NeoVolta NV14 User manual
NV14EnergyStorageSystem
InstallationManual
TableofContents
SafetyInformation........................................................................................................................................1
1.1 SymbolsUsedinManual...............................................................................................................1
1.2 GeneralSafetyWarnings..............................................................................................................1
1.3 SafetyInstructions........................................................................................................................2
2 ProductDescription..............................................................................................................................3
2.1 ProductOverview.........................................................................................................................3
2.2 SystemArchitecture......................................................................................................................5
3 ToolsandMaterials...............................................................................................................................5
4 Unpacking.............................................................................................................................................6
4.1 PartsList........................................................................................................................................6
4.2 PreparingCabinetforInstallation.................................................................................................6
4.3 PreparingBatteriesforInstallation...............................................................................................6
4.3.1 BatteryUniqueIDSetting.....................................................................................................7
4.3.2 BatterySleepMode..............................................................................................................7
5 InstallationRequirements.....................................................................................................................8
5.1 SiteLocationandPrep..................................................................................................................8
5.1.1 CabinetDimensions..............................................................................................................8
5.1.2 ClearanceRequirements.......................................................................................................9
5.1.3 CriticalLoadBox..................................................................................................................10
5.1.3.1 CriticalLoadBoxCircuits.................................................................................................10
5.1.4 IndoorLocationPreparation...............................................................................................11
5.1.5 OutdoorLocationPreparation............................................................................................11
5.1.6 SecuringtheNV14...............................................................................................................12
6 ElectricalConnections.........................................................................................................................13
6.1 Wiring..........................................................................................................................................13
6.1.1 UtilityGridConnection.......................................................................................................13
6.1.2 PV1,VDCConnection(PV2,VDCConnection,ifpresent)...................................................14
6.1.3 PV,VACConnectionorGeneratorConnection...................................................................14
6.1.4 OutputConnection.............................................................................................................15
6.2 BatteryInstallation......................................................................................................................15
6.2.1 Battery1InstallationInstructions.......................................................................................16
6.2.2 Battery2and3Installation.................................................................................................17
6.3 BatteryWiringConnections........................................................................................................17
7 Operation............................................................................................................................................18
7.1 ApplyingPower...........................................................................................................................18
8 SystemSettings...................................................................................................................................19
8.1 OperationandDisplayPanel.......................................................................................................20
8.2 LCDDisplayIcons........................................................................................................................21
8.2.1 MainScreen........................................................................................................................21
8.2.1.1 FeaturesoftheMainScreen...........................................................................................21
8.2.2 SystemSetupMenu............................................................................................................22
8.2.2.1 BasicSetting....................................................................................................................22
8.2.2.2 BatterySetting................................................................................................................23
8.2.2.3 SystemWorkMode.........................................................................................................23
8.2.2.4 GridSetting.....................................................................................................................24
8.2.2.5 SolarAC...........................................................................................................................25
8.2.2.6 AdvancedFunctions........................................................................................................25
8.2.2.7 DeviceInfo......................................................................................................................25
9 InstallingFrontCovers........................................................................................................................26
10 Specifications..................................................................................................................................27
11 TechnicalReference........................................................................................................................28
12 ContactInformation........................................................................................................................28
13 Appendix.........................................................................................................................................29
13.1 Schematic....................................................................................................................................29
13.2 FaultMessages............................................................................................................................30
NV14EnergyStorageSystem
1
SafetyInformation
1.1 SymbolsUsedinManual
WARNING:Thisindicatesafactorfeatureveryimportantforthesafetyoftheuserto
preventinjuryordeathand/orwhichcancauseserioushardwaredamageifnotapplied
appropriately.
CAUTION:Presentsinformationtopreventdamagetothisproduct
1.2 GeneralSafetyWarnings
WARNING:
Donotattempttoself‐installtheNV14EnergyStorageSystem.Aqualified
solarinstallationprofessionalorelectricianmustinstallandcommissionNeoVoltaenergy
equipment.ContactNeoVoltaforalistofAuthorizedinstallersinyourregion.
SHOCKRISK:
HIGHVOLTAGEELECTRICITY
WARNING:
BeforeinstallingtheNV14EnergyStorageSystem,readallinstructionsand
cautionmarkingsinthisguideandinstallationmanual
.
WARNING:
ElectricalinstallationintheUnitedStatesshallbedoneinaccordancewithall
localelectricalcodesand/ortheNationalElectricalCode(NEC),ANSI/NFPA70.
