTRUCTIONS
products have been manufactured in accordance with safety standards and conforms to
the stipulations of current standards in force.
When correctly assembled, installed and used according to the present instructions, they will not
persons, animals or items.
Symbols used in the manual
This indication draw the attention about potential dangers for safety and
health of peoples and animals.
................................
................................
...............................
................................
................................
..........................
Notes for functioning and use
................................
................................
Technical and constructional information
................................
...........................
................................
................................
................................
................................
................................
...................
................................
................................
.........................
Advices and instruction for mounting
................................
................................
................................
................................
.........................
Replace P2 rain sensor on N series units
................................
................................
................................
........................
................................
................................
................................
................................
................................
....................
ciples of warranty certificate
................................
..................
................................
................................
....................
INSTALLER INSTRUCTIONS
products have been manufactured in accordance with safety standards and conforms to
When correctly assembled, installed and used according to the present instructions, they will not
This indication draw the attention about potential dangers for safety and
...............................
4
..........................
4
................................
.. 4
...........................
4
................................
.... 5
...................
5
.........................
5
................................
.. 5
.........................
6
................................
................ 7
........................
7
................................
......... 7
....................
7
..................
7
....................
8
1.
SAFETY INDICATIONS
1.1. General notes
WARNING
:
B
EFORE INSTALLING THI
INDICATIONS HAVE BEE
PREVENT CONTACT WITH
MANUAL SHOULD BE CON
The manufacturer accepts no responsibility for damage to people,
animals or things incurred by improper use.
Use for any applications other than those indicated must be authorised by
the manufacturer after technical review of the assembly.
Plastic b
ags, polystyrene, small metal parts such as nails, staples etc. should
be placed out of the reach of children as they constitute a potential source of
risk.
The appliance is not intended for use by people (including children) whose
physical, sensory and
experience or knowledge; such persons must be supervised to ensure that they
do not play with the appliance.
Do not use solvents or jets of water to wash the appliance. The appliance
should not be
submerged in water.
1.2. Notes for funct
ion
NRS1
is a sensor to detect rain
to a device able to
interpret it
must be authorised by the
manufacturer after technical review of the assembly

This product is designed to be used with the manufacturer's original products. Use
with any other products may result in damage or malfunctions.
 The initial start-
up of the sensor should be carried out
person following the manufacturer's instructions.

After removing packaging, check for any damage on the appliance

Before using the rain sensor, check that the power has the same nature, quality and
tension as those indicated on

This machine is destined exclusively for the use for which it has been designed and
the manufacturer accepts no responsibility for damage incurred by improper use.

Repairs should only be performed by qualified pe
authorised by the manufacturer.

The product must be disposed of in compliance with local environmental regulations
and not as household waste.
2. TECHNICAL AND CO
N
 NRS1 sensors
signal the rain event to an apparatus able to interpret and command
the connected devices. The sensor is insensitive to the formation of dew or
moisture after rainfall dries very quickly and being heated
allow the formation of ice.

