NetterVibration NTK Series User manual

Operating instructions for
Netter pneumatic linear vibrators
Series NTK
Feb. 2021
No. 1977E
Page 1/24
These operating instructions apply to:
NTK 8 AL
NTK 15 X
NTK 16
NTK 18 AL
NTK 18 AL M1
NTK 25 AL
NTK 25
NTK 28 AL
NTK 40 AL
NTK 40
NTK 55 AL
NTK 55
NTK 85
NTK 110

2
Contents
1General information 3
2Safety 5
3Technical data 7
4Design and function 13
5Transport and storage 14
6Installation 15
7Start-up and operation 19
8Maintenance and servicing 21
9Troubleshooting 22
10 Spare parts and accessories 23
11 Disposal 24
Please refer to the delivery note for the scope of delivery.
Check the packaging for possible transport damage. In the event of
damage to the packaging, check the contents for completeness and
possible damage. Inform the carrier in the case of damage.
The pneumatic linear vibrators of the series NTK are hereafter referred
to as "NTK".
Document no.
1977E
Version no.
1
Date of issue
Feb. 2021
Scope of
delivery
Designation
Version of
document

General information
3
1 General information
Before installing the NTK read these instructions carefully. It is the basis
for any action when dealing with the NTK, and may be used for training
purposes. The instructions should be subsequently stored at the operation
site.
The target group for these instructions is technical staff, who have basic
knowledge in pneumatics and mechanics.
Only complying technical staff may work on the NTK.
The NTK may only be installed, put into operation, maintained, troubleshot
and disassembled by persons authorised by the operator.
This documentation is protected by copyright.
Netter Vibration reserves all rights such as translations, reprinting and re-
production of the instructions, as well as parts thereof.
All technical information, data and instructions for installation, operation
and maintenance in these instructions are based on the latest information
available at the time of printing and take our past experience to the best of
our knowledge into account.
No claims can be derived from the information, illustrations and descrip-
tions in these operating instructions.
The manufacturer does not assume liability for damages resulting from:
•failure to observe the instructions,
•improper use,
•unauthorised repairs,
•technical modifications,
•use of non-permissible spare parts.
Translations are made to the best of our knowledge.
Netter Vibration does not assume liability for translation errors, even if the
translation was made by us or on our behalf. Only the original German text
remains binding.
Explanation of additions to names in model designations:
•NTK AL: models with aluminium housing
•NTK S: models with stainless steel housing
•NTK X: models with plastic housing
•NTK HT: models for high ambient temperatures
•NTK NT: models for low ambient temperatures
•NTK L: models for oil-free operation
Use and
storage
Target group
Copyright
Limitation of
liability
Model
designations

General information
4
•NTK NF: low frequency models
•NTK HF: high frequency models
The pneumatic linear vibrators of the series NTK comply with the EC Ma-
chinery Directive 2006/42/EC.
In particular, the standard EN ISO 12100 has been observed.
The following instruction and warning symbols are used in these instruc-
tions:
DANGER
indicates an immediate danger.
Disregard of this notice will result in death or severe person-
al injuries.
WARNING
indicates a potential danger.
Disregard of this notice can result in death or severe per-
sonal injuries.
CAUTION
indicates a potentially dangerous situation.
Disregard of this notice can result in minor or moderate per-
sonal injuries.
NOTICE
indicates potential material damage.
Disregard of this notice can result in material damage.
IMPORTANT
indicates actions, methods or notes that are not relative to safety, e.g. use-
ful information and tips.
Environmentally safe disposal
indicates the obligation of environmentally safe disposal.
Directives /
standards
observed
Instruction
and warning
symbols
Personal
injuries
Material
damages
Notes

Safety
5
2 Safety The NTK are intended for generating linear vibrations.
General applications are: loosening, conveying, sorting, compacting, sepa-
rating bulk materials and reducing friction. NTK are used for emptying
bunkers, as drives for conveyor troughs, sieves and vibrating tables.
The NTK are designed for installation in machines and may only be put
into operation, if it has been assured that the complete machine complies
with the regulations of the machinery directive.
The NTK may also be used outdoors and in dusty and humid environ-
ments. The NTK may not be submerged in bulk materials or in liquids.
Any other use is considered improper.
Installation, commissioning, maintenance and troubleshooting of the NTK
may only be performed by authorised qualified personnel.
All handling of the NTK is the responsibility of the operator.
WARNING
Falling parts
The NTK, construction parts as well as fastening screws can
come loose due to vibration. Falling parts lead to severe
personal injuries.
➢For mounting the NTK use only suitable fastening
screws.
➢Use only self-locking washers, self-locking nuts or suita-
ble screw safety agent to secure the NTK.
➢Check the fastening screws after one hour of operation
and thereafter at regular intervals (generally monthly).
➢If necessary, tighten the fastening screws with a torque
wrench.
➢Appropriate safety measures are compulsory for critical
installation situations.
Intended use
Qualification
of qualified
personnel
Falling parts

