Global V900-B1 User manual

V900 Series
GSM REMOTE CAMERA
User Manual
Manual version 1.9

V900-B1 GSM REMOTE CAMERA USER MANUAL
2
V900 Series GSM Remote Camera
Thank you for purchasing the V900. This camera is a remote controlled
image-capturing device consisting of a microphone, infrared lights and a high quality
300,000-pixel camera lens. The V900 can capture images according to a
pre-programmed remote command and then send it to your multimedia messaging
(MMS) enabled mobile phone with color display, or to an e-mail address. You can
control and change the camera settings via SMS command.
The MMS sent by the V900 can be viewed either by using your mobile phone. You
can also opt to view a slide of consecutive photos taken by the GSM Remote camera.
The built-in high-light infrared LED’s allows the camera to capture clear images, even
in dark environment or areas with insufficient lighting.
The V900 is compatible with standard 433MHz (or 315MHz) wireless sensors such as
wireless infrared body-, door- and smoking sensors.
As soon as the wireless sensor triggers the camera alarm, you or your families and/or
your guards can thus receive the alarm message via SMS, MMS or standard calls,
according to the pre-programmed.
However, the camera can perform its duty well without any wireless sensor too. The
V900 has a motion detective function and an integrated infrared body detector. It will
therefore detect any unauthorized entry into your house and notify you via SMS, MMS,
standard calls or E-mail.
All services and functions need to be supported by the GSM network and a SIM card.
This brochure suits for V900-B1 model.
Details of the functioning and advanced operation of this device are described in this
instruction manual.

V900-B1 GSM REMOTE CAMERA USER MANUAL
3
CONTENTS
For your safety........................................................................................................................................ 6
EXCEPTION CLAUSE.......................................................................................................................... 6
Chapter 1 FEATURES AND ACCESSORIES..........................................................................................7
1.1 Main function.................................................................................................................................... 7
1.2 Sales package contents......................................................................................................................8
1.3 Products features............................................................................................................................... 8
1.4 Remote control Instruction ............................................................................................................... 9
1.5 Light indicator .................................................................................................................................. 9
Chapter 2 Installation.................................................................................................................................10
2.1 Install the SIM card ........................................................................................................................10
2.2 Extending the device’s base board.................................................................................................. 10
2.3 Connecting to power adapter..........................................................................................................10
2.4 Mount the V900 device................................................................................................................... 10
2.5 Power on/ off .................................................................................................................................. 11
Chapter 3 Define the user.........................................................................................................................11
3.1 User Authorization Level................................................................................................................ 11
3.2 Define Master user to start the device............................................................................................. 13
3.2.1Add a master number to the device...............................................................................13
3.2.2 Change the master number............................................................................................13
3.2.3 Change password............................................................................................................14
3.3 Define family user .......................................................................................................................... 14
3.3.1Add a family number........................................................................................................14
3.3.2 Check family user’s number ...........................................................................................15
3.3.3 Delete family number.......................................................................................................15
3.4 Define Guest user ........................................................................................................................... 15
3.5 Define emergency number.............................................................................................................. 15
3.5.1 Add emergency number..................................................................................................16
3.5.2 Delete emergency number.............................................................................................16
3.5.3 Check emergency number..............................................................................................17
Chapter 4 Basic use and settings............................................................................................................17
4.1 Network parameter settings............................................................................................................ 17
4.1.1 Sending MMS message via WAP..................................................................................17
4.1.2 Sending MMS message via HTTP................................................................................18
4.2 To capture images........................................................................................................................... 19
4.2.1 To capture one image and send to the user mobile....................................................19
4.2.2 To capture more than one image and send to the user’s mobile..............................19
4.2.3 To capture images and send to user’s E-mail address...............................................20
4.2.4 To capture images and send to an appointed mobile or E-mail address.................21
4.3 E-mail settings ................................................................................................................................ 21
4.3.1 Add/ modify an E-mail address......................................................................................21
4.3.2 Delete all E-mail address(es).........................................................................................22
4.4 Timed sends images to mobile........................................................................................................ 22
4.4.1 Enable timing sends MMS images................................................................................22

