NEO ION 440 User manual

P. 1
- Neo ION 440
USER MANUAL / MANUAL DE USUARIO
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE
POR FAVOR LEA LAS INSTRUCCIÓNES ANTES DE USAR
ION 440
3-in-1
moving head, spot, wash
and beam functions

P. 2
Neo ION 440 -
1. OVERVIEW
Ion 440 3-in-1
Moving head that accomplish spot, wash and beam
functions, featuring a 2º-34º linear zoom.
Ion 440 3-in-1 is a versatile moving head that ac-
complish spot, wash and beam functions, featuring
a 2º-34º linear zoom. Powered by an Osram Sirius®
HRI 440W lamp, the xture achieves an outstanding
748,000 Lux @ 16 feets in its beam function, with a 2º
beam angle. Ideal for the most demanding applica-
tions, the unit is equipped with a smooth CMY color
mixing system that, in addition to its 13 dichoric lters
and 3200K CTO lter, enables endless chromatic com-
binations. On the other hand, Ion 440 3-in-1 sports a 6
rotating, indexable and interchangeable gobo wheel,
a 18 static gobo wheel, 3/6 facet rotating prism, iris
& frost lter. With Rapid and precise movements,
advanced RDM function & auto-focus, a capability
that guarantees a really crisp projection at any beam
angle, Ion 440 3-in-1 is not only powerful and versatile;
it’s a complete solution for lighting designers.
Source & Optics
• Light Source: Osram Sirius® HRI 440W
• Color temperature: 7500K
• Lamp Life: 1,500 hours
• Zoom: 2º-34º linear zoom
Photometric data
• Luminous Flux: 24,000 lumen
• 2º Beam angle: 748,000 lux @ 15 .
• 34º Beam angle: 10,050 lux @ 15 .
Effects & Functions
• Three CMY color wheels with 13 dichroic lters &
3200K CTO lter
• Bidirectional rainbow eect
• Color bounce
• Rotating gobo wheel: 6 interchangeable and
indexable rotating gobos + open
• Static gobo wheel: 18 indexable gobos + open
• Animation and movement gobo eects
• Gobo shake & scroll
• Frost lter
• 3/6 facet rotating prism
• Auto-focus
• Iris
• Dimmer: Full range 0-100%
• Strobe eect
Control
• DMX Channels: 18/20/31/32
• Wireless DMX (optional)
• Advanced RDM Function
• Indicated temperature for base, arm & lamp
• IC backup communication
• Soware update via DMX
• Fan speed based on temperature
Movement
• Pan: 540° / 630º
• Tilt: 265°
• 3-phase motor
• 16-bit resolution
• Auto repositioning
Physical
• DMX Connectors: 2 XLR connectors (XLR-3
input & output)
• Power supply connectors: PowerCON® In/Out
• 2.4 inches LCD graphic display
• Dimensions: 428x324x718 mm. / 17x13x28 in.
• Weight: 25 Kg. / 55 Lbs.
English version

P. 3
- Neo ION 440
English version
Description of the Device
9. Wireless indicator
10. Mic
11. Le button
12. Battery indicator
13. Up button
14. Down button
15. Enter button
16. Right button
17. Ethernet out
18. 5-pin DMX in
19. Ethernet in
20. 5-pin DMX out
21. Powercon in
22. Fuse
1. Project lens
2. Head
3. Arm
4. Base
5. Display
6. Foot stand
7. Operation button
8. Handle
1
2
3
4
7
8
65
910 11 1213 14 1615
17 18 19 20 21 22

P. 4
Neo ION 440 -
Colors and Gobos
Open
1UV
2Blue
3 Dark pink
4 Light blue
5 Sky blue
6 Linear Cyan
7 Red
8 Light orange
9 Orange
10 Brown
11 Dark red
12 Linear Magenta
13 Green
14 Megenta
15 Light orange
16 Dark Green
17 Grass green
18 Linear Yellow
English version

