Neostar Electronics THC-1002IR User manual
www.neostar.de
THC-1002IR
HD-TVI BulleT Camera
user manual
www.neostar.de
Thank you for purchasing our product. If there are
any questions, or requests, please do not hesitate to
contact the dealer.
This manual may contain several technical incorrect
places or printing errors, and the content is subject
to change without notice. The updates will be added
to the new version of this manual. We will readily
improve or update the products or procedures
described in the manual.
Privacy Notice
This manual may contain several technical
incorrect places or printing errors, and the content
is subject to change without notice. The updates
will be added to the new version of this manual.
We will readily improve or update the products or
procedures described in the manual.
Please refer to the product specication for camera
parameters and functions.
REGULATORY INFORMATION
Fcc iNFormatioN
FCC compliance: This equipment has been tested
and found to comply with the limits for a digital
device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at his
own expense.
Fcc coNditioNs
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
eU coNFormity statemeNt
This product and - if applicable - the
supplied accessories too are marked
with «CE» and comply therefore with the
applicable harmonized European sstandards listed
under the Low Voltage Directive 2006/95/EC, the EMC
Directive 2004/108/EC, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive):
Products marked with this symbol cannot
be disposed of as unsorted municipal waste
in the European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information see: www.recyclethis.info.
2006/66/EC (battery directive):
This product contains a battery that
cannot be disposed of as unsorted
municipal waste in the European Union.
See the product documentation for specic battery
information. The battery is marked with this
symbol, which may include lettering to indicate
cadmium (Cd), lead (Pb), or mercury (Hg). For proper
recycling, return the battery to your supplier or to a
designated collection point. For more information
see: www.recyclethis.info.
1. INTRODUCTION
1.1. ProdUct FeatUres
This series of camera adopts new generation sensor
with high sensitivity and advanced circuit design
technology. It features high resolution, low image
distortion and low noise, etc., which makes it suitable
for surveillance system and image processing system.
▪High performance CMOS sensor and high
resolution bring high-quality image;
▪Low illumination;
▪OSD menu, parameters are congurable;
▪Support auto white balance, auto gain control,
electronic shutter control;
▪Support image eect adjustment;
▪Unit transmission control;
▪Advanced 3-axis design meets dierent
installation requirements.
1.2. overview
1.2.1. overview oF tyPe i camera
1.2.2. overview oF tyPe camera
2. INSTALLATION
BeFore yoU start:
▪Please make sure that the device in the package
is in good condition and all the assembly parts
are included.
▪Make sure that all the related equipment is
power-o during the installation.
▪Check the specication of the products for the
installation environment.
▪Check whether the power supply is matched
with your power output to avoid damage.
▪Please make sure the wall is strong enough to
withstand three times the weight of the camera
and the mounting.
▪If the wall is the cement wall, you need to insert
expansion screws before you install the camera.
▪If the wall is the wooden wall, you can use self-
tapping screw to secure the camera.
▪If the product does not function properly, please
contact your dealer or the nearest service center.
Do not disassemble the camera for repair or
maintenance by yourself.
2.1 ceiliNg moUNtiNg For tyPe i
tyPe ii/camera
stePs:
1. Drill the screw holes in the ceiling according to
the supplied drill template.
2. Hammer the supplied plastic expansion bolt
into the screw holes.
3. Route the cables to the cable hole and connect
the corresponding power cable and video cable.
4. Fix the camera to the ceiling with the supplied
screws.
Figure 2-1 Drill Template
Figure 2-2 Fix the Camera to the Ceiling
HD Video Cable
Power Cable
Mounting Base
Sun Shield
Lens
IR LED
Sun Shield
Mounting Base
Power Cable
HD Video Cable
Lens
All Screw Holes: for
mounting base
Type IType II
1.2.3 overview oF tyPe camera
Lens
Power Cable
HD Video Cable
Sun Shield
www.neostar.de
Figure 2-1 Remove the Bubble
DAY/NIGHT
1. MODE AUTO
2. DTON 63
3. NTOD 63
4. DELAYTIME20
5. RETURN RET
AWB
1. MODE AUTO
2. R-GGAIN 255
3. B-GGAIN 151
4. RETURN RET
5. Adjust the surveillance angle.
1). Loosen No.3 adjusting screw to adjust the
panning position (0° ~ 360°).
2). Tighten No.3 adjusting screw.
3). Loosen the No.2 adjusting screw to adjust the
tilting position (0° ~ 90°).
4). Tighten No.2 adjusting screw.
5). Loosen No.1 adjusting screw to adjust the
azimuth angle of the image (0° ~ 360°).
6). Tighten No.1 adjusting screw.
1. Drill the screw holes on the wall according to
the supplied drill template.
2. Attach the wall mount to the wall and tighten
the screws to x it.