V900-B1 GSM REMOTE CAMERA USER MANUAL
4
4.4.2 Set time period to send MMS images...........................................................................22
4.4.3 Disable timing send MMS image...................................................................................23
4.5 Remote control................................................................................................................................ 24
4.5.1Add remote control(s) to the device...............................................................................24
4.5.2 Remote control instruction..............................................................................................24
4.5.3 The SMS notification message upon arming or disarming the camera via remote
control..........................................................................................................................................25
4.5.4 Remove remote control from the device.......................................................................25
4.6 Emergency Alarms.......................................................................................................................... 26
4.7 Listen in live voice.......................................................................................................................... 26
4.7.1 Call the camera to listen in.............................................................................................26
4.7.2 Listening in upon emergency alarm..............................................................................27
4.7.3 Listening in upon automatically alarm...........................................................................27
4.8 Infrared body detector..................................................................................................................... 27
4.9 Motion detection............................................................................................................................. 28
4.9.1 Activate/Deactivate motion detection............................................................................29
4.9.2 Sensitivity of motion detection........................................................................................29
4.9.3 Condition of motion detection alarm..............................................................................29
4.10 Wireless sensor(s)......................................................................................................................... 30
4.10.1Add a wireless sensor and set corresponding alarm mode.....................................30
4.10.2 Remove wireless sensor...............................................................................................31
4.11 Arming or disarming V900 device manually................................................................................ 32
4.11.1 Arming V900 device manually......................................................................................32
4.11.2 Default arming mode .....................................................................................................32
4.11.3 Disarming V900 device manually ................................................................................33
4.12 Timed arming the device............................................................................................................... 33
4.12.1 Enable timing arms the device.....................................................................................33
4.12.2 Set time period to arm the device................................................................................34
4.12.3 Disable timing arm the device......................................................................................34
4.13Auto-disarming the device............................................................................................................ 35
4.13.1Activate auto-disarming the device .............................................................................35
4.13.2 Disable the function of auto-disarming V900 device (default).................................35
4.14 Device language setting................................................................................................................ 36
4.15 Check status.................................................................................................................................. 36
4.16 Getting help .................................................................................................................................. 36
4.17 Resetting the device...................................................................................................................... 37
Chapter 5 Advanced settings...................................................................................................................38
5.1 Image settings................................................................................................................................. 38
5.1.1 Image size.........................................................................................................................38
5.1.2 Image quantity..................................................................................................................38
5.1.3 Image brightness..............................................................................................................39
5.1.4 Image direction.................................................................................................................39
5.1.5 Image contrast..................................................................................................................39
5.1.6 Image compressibility......................................................................................................40
5.1.7 Image Interval...................................................................................................................40

V900-B1 GSM REMOTE CAMERA USER MANUAL
5
5.2 Automatic alarm settings ................................................................................................................ 40
5.2.1 Warning tone upon alarm triggering..............................................................................41
5.2.2 No warning tone upon alarm (Default)..........................................................................41
5.2.3 No SMS notification upon alarm....................................................................................41
5.2.4 SMS notification upon alarm (Default)..........................................................................41
5.2.5 No MMS notification upon alarm....................................................................................41
5.2.6 MMS notification upon alarm (Default)..........................................................................42
5.2.7 No call notification upon alarm (Default).......................................................................42
5.2.8 Call notification upon alarm............................................................................................42
5.2.9 No MMS notification to pre-set E-mail address (Default)...........................................42
5.2.10 MMS notification to pre-set E-mail address...............................................................43
5.3 Turn on/off LED indicator on the device........................................................................................ 43
5.4 Turn on/off Infrared lights during arming the device...................................................................... 43
5.5 SMS notification upon the power supply changing........................................................................ 44
Chapter 6 Maintenance.............................................................................................................................44
Chapter 7 General Troubleshooting........................................................................................................45
Chapter 8 Main Technical Parameters....................................................................................................46
Appendix: SMS commands list................................................................................................................46

