NetzHome WT09 User manual

Installing the APP
1. Before powering up the Sensor, please install our free ‘NEXUSHOME ‘ APP onto your phone. The APP is available in an IOS version on the
Apple App Store and an Android version on the Google Play Store. Ensure your phone is connected to WIFI to complete account setup.
2. Once downloaded, click and open the APP. The following message will appear. Please click OK.
3. Now complete your User Prole by inpung your email address and a 6 digit or longer Password, click the REGISTER buon, check your
email and click the link in the email from “Nefy” to complete registraon.
WT09
WIFI PIR SENSOR
Product Specicaon
• Built-in WIFI module that sends all alerts to your Smartphone
• Send alert once moon is detected
• Life-me cloud service provided free of charge
• Powerful APP for your Smartphone provided free of charge
• User can create oorplans in the APP showing device locaon
• APP records last 30 acvaons me and date stamped
• 3 x AA baery, last for one year
• Blue LED for status indicaon
• Schedule up to 4 periods per day when unit is automacally
turned o
Geng started
Congratulaons on your purchase of this powerful WIFI PIR sensor. PIR Sensor can monitor movement in your home and send you alerts if
there’s unexpected acvity when you’re away. Such signal is selectable as an Alarm Sound + Nocaon, Nocaon Sound + Nocaon or
just a silent Nocaon. This product works together with your smart phone and internet via WIFI. Please check that your smart phone is
either an Android or IOS (iPhone) and that the latest rmware has been installed. Please also check that your WIFI router is working properly
and that its operang manual conrms that it operates on 2.4 GHz with WPA/WPA2 encrypon.
1 2 3
install click OK register
Seng up your DEVICE
1. Go to the locaon in the Building where you eventually wish to install the Sensor. Look at your smart phone and ensure you have a good
and steady WIFI connecon there. Now, exit the APP, open SETTINGS on your smart phone and click “Wi-Fi”. Check what is showing. If
you just have a main Router, it should be showing its reference name (or SSID). Each Router or Extender has its own unique reference
name or SSID. However, if you have a network with one or more extenders, it may also be showing, underneath, under “Choose a
Network”, the SSID of an overlapping Extender, as in the picture 1 above. In this case, check whether you are closest to the main Router or
to an Extender and manually select, if necessary, the alternave closest/strongest SSID. THIS IS VERY IMPORTANT. The Sensor will only
communicate Alarm signals to the WIFI Router or Extender that you are about to “pair” it to so it is essenal that you pair it to the closest/
strongest Wi-Fi signal.
2. Re-Open the APP and click PROFILE at the boom of the opening HOME page. This will take you to the APP’s SETTINGS Page. Click
“ADD DEVICE/WIFI SETTING”.
3. Please select “Wireless” at the boom right hand side of the Page.
connect WiFi click “Add Device/WiFi Setting”
1 32
choose Wireless Pairing
1

4. Move the Sensor temporarily, right next door to the Router or Extender that you are pairing to. Carefully unscrew and open the baery
cover. Insert three new, good quality Alkaline AA baeries, ensuring correct polarity. The Sensor will now automacally enter “Pairing
Mode”. You have 30 seconds to start the Pairing Process.
5. Go back to the App on the “ADD DEVICE/WIFI SETTING” page. You will see the same SSID of the Router/Extender that you selected in
your phone’s WIFI Sengs at the top of the Page. Enter the password of that Router or Extender and press PAIR NEW DEVICE.
6. The Sensor will now start pairing to the Router or Extender and you will see the wheel whirling. It can take up to 60 seconds for a “pairing
successful” message to appear. If you see the message “me out, try again”, disconnect the baeries from the sensor, reconnect them
to enter pairing mode again and repeat the process. If this error message connues, double check that the SSID on this page and the
password both match the Router or Extender to which you are aempng to pair the Sensor to. Once pairing is successful, you can now
close the baery door.
4 5
enter the name of WIFI and password Pairing
6
insert three AA batteries
How to use
1. Exit the PAIRING Page in the APP by clicking at the top of the screen (iOS only, for Android users press Backwards on your Smartphone).
Then, click at the top of the APP’s SETTING PAGE to return you to the APP’s Home Screen. Now press SECURITY SENSOR TAG. This
will take you to the Alert Mode Screen. This allows you to choose the Sound you will hear on your phone when an Alarm nocaon is
received from both the PIR Sensor and all other Nexus devices you may have paired to your Router.