Safety
6
WARNING
Compressed air
A loosened hose which is under pressure can lead to personal injuries.
➢Screw the hose lines on carefully.
➢Check the hose lines and connections after one hour of operation and
thereafter regularly (generally monthly).
➢Retighten the hose lines, if necessary.
➢Ensure that the compressed air is disconnected from the supply lines
during all work on the NTK.
➢Prevent the NTK from being switched back on during all work.
WARNING
Moving parts
NTK have moving parts which can cause injury.
➢The direct contact of a vibrating part must be prevented on site by con-
structive measures, eg. by a screen.
NOTICE
Operation of the NTK with silencers is mandatory.
Silencers reduce the noise level and protect the NTK from contamination
entering.
NOTICE
NTK may not be operated in a dusty environment without dust protection.
Compressed
air
Moving parts
Silencer
Dust
protection

Technical data
7
3 Technical data
Drive medium
NTK must be operated with clean, lubricated compressed air or lubri-
cated nitrogen according to the following specification (according to
ISO 8573-1):
[ 5 :
6 :
4 ]
Filter ≤ 5 µm
Humidity, pressure
dew point ≤ +10 °C
Total oil content
≤ 5 mg/m3
NTK L-versions are suitable for operation with oil-free compressed air
according to the following specification (according to ISO 8573-1):
[ 5 :
6 :
2 ]
Lubrication
ISO viscosity class according to DIN ISO 3448, VG 5 to 15
Fill the mist lubricator with acid- and resin-free compressed air oil.
The use of a mist lubricator is mandatory:
•for the models NTK16, NTK 25, NTK 40, NTK 55, NTK 85,
NTK 110,
•when using additional oscillating weights,
•if NTK is used as an impactor,
•when using dried compressed air,
•in aggressive ambient conditions.
A mist lubricator is recommended by Netter Vibration for all NTK vibra-
tors (except NTK L).
Recommendation for tempera-
tures from 0 °C to 60 °C:
Klüber "AIRPRESS 15"
Specification for temperatures
0 °C to -20 °C:
Klüber "ISOFLEX PDP 10"
Specification for temperatures
below -20 °C with NT versions:
BREAK FREE®CLP
Specification for temperatures
above 60 °C with HT versions:
Aral „Farolin“
Ambient
temperatur*
NTK with AL-housing (black)
5 °C to 60 °C
NTK 15 X with plastic housing
5 °C to 100 °C
NTK with steel or stainless steel
housing
-10 °C to 150 °C
NT versions
to -32 °C
HT versions
up to 200 °C
Operating
pressure*
2,0 to 6,0 bar
Ambient
conditions
When operated oil-free or in dusty environment, NTK vibrators must
not be used without bellows or other dust protection.
* Higher operating pressures and temperatures are only permitted after consultation with
and the written consent of application engineers from Netter Vibration.
Permissible
operating
conditions

Technical data
8
The following table distinguishes between three versions:
S1
The piston swings freely.
The housing is screwed to
the mass to be vibrated.
1
Housing
2
Piston
3
Additional oscillating weight
S2
The piston with an additional
oscillating weight swings
freely.
The housing is screwed to
the mass to be vibrated.
S3
The housing swings freely.
The piston is screwed to the
mass to be vibrated.
For types of NTK, where the weight of the piston and the housing are only
slightly different, S1 and S2 are indicated, otherwise S1 and S3. The name
of the additional oscillating weight used is given in brackets (K+SM 8-2
stands for "piston plus additional oscillating weight SM 8-2").
Freely swing-
ing part