V900-B1 GSM REMOTE CAMERA USER MANUAL
6
1. Purchase a GSM SIM card (mobile phone card) from GSM network
service and install it in the device. This SIM card number is referred as
V900 device number on this brochure.
2. The user needs to activate the MMS function and Caller ID Presentation
function of SIM card, and deactivate PIN code of the SIM. Contact with
GSM network service for support.
3. Change the original password at the beginning use. Be sure to keep the
password and SIM card number secret. Do not disclose this information
to anyone other than the authorized users in order to ensure your safety.
For your safety
This product is a wireless signal transmission device. Keep it away from
electronic equipment likely to interfere with the wireless signals, in order to
avoid signals interference.
Switch off your V900 and mobile phone when entering areas marked
"Explosive", "Might explode", "Closed wireless transceiver devices" etc.
Do not cast this product in a fire, as this may cause the battery to explode.
This product should only be operated from power approved by the product
manufacturer. The use of any other types of power may damage the product.
Keep the product and its accessories out of the children reach.
EXCEPTION CLAUSE
1. We operate on a policy of continuous development. We reserve the right to
make changes and improvements to any of the products described in this
document without prior notice.
2. For the latest product information, please visit: http://www.vision900.com. We
don’t guarantee for the document veracity, reliability or any content except
regulate in proper laws. Including no guarantee for product suitable market or
suitable area promise.
3. Use only this product according to the law. Respect one another’s privacy.
Neither monitor another’s home nor private. We hold no responsibility for the
illegal use of this product.
4. We hold no responsibility for any loss of data or income; or any special,

V900-B1 GSM REMOTE CAMERA USER MANUAL
7
incidental, consequential or indirect damages howsoever caused.
5. The contents of this document are provided “as is”. Except as required by
applicable law, no warranties of any kind, either expressed or implied, including,
but not limited to the accuracy, reliability or contents of this document. We reserve
the right to revise this document or withdraw it at any time without prior notice.
Chapter 1 FEATURES AND ACCESSORIES
1.1 Main function
This product uses a GSM SIM card. It can send multimedia messaging (MMS)
images to MMS enabled mobile phones with color display or to an E-mail
address.
Remote control: Control and configure the camera with short messages (SMS)
commands from a mobile phone.
Real time audio: call the camera number (SIM card) to listen in live voice.
Motion detection: Detect and notify authorized users of any motion in the
monitoring area(s).
Integrated infrared body detector.
Sensor detection: Allowed to load up to 15 sensors such as door magnet
sensors, infrared body sensors, smoke sensors, gas sensors etc. Any
activated sensor will notify the authorized users via SMS.
Infrared light: The built-in high-light infrared LED’s allows the camera to
capture clear images, even in dark environments or areas with insufficient
lighting.
High quality camera: 300,000 pixel CMOS camera in order to obtain a clear
image via MMS.
Send images to mobile: The camera will send MMS images to your mobile.
Therefore you can check on the monitored areas at any time and anywhere
GSM/GPRS network coverage and MMS service coverage.
Send images to E-mail: The camera can send images to preset available
E-mail address.
Multi-mode alarm: The camera can send alarm messages via SMS, MMS,
E-mail or standard phone call.
Fixed time monitor: The monitoring schedule can be set with multiple time
intervals.
Easy installation: Wireless connection. The camera can be installed at any

V900-B1 GSM REMOTE CAMERA USER MANUAL
8
place required by the authorized user.
Accessories: Includes 2 remote controls each consisting of a panic button as
well as buttons to arm or disarm the device.
Built-in lithium battery: Rechargeable battery ensures operation of V900
device amid external power failures.
Downloadable user manual: This manual can be downloaded at any time via
SMS command.
1.2 Sales package contents
1. Remote camera 1 unit
2. Power adapter(5.5V/2A)1 unit
3. Remote control 2 units
4. User manual 1 unit
1.3 Products features
Figure 1: V900-B1 device Instructions
1.SIM card Slot(rubber cover)7. Power Interface (Mini USB)
2.Camera 8. Line Holder
3.Infrared lights(8 pcs)9. Slot buckle
4.Micphone 10. Hanging hole
5.Indicator 11. Setting key
6.Power switch 12. Base board
13. Infrared body detector
Strong suggest: Keep the lens of the camera clean to insure best imaging quality.