WARNING
:
ConnectingtheNV14EnergyStorageSystemtotheelectricutilitygridmust
onlybedoneafterreceivingpriorapprovalfromtheutilitycompanyandinstallation
completedonlybyqualifiedpersonnel/licensedelectrician(s).
WARNING
:
ThisequipmentisNOTintendedforusewithlifesupportequipmentorother
medicalequipmentordevices.
WARNING
:
Forcontinuedprotectionagainstriskoffire,replaceanyfusesonlywithsame
typeandrating.
NV14EnergyStorageSystem
2
1.3 SafetyInstructions
Thischaptercontainsimportantsafetyandoperatinginstructions.Readandkeepthismanualforfuture
reference.
CAUTION:
BeforeusingtheNV14EnergyStorageSystem,pleasereadtheinstructions
andwarningsignsofthebatteryandcorrespondingsectionsintheinstructionmanual.
WARNING:
DonotdisassembletheNV14EnergyStorageSystem.Ifyouneed
maintenanceorrepair,contactanauthorizedNeoVoltaservicedealer.Improperreassembly
mayresultinelectricshockorfire.
WARNING:
Toreduceriskofelectricshock,disconnectallwiresbeforeattemptingany
maintenanceorcleaning.Turningofftheunitwillnotreducethisrisk.
CAUTION:
Neverchargeafrozenbattery.
CAUTION
:
StrictlyfollowinstallationprocedurewhenyouwanttodisconnectACorDC
terminals.RefertoInstallationsectionofthismanualforthedetails
WARNING
:
TheNV14EnergyStorageSystemmustbeconnectedtoapermanentgrounded
wiringsystem.
CAUTION
:
Disconnectallsmartbatteriesandsetthemto‘sleepmode’beforeservicingthe
inverterortouchingelectricalterminals.Refertosmartbatterydocumentationforcomplete
safetyinstructions.
CAUTION
:
Beverycarefulwhenworkingwithmetaltoolsonoraroundbatteries.Dropping
atoolmaycauseasparkorshortcircuitinbatteriesorotherelectricalparts.Additionally,
riskofbatteryexplosionispossible.
NV14EnergyStorageSystem
3
2 ProductDescription
2.1 ProductOverview
Thisisamultifunctionalinverter,combiningfunctionsofinverter,solarchargerandbatterychargertooffer
uninterruptiblepowersupportwithportablesize.ItscomprehensiveLCDdisplayoffersuserconfigurableand
easilyaccessiblebuttonoperationsuchasbatterychargingcurrent,AC/solarchargerpriority,andacceptable
inputvoltagebasedondifferentapplications.
Figure1
TB6
TB5
F6&F7
TB4
F4&F5
TB3
CB3
TB2
CB2
TB1
CB1
SW1
F1
F2
F3
BATT1
BATT2
BATT3
INVERTER
SW2
SW3
LCD
DISPLAY
NV14EnergyStorageSystem
4
ComponentLocations(Figure1)
SW1 SystemDisconnectSwitch
CB1 GridInputCircuitBreaker
TB1 GridInputNeutralTerminal
CB2 PVAC,orGeneratorInputCircuitBreaker
TB2 PVAC,orGeneratorInputCircuitBreakerNeutralTerminal
CB3 OutputCircuitBreaker
TB3 OutputNeutralTerminal
F4‐F5 PV1‘+’InputFuses
TB4 PV1‘‐’InputTerminal
F6‐F7 PV2‘+’InputFuses
TB5 PV2‘‐’InputTerminal
BATT1 Battery
BATT2 Battery
BATT3 Battery
F1 BATT1Fuse‘+’
F2 BATT2Fuse‘+’
F3 BATT3Fuse‘+’
TB6 GroundBar
SW2 InverterON/OFFSwitch
SW3 InverterDCBusON/OFFSwitch
NV14EnergyStorageSystem
5
2.2 SystemArchitecture
ThefollowingshowsthebasicarchitectureoftheNV14EnergyStorageSystemwiththevariousdevicesthat
are acceptable interfaces to the system (Figure 2). It is the responsibility of the authorized installer to
determinethespecificdevicesandinterfacerequirementsateachlocation.