P. 5
- Neo ION 440
Static gobo wheel
Rotating gobo wheel (slot-in-out gobos)
English version

P. 6
Neo ION 440 -
Before operate this unit, please carefully read this users guide and keep if needed in
future. It’s necessary to respect following rules.
The disposal of the device aer lifecycle could damage the environment, need to take
it to special company for recycling or return to authorized dealer.
The products referred to in this manual conform to the Eur opean Community Direc-
tives and are therefore marked with CE logo.
Keep this device away from children and unauthorized users, the manufacturer will
not take responsibility for the damage due to any disregard of the information provid-
ed in this manual and wrong operation.
Before operate the device, pls make sure the xture is in good housing, ensure pan
and tilt can rotate in its complete range.
Pls make sure minimal 0.5m distance need to kept between the xture to any am-
mable material.
The device can only run with 100-240v voltage, 50/60Hz power, don’t connect to any
other wrong power. Disconnect the device from main power before open the shield or
maintenance.
The device is designed only for indoor usage, pls keep it away from moisture. Do not
expose the device under the sun or directly to any other lighting source.
Never look directly into the projecting lens when the xture is power on, the light may
trigger epileptic seizures in photosensitive persons or persons with epilepsy. Espe-
cially at beam eect, extreme caution and observance of these safety instructions is
mandatory.
Don’t put or install the device on a surface that subject to vibration
or bumps.
2. SAFETY AND MAINTENANCE INFORMATION
Safety info

--0.5m
English version

P. 7
- Neo ION 440
Maintenance
Ta=45°C The device is supposed to work in the temperate range -15° C and +45° C, do not use
the device when the temperate exceed this range.
The lens, shield need to be replaced when obviously broken, never use the device
when the shield is not completed closed.
Safety I class device, need to be earth connected.
When the xture is hanged overhead, the safety rope must be xed to the bottom of
the device to the appropriate xing point.
Always carry the device by the handles, do not take the head or arm directly for
transportation.
• Operation only allowed to qualied person,
damages due to unprofessional operation or re-
move of any parts inside will not be considered
in warranty service. There are no serviceable
parts inside the device or package, service only
leaves to authorized dealers.
• Never allow the optical components contact
with oil, fat or any other liquid.
• A regular clearance of the device is needed for
long-term usage, this is very helpful to maintain
the lifetime and brightness need to use a so
and lint-free cloth to clean the optical system,
fan and air owing tunnel.
English version

P. 8
Neo ION 440 -
Replacement of the fuse
Trouble Shooting
Need to replace with same type and rating, which
originally installed in the device.
Step One: Unplug power cable from main power.
Step Two: Unscrew the fuse holder out of the hous-
ing with a screwdriver.
Step Three: Remove the broken fuse and replace
with an exact same type of new fuse.
Step Four: Insert the fuse holder back to the hous-
ing and screw tight and reconnect power.
Problems Possible reasons Checking or solutions
Device not
power up
Powercon or power cable damaged Change a good power cable to try
Faulty power supply Replace new power supply
Pan/Tilt error
or vibrate
Faulty Pan/Tilt PCB Replace PT001 PCB
Faulty opto sensor Replace opto sensor OP001
Cable loosen Check the cable connect to OP001
Lamp o
Temperature protection Check the temperature from menu
Fan not working Check the fan speed info from menu
Faulty Lamp Replace new Lamp
Dimmer and strobe set at 0 Set dimmer and strobe channel at 255
Faulty power supply Replace new power supply
Device not response
to DMX
Faulty communication IC Replace the IC with back-up one in the
display PCB
Faulty display PCB Replace new display PCB
Wrong DMX addressing Check the address and setting
Faulty DMX cable Change to a good DMX cable
English version

P. 9
- Neo ION 440
3. INSTALLATION
The device could be either put on a solid and even
Surface, or mounted upside down or sideways like
le picture.
The mounting place must be suicient stable and
be able to support a weight of 10 times of the unit’s
weight. When the xture is hanged, always addi-
tionally secure the device with the safety chain,
fasten the safety rope at a suitable position so that
the maximum fall of the projector will be 20 cm.
How to do mounting installation.
Step two: Install the clamp and bracket on the
bottom of panel, fasten the quick-locks;
Step one: Installation the clamp onto the
omega bracket;
English version

P. 1 0
Neo ION 440 -
4. CONTROL MENU
Meaning of the icon in menu
Default setting shadowed. mark with 1 can be basic
reloaded, 2 be program reloaded, 3 can be private
reloaded.
Step three: Install the whole device onto
appropriate truss and fasten the clamps, tight
the safety rope with the truss or other xing
point at a suitable position that drop down
distance not exceed 20 cm.
Connect Light Infomation Set Program
Menu tree
Connect
DMX Address 1 XXX DMX address setting
Wireless 1 (Wireless Module) Wireless Enabled
Artnet 1 (Only Artnet Module) Artnet Enabled
Light
Turn On/O
Automatic
DMX Control
(Only HID Lamp)
ON/OFF
ON/OFF
ON/OFF
Turn On the lamp
Lamp On/o when power on
DMX control or not
(HID Lamp)
English version