Alert Mode = Siren Sound (5 seconds repeated twice) + incoming Nocaon
Chime Mode = Short Alert Tone + incoming Nocaon
Silent Mode = No Siren, no Alert Sound, just the Nocaon
O Mode = No Siren, no Alert Sound and no Nocaon (All alerts from the Sensor will sll be listed the DEVICE’s HISTORY page)
2. Click at the boom of the screen. This will take you to the DEVICE page. Here you will see all the Sensors, including any other type of
Nexus sensors that have been paired to the APP.
Once there’s unexpected movement in your home. You will see the blue LED ash once followed, a few seconds later by a further two
quick ashes, to indicate a nocaon Alert has been sent to the APP. Depending on the Alert Mode you have chosen, this will be audible
or silent. You will see the nocaon appear NexusHome now
PIR SNESOR : Alert and the Device will start to ash with the Alert’s me and date stamped
alongside. Press the “Refresh” Buon at the top le hand side of the page to cancel the ashing. If you now press the Device Icon, you
will be taken to its HISTORY PAGE which will list the last 30 nocaons. On this page you can also:
i) Toggle between turning a local Alarm On or o (On means that when the sensor is triggered, the oponal Nexus WIFI socket
will also start beeping)
ii) Press to set the Baery Save me to 15 minutes, 45 minutes, or 0 minute.
‘’Baery Save Time” means that, aer detecng inmal movement, the Sensor will ignore any subsequent movement for the Time
Period selected, thereby dramacally conserving baery life. If the Sensor is mounted in a locaon where it is likely to see high trac
(ie regular movement), it is therefore important that you select either 15 or 45 minutes. Otherwise, not only will the Sensor’s baeries
run down quickly, but you will receive constant nocaons.
iii) Swipe the “History Secon” to the Le to get to the “Device Disabled Sengs”. Here you can select up to 4 daily periods in which the
Sensor is automacally switched to O Mode.
a/ Tap on One of the 4 periods to take you to the Time Selecon Screen.
b/ Select the Time Period at the top of the Screen you want the Sensor to turn O automacally and then select the Days of the Week.
Press to return to the Time Selecon Screen.
c/ The Periods you selected will now be shown on the Screen. Click on to manually turn a Time Period O.
12
4 different modes device list and history
iii)
b/ select time period
c/ turn a time
period off
a/ Top on one of
the 4 periods
Device Disabled Settings Device Disabled Settings
i)
ii)
PANIC BUTTON
PIR SENSOR
DOOR SENSOR
2

How to share an Alert Nocaon from a DEVICE with another Smartphone
1. Ensure that the free ‘NEXUSHOME ‘ APP has been installed on the other Smartphone and complete the registraon process, following the
procedure detailed in “Installing the APP” above.
2. Press at the top right of the Device Page in the APP on the Smartphone.
3. Now select the Sensor you wish to share, then press and complete the “Share Device to” box with the other user’s email address they
used when registering their user prole. Press to exit.
4. Open the APP on that other User’s Smartphone and press PROFILE at the boom of the opening Home Page.
This will take you to the APP’s SETTINGS PAGE. In the secon “Received Device” you will see a number in green. This denotes the number
of Devices that you have selected to share with that User.
5. Press “Received”. This will take you to a list of those Devices. The new User can now choose whether to accept or reject Nocaons
from those Devices. Note that the new User can select, separately, on their APP’s Device Alert Page whether such nocaons are
Audible, Silent or O.
Advanced Informaon for the DEVICE PAGE
Press to Refresh/Reset the Device Page and stop a ashing Sensor Icon.
Press this Icon, at the top of the page, to return to the APP’s Home Screen
(iOS only, for Android press back on smartphone).
Enables you to share Alert nocaons for a Sensor with any other user who has already
downloaded the Nexus APP. See below for full details. Whilst in this secon, you can also alter
the order in which the Devices are listed on your screen. Press on” the right of the Device
whose order you wish to change and then drag it to its new posion on the screen.
A personalized descripon of the Sensor.
Press the Sensor’s Icon, to go to its HISTORY page and press “PIR SENSOR” seen just above the
ID. Complete CHANGE DEVICE NAME and save it.
This is the Device’s unique ID.
How to delete a DEVICE from the APP
Whilst on the DEVICE PAGE, hold and swipe the Devices Descripon to the le of your screen and press
For Android, just press and hold then conrm with the prompt window for deleon.