Figure2
3 ToolsandMaterials
DigitalVoltmeter
AC/DCClamp‐onCurrentMeter
Drill+3/8”Drill
TapeMeasure
StudFinder
HandCart
ScrewDrivers(Philipsandsmallblade)
Socketwrenchwith9/16”socket
Code‐compliantconduitandwire
Breakerpanelforcriticalloads
5/32”(or4mm)Hexkeytool
NV14EnergyStorageSystem
6
4 Unpacking
4.1 PartsList
TheNV14EnergyStorageSystemisdeliveredin2separatepackages:
Cabinet
Three(3)individualbatteries
InstallationKit
o WallMountingBracket(2)
o 3/8x2”LagBolt(4)
o 3/8FlatWasher(4)
o LevelingFeetAdjustmentTool
o WifiDataLogger
o 10ftWifiExtenderCable
o WhiteScrewCaps(10)
o InstallationManual
o SolarmanWifiInstallationManual
4.2 PreparingCabinetforInstallation
WARNING
:
TheNV14EnergyStorageSystemcabinet,withoutbatteries,weighs250lbs
(114kg).
Movethecabinet,asshipped,asclosetotheinstallationsiteaspossible
Removethefrontcover.Setasideforfutureuse.
Removethelowerfrontcover.Setasideforfutureuse.
Standthecabinetupright.
WARNING
:
Thecabinet,withoutbatteries,istopheavy.Takecarenottotipovercabinet
priortosecuringittoitspermanentlocation.
TheNV14EnergyStorageSystemcabinethasfour(4)conduitlandinglocationsidentifiedby¼”
diameterindentationsintheupperleftsideoftheenclosure.Itistheresponsibilityoftheinstallerto
determinethebestlocationtopunchforconduitknockouts.
4.3 PreparingBatteriesforInstallation
WARNING
:
BATTERIESAREHEAVY.Eachbatteryweighsapproximately105lbs(48kg).Two
(2)personliftingandplacementisstronglyrecommendedtopreventpersonalinjury.
NV14EnergyStorageSystem
7
Eachbatteryisshippedinaseparatepackage.Removebatteryfromitspackagingandsetuprightnear
theinstallationlocation.
4.3.1 BatteryUniqueIDSetting
Thebatteryhasa6positiondip‐switchthatrequiresadjustmentpriortoconnectingtotheNV14Energy
StorageSystem.Thepositionofthefour(4)left‐mostdipswitchpinsdeterminesthebatteryIDwithin
theoverallsystem.EachbatterymusthaveauniqueID.Thefifth(5
th
)pindeterminesthe
communicationspeedsetting.Allbatteriesmusthavethispininthedown,orOFFposition.Theright‐
most,or6thpin,hasnoeffectandisreservedforfutureuse.LeavethisintheOFFposition.
Thesuggesteddipswitchsettingsareasfollows:
Battery1:
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6
ID
ON ON OFF OFF OFF OFF 4
Battery2:
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6
ID
ON OFF ON OFF OFF OFF 6
Battery3:
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6
ID
ON ON ON OFF OFF OFF 8
4.3.2 BatterySleepMode
Eachbatteryisshippedin‘sleepmode’inwhichnovoltageispresentatthebatteryterminals.Whena
batteryisinsleepmode,allindicatorsareunlit.Ifabattery‘wakesup’priortoinstalling,placeitinto
sleepmodebypressingtheresetbuttonfor5seconds.Thebatteryresetbuttoncanbepressedusing
anythin,solidmaterial(suchastheendofapaperclip).
NV14EnergyStorageSystem
8
5 InstallationRequirements
5.1 SiteLocationandPrep
TheNV14EnergyStorageSystemcanbeinstalledindoors,suchasagarage,oroutdoorsmountedusing
aconcreteorpre‐formedpad.ThecabinetisaNEMA3Rratedcabinetsuitableforoutdooruse.
5.1.1 CabinetDimensions
Figure3
NV14EnergyStorageSystem
9
5.1.2 ClearanceRequirements
TheNV14EnergyStorageSystemrequiresclearanceforcoolingandserviceaccess.Thecabinetmustbe
installedwith2”clearanceoneachsideand36”clearancetothefront.Thereisnoverticalclearance
requirementotherthannottousethetopasashelfforstorage(eithertemporaryorpermanent).