The sensor is fed with a tension between
4
SAFETY INDICATIONS
EFORE INSTALLING THI
S APPLIANCE
,
ENSURE ALL SAFETY
INDICATIONS HAVE BEE
N READ CAREFULLY AND
UNDERSTOOD IN ORDER
PREVENT CONTACT WITH
ELECTRICITY
,
INJURY OR ANY OTHER
MANUAL SHOULD BE CON
SERVED FOR FURTHER C
ONSULTATION AT A LAT
The manufacturer accepts no responsibility for damage to people,
animals or things incurred by improper use.
Use for any applications other than those indicated must be authorised by
the manufacturer after technical review of the assembly.
ags, polystyrene, small metal parts such as nails, staples etc. should
be placed out of the reach of children as they constitute a potential source of
The appliance is not intended for use by people (including children) whose
physical, sensory and
mental abilities are reduced, or in case of lack of
experience or knowledge; such persons must be supervised to ensure that they
do not play with the appliance.
Do not use solvents or jets of water to wash the appliance. The appliance
submerged in water.
ion
ing and use
is a sensor to detect rain
that through
the connected cable transmits the signal
interpret it
.
Use for any applications other than those indicated
manufacturer after technical review of the assembly
This product is designed to be used with the manufacturer's original products. Use
with any other products may result in damage or malfunctions.
up of the sensor should be carried out
by a skilled and qualified
person following the manufacturer's instructions.
After removing packaging, check for any damage on the appliance
Before using the rain sensor, check that the power has the same nature, quality and
tension as those indicated on
the technical data label on the appliance.
This machine is destined exclusively for the use for which it has been designed and
the manufacturer accepts no responsibility for damage incurred by improper use.
Repairs should only be performed by qualified pe
rsonnel at assistance centres
authorised by the manufacturer.
The product must be disposed of in compliance with local environmental regulations
and not as household waste.
N
STRUCTIONAL INFORMATION
signal the rain event to an apparatus able to interpret and command
the connected devices. The sensor is insensitive to the formation of dew or
moisture after rainfall dries very quickly and being heated
-
below +
The sensor is fed with a tension between
12V and 24V .
ENSURE ALL SAFETY
UNDERSTOOD IN ORDER
TO
INJURY OR ANY OTHER
INCIDENT
. T
HE
ONSULTATION AT A LAT
ER DATE
.
The manufacturer accepts no responsibility for damage to people,
Use for any applications other than those indicated must be authorised by
the manufacturer after technical review of the assembly.
ags, polystyrene, small metal parts such as nails, staples etc. should
be placed out of the reach of children as they constitute a potential source of
The appliance is not intended for use by people (including children) whose
mental abilities are reduced, or in case of lack of
experience or knowledge; such persons must be supervised to ensure that they
Do not use solvents or jets of water to wash the appliance. The appliance
the connected cable transmits the signal
Use for any applications other than those indicated
manufacturer after technical review of the assembly
.
This product is designed to be used with the manufacturer's original products. Use
with any other products may result in damage or malfunctions.
by a skilled and qualified
After removing packaging, check for any damage on the appliance
.
Before using the rain sensor, check that the power has the same nature, quality and
the technical data label on the appliance.
This machine is destined exclusively for the use for which it has been designed and
the manufacturer accepts no responsibility for damage incurred by improper use.
rsonnel at assistance centres
The product must be disposed of in compliance with local environmental regulations
signal the rain event to an apparatus able to interpret and command
the connected devices. The sensor is insensitive to the formation of dew or
below +
5 °C - does not

