Nemco FryKutter 56450A-1D Manual

Operating and Maintenance Instructions
1
56450A-1D 1/4” Chop
56450A-2D 3/8” Chop
56450A-3D 1/2” Chop
IMPORTANT
CLEAN MACHINE THOROUGHLY BEFORE USING IT FOR THE FIRST TIME!
1. To get the best operation and life from your machine, please read and comply with these instructions.
2. Clean machine thoroughly after each use using cleaning instructions below.
3. Minimize the use of alkaline cleaners as they may cause pitting and dulling of the finish.
SAFETY INSTRUCTIONS
Remember that the blades are VERY SHARP! Be careful when handling and operating the machine to keep hands away from
the BLADES.
PREPARATION
1. The FryKutter is to be mounted in a horizontal fashion and attached to a solid sturdy sink or prep table.
2. If unit fails to operate properly when first used call NEMCO customer service at 1-800-782-6761.
OPERATION OF FryKutter
1. With the LEVER in the fully opened position, lay the prepared produce in the trough.
2. Remove hands and fingers from the cutting area.
3. With one quick motion pull on LEVER to cut produce. Occasionally if the produce is very large, or if it is positioned at an angle to
the blades, this may have to be repeated to cut it entirely through.
CAUTION: Do not attempt to chop produce larger than the opening in the BLADE HOLDER.
4. Clean the machine after cutting is completed, using cleaning instructions below.
TO CLEAN THE FryKutter
1. Always thoroughly wash the PUSH BLOCK and the BLADE AND HOLDER ASSEMBLY.
2. Release PUSH BLOCK by turning the THUMB SCREWS located on the PUSH BLOCK GUIDE in a counter clockwise motion until the
PUSH BLOCK is loose.
3. To reassemble the PUSH BLOCK hold it up against the PUSH BLOCK GUIDE and fasten it by turning the THUMB SCREWS.
4. To remove the blade assembly, unscrew the GUIDE RODS to release the BLADE AND HOLDER ASSEMBLY and carefully remove it.
5. To reattach the BLADE AND HOLDER ASSEMBLY, hold the BLADE AND HOLDER ASSEMBLY tight to the bottom of the FRAME.
Completely tighten both GUIDE RODS so the BLADE AND HOLDER ASSEMBLY is held tightly against the bottom of the FRAME.
TO LUBRICATE
1. When necessary, lubricate GUIDE RODS and PINS at each joint utilizing with Mineral Oil or Food Grade Grease.
2. DO NOT LUBRICATE WITH COOKING OIL –IT GETS STICKY.

NEMCO FOOD EQUIPMENT 301 Meuse Argonne, Hicksville, OH 43526
Phone: [phone] Fax: [phone] Toll free: 1-800-782-6761
www.nemcofoodequip.com
2
10-1-2018