NV14
2" 2"
36"
SERVICECLEARANCE
REQUIREMENT
NV14EnergyStorageSystem
10
5.1.3 CriticalLoadBox
Allinstallsmusthaveacriticalloadboxinstalledthatconsistsofthebasicloadsneededincaseofutility
gridfailureorpowerloss.TheNV14willprovidepowertothecriticalloadbox.Allneutralwiresforeach
criticalloadboxbreakermustbeisolatedfromthemainservicepanelandinstalledonthecriticalload
boxneutralbar.ThecriticalloadboxneutralbarmustbewiredtotheNV14OutputLoadNeutral
terminalblock.
WARNING:
ElectricalinstallationintheUnitedStatesshallbedoneinaccordancewithall
localelectricalcodesand/ortheNationalElectricalCode(NEC),ANSI/NFPA70.
WARNING:
Failuretoinstallcriticalloadboxcorrectlycouldresultinpoorpowerquality
(suchasflickeringlights)andpossiblyunsafegroundloops.
5.1.3.1 CriticalLoadBoxCircuits
Itisnotpossibletodetailallpossibleloadsthatmustberemovedfromthemainservicepaneland
installedonthecriticalloadbox.Butsomeofthegeneralguidelinestofolloware:
Alllightingcircuits
All120Vreceptaclecircuits(thisshouldincluderefrigeratoroutlet)
AnyLowPowerorLowUsecircuitsneededunderemergencyconditions
Donotincludenon‐essentialcircuitsthatcoulddrainbatteriesquicklysuchas:
AirConditioner
Washer/Dryer
Pooland/orJacuzzi
WARNING:
Whenmovingbreakerstocriticalloadbox,donotsplitmulti‐wirecircuitsthat
sharethesameneutral.Eithermovebothbreakerswithasharedneutraltothecriticalload
boxordonotmoveeitherone.Nevermoveonebreakerofamulti‐wirecircuitandnotthe
other.Unsafegroundloopscouldoccur.
NV14EnergyStorageSystem
11
5.1.4 IndoorLocationPreparation
TheNV14EnergyStorageSystemmustbeinstalledonarigid,flatlevelsurfacecapableofsupportingthe
fullweightofthecabinet.Ifinstalledinsideagarage,itmaybenecessarytoraisetheNV14abovethe
garageconcretesilltoallowtheNV14tobeplacedflushagainstthegaragewall.Ifaraisedplatformis
used,itmustbealevelandsturdyenoughtosupportthefullweightoftheNV14(575lbs).Theraised
platformmustextendbeyondtheNV14cabinetby3”onbothsidesandfront(Seefigure4).
Figure4
5.1.5 OutdoorLocationPreparation
TheNV14EnergyStorageSystemmaybeinstalledinanoutdoorlocationagainstawall–preferably
underaneave.TheNV14EnergyStorageSystemmustnotbeinstalledonasouth‐facingwalltoprevent
possibleoverheatingandashortenedbatterylife.
TheNV14EnergyStorageSystemmustbeinstalledonarigid,flatlevelsurfacecapableofsupportingthe
fullweightofthecabinet.Aconcretesurfaceorpre‐castconcretepadishighlyrecommended.Ifusinga
pre‐castpad,thepadmustbeaminimumof4”thickandoverhangthecabinetby3”onbothsidesand
front.
NV14EnergyStorageSystem
12
5.1.6 SecuringtheNV14
TheNV14EnergyStorageSystemmustbeinstalledusingthewallmountingbracketsandhardware
provided.Thewallmountingbracketsmustbeanchoredtoaminimumoftwo(2)verticalwallstuds
(Seefigure5).3/8”x2½”lagboltswithwashersmustbeusedtomountthewallmountingbracketto
theverticalstuds.
PositiontheWallMountingBracketsothatthetopoftheupperlipisapproximately½”‐¾”higherthan
thecabinetmountingbracketlowerlip(Seefigure4).Thecabinetisequippedwithlevelingfeetfor
minorheightadjustmentsasneeded.Alevelingfootadjustmenttoolisprovided.
Whenanadequateinstallationsitehasbeenprepared,positiontheNV14EnergyStorageSystem
cabinetinplaceagainstthewall.Liftthecabinetupafewinchestoclearthewallmountingbracket.
Lowerthecabinetsothatthecabinetmountingbracketmateswiththewallmountingbracket.Adjust
thelevelingfeetasneededtoensurethatallfour(4)levelingfeetaretouchingthefloororconcrete
slab.