3
Press this icon to return to the APP’s Alert Mode Screen.
Press this icon to take you to the APP’s Floorplan Screen.
Here you can create personalized Floorplans showing the locaons of Doors, Windows and
individual Sensors (see below)
1
2
34
5
press edit press share press “Received Device”
Personalized Icon or Photo for the Sensor.
Press the Sensor’s Icon to go to its HISTORY PAGE, then press its Icon again on
this page. Choose “Take photo”, “From album” or “Default icons” to create a
personalized Icon.
Flashing - Indicates a Sensor has sent an Alert nocaon.
Press the Icon to go to the Sensor’s HISTORY PAGE
Indicates a Low Baery.
Although baeries should connue to last for up to a month aer this Icon
appears, you should change them immediately, respecng the correct polarity
and using good quality Alkaline baeries. Always test a Sensor aer replacing the
baeries.
The Sensor sends a “heartbeat” signal to the Router every 4 hours.
This Icon indicates that contact has been lost between them.
Shows that a Device is acve.
Click on this Icon to toggle the Device to be acve or non-acve
Indicates whether the Sensor is also sending an Alert Signal to the oponal
Nexus Indoor Siren (sending a signal as shown). Press the Sensor’s icon to go to
DEVICE HISTORY, then press the Siren Icon on that page to toggle O
PIR SENSOR
PIR SENSOR
PIR SENSOR PIR SENSOR
DOOR SENSOR
TEMP. SENSOR
PANIC KNOB

Advanced Informaon for the Floor plan Page
Swipe the screen to the Le to reach a new oorplan
Press to add an addional oorplan.
Press to show the list of all your Devices. Then press on an individual device
from that list to add it to that Floorplan. Press to add an addional oorplan.
Drag a Device Icon here to delete it from that oorplan.
Press to turn Devices on this page On/O .
Press to edit the oorplan on the screen. This will then take you to the screen
below le.
Whilst in Eding Mode:
Use your nger on the screen up/down/
sideways to create a drawing.
Press to delete this Floorplan completely
Press to delete your last acon
Press to add Door/Window Symbols, drag to Floorplan locaon,
press screen to return
Press to remove all from this Floorplan
(Boom Right) Drag a Socket Icon here to delete it from that
Floorplan
Press to Save the Drawing
IMPORTANT
1. Do not place any other magnets or magnezed materials close to a Sensor as this could cause a false trigger.
2. Make sure your WIFI router and its signal strength cover all the Sensors locaons. Please note that a WIFI signal may not penetrate
through concrete walls or solid doors and that, if it does, it is usually SEVERELY reduced. You may therefore need to add one or more WIFI
Repeaters to increase signal coverage. If you do this, then ensure that individual devices are paired to the closest Repeater or Router.
Since all Router/Repeater SSID’s are dierent, you must ensure that the Sensor is paired to the correct SSID (see seng up your WIFI
Device above).
3. Aer installing a Sensor, please test it at least a couple of mes to check the performance.
Trouble Shoong
• CANNOT PAIR THE SENSOR SUCCESSFULLY
1. Check whether the Sensor has enough baery power. Always use new, good quality, Alkaline baeries.
2. If there are too many WIFI connecons around your Sensor, turn them o to avoid any disturbance and pair again.
3. Check that the router is working properly and that it operates on 2.4GHz
4. Check that the SSID and password are correct.
• DOESN’T WORK PROPERLY or LOSS OF SIGNAL ICON APPEARS
1. Check whether the Sensor is within coverage of your WIFI router/repeater. Move the Sensor or Router to a dierent locaon.
2. Check that the router is working properly
3. Check the power level of the tag. If it shows a baery low icon in the APP, please replace the baeries.
Safety
FIRE, BATTERY AND ELECTRIC SHOCK HAZARDS
1. Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint, or insert foreign objects into the
Sensor. Such acons could result in an electric shock. Clean the Sensor only with a dry cloth.
2. Do not expose the Sensor to extremely high or low temperatures or leave them in direct sunlight for extended periods of me.
3. Do not leave the Sensor near open ames such as cookers, candles or replaces.
4. It’s dangerous if you replace baeries incorrectly or with the wrong polarity. You should only use the same or equivalent type of baery to
replace a damaged or drained one. The Baery should not be exposed to an overheang environment such as extreme sunshine or re.
Always use a good quality Alkaline baery for best results.
4