V900-B1 GSM REMOTE CAMERA USER MANUAL
9
1.4 Remote control Instruction
Figure 2: Remote control Instruction
1. Antenna 3. Arm the device button
2. Remote control indicator 4. Disarm the device button
5. Emergency button
Battery: There is battery holder on the rear of the remote control. It needs one 27A/12V battery.
When this battery is running out of power, V900 device will emit “Beep, beep”warning tone and
then send a SMS notification message to Master user.
1.5 Light indicator
Color
Action
Status
Red
Flash slowly
Searching the network.
Flash quickly
Sensor alarm, motion detection alarm, infrared body
detector alarm.
Constant Light
Not installed SIM card, or the remote camera damaged.
Green
Constant Light
Armed status.
Flash slowly
Disarmed status.
Flash quickly
Processing data.
Light 2 seconds
Successfully reset factory setting, or loading sensor.
Orange
Flash
Loading remote control status.
Red and
Green
Two color lights
alternately
Loading sensor
Note: Slow flash 1 time per second, quick flash 2 times per second.

V900-B1 GSM REMOTE CAMERA USER MANUAL
10
Chapter 2 Installation
2.1 Install the SIM card
Remove the rubber cover from the left side of V900 device.
Open the SIM card slot by pressing the small dot beside the SIM card slot with the
tip of a pencil, and pop open the slot.
Insert the SIM card into the slot.
Push the slot back into place.
Put the rubber cover back in its place.
2.2 Extending the device’s base board
Hold the base of V900 device and pull the top part and the bottom part (base)
in opposite directions (i.e. away from each other).
Then the slot buckle will be pulling open.
The head of V900 device can now be moved freely and located at any
direction.
2.3 Connecting to power adapter
Connect the adapter to an AC power, and connect the mini-USB plug to the
power interface of the V900 device .(See Figure 1 V900 device Instruction,7)
This device has a built-in rechargeable Lithium battery.
The camera will notify the user when the power changes. For example, if the
power adapter is disconnected or failure of the AC power occurs, V900 device
will notify the user “External power cut. The device is operating on battery.”
If V900 device is again connected to the external power, or the AC power is
available again, the notification will be sent to the user, i.e.” The device is now
resuming the use of external power source.”
Low battery: The configure setting can not be saved when V900 device is
operating on low battery.
2.4 Mount the V900 device
V900 device can be mounted on a wall (vertically with the screws) or put down on any
suitable horizontal surface.
How to choose the Installing place:
In order to capture better image quality, avoid any areas where bright light will

V900-B1 GSM REMOTE CAMERA USER MANUAL
11
be irradiated directly into the lens of the camera on the device.
In order to avoid backlighting photography, it is suggested that the camera is
located at the place where can look down the monitoring place with the
minimum angel 30°.
The GSM network’s signal strength may affect the image, live voice quality
and MMS transmission speed. Therefore, upon installation, the user should
ensure that V900 device is located in an area with a strong network signal.
After installation, the user should perform a test-run by taking several images
and sending it to the user’s mobile phone. This allows the user to check the
image quality of the device. The position of V900 device can then be adjusted
until a satisfactory image quality level is reached.
2.5 Power on/ off
Power on:
Operation
Indicator light
Status
Turn the power
switch to “On”
position.
Red light is on for 3-5 seconds.
Red light flashing slowly for about
35 seconds.
A “Beep…” tone will be heard.
Green light flash slowly, or
green light be on constantly.
V900 device is disarmed,
or armed.
Power off:
Turn the power switch to downside “Off” position.
Chapter 3 Define the user
3.1 User Authorization Level
There are three levels, each with a different authorization level, namely Master,
Families and Guest.
Table 3.1 the difference in authority for Master, Families and Guests users:
User Type
Functions
Master
Families
Guests
Change authority, password
YES
NO
NO
Automatic
Alarm
Receive SMS
YES
NO
NO
Receive MMS
YES
NO
NO