Figure 2-3 3-axis Adjustment
Figure 2-4 Disassemble Mounting Plate
Figure 2-5 Drill Template & Install Mount
Figure 2-8 Angle Adjustment
Figure 2-7 Fix the Camera
Figure 2-6 Screw the Mounting Plate
Figure 2-1 Remove the Bubble
Figure 3-5 EFFECT
Figure 2-1 Bubble
2.2 wall moUNtiNg For tyPe iii camera
stePs:
1. Wiggle the mounting plate to disassemble it
from the wall mount.
4. Screw the mounting plate onto the camera.
5. Fix the camera to the wall mount with the
supplied screws.
5. Adjust the surveillance angle.
1). Loosen No.1 adjusting screw to adjust the
pan position (0° ~ 360°).
2). Tighten No.1 adjusting screw.
3). Loosen No.2 adjusting screw to adjust the
tilting position(0° ~ 90°).
4). Tighten No.2 adjusting screw.
3. MENU OPERATION
Mounting Plate
Mounting Plate
1
2
360
90
Menu
AE
AWB
DAY&NIGHT SYSTEM
SPECIALEFFECT
DC
ESC
HOLD
FRAME
RATE
AUTO
USER
HOLD
8000K
6000K
COLOR
B/W
AUTO
CAMERA
ID
ID DISP
PRIVACY
ZONE
MOTION
HLC
LAUGUAGE
COLOR
GAIN
COLOR
HUE
SHARPNESS
EXIT
VIDEO.
OUT
4200K
3200K
CONTRAST
BRIGHT
MIRROR
FLIP
NAME
DISP
FACTORY
INIT
3.1 video.oUt
You can set the frame rate as 25 fps/30fps.
3.2 day/NigHt
Color, B/W, AUTO and EXT are selectable for DAY/ NIGHT
switches. Under the mode of the AUTO and EXT, you can
set the IR LED as Smart and CDS. If the IR LED is selected
as Smart, you can set the brightness of the IR LED.
3.3.3 awB
Auto, User, Push, 8000k, 6000k, 4200k and 3000k are
selectable for AWB. Under the mode of AUTO, you
need to set the R-G/B-G Gain and to select an indoor/
outdoor mode. If the AWB mode is select as User, You
need to set the R/G/B Gain manually.
3.3.4 ae
You can set the AE mode as HOLD, DC and ESC.
Brightness: Brightness refers to the brightness of the
image.
Shutter: Shutter denotes the speed of the shutter.
You can set the shutter as AUTO, 1/25, 1/30, 1/50, 1/60,
1/100, 1/120, 1/250, 1/500, 1/1k, 1/3k and 1/10k.
Flicker: You can set the icker status as 50HZ/60HZ to
prevent image icking.
BLC: BLC bases on the back area to enhance the
brightness of the whole image. You can set the BLC
gain from 0 to 16.
AGC: AGC optimizes the clarity of image in poor light
scene. The value of AGC can be set from 1-5.
LSC: LSC corrects the phenomenon where theimage
gets darkened or blurred on the periphery.
3.3.5 sPecial
Motion: Set the Motion status as ON or OFF. Set the
SENSITIVITY from 0 to 255. Set the alarm status as ICON/
TRANCE/OFF. Set the hold time from 0 second to 255
seconds.
HLC: HLC supplements the brightness of the peripheral
area of the image. You can set the mask value and
threshold from 0 to 255.
3.3.6 eFFect
Color Gain: Color gain adjust this feature to change
the saturation of the color. You can set the value from
0 to 255.
Color Hue: You can adjust the image HUE from 0 to
71.
Sharpness: Sharpness determines the amount of
detail that an imaging system can reproduce. You can
set the value from 0 to 255.
Contrast: Contrast enhances the dierence in color
and light between parts of an image. You can set the
value from 0 to 255.
Bright O.: Bright O. refers to the brightness
compensation of the image. You can set the bright
compensation value as 0 or 1.
Mirror: You can set the Mirror status as ON/OFF.
Flip: You can set the FLIP status as ON/OFF.
3.3.7 system
EFFECT
1. COLORGAIN 200
2. COLORHUE 200
3. SHARPNESS25
4. CONTRAST 150
5. BRIGHT OFF. 1
6. MIRRORON
7. FLIP ON
8. RETURN RET
SPECIAL
1. PRIVACYZONE
2. MOTION
3. HLC
4. RETURN RET
Figure 2-1 Remove the Bubble
Privacy zone: Select a PRIVACY area. Set the MASK PAT as
OFF, GRAY, WHITE or BLACK. Set the SX/EX/SY/EY value
to dene the position and size of the area.
SYSTEM
1. CAMERA ID 255
2. ID DISP.ON
3. NAME DISP.ON
4. LANGUAGE ENG
5. FACTORYINITOFF
6. RETURN RET
Figure 3-6 SYSTEM
You can set the camera ID from 0 to 255. Select the ID
display and name display status as ON/OFF.
Chinese and English are selectable for the language of
the menu.
You can restore the camera to the default by setting the
factory initialization status as ON.
3.3.8 eXit
Exit and Save & exit are selectable.