Technical data
9
Type
NTK /
Freely oscillating part
Oscillating
weight*
[kg]
Air
consumption
[l/min]
Frequency
[min-1]
Centrifugal
force
[N]
Unbalance
[cmkg]
2 bar
6 bar
2 bar
6 bar
2 bar
6 bar
2 bar
6 bar
8 AL
S1
0.030
7
32
2,440
3,657
15
44
0.05
0.06
(K+SM 8-2)
S2
0.088
6
25
1,380
2,080
15
50
0.15
0.37
15 X
S1
0.135
17
72
1,745
2,544
49
104
0.29
0.33
(K+SM 16-2)
S2
0.675
14
54
758
1,152
53
123
1.69
1.95
16
S1
0.150
14
58
1,680
2,400
42
106
0.27
0.34
16
S3
1.330
8
39
600
923
96
210
4.90
4.50
18 AL , 18 AL M1
S1
0.210
19
68
1,600
2,350
41
109
0.29
0.36
(K+SM 16-1)
S2
0.530
13
58
972
1,572
61
191
1.18
1.41
25 AL
S1
0.420
34
149
1,289
1,986
107
269
1.18
1.24
(K+SM 25-3)
S2
1.655
22
115
686
1,080
177
419
6.88
6.55
25
S1
0.470
38
156
1,440
2,270
127
374
1.12
1.32
25
S3
2.600
24
102
690
1,067
237
612
9.10
9.82
28 AL
S1
0.590
38
135
1,488
1,818
255
381
2.10
2.10
(K+SM 16-2)
S2
1.130
30
136
1,110
1,488
240
423
3.55
3.48
40 AL
S1
1.240
54
220
1,231
2,094
239
519
2.88
2.16
(K+SM 25-3)
S2
2.475
36
210
900
1,389
298
787
6.72
7.44
40
S1
1.270
49
228
1,200
1,930
282
503
3.57
2.46
40
S3
4.200
34
161
600
1,108
385
1,100
19.48
16.36
55 AL
S1
2.100
98
398
1,500
2,400
447
839
3.62
2.66
(K+SM 85-1)
S2
3.430
83
384
1,113
1,768
492
1,077
7.25
6.28
55 NF
S1
2.100
101
408
1,405
2,351
441
872
4.08
2.88
55 NF
S3
5.900
64
330
884
1,467
617
1,588
14.40
13.47
85 NF
S1
5.200
166
545
1,892
2,830
767
2,215
3.91
5.04
85 NF
S3
12.100
148
532
1,200
1,838
1,073
2,428
13.59
13.11
110
S1
8.000
210
652
2,133
3,040
1,505
3,986
6.03
7.87
110
S3
16.600
207
634
1,447
2,133
1,548
3,974
13.48
15.93
* all specified weights incl. fastening screw of additional oscillating weight
These data are comparative values and can vary depending on the application. Further data on request.
By changing the weight of the freely oscillating part (e.g. by attaching an
additional oscillating weight to the piston or housing), the oscillation band-
width and the unbalance change. This means that by selecting the freely
oscillating part, the unbalance can be preselected.
Parameters
Unbalance

Technical data
10
The sound pressure level is 64 - 79 dB (A) at an air pressure of 6 bar, de-
pending on the type (with silencer), and lower at a lower air pressure.
The technical performance data changes over the service life (wear and
contamination).
Type
NTK
ØA
B
C
D
E
F
G +
H
J
ØK
L
M
R
S
T
U
SW
8 AL
8
17
91
22
5
32
18.5
M 5
M 6
-
M 5
M 5
15
7
47
76.5
7
25 AL
25
50
138
54
7
52
29.5
M 16
M 16
-
G 1/4
G 1/4
25
18
72
120.5
22
28 AL
28.5
50
160
54
15
53
31.5
M 10
M 16
-
G 1/4
G 1/4
20
22
94
143
24
40 AL
40
73
140
79
12
57
34.5
M 16
M 16
8
G 3/8
G 1/4
25
20
73
122.5
32
55 AL
55
98
133
109
20
58
38.5
M 20
M 20
10
G 3/8
G 3/8
40
35
66
115
46
all information in [mm] except J, L and M
+central oscillation position
Sound level
Service life
Dimensions
for AL
except 18