V900-B1 GSM REMOTE CAMERA USER MANUAL
12
User Type
Functions
Master
Families
Guests
Receive alarm calling
YES
YES
NO
Get images by E-mail
YES
NO
NO
Emergency
alarm
Receive SMS
YES
NO
NO
Receive MMS
YES
NO
NO
Receive emergency calling
YES
YES (Only emergency number)
Call the camera to listen in live voice
YES
YES
NO
Get work status, images, help and
instruction by sending SMS command
YES
YES
YES(Password)
Get images by E-mail
YES
YES
NO
Set remote camera by SMS command
YES
YES
NO
Add, modify or delete sensor
YES
YES
NO
Device language setting
YES
NO
NO
Set infrared body detect function
YES
YES
NO
Note
Any MMS enable mobile phone can receive the images captured by V900
device by sending SMS command with password.
Any SMS enable mobile phone can control V900 device with the password
command.
All the settings of V900 device can be set or adjusted via a SMS command.
About the SMS Command:
1)Master and families users’ SMS command format: #code#content#.
2)Guest users’ SMS command format: #code#password#content#.
3)The password must be a four-digit number.
4)The original password is 1234.
5)The maximum digits that are allows for the phone number is sixteen.
6)V900 device will reply to the user after it receives the SMS command.
Note
The “#”symbol must not be ignored when typing an SMS command.
No allow any space within the commands.

V900-B1 GSM REMOTE CAMERA USER MANUAL
13
3.2 Define Master user to start the device
In order to enable all the functions on the device, the Master user must store his/ her
mobile number in the device’s memory. Only one Master’s mobile number (Master
number) is allowed for a camera.
3.2.1 Add a master number to the device
Authority: Master user.
Description
If V900 device is being used for the first time, or V900 device has been reset, the
master user’s number must be programmed into the device, in order to ensure
activation. The following methods can be used:
Method
Method 1:
The user must call V900 device with his/her mobile phone. V900 device will notify
the user that the number is currently busy and this indicates that the user’s
mobile number has been recognized as Master number.
Method 2:
The user must edit and send the following SMS to device via his/her mobile
phone (the phone number will be the Master number) in order to:
Add a master number to the device: #00# (1)
Successful SMS reply
Welcome to the GSM Remote Camera. Your password is 1234.
Failed SMS reply
If a user tries to activate V900 device again, by using method 1, V900 device will
hung up the call. No notification message (via SMS) will be sent to the user. By
using method 2, V900 device will send a notification via SMS stating “Master
user already exists.”
3.2.2 Change the master number
Authority: Master user
Method
The user sends following SMS message in order to:

V900-B1 GSM REMOTE CAMERA USER MANUAL
14
Change the master user’s number: #14#NewMasterNumber#(2)
Successful SMS reply
New master number is *********.
Then the old master user’s number will not be able to control V900 device
anymore.
3.2.3 Change password
Authority: Master user.
Description
In order to ensure your privacy and safety during the use of this device, change
the password once V900 device is being used.
Method
The user sends following SMS message in order to:
Change the password: #04#oldpassword#newpassword#(3)
The password is a four digit number.
The original password is 1234.
Successful SMS reply
The password has been successfully changed to ****.
Failed SMS reply
If a user, other than the master user, attempts to change the password, a
notification message will be sent via SMS: “Sorry, you are not authorized to use
this command.”
3.3 Define family user
Family users have the authority to listen in on the device, receive images, load the
sensors and remote controls to the device, and receive notification when motion
detection activated. The family user’s mobile numbers are set by the Master user.
The family users should remember and safeguard the device’s SIM number.
3.3.1 Add a family number
Authority: Master user.
Method
The user sends following SMS message in order to:

V900-B1 GSM REMOTE CAMERA USER MANUAL
15
Add a family number: #06#FamilyNumber#(4)
Add several family numbers: #06#FamilyNumber#...#FamilyNumber#(5)
Up to 10 family users’ number can be stored on one device.
Successful SMS reply
The family number has been added successfully.
3.3.2 Check family user’s number
Refer to Chapter 4.15 Check status.
3.3.3 Delete family number
Authority: Master user.
Method
The user sends following SMS message in order to:
Delete a family number: #113#FamilyNumber# (6)
Delete several family numbers simultaneously: (7)
#113#FamilyNumber#…#FamilyNumber#
Delete all family numbers: #113# (8)
Successful SMS reply
Family number deleted successfully.
Failed SMS reply
Failed to delete family number.
3.4 Define Guest user
Any selected person can operate in the Guest category if they know the password
and the SIM number. The Guest user(s) can then use their mobile phones to send a
SMS command including password to V900 device in order to obtain an MMS image.
3.5 Define emergency number
The Emergency Number is the phone numbers which V900 device will dial when the
emergency button of the remote control is pressed. Emergency numbers could be the
telephone numbers of guards, family numbers, police etc.

V900-B1 GSM REMOTE CAMERA USER MANUAL
16
3.5.1 Add emergency number
Authority: Master user.
Description
The master user’s number default to be emergency number.
When the Emergency button is pressed, V900 device will automatically dial the
Master user’s number, followed by the other pre-set emergency numbers (the
default mode is dial phone mode).
Each camera can have up to 9 emergency numbers. (Not including the Master
user’s number).
Method
The user sends following SMS message in order to:
Add single emergency number on the device:(9)
#106#EmergencyNumber#
Add several emergency numbers on the device: (10)
#106#EmergencyNumber#…#EmergencyNumber#
The EmergencyNumber is the phone numbers.
Up to 9 emergency numbers can be stored on one device.
Successful SMS reply
Added emergency number successfully.
Failed SMS reply
If 9 emergency numbers (the maximum amount per device) are used on V900
device and the master user attempts to add another one, the following
notification message will be sent via SMS: “The Emergency numbers are full.
Please delete old numbers.”
If an existing number is being added again, the following notification message
will be sent via SMS: “Emergency number already exist.”
3.5.2 Delete emergency number
Authority: Master user.
Method
The user sends following SMS message in order to:
Delete an emergency number: (11)
#107#EmergencyNumber#

V900-B1 GSM REMOTE CAMERA USER MANUAL
17
Delete several emergency numbers: (12)
#107#EmergencyNumber#…#EmergencyNumber#
Delete all emergency numbers: #107# (13)
Successful SMS reply
Emergency number successfully deleted.
3.5.3 Check emergency number
Refer to Chapter 4.15 Check status.
Chapter 4 Basic use and settings
4.1 Network parameter settings
Authority: Master user.
Note
In general, the user does not need to set the network parameter before use. The
correct parameters have been set by the manufacturers according to every
country’s respective GSM provider. If V900 device is unable to send MMS
messages continually, the user can attempt to do the following settings:
4.1.1 Sending MMS message via WAP
Description
There is a MMS center list on V900 device which including up to 9 GSM
network providers in the country. Contact the dealer of device for detail
operator list.
If there are several GSM network providers in a country, in general, their MMS
parameters have been preset on V900 device MMS center list. The user needs
to choose the correct GSM provider according to the SIM card by using
command 14.
If the SIM card comes from a different GSM provider which is not on the MMS
center list, the user must add the new GSM provider’s MMS parameter onto
the list and then choose it by using command 15, 16 and 17.
Method