P. 11
- Neo ION 440
Max
Temperature 1
80~139°C/176~282°F Lamp o if temperature con-
tinuously over for 2 minutes
Lamp Adjust 1 PAN…… Adjust value of channel
Information
Time Info.
Current XXXX(Hours)
Fixture Life XXXX(Hours)
Lamp Life XXXX(Hours)
(Only HID Lamp)
Fixture boot time
Fixture total run time
Lamp total run time
Lamp Info.
(Only HID Lamp)
Voltage
Current
Power
HID Lamp Information
(HID Lamp)
Temperature Near Lamp Temp (depends on xture) Temperature Sensors
Fans Speed Near Lamp Fan (depends on xture) Fan speed Sensors
Channel Value PAN…… Display value of channel
Error Message Pan,Tilt…… Error channels
Fixture Model xxxxxxxxxxxx Display model brand and
model
Soware Ver 1U01 V1.0.00…………….. Version of each IC
Set
Reset All
Pan&Tilt
:
Reset all
Reset Pan&Tilt
:
Movment
Pan Reverse 1
Tilt Reverse 1
Pan Degree 1
Encoders 1
Pan/Tilt Mode 1
ON/OFF
ON/OFF
630/540
ON/OFF
Stand/Smooth
Pan Reverse
Tilt Reverse
Choose Pan Degree
Encoder wheel on/o
Choose pan/tilt mode
UI Set
Mic Sens. 3
No Signal 1
Temperature.
C/F 1
Fans Mode 1
Hibernation 1
Backlight 1
Flip Display 1
Display Bright 3
Brand Show 1
Key Lock 1
Language 3
0~99%,60%
Close/Hold/Auto/Mu-
sic
Fahrenheit /Celsius
Auto Speed /High
Speed
OFF, 01M~99M,15M
02~60m 02m
ON/OFF
00~31 10
ON/OFF
ON/OFF
En/Fr/Sp/
Sensitivity of Mic
Mode when no signal
Temperature at °C/°F
Fans mode
Sleeping mode
Show backlight time
Display 180°reverse
Display Brightness
Show brand or not
Key lock on/o
Language Select
Fixture Set
(Only Led Lamp)
Theater Mode
Dimmer Curve
Halogen (Only
RGB Led)
ON/OFF
Curve1……
O/2700k/3200k
/5600k
Theater Mode
Dimmer Curve (Only Led)
Halogen (Only RGB Led)
English version

P. 12
Neo ION 440 -
English version
Users
User Mode 1 Standard
Extended
:
User
Standard mode
Extended mode
:
User program mode
Edit User 3 Max Channel = XX
PAN = CH01
:
Edit users mode
Calibration 3 -Password-
Pan
:
=XXX
=XXX
:
Password: 050
Calibrate channel value
Fixture ID 3 Name
-Password-
PID Code
Name
Password: 050
Set PID of RDM
Wireless Set 1
(Wireless Module)
DMX On Cable
Reset Connect
ON/OFF
ON/OFF
DMX Send Out
Reset Connect
Ethernet Set 3
(Only Artnet
Module)
IP Address
IP Mask
Universe
DMX On Cable
2.x.x.x
255.0.0.0
0
ON/OFF
Ethernet Set
(Only Artnet Module)
Reload Default
Basic Reload (1)
Program Reload
(2)
---Password---
Private Reload
(3)
All Reload
Update Fixture
ON/OFF
ON/OFF
XXX
ON/OFF
ON/OFF
ON/OFF
Basic Reload
Program Reload
Password: 050
Private Reload
All Reload
Soware upgrade
Program
Play 1
DMX Receive
Slave Receive
Sequence
Music
Slave Receive 1,2,3
Master / Alone
Master / Alone
DMX Receive
Choose slave position
Run Sequence
Music mode
Select Chase 2
Chase Part 1
Chase Part 2
Chase Part 3
Chase 1 ~ 8 Chase 1
Chase 1 ~ 8 Chase 2
Chase 1 ~ 8 Chase 3
Select and run auto
program
Edit Chase 2
Chase 1
:
Chase 8
Chase
Test
Step 01
Step 64
=SCxxx
=SCxxx
Test
Beginning scene
Ending scene
Edit Scenes 2
Edit Scene 001
~ Edit Scene 250
Pan,Tilt,……
--Fade Time--
--Secne
Time--
DMX Input
=xxx
=xxx
=xxx
Input manual scene
Modify manually fading time
Modify manually scene time
Input scene from exterior
controller
Scenes Record ScXX=>ScXX Auto Input scenes