5
 Electrical connection must comply with the rules in force on electrical systems.
 All connected devices must be manufactured according to the regulations in force
and comply with regulations issued by the European Community.
3. TECHNICAL DATA
Model
NRS1
Power supply voltage (U
n
) 12V - 24V
Maximum absorbed power (I
n
) 20 mA (120 mA with active heater)
Type of sensor Capacitive
Heater intervention < +5 °C
Type of contact SPDT
Rating contact 0,5 A / 125V~ – 1 A / 24V
Functioning temperature -20 - +65 °C
Feeding cable length 5 m
Feeding cable type / number of wires PVC protected from UV / 5 wires
Protection index IP65
Dimensions 45x93 h=19 mm
Weight 52 g (cable excluded)
Any data reported in this table is not binding and may be susceptible to variations without notice.
4. ID PLATE AND MARKING DATA
NRS1 rain sensors have CE marking and comply with the Standards listed in the
Declaration of Conformity.
The plate data is displayed on an adhesive label placed on the outside of the casing,
which must remain intact and visible.
The main information it displays includes: manufacturer's address, product name -
model number, technical characteristics, production date and serial number.
In the event of a complaint, please indicate the serial number (SN) displayed on the
label. An explanation of the symbols used on the label to abbreviate the technical
characteristics is given in the table in the chapter on “TECHNICAL DATA”.
5. TECHNICAL INFORMATION
NRS1 rain sensor, to completely fulfil its task, has to be placed out in the open fully
exposed to any precipitation, possibly over the roof or in a similar position, or where
can be affected by rainfall.
Sensor can be connected to all stations or devices where signal processing is
foreseen or where a free contact signal is necessary (free from tension).
Feeding cable is 5 m long, made weather resistant, fire retardant and UV resistant.
6. ADVICES AND INSTRUCTION FOR MOUNTING
THESE INSTRUCTIONS ARE INTENDED FOR TECHNICAL AND SPECIALIZED PERSONNEL.
THUS BASIC SAFETY AND WORKING TECHNIQUES ARE NOT DISCUSSED.
To guarantee perfect function and facilitate installation, please note the following
indications and warnings:
Check that the cable length is sufficient to link to the station or control
apparatus. The eventual junction for extending the cable must be
sealed with a cable of the same type and colours.
Warning.
Check that the power supply is the same as those indicated on
technical data applied to the device.
To keep efficient and have a perfect functioning we suggest to clean the
sensitive part
at least any 6 months or any time is dirty due to smog, leaves,
impurity, etc.
Advices for sensor installation:
1.
Choose the most suitable position where place the rain sensor. It has to be put
outside in direct contact with weathering.
2. The sensor is
placed slightly tilted (~ 20 °) to facilitate the flow of water, in a position
that does not have shelters to the fall of rain. Place it under the trees is not
recommended because it alters the natural weather event
3.
Support can be of 2 types depending fro
suggested to make the cable exit below
o Surface flat / tilted –
with high resistance adhesive and suitable for weather or
fixed with a screw;
o Fix support
such as rod or similar where
with a screw.
4. Complet
e cable system and electrical connection to the station or control and
feeding apparatus following the schema on next page
clamps the cable to make it integral with the supporting structure
5. Make a functional test.
To test a rain sensor is sufficient to wet (pour or spray water) on sensitive part of it; the
sensor transmits the signal of “wet sensor”. LED indicators of various apparatus should
light.
7.
ELECTRICAL CONNECTIONS
Electrical connections should be
and keeping in mind the meani
of the feeding cable.
Sensor can work with any station unit or apparatus able to interpret its signal,
therefore the connections of the
instructions of the central or equipment.
The table below shows the caption of any wires and the wiring diagram
Caption of each wire -
NRS1:
 1 - R
ED
(+) connected to
+1
 2 - B
LACK
(-) co
nnected to
 3 - B
LUE
(N.O. contact);
 4 - P
URPLE
(N.C. contact);
 5 - G
REEN
(Common).
6
Check that the cable length is sufficient to link to the station or control
apparatus. The eventual junction for extending the cable must be
sealed with a cable of the same type and colours.
Check that the power supply is the same as those indicated on
technical data applied to the device.
To keep efficient and have a perfect functioning we suggest to clean the
at least any 6 months or any time is dirty due to smog, leaves,
Advices for sensor installation:
Choose the most suitable position where place the rain sensor. It has to be put
outside in direct contact with weathering.
placed slightly tilted (~ 20 °) to facilitate the flow of water, in a position
that does not have shelters to the fall of rain. Place it under the trees is not
recommended because it alters the natural weather event
.
Support can be of 2 types depending fro
m attack surface
suggested to make the cable exit below
:
with high resistance adhesive and suitable for weather or
such as rod or similar where
to apply
the metal bracket
e cable system and electrical connection to the station or control and
feeding apparatus following the schema on next page
.
Bind with one or more
clamps the cable to make it integral with the supporting structure
To test a rain sensor is sufficient to wet (pour or spray water) on sensitive part of it; the
sensor transmits the signal of “wet sensor”. LED indicators of various apparatus should
ELECTRICAL CONNECTIONS
Electrical connections should be
carried out in compliance with safety rule
and keeping in mind the meani
ng of various symbols and
Sensor can work with any station unit or apparatus able to interpret its signal,
therefore the connections of the
power cord are called in the specific
instructions of the central or equipment.
The table below shows the caption of any wires and the wiring diagram
NRS1:
+1
2/24V;
nnected to
-12/24V;
Check that the cable length is sufficient to link to the station or control
apparatus. The eventual junction for extending the cable must be
perfectly
Check that the power supply is the same as those indicated on
To keep efficient and have a perfect functioning we suggest to clean the
at least any 6 months or any time is dirty due to smog, leaves,
Choose the most suitable position where place the rain sensor. It has to be put
placed slightly tilted (~ 20 °) to facilitate the flow of water, in a position
that does not have shelters to the fall of rain. Place it under the trees is not
m attack surface
; in both cases is
with high resistance adhesive and suitable for weather or
the metal bracket
– provided –
e cable system and electrical connection to the station or control and
Bind with one or more
clamps the cable to make it integral with the supporting structure
.
To test a rain sensor is sufficient to wet (pour or spray water) on sensitive part of it; the
sensor transmits the signal of “wet sensor”. LED indicators of various apparatus should
carried out in compliance with safety rule
s
ng of various symbols and
colours of the wires
Sensor can work with any station unit or apparatus able to interpret its signal,
power cord are called in the specific
The table below shows the caption of any wires and the wiring diagram
.