CAUTION:
Allfourlevelingfeetmustbefirmlyonthesurface.Donot‘hang’thecabinet
solelyfromthewallmountingbracket.
Figure5
NV14EnergyStorageSystem
13
6 ElectricalConnections
6.1 Wiring
WARNING
:
VerifyallsourcepowerisOFFordisconnectedpriortowiringtheNV14Energy
StorageSystem
CAUTION:
Thefollowingwiringinformationcontainsgeneralwiringconnectionswithin
theNV14EnergyStorageSystem.Theseinstructionsarenotintendedtodescribeallpossible
residentialconfigurations.ItistheresponsibilityoftheNeoVoltaauthorizedinstallerto
determinethewiringrequirements,codes,andsafetystandardsatthespecificsite.
TheNV14EnergyStorageSystemhasthree(3)possibleinputlocationsandone(1)outputlocation.
Allowedinputsourcesare:
UtilityGrid:120/240VACsplitsinglephasewithneutral
DCPV:Amaximumoffour(4)DCPVinputswitheachinputprotectedwith15Afuses
ACPVorGenerator:240VACinput.EitherACPVsourceorGeneratorSourceispermittedbut
notboth.
Outputis120/240VACsplitphasewithneutral(sameasutilitygrid)
WARNING
:
VerifythedisconnectswitchandallcircuitbreakersintheNV14Energy
StorageSystemareintheOFFpositionpriortomakingwiringconnections.
6.1.1 UtilityGridConnection
Usecopperwireonly.Theminimumwiresizethatcanbeusedis8AWG.Themaximumwiresizethat
willfitintheterminalsis6AWG.Connectthe120/240VwiresfromtheutilitytothetopofCB1.Torque
to25in‐lb.(2,8Nm).Connect120/240VneutralwirefromtheutilitygridtothetopofTB1.Torqueto25
in‐lb.(2,8Nm).RefertoFigure6belowforlocationofCB1andTB1wiringlocations.
Figure6
UTILITYGRID
INPUT
NV14EnergyStorageSystem
14
6.1.2 PV1,VDCConnection(PV2,VDCConnection,ifpresent)
Usecopperwireonly.Theminimumwiresizethatcanbeusedis10AWG.Themaximumwiresizethat
willfitintheterminalsis6AWG.ConnectthePV1‘+’wiresfromtheVDCPVsourcetothetopoffuseF1
orF2.Torqueto25in‐lb.(2,8Nm).ConnectthePV1‘‐‘wirefromtheVDCPVsourcetothetopofTB4.
Torqueto25in‐lb.(2,8Nm).RefertoFigure7belowforlocationofPVfusesandterminalwiring
locations.
Figure7
6.1.3 PV,VACConnectionorGeneratorConnection
Usecopperwireonly.Theminimumwiresizethatcanbeusedis8AWG.Themaximumwiresizethat
willfitintheterminalsis6AWG.Connectthe120/240VwiresfromtheVACPVsourcetothetopofCB2.
Torqueto25in‐lb.(2,8Nm).Connect120/240VneutralwirefromtheVACPVsource(ifpresent)tothe
topofTB2.Torqueto25in‐lb.(2,8Nm).RefertoFigure8belowforlocationofCB2andTB2wiring
locations.
Note:AnexternalgeneratorcanbeinstalledatCB2andTB2ifdesired.Whengeneratorsourceis
installed,VACPVsourceisnotallowed.
Figure8
PV2,DC
PV1,DC
PV,VAC
NV14EnergyStorageSystem
15
6.1.4 OutputConnection
Usecopperwireonly.Theminimumwiresizethatcanbeusedis8AWG.Themaximumwiresizethat
willfitintheterminalsis6AWG.ConnecttheoutputwiresatthetopofCB3.Torqueto25in‐lb.
(2,8Nm).ConnecttheoutputneutralwireatthetopofTB3.Torqueto25in‐lb.(2,8Nm).RefertoFigure
9belowforlocationofCB3andTB3wiringlocations.
Figure9
6.2 BatteryInstallation
Therearethree(3)batteriesthataresuppliedwiththeNV14EnergyStorageSystem.Theyaresupplied
separatelyandneedtobephysicallyinstalledandwired.Thebatteriesareshippedin‘sleepmode’.