P. 13
- Neo ION 440
English version
5. DMX CONNECTION AND DMX PROTOCOL
The device is controlled by universal DMX 512 pro-
tocol, DMX address is the start channel used to re-
ceive instructions from the external controller. For
independent control, each xture must be assigned
its unique address control channels. For example,
this device has four channel modes: 31/32/18/20,
if we set the mode at standard 31 channels mode,
and there are several models need to be inde-
pendently controlled, we just simply address rst
xture at 1, and second xture at 32, third one at
63, etc.
If the devices have the same address, they will
behave synchronically.
DMX addressing is limited, don’t set the address
so high that without enough control channels
for the xtures. Display is ashing when no DMX
signal is received.
DMX addressing
Connection: use DMX cable with 5 pin XLR-plugs
to connect the controller with the xture or one
xture with another.

P. 14
Neo ION 440 -
DMX chart
Channel Name Function Min DMX Max DMX
St Ex1 Ba1 Ba2
1 1 1 1 Pan Pan Coarse 0255
2 2 2 Pan ne Pan Fine 0 255
3 3 2 3 Tilt Tilt Coarse 0255
4 4 4 Tilt ne Tilt Fine 0 255
5 5 3 5 Movment
Speed
fastest to Slowest 0255
6Movment
Function
Normal 015
Movement With Backout 16 31
TBD 32 255
67Shutter
Function
Normal Shutter Functions 0 15
Pulse-eect Forward 16 31
Pulse-eect Reverse 32 47
Random Strobe 48 63
TBD 64 255
7 8 Shutter
Normal Shutter Functions
Close 031
Strobe Rate (slow to fast) 32 223
Open 224 255
Pulse-eect Forward
Close 031
Strobe Rate (slow to fast) 32 223
Open 224 255
Pulse-eect Reverse
Close 031
Strobe Rate (slow to fast) 32 223
Open 224 255
Random Strobe
Close 031
Strobe Rate (slow to fast) 32 223
Open 224 255
46Shutter
Shutter closed 031
No function (shutter open) 32 63
Strobe eect slow to fast 64 95
No function (shutter open) 96 127
English version

P. 15
- Neo ION 440
English version
Pulse-eect in sequences 128 159
No function (shutter open) 160 191
Random strobe eect slow to fast 192 223
No function (shutter open) 224 255
8 9 5 7 Dimmer Dimmer(Close to Open) 0 255
910 Color 1
Function
Indexed 015
Indexed With BackOut 16 31
Forward Spin 32 47
Reverse Spin 48 63
Continuous 64 79
Color Bounce 80 111
TBD 112 255
10 11 Color 1
Indexed & Indexed With Back-
Out&Color Bounce
Position 1 (Open) 020
Position 2 21 41
Position 3 42 62
Position 4 63 83
Position 5 84 104
Position 6 105 125
Position 7 126 146
Position 8 147 167
Position 9 168 188
Position 10 189 209
Position 11 210 230
Position 12 231 255
Forward Spin
Stop to fastest 0255
Reverse Spin
Stop to fastest 0255
Continuous
Positioning from 0-360 degrees 0255
68Color 1 &
Cyan
Indexed
Cyan 0->100% 0127
Position 1 128 129
Position 2 130 131
Position 3 132 133
Position 4 134 135

P. 1 6
Neo ION 440 -
Position 5 136 137
Position 6 138 139
Position 7 140 141
Position 8 142 143
Position 9 144 145
Position 10 146 147
Position 11 148 149
Indexed With Bounce
Position 1 150 159
Position 2 160 169
Position 3 170 179
Position 4 180 189
Position 5 190 199
Position 6 200 209
Position 7 210 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
11 12 Color 2
Function
Indexed 015
Indexed With BackOut 16 31
Forward Spin 32 47
Reverse Spin 48 63
Continuous 64 79
Color Bounce 80 111
TBD 112 255
12 13 Color 2
Indexed & Indexed With BackOut &
Color Bounce
Position 1 (Open) 020
Position 2 21 41
Position 3 42 62
Position 4 63 83
Position 5 84 104
Position 6 105 125
Position 7 126 146
Position 8 147 167
Position 9 168 188
Position 10 189 209
Position 11 210 230
English version