Technical data
11
Typ
NTK
ØA
B
C
E
F
G +
HK /
HD
J
ØK
L *
M **
Q ***
R
S
T
U
SW
15 X
15
50
114
9
38
23.5
M 10
-
-
G 1/8
G 1/8
-
20
10
55
99
13
16
16
49
111
5
38
21.5
M 10
-
-
G 1/8
G 1/8
-
21
10
57
96
14
18 AL
18
49
116
8
42
25.0
M 10
-
-
G 1/8
G 1/8
-
21
10
62
101
16
18 AL
M1
18
49
116
8
42
25.0
M 10 /
M12
-
-
G 1/8
G 1/8
-
21
10
62
101
16
25
25
64
138
9
52
30.5
M 16
-
-
G 1/4
G 1/4
-
25
10
73
125
22
40
40
84
140
12
54
33.0
M 16
-
-
G 3/8
G 1/4
-
40
15
73
123
32
55 NF
55
110
125
17
50
35.0
M 20
96
G 3/8
G 3/8
8.5
40
30
60
108
46
55 HF
55
110
115
27
50
40.5
M 20
96
G 3/8
G 3/8
8.5
40
30
50
98
46
85 NF
85
160
122
20
50
32.5
M 20
143
12.8
G 3/8
G 3/8
10.5
40
20
57
105
-
85 HF
85
160
112
30
55
42.5
M 20
143
12.8
G 3/8
G 3/8
10.5
40
20
47
95
-
110
110
200
122
22
55
38.5
M 20
182
12.8
G 1/2
G 3/8
12.5
40
25
57
105
-
all information in [mm] except H, L and M
+central position of vibration
* from NTK 85 E on: 2 connections (L1 and L2)
** for NTK 110 E: 2 connections (M1 and M2)
*** additional mounting holes (amount n): for NTK 55 E n=4, for NTK 85 E n=6, for NTK110 E n=8
Dimensions
for other types

Technical data
12
Netter Vibration recommends the following tightening torques for fastening
screws and nuts of the strength class 8.8 (sliding friction coefficient 0.14):
Type:
NTK
Thread
Tightening torque*
[Nm]
8 AL
Housing
M 6
8.5
Piston
M 5
5.9
15 X
Housing/piston
M 10
18
16, 18 AL
Housing/piston
M 10
40
18 AL M1
Housing
M 12
70
Piston
M 10
40
25, 25 AL
Housing/piston
M 16
95
28 AL
Housing
M 16
95
Piston
M 10
40
40, 40 AL
Housing/piston
M 16
180
55, 55 AL
Housing/piston
M 20
345
Mounting hole
M 8
25
85
Housing/piston
M 20
400
Mounting hole
M 10
51
110
Housing/piston
M 20
430
Mounting hole
M 12
87
* when using the entire thread length
Netter Vibration recommends the following cross-sections for 3/2-way
valves and hoses:
Type:
NTK
Connection thread
Hose/valve size *
Exhaust air thread
8 AL
M 5
DN 4
M 5 or G 1/8
15 X
G 1/8
DN 4
G 1/8
16
G 1/8
DN 6
G 1/8
18 AL, 18 AL M1
G 1/8
DN 6
G 1/8
25, 25 AL, 28 AL
G 1/4
DN 6
G 1/4
40, 40 AL
G 1/4
DN 6 - 9
G 1/4
55, 55 AL
G 3/8
DN 9 - 12
G 3/8 - G1/2
85, 110
G 3/8
DN 12
G 1/2
* DN = nominal diameter (inner diameter)
Tightening
torques
Valves / hoses

Design and function
13
4 Design and function
1
Cover
2
Housing
3
Air inlet/grommet
4
Air outlet/silencer
5
Piston
6
Additional oscillating weight (optional)
A
Chamber A
B
Chamber B
The NTK generate linear vibrations.
The vibration is generated by a freely oscillating, self-reversing piston.
Both weights, the piston (5) with an additional oscillating weight (6) on the
one hand, the housing (2) and the weight to which it is attached on the
other, oscillate in relation to their total weights against each other. If the
vibration amplitude of the weight to be vibrated should be higher, then a
larger additional oscillating weight (6) is simply screwed to the piston (5).
To keep the weight to be vibrated low, the piston can be connected to it (in
the case of steel housings), in which case the housing (2) oscillates freely,
if necessary with an additional oscillating weight.
The compressed air enters chamber A via the air inlet (3). The piston is
pressed by the air in the direction of the cover (1). When the piston ex-
ceeds a defined position, then compressed air reaches chamber B via
control bores in the piston. As the piston surface of chamber B is greater
than that of chamber A, the piston is pressed in the opposite direction.
When another control bore reaches the air outlet (4), then chamber B is
vented and the process begins again.
As the piston always reverses again before the end stop, the exhaust air
only produces a slight noise, which is minimized by a silencer (4).
Design
Function