Batteriesinsleepmodedonothaveanylivevoltageontheterminals.Whenabatteryisinsleepmode,
allindicatorsareunlit.Ifabattery‘wakesup’priortoinstalling,placeitintosleepmodebypressingthe
resetbuttonfor5seconds.Thebatteryresetbuttoncanbepressedusinganythin,solidmaterial(such
astheendofapaperclip).
WARNING
:
BATTERIESAREHEAVY.Eachbatteryweighsapproximately105lbs.(48kg).
Two(2)personliftingandplacementisstronglyrecommendedtopreventpersonalinjury.
TheNV14EnergyStorageSystemissuppliedwithbatterybracketstokeepbatteriessecurelyinplace
afterinstallation.Thebracketsareinstalledandmustberemovedpriortoplacingbatteriesandre‐
installedafterbatteryplacement.
OUTPUT
NV14EnergyStorageSystem
16
WARNING
:
Toprotectagainstcabinetdamage,donotoperatetheNV14EnergyStorage
Systemwithoutbatterybracketsproperlyinstalled.
6.2.1 Battery1InstallationInstructions
Removeupperbatteryholddownbracket(seefigure10)
Liftbatteryupontobatteryshelf
Pushbatteryflushagainstthebackofthecabinetandslidebatterytotheleftuntilbatteryis
behindleftsideenclosurelip.Becarefulnotto‘pinch’batterywiresbetweenbatteryand
cabinet.Itissuggestedtoplacethebatterywiresacrossthetopofthebatterywiththe
terminalsoutsidethecabinet.
Replaceupperbatteryholddownbracket
Note:Donotconnectterminalwiringatthistime.Notethewireterminallughasaprotectivecover.Do
notremoveuntilreadytowirethebatteriesatalaterstepintheinstallationprocess.
Figure10
UPPERBATTERY
HOLDDOWNBRACKET
NV14EnergyStorageSystem
17
6.2.2 Battery2and3Installation
Removelowerbatteryholddownbracket(seefigure11)
Lifteachbatteryupontocabinetbase.Therearebatteryglidestoeaseslidingbatteryintoplace.
Pushbatteryflushagainstthebackofthecabinetandslidebatterytotherespectivesideuntil
batteryisbehindsideenclosurelip.Becarefulnotto‘pinch’batterywiresbetweenbatteryand
cabinet.Itissuggestedtoplacethebatterywiresacrossthetopofthebatterywiththe
terminalsoutsidethecabinet
Donotreplacelowerbatteryholddownbracketatthistime.Setbracketandhardwareaside
andinstallafterbatterywiringstepsarecompleted.
Note:Donotconnectterminalwiringatthistime.Notethewireterminallughasaprotectivecover.Do
notremoveuntilreadytowirethebatteriesatthenextstepintheinstallationprocess.
Figure11
6.3 BatteryWiringConnections
Removebatteryterminalcoverandsetaside.
Connecttheblackbatterywiretoeachbatterynegativeterminalusingtheterminalhardware
providedwitheachbattery.Eachbatteryhastwo(2)terminalsmarkedas‘‐‘.Eitherterminalis
acceptabletoinstalltheblackbatterywire.Torquethebatteryterminalto160in‐lbs.(18Nm).
Connecttheredbatterywiretoeachbatterypositiveterminalusingtheterminalhardware
providedwitheachbattery.Eachbatteryhastwo(2)terminalsmarkedas‘+‘.Eitherterminalis
acceptabletoinstalltheredbatterywire.Torquethebatteryterminalto160in‐lbs.(18Nm).
ConnecttheCAT5ethernetcabletothebatteryRS485port.Therearetwo(2)RS485ports.The
upperbatteryhasone(1)CAT5cabletoinstall.EitherRS485portonthebatteryisacceptable.
Thelowerbatterieshavetwo(2)CAT5cablestoinstallineachoftheRS485ports.
Replacebatteryterminalcovers.
Note:Toinstallwiringonlowerbatteries,itisnecessarytoslidethebatteriesoutfromthecabinet
approximately3”–enoughtoexposethebatteryterminals.Donotslidebatteryallthewayoutof
thecabinetasthebatterywiringwillnotbelongenough.
Pushthelowerbatteriesbackintothecabinetflushagainstthebackofthecabinetandslide
batteryisbehindenclosurelip.Becarefulnotto‘pinch’battery.
Installthelowerbatteryholddownbracketpreviouslyremoved.
LOWERBATTERY
HOLDDOWNBRACKET
Other manuals for NV14
1
Table of contents
