NETGEAR D6200B User manual

NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
January 2013
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label
of your product and use it to register your product at
https://my.netgear.com.
You must register your product before you can use NETGEAR
telephone support. NETGEAR recommends registering your
product through the NETGEAR web site.
Phone (US only): 1-888-NETGEAR
Phone (Other Countries):
See http://support.netgear.com/general/contact/default.aspx.
NETGEAR recommends that you use only the official NETGEAR
support resources.
D6200B WiFi Modem Router
Installation Guide
Package Contents
The box should contain the following items. If any items are
incorrect, missing, or damaged, contact your NETGEAR dealer.
Ethernet cable
Power adapter
D6200B Modem
DSL cable
Router
GM plug to US jack adapter
The filter or splitter
provided depends
on the region.

1. ADSL Internet 2. Computer
3. Power
4. Open browser
You can use this diagram to connect your modem router to ADSL or cable/fiber modem, or you can follow the
or cable/fiber
modem*
instructions in this booklet.
After power on, wait for
the WiFi LED to turn blue.
If the web page does not display,
close and reopen the browser to
http://routerlogin.net in the address
bar. Enter the user name admin
and the password password.
*Note: Connect to the telephone line for ADSL Internet or to the cable/fiber modem from the Gigabit Ethernet WAN port.
User Manual
You can get the user manual online at
http://downloadcenter.netgear.com or through a link in the product’s user
interface.
Compliance
For the complete EU Declaration of Conformity, visit
http://support.netgear.com/app/answers/detail/a_id/11621/.
NETGEAR, the NETGEAR logo, and Connect with Innovation are
trademarks and/or registered trademarks of NETGEAR, Inc. and/or its
subsidiaries in the United States and/or other countries. Information is
subject to change without notice. © NETGEAR, Inc. All rights reserved.
Intended for indoor use only in all EU member states, EFTA states, and
Switzerland.

Contents
Before You Begin (DSL Connection). . . . . . . . . . . . . . . . . . . . . 2
Install Your Modem Router . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 3
1. Connect the router to your Internet service. . . . . . . . . . . 3
2. Power on your router.. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Connect a computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. Open a web browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preset Wireless Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Wireless Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . 7
Join the Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
WPS Method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Manual Method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Access the Router to Make Changes . . . . . . . . . . . . . . . . . . . . . 9
NETGEAR genie App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
NETGEAR genie Mobile App . . . . . . . . . . . . . . . . . . . . . . 11
ReadySHARE Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ReadySHARE Printer . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . 13
Control Center Configuration . . . . . . . . . . . . . . . . . . . . . . 15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2
Before You Begin (DSL Connection)
If you are connecting to a DSL line, make sure that your DSL service
is active before you install the modem router. You need the
information listed here to install your DSL modem and connect to the
Internet. Locate it and have it on hand before you start the installation
procedure.
•DSL user name and password. These are included in the
welcome letter your DSL Internet service provider (ISP) sent you
when you signed up for your service. Record your DSL Internet
service account user name and password here:
User name:
Password:
•Your telephone number or DSL account number. If you do not
have voice service, you can use your DSL account number in
place of a phone number.
If you do not know or cannot locate your user name and
password, call your DSL Internet service provider.
Be specific when speaking with your DSL Internet service
provider. For example, you could say:
I need my DSL service user name and password. Can you help
me?
Note: If your provider says that they do not support NETGEAR
devices, tell them you need only your DSL user name and
password; you do not need support.

3
Install Your Modem Router
Note: Keep your modem router in a vertical position.
1. Connect the router to your Internet service.
You can connect either directly to a DSL line or to a fiber/cable
modem.
To connect to a DSL line:
a. Install an ADSL microfilter between the phone line and the
phone.
b. Connect the ADSL port of the modem router to the ADSL
port of the microfilter
c. Use an ADSL microfilter for every phone line in the house if
your modem router and telephone connect to the same
phone line.
Plugs into the ADSL line

4
To connect to a cable/fiber modem:
Connect one end of the yellow Ethernet cable to the WAN port on
the router, and connect the other end to your cable/fiber modem.
2. Power on your router.
a. Connect the power adapter to the router, and plug the power
adapter into an outlet.
b. Wait until the WiFi LED turns solid blue.