P. 17
- Neo ION 440
English version
Position 12 231 255
Forward Spin
Stop to fastest 0255
Reverse Spin
Stop to fastest 0255
Continuous
Positioning from 0-360 degrees 0255
7 9 Color 2 &
Magenta
Indexed
Magenta 0->100% 0127
Position 1 128 129
Position 2 130 131
Position 3 132 133
Position 4 134 135
Position 5 136 137
Position 6 138 139
Position 7 140 141
Position 8 142 143
Position 9 144 145
Position 10 146 147
Position 11 148 149
Indexed With Bounce
Position 1 150 159
Position 2 160 169
Position 3 170 179
Position 4 180 189
Position 5 190 199
Position 6 200 209
Position 7 210 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
13 14 Color 3
Function
Indexed 015
Indexed With BackOut 16 31
Forward Spin 32 47
Reverse Spin 48 63
Continuous 64 79
Color Bounce 80 111
TBD 112 255

P. 18
Neo ION 440 -
14 15 Color 3
Indexed & Indexed With Back Out &
Color Bounce
Position 1 (Open) 020
Position 2 21 41
Position 3 42 62
Position 4 63 83
Position 5 84 104
Position 6 105 125
Position 7 126 146
Position 8 147 167
Position 9 168 188
Position 10 189 209
Position 11 210 230
Position 12 231 255
Forward Spin
Stop to fastest 0255
Reverse Spin
Stop to fastest 0255
Continuous
Positioning from 0-360 degrees 0255
810 Color 3 &
Yellow
Indexed
Yellow 0->100% 0127
Position 1 128 129
Position 2 130 131
Position 3 132 133
Position 4 134 135
Position 5 136 137
Position 6 138 139
Position 7 140 141
Position 8 142 143
Position 9 144 145
Position 10 146 147
Position 11 148 149
Indexed With Bounce
Position 1 150 159
Position 2 160 169
Position 3 170 179
Position 4 180 189
Position 5 190 199
English version

P. 1 9
- Neo ION 440
Position 6 200 209
Position 7 210 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
15 16 Cyan Cyan 0->100% 0255
16 17 Magenta Magenta 0->100% 0255
17 18 Yellow Yellow 0->100% 0255
18 19 Rot Gobo
Function
Indexed 015
Indexed With BackOut 16 31
Forward Spin 32 47
Reverse Spin 48 63
Continuous 64 79
Shake 80 95
TBD 96 255
19 20 Rot Gobo
Indexed & Indexed With Back-
out&Shake
Position 1 (Open) 035
Position 2 36 71
Position 3 72 107
Position 4 108 143
Position 5 144 179
Position 6 180 215
Position 7 216 255
Forward Wheel Spin
Stop to fastest 0255
Reverse Wheel Spin
Stop to fastest 0255
Continuous
Positioning from 0-360 degrees 0255
911 Rot Gobo
Indexed
Position 1 (Open) 06
Position 2 713
Position 3 14 20
Position 4 21 27
Position 5 28 34
Position 6 35 41
Position 7 42 48
English version

P. 2 0
Neo ION 440 -
Indexed With Backout
Position 1 (Open) 49 55
Position 2 56 62
Position 3 63 69
Position 4 70 76
Position 5 77 83
Position 6 84 90
Position 7 91 97
Indexed With Shake
Position 2 98 118
Position 3 119 139
Position 4 140 160
Position 5 161 181
Position 6 182 202
Position 7 203 223
Forward Wheel Spin
Stop to fastest 224 239
Reverse Wheel Spin
Stop to fastest 240 255
20 21 Gobo Rot
Function
Continuous 015
Forward Spin 16 31
Reverse Spin 32 47
Forward Animate Rotate 48 63
Forward Animate Rotate With Backout 64 79
Reverse Animate Rotate 80 95
Reverse Animate Rotate With Backout 96 111
TBD 112 255
21 22 Gobo Rot
Continuous
Positioning from 0-360 degrees 0255
Forward Spin
Stop to fastest 0255
Reverse Spin
Stop to fastest 0255
Forward Animate Rotate & Forward
Animate Rotate With Backout
Stop to fastest 0255
Reverse Animate Rotate & Reverse
Animate Rotate With Backout
Stop to fastest 0255
English version