7
7.1. Replace P2 rain sensor on N series units
In the case of useNRS1 rain sensor to replace the old P2 on N series stations, during
connection phase operate as follows:
 RED wire connected at the place of WHITE wire;
 BLACK AND GREEN WIRES CONNECTED TOGETHER AT THE PLACE OF YELLOW WIRE;
 BLUE WIRE CONNECTED AT THE PLACE OF BLUE WIRE;
 PURPLE WIRE HAS TO BE INSULATED AND NOT CONNECTED.
8. DIP-SWITCHES SELECTION
In the sensor base, covered by a black cap, there is the access to dip-switches to
program the sensor which give the possibility of modifying status and sensitiveness.
Dip-switches meaning is the following:
DIP 1
DIP2
SENSITIVENESS
OFF
OFF
Maximum sensitiveness
ON OFF Medium-high sensitiveness
OFF ON Medium-low sensitiveness
ON ON Minimum sensitiveness
The sensor leaves the factory with the maximum sensitiveness set.
9. LED SIGNALS
Rain sensor has 2 signalling LED that indicate the functioning status.
 B - BLUE led flashing indicates that the sensor is fed.
 R - RED led lit fix indicates “wet sensor”; it has active command.
10. ENVIRONMENTAL PROTECTION
All materials used in the manufacture of this appliance are recyclable. We recommend
that the device itself, and any accessories, packaging, etc. be sent to a centre for
ecological recycling as established from laws in force on recycling. The device is
mainly made from the following materials: aluminium, zinc, iron, plastic of various type,
cuprum. Dispose materials in conformity with local regulations about removal.
11. CERTIFICATE OF GUARANTEE
The manufacturer will guarantee good function of the appliance. The manufacturer
shall undertake to replace defective parts due to poor quality materials or
manufacturing defects in accordance with article 1490 of the Civil Code. The
guarantee covers products and individual parts for 2 years from the date of purchase.
The latter is valid as long as the purchaser possesses proof of purchase and
completion of all agreed conditions of payment. Guarantee of good function of
appliances agreed by the manufacturer implies that the latter undertakes to repair or
replace free of charge and in the shortest period possible any parts that break while
under warranty. The purchaser is not entitled to any reimbursement for eventual direct
or indirect damage or other expenses incurred. Attempt to repair by personnel
unauthorised by the manufacture shall render the warranty null and invalid. The
8
warranty does not cover fragile parts or parts subject to natural wear and tear or
corrosion, overload, however temporary etc. The manufacturer will accept no
responsibility for eventual damage incurred by erroneous assembly, manoeuvre or
insertion, excessive stress or inexpert use. Repairs performed under guarantee are
always "ex factory of the manufacturer". Respective transport expenses (out/back) are
the responsibility of the purchaser.
12. DECLARATION OF CONFORMITY
The undersigned,
Company name: NEKOS S.r.l
Postal address: Via Capitoni, 7/5
Postcode and city: 36064 Colceresa VI
Telephone number: [phone]
E-mail address: [email protected]
declare that the document is issued under our sole responsibility and belongs to the following product:
Apparatus model / Product: Heated rain sensor NRS1
Trademark: NEKOS
Model/Type: NRS1
Batch: see data label
Serial number: see data label
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
 2014/30/EU ElectroMagnetic Compatibility Directive (EMCD)
 2014/35/EU Low Voltage Directive (LVD)
 2011/65/EU Restriction of the use of certain hazardous substances Directive (RoHS Directive)
 2015/863/EU Delegated Directive amending Annex II of Directive 2011/65/EU of the European Parliament
and of the Council regarding the list of substances with usage restrictions
The following harmonised standards and/or technical specifications have been applied:
EMC:
EN 61000-6-3:2007 + A1:2011 + AC:2012
EN IEC 61000-6-2:2019
LVD
EN 60335-1:2012 + AC:2014 + A11:2014
RoHS
EN 50581:2012
Place: Colceresa
Date: 04/03/2020
Signature: Giuliano Galliazzo (A.D. – President)
NEKOS S.r.l. - Via Capitoni, 7/5
36064 Colceresa (VI) – ITALY
[phone] –  [phone]
www.nekos.it [email protected]