5
3. Connect a computer.
You can use an Ethernet cable or connect wirelessly.
• Use an Ethernet cable (not provided) to connect your
computer to an Ethernet port on your router.
• Connect wirelessly by using the preset wireless security
settings on the label on the bottom of the router.
4. Open a web browser.
The NETGEAR genie installation wizard displays.
D6200

6
If you do not see the genie screen, close and reopen the browser,
and enter http://routerlogin.net in the address bar. See
Troubleshooting on page 16.
5. Click Next to allow the genie to help you. Follow the steps to set up
your Internet connection.
Note for DSL: If your DSL Internet service requires a user name
or password, you are prompted to enter this information. If you do
not have this information, contact your Internet service provider
(see Before You Begin (DSL Connection) on page 2).
Preset Wireless Security
This product has a unique WiFi network name (SSID) and network
key (password). The default SSID and password are uniquely
generated for every device, like a serial number, to protect and
maximize your wireless security. This information is on the label on
the bottom of the product.
The WiFi network name (SSID) and password are here.
NETGEAR recommends that you do not change the preset SSID and
password. If you do change the settings, the security SSID or
password on the bottom of the product no longer apply.

7
Note: Your network name (SSID) and password are case-sensitive.
Your network name, security method, and password need to be the
same for all the wireless devices that are connected to your router on
a network.
Wireless Network Settings
Record the default preset wireless settings that are printed on the
label in the spaces here for easy reference.
2.4 GHz WiFi network name (SSID):
2.4 GHz network key (password):
5 GHz WiFi network name (SSID):
5 GHz network key (password):
If you change the default settings, record them here for easy
reference, and then store this booklet in a safe place:
2.4 GHz WiFi network name (SSID):
2.4 GHz network key (password):
5 GHz WiFi network name (SSID):
5 GHz network key (Password):
To retrieve or update your wireless password, type
http://www.routerlogin.net in a web browser and log in using the
default user name (admin) and password (password).
Select Basic > Wireless Settings to locate your wireless passwords.

8
Join the Wireless Network
You can use either the Wi-Fi Protected Setup (WPS) method or the
manual method to join your wireless network.
WPS Method
WPS lets you join your WiFi network without typing the password.
If your wireless device supports WPS, the first time you join the
network, you might be prompted to press the WPS button on the
modem router.
1. Press the WPSbutton on the modem router.
2. Within 2 minutes, press the WPSbutton on the computer or
wireless device that is trying to join the network. Follow the WPS
instructions that came with your computer or wireless device to join
the network.
Note: Some older wireless computers or devices cannot use WPS.
Manual Method
1. On your computer or wireless device, open the software that
manages its wireless connections. This software scans for
wireless networks in your area.
2. Look for the WiFi network name (SSID) on the list and select it. The
SSID is on the label on the bottom of the modem router.
Note: If you changed the name of your network during the setup
process, look for that network name.
3. Enter the preset password (or your custom password if you
changed it), and click Connect.

9
Access the Router to Make Changes
After you use genie to set up the modem router, you can log in to the
modem router to view or change its settings.
To log in to the modem router:
1. Launch a web browser from a computer or wireless device that
is connected to the modem router.
2. Type www.routerlogin.net or www.routerlogin.com in the
address field of the browser. A login screen displays:
3. Enter admin for the user name and password for the password.
The genie Home screen displays:
D6200
See the user manual for information about the modem router
screens and features.

10
NETGEAR genie App
The genie app is your home network dashboard. It lets you easily
view, manage, and control your entire home network, and helps you
fix common network problems. You can use the genie app or the
genie mobile app.
Internet
STATUS GOOD
Network Map
Number of devices 16
Parental Controls
WiFi Connection
STATUS Connected
Router Settings
Click here
ReadySHARE
Click here
Click here
genie app
Visit the NETGEAR genie web page at www.netgear.com/genie.
From the genie app, you can view and configure settings for the
following:
• Internet. Monitor and repair Internet connectivity issues for both
wired and wireless connections.
• WiFi Connection. View or change your router wireless settings.
• Router Settings. Log in to your router to view or change its
settings.
• Network map. View network devices connected to your network.
• Parental Controls. Manage parental controls to protect devices
in your network from inappropriate content.
• ReadySHARE. If you connected a USB storage device or printer
to the USB port on the router, then you can access its contents.
• Support. Support FAQs are available on your computer without
an Internet connection. You can get answers to common router

11
issues here. Some simple network tools are available to help you
debug the network as well.
NETGEAR genie Mobile App
To install the genie mobile app:
1. Use your mobile device to navigate to the Apple AppStore or
Google Play for Android and search for NETGEAR genie. You
can use the following QR codes to speed up this process:
Android appiPad app iPhone app
2. Install the app on your iPad or phone.