V900-B1 GSM REMOTE CAMERA USER MANUAL
18
The user sends following SMS message in order to:
Choose a network operator’s MMS parameter from V900 device MMS list: (14)
#145#name#
The name should be the name of GSM provider, such as Vodafone. For
example: #145#vodafone#
Set sending MMS message via WAP: #148#0# (15)
Set MMS center for WAP: #124#MMScenter#(16)
The MMScenter should be the MMS center address of GSM provider. For
example: #124#http://mmsc.monternet.com#
Set APN parameters for WAP: (17)
#125#GatewayIP#GatewayPort#APN#APNusername#APNpassword#
For example: #125#10.0.0.172#9201#cmwap#wap#wap#
Successful SMS reply
Para:*********************.
4.1.2 Sending MMS message via HTTP
Description
Only one HTTP MMS center can be set onto the device. In general, it has been
preset on the device. Contact the dealer for details. The user needs to set the
correct GSM provider according to the SIM card by using command 18.
If the SIM card comes from a GSM provider which is different with the default
MMS center, the user must add the new GSM provider’s MMS parameter onto
V900 device by using command 19 and 20.
Method
The user sends following SMS message in order to set:
Sending MMS message via HTTP: #148#1# (18)
Add a network provider’s ISP and MMSC onto the list: (19)
#149#0#ISP#MMSC#
ISP should be the GSM network provider’s ISP name. Such as Vodafone or
other characters you like. For example: #149#0#0#http://mms#
MMSC should be the MMS center address. Such as MMS center in Russia:
http://mmsc:8002
Add APN parameters onto the list: (20)
#150#0#GatewayIP#GatewayPort#APN#APNusername#APNpassword#
For example: #150#0#10.0.0.10#80#mms.t-mobile.cz#mms#mms#

V900-B1 GSM REMOTE CAMERA USER MANUAL
19
4.2 To capture images
Authority:
Master/ family / guest send SMS to the camera to get the MMS image or send the
image(s) to an appointed mobile or E-mail address.
Master/ family member call the camera to get the images.
Master/ family send SMS command to the camera to send MMS image to an E-mail
address (Need to pre-set E-mail address).
4.2.1 To capture one image and send to the user mobile
Authority: Master, family and guest users.
Method
Method 1:
Master or family user calls the camera and hand up upon hearing the ringing
tone.
V900 device will reply SMS notification: “Image capturing request received.
The device is busy sending the MMS messages.”
The user will then receive the MMS message momentarily.
The guest users are unable to capture an image by using method 1. If the
guest users call the device, it will neither send a notification message nor an
MMS message.
Method 2:
The user sends following SMS message in order to:
Capture one image and send to the user mobile:
For master and family users:#03# (21)
For guest users:#03#password#(22)
4.2.2 To capture more than one image and send to the
user’s mobile
Authority: Master, family and guest users.
Method
The user sends following SMS message in order to:
Capture more than one image and send to the user mobile:
For master and family users: #03#ImageQuantity#(23)
For guest users:#03#Password#ImageQuantity#(24)

V900-B1 GSM REMOTE CAMERA USER MANUAL
20
Image quantity should be in the range of 1-8 when the image size is set at
160×128 or 320×240 (See 5.5.1 image size.) The default image size is
320×240(QVGA).
Image quantity should be in the range of 1-2 when the image size is set at
640×480.
Successful SMS reply
Your request received, V900 is sending the MMS image.
The user will then receive the MMS message momentarily.
The file format of the sent MMS images is: “Model-Time.jpg”. For example, a
file with name of V900-094843.jpg means the image is captured with a V900
device at 9:48:43AM.
If a sent MMS file has several sequential pictures, the size of the pictures is
pre-set by user (See 5.1.1 image size.). The interval between the pictures is
default 0.5s and can be pre-set by user (See 5.1.8 image Interval).
4.2.3 To capture images and send to user’s E-mail address
Authority: Master and family users.
Description
If the master or family user wishes to send the images to his/her E-mail address,
the E-mail address must be set at first. See chapter 4.3 E-mail settings for more
information regarding this function.
Method
The user sends following SMS message in order to:
Capture image(s) and send to pre-set E-mail: (25)
#03#ImageQuantity#1#
Image quantity should be in the range of 1-8 when the image size is set at
160×128 or 320×240.
Image quantity should be in the range of 1-2 when the image size is set at
640×480.
Successful SMS reply
Your request received, V900 is sending the MMS image.
Table of contents
Other Global Security Camera manuals