Transport and storage
14
5 Transport and storage
Special conditions of transport are not required.
Use suitable lifting equipment to move the NTK 85 E and the NTK 110 E.
A transport lug can be screwed into
the piston or into the housing (M 20
thread) when lifting.
Note:The piston moves out of the
housing when lifted and into the
housing when lowered.
Be careful
when lifting and lowering
The NTK are packed and ready for assembly. Accessories and add-on
parts are delivered unmounted, unless otherwise agreed upon.
The packaging protects the NTK from transport damage. The packaging
material has been selected from an environmentally safe and technically
disposable point of view and is therefore recyclable.
The return of packaging to the material cycle conserves raw materials and
reduces the amount of waste.
•Store the NTK in a dry and clean environment.
•Protect the NTK from UV-exposures, weather and ozone.
•The storage temperature is between -20 °C and +60 °C.
•Close all openings when re-storing.
•Preserve the NTK with steel housing before storing:
1. Put anti-corrosion oil into the air in- and outlet of the NTK.
2. Pull the piston of the NTK in and out while turning it several times.
3. Close the air supply connections of the NTK.
Transport
conditions
Packaging
Storage
conditions

Installation
15
6 Installation
Observe the safety instructions in chap. Safety, from page 5 on.
1
Maintenance unit
2
3/2-way valve
3
Additional weight (optional)
4
NTK
Special circuit diagrams are available on request.
Information regarding tightening torques for screws as well as cross sec-
tions for valves and hoses can be found in Ch. Technical data, page 7.
When installing the NTK, carry out the following steps in succession:
1. Notice: The NTK must rest fully so that no tension in the housing oc-
curs when tightening the fastening screw, which could cause mechan-
ical damage. Mount the NTK with the central fastening screw and a
suitable lock washer on a clean and even surface (±0,1 mm flatness)
without any paint residues or burn-ins.
Depending on the intended use, NTK can be screwed on either with
the housing or with the piston.
Types from size NTK 55 E up have additional
mounting holes (4) in the housing.
If necessary, use all additional mounting holes
and the corresponding number of lock washers
to additionally secure the housing to the mass
to be vibrated.
4
Mounting hole
2. Observe the recommended values for screw sizes and tightening tor-
ques.
3. In addition, use a medium-strength liquid safety agent to secure the
screw connections.
4. Observe the recommended cross-sections for valves and hoses. For
the air supply, preferably use screw connections with integrated seals
Standard-
installation
Technical data
Procedure

Installation
16
or liquid sealant. Notice: Do not use sealing tape for the screw con-
nections. Do not use longer screw threads for the air supply than in-
tended (e.g. no pipes with external thread). Otherwise, the housing
may become deformed and the piston may jam.
5. Fasten the compressed air supply securely.
6. Mount the silencer/silencers.
The loss of pressure increases with hose length. The nominal diameters in
Ch. Technical data, from page 7 on, apply to hose lengths up to 3 m.
Longer supply lines require larger cross-sections.
If necessary, the escaping air is diverted through a hose, which must be
installed as follows:
1. Remove the silencer.
2. Fasten the exhaust air hose directly to the exhaust air connection.
3. Mount the silencer at the free end of the exhaust hose.
If the NTK is to achieve full performance, then the exhaust hose must have
a larger nominal size than the supply hose.
Notice: In dusty environment or with oil-free operation the NTK must be
operated with bellows or other suitable dust protection.
How to assemble the optional Netter bellows NFB:
1. Clean (degrease) the contact surfaces on the NTK and on the addi-
tional oscillating weight.
2. Remove the protective foil from an adhesive surface on the bellows.
3. Slide the bellows over the piston and glue the bellows to the body of
the NTK.
4. Hold the piston by the wrench flats with a wrench. Attach the addition-
al oscillating weight to the piston with a screw with a medium-strength
screw locking agent. If no additional oscillating weight is used with
freely oscillating piston, a sheet metal disk with the diameter of the vi-
brator housing must be screwed onto the piston.
5. Remove the protective film from the free adhesive surface of the bel-
lows and press the adhesive surface onto the additional oscillating
weight or the sheet metal disc.
With the easy-to-release Velcro fasteners on the bellows, the wrench flats
on the piston remain accessible.
Air supply
Air discharge
line
Fitting the
bellows