12
3. Launch the app to display the dashboard screen.
To use this app, you need a
WiFi connection from your
phone or iPad to your NETGEAR
home network.
• Manage WiFi settings and guest
access for your home network.
• View a map of your network.
• Set up or manage parental
controls.
• Use the traffic meter to check
your Internet usage.
• With My Media, play media on
devices on your network.
ReadySHARE Access
After installation, you can insert a USB storage device into the USB
port on the modem routerand share the contents with others on the
network. (If your USB device has special drivers, it is not compatible.)
USB port
on the rear

13
If your USB device needs a power supply, you have to use it when
you connect the USB device to the USB port. It might take up to 2
minutes before the USB drive is ready for sharing after you connect it.
To access your USB device:
On Windows systems, use any of these methods:
•Select Start > Run and enter \\readyshare in the dialog box.
Click OK.
•Open Explorer or Safari and enter \\readyshare in the address
bar.
•Open My Network Places, and enter \\readyshare in the address
bar.
On Mac systems, do this:
1. Select Go > Connect to Server.
2. Enter smb://readyshare as the server address.
3. Click Connect.
The readyshareconnect.exe file (for Windows) is available to
download here: www.netgear.com/readyshare
ReadySHARE Printer
The USB Control Center utility allows you to control a shared USB
device from the computer that is connected to the USB port on your
router. The utility allows you to control a printer.
Install the utility on each computer on your network from which you
want to control the device. You can download this utility at
www.netgear.com/readyshare.

14
When you launch the USB Control Center utility, a screen similar to
the following displays:
The main screen shows a device icon, the description for this USB
device, and its status.
Available. The device is available from the computer that you are
using.
Waiting to Connect. You need to connect to this device from the
computer that you are using. The first time you connect, you might be
prompted to install the device driver.
The following menu selections are available:
•System. Exit the utility.
•Tools. Access the Control Center - Configuration screen to set up
your shared USB device. See the following section, Control
Center Configuration.
•About. View details about the USB Control Center software.

15
Control Center Configuration
Select Tools > Configuration to display the following screen:
Automatically execute when logging on Windows. Select this
check box to have the utility start automatically when you are logged
in to Windows.
Timeout. Specify the time-out value for holding the USB resource
when it is not in use.
Language. Select the display language for this utility.

16
Troubleshooting
If the browser does not display the web page:
•Make sure that the computer is connected to one of the four LAN
Ethernet ports, or wirelessly to the router.
•Make sure that the modem router has power and that the WiFi
LED is lit.
•Close and reopen the browser so the browser does not cache the
previous page.
•Browse to http://routerlogin.net.
•If the computer is set to a static or fixed IP address (this is
uncommon), change it to obtain an IP address automatically from
the modem router.
If the modem router does not power on:
1. Make sure that the On/Off button on the back of the modem
router is in the on position.
2. Check your cables.
•Disconnect and reconnect each cable. There is usually an
audible click when the cable is correctly connected.
•For ADSL connections, see if the telephone cable connecting
your modem router to the wall jack is plugged into a filter. If
you do not have telephone voice service, a filter is not
required. A filter that is installed where it is not needed might
eliminate your ADSL signal.
3. Power down your modem router, and then power it up again.
a. Turn off the modem router.
b. Unplug the power adapter cord and all other cables from the
back of the modem router.
c. Wait 30 seconds, then reconnect the cables and power
adapter cord to your modem router, and turn it on.

17
d. Make sure that the Power LED is lit. If the LED is off, try
plugging the power adapter cord into another power outlet.
e. Wait for the WiFi LED to turn blue.
4. Open a web browser and try to access the Internet.
If steps 1–4 do not resolve the problem:
5. Reset your modem router.
To reset your modem router, use a pin or paper clip to press in
and hold the Reset button.

18
Trademarks
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks
and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the
United States and/or other countries. Information is subject to change without
notice. Other brand and product names are registered trademarks or
trademarks of their respective holders. © NETGEAR, Inc. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in any form or by
any means without the written permission of NETGEAR, Inc.
Statement of Conditions
In the interest of improving internal design, operational function, and/or
reliability, NETGEAR reserves the right to make changes to the products
described in this document without notice. NETGEAR does not assume any
liability that may occur due to the use or application of the product(s) or circuit
layout(s) described herein.