Installation
17
For inclined or horizontal mounting of the NTK, the
vibration mass of the freely oscillating part S1, S2 or
S3 (see section Parameters, page 9) may only ex-
ceed the following value if the vibration mass is sup-
ported by a spring:
Type
NTK
Vibration mass to
be supported
[kg]
8 AL
0.15
15 X
0.70
16
1.00
18 AL, 18 AL M1
0.75
25 AL
1.60
25
3.00
28 AL
1.60
Type
NTK
Vibration mass to
be supported
[kg]
40 AL
3.5
40
5.0
55 AL
6.5
55 NF
9.5
85 NF
18.0
110
20.0
Using the NTK as impactor is possible.
A prior consultation with Netter Vibration is recommended.
The piston must strike against a surface
standing vertically to the NTK.
For this application lubricated com-
pressed air is mandatory.
Warning: NTK have moving parts which can cause injuries. Direct contact
with an oscillating part must be prevented on site by structural measures,
for example by shielding.
For the NTK 8 AL type a cover sleeve can be supplied.
Supported
vibration
mass
Using as
impactor
Provide
shielding

Installation
18
Check that the following steps have been carried out:
Compliance with permissible ambient temperatures ensured?
Central fastening screw with suitable lock washer installed?
Screw size and tightening torques observed?
Additional medium-strength liquid safety agent for securing the
screw connections used?
Maintenance unit (filter, regulator, mist lubricator*), valve and
supply line installed?
* not applicable for NTK L-models
When operated in a dusty environment or with oil-free opera-
tion: bellows/dust protection mounted?
If there is a risk of clamping: shielding mounted?
Compressed air supply safely fastened?
Details on hose length and nominal width observed?
Silencer mounted?
NTK secured against falling by means of a safety cable in criti-
cal assembly situations?
For inclined or horizontal mounting:
Maximum permissible vibration mass of the freely oscillating
part complied with or vibration mass supported?
Checklist
installation

Start-up and operation
19
7 Start-up and operation
Observe the safety instructions in chap. Safety, from page 5 on.
Please refer to chap. Technical data, page 7 for permissible operating
conditions.
The frequency of the NTK should be set with the pressure regulator of the
maintenance unit.
The frequency is reduced by lowering the air pressure before the NTK.
The centrifugal force is hereby also reduced. At the same time the ampli-
tude remains almost constant.
If required, install a throttle valve in the exhaust air line in order to adjust
the amplitude of the NTK by throttling the exhaust air. By throttling the ex-
haust air, the centrifugal force is reduced. The frequency hereby remains
almost constant.
Important: Reduced cross-sections already throttle (observe the nominal
diameter).
Reduce the amplitude only up to approx. 50 %. This can cause start-up
problems if below.
Depending on the vibration mass attached to the piston, the amplitude and
frequency change.
A smaller vibration mass increases the frequency and reduces the ampli-
tude. A larger vibration mass increases the amplitude and reduces the fre-
quency.
Set the mist lubricator to the smallest safely adjustable number of drops
while the NTK is running. Notice: The NTK is ready for operation only af-
ter adjustment and correct functioning of the mist lubricator.
Netter Vibration recommends setting the following number of drops, de-
pending on the type of NTK, on the mist lubricators:
NTK
Number of drops
8 AL, 15 X, 16, 18 AL, 18 AL M1, 25, 25 AL, 28 AL
1-2 drops/min
40, 40 AL, 55, 55 AL
2-3 drops/min
85, 110
3-4 drops/min
Permissible
operating
conditions
Setting the
frequency
Adjustment of
amplitude
Influence of
vibrating mass
Setting mist
lubricator
Recommend-
ed number of
drops

Start-up and operation
20
Check that the following steps have been carried out:
Screw connections checked before start-up?
Desired frequency set on pressure regulator?
Desired amplitude set by throttling the exhaust air?
Mist lubricator set?
After one hour of operation:
Hose supply connections as well as fastening screws checked,
retightened, if necessary?
Then follow the maintenance plan.
Checklist
start-up
