Neunaber IMMERSE REVERBERATOR MK II User manual

IMMERSE REVERBERATOR MK II

Thank you for purchasing our product. We really mean it.
We hope to earn your trust by delivering a quality product
that inspires you to make great music.
Neunaber products are designed and manufactured in
Orange, California USA.
IMMERSE REVERBERATOR MK II
USER GUIDE
Please visit www.neunaber.net for more information and support.

INTRODUCTION
The Immerse Mk II represents the very best in pedal reverberation — with studio-
quality algorithms, high-fidelity circuitry, heavy-duty components and construction
— all in a small footprint. The Mk II is a monumental step forward and features
completely-redesigned circuitry and upgraded algorithms:
• Mix adjustable from 100% dry to 100% wet
• Increased headroom
• New W3T reverb algorithm
• New Sustain eect
• Various improvements to most eects
• Easier-to-read graphic layout
The Mk II implements a high-quality buered bypass. The signal is always buered
whether engaged or bypassed. We chose this type of bypass because the last
output in a pedal chain should be buered, and reverb is typically placed at the
end of a pedal chain.

FX send
input
FX return
overdrive
distortion
SIGNAL CHAIN
Q: Where do you place this eect? A: Reverb sounds best at the end of the chain.
EFFECTS LOOP
Using the drive channel of your amp? Connect reverb in the eects loop.
Note: Enable kill dry for parallel FX loops only.
OR modulation
delay
overdrive
distortion

CONNECTIONS
TRS (tip-ring-sleeve)
TS (tip-sleeve) no connection
OR
OR
STEREO INSTEREO OUT
MONO INMONO OUT
1
2
1
2
1
2
1
2
OR
OR
MONO IN
STEREO IN
STEREO OUT
SUMMED MONO OUT
1
2
1
2
1
2
1
2

CONNECTIONS
The Power Jack accepts a standard (5.5 mm OD x 2.1 mm ID) center-negative
pedal power adapter (not included). The power adapter must be between 9 V and
12 V and capable of supplying 80 mA or more.
The Input Jacks accept inputs directly from your instrument, amplifier eects
loop send, or other eect pedals via standard 1/4” (6.35 mm) phone connectors.
Inputs 1 and 2 should not be used with two discrete signals, such as two dierent
instruments.
The Output Jacks supply output to another eect pedal, an amplifier, or eects
loop return via standard 1/4” (6.35 mm) phone connectors. The output is buered
and capable of driving long cables.
SWITCHES
The Footswitch engages the eect, and the LED lights when the eect is active.
There are two mini-switches next to the Power jack:
• Kill Dry removes the dry signal, even when bypassed. This should be enabled
for parallel eect loops and disabled for serial (common) eect loops.
• Trails allows the eect to naturally trail after the pedal is bypassed. With
normal bypassing, the eect is abruptly cut o; however, normal bypassing
results in lower noise while the pedal is bypassed.

W3T™ Version 3 of the WET algorithm — our flagship reverb. Smoother
decay and more three-dimensional sounding, it enhances what
you play without covering it. Adjustable pre-delay further
separates the dry signal and reverb up to an additional 200
milliseconds (ms).
Plate A physical plate reverb uses transducers mounted to a large,
suspended metal plate. It is known for its bright, diused sound.
Adjustable pre-delay further separates the dry signal and reverb
up to an additional 200 ms.
Hall Hall reverb simulates the sound of a well-designed concert hall.
The Mod knob controls the modulation depth — try increasing it
for a lush, modulated hall reverb.
Spring A physical spring reverb uses metal springs suspended between
transducers and produces a distinctive “twerp.” The Mod knob
increases the modulation rate — try increasing the modulation
rate for a classic vibrato-spring reverb sound.
EFFECTS

EFFECTS
Sustain Built on our W3T reverb, Sustain is a magical eect that can be
configured as a sustain eect or virtually infinite reverb. What you
play is recycled in an infinite loop during a ”hold” phase, then
decays out during a “release” phase. The Time knob adjusts the
hold time, while the Depth knob adjusts the release. The Mod
knob controls the modulation depth.
Echo This eect adds echo and reverb. The Time knob adjusts the
echo time, from 50 to 700 ms. Depth controls both the reverb
decay and echo repeats. Blend controls the mix between the
reverb and echo eects.
↓tune Detune is a an eect that pitch-transposes a signal slightly
downward. This eect adds detune to a detuned reverb to
produce a thick, chorus-like eect. The Blend knob controls the
mix between the reverb and detune eects.
Shim Shimmer is a reverb eect reminiscent of a synth pad that follows
what your instrument plays. The Blend knob controls the mix
between the reverb and shimmer eects.

CONTROLS
Mix The Mix knob adjusts the blend of dry (unaected) signal to
eect and ranges from 100% dry to 100% eect.
Eect The center knob selects the reverb eect. The knobs below
may change function depending on the selected eect.
Depth The Depth knob controls the reverb depth (also called decay
time). When the Echo eect is selected, it also controls the
number of repeats (regeneration).
Time
Tone
This knob adjusts the eect tone except as follows:
• Sustain, knob controls Hold time
• Echo, knob controls the Delay time
Pre-Dly
Mod
Blend
This knob controls the reverb-to-eect blend except as follows:
• W3T and Plate, knob controls pre-delay
• Hall and Sustain, knob controls modulation depth
• Spring, knob controls modulation rate

EXAMPLE SETTINGS
Dreamland
mix depth
tone pre-dly
W3T
A Touch of Class
mix depth
tone pre-dly
W3T
Arena Rock
mix depth
tone pre-dly
plate
Subtle Thickening
mix depth
tone pre-dly
plate

Vibrato Spring
mix depth
tone mod
spring
Big Bright Spring
mix depth
tone mod
spring
Americana
mix depth
time blend
echo
Echoes
mix depth
time blend
echo
EXAMPLE SETTINGS

Modulated Hall
mix depth
tone mod
hall
Infinite
mix depth
time mod
sustain
Sustain
mix depth
time mod
sustain
Soundscape
mix depth
time mod
sustain
EXAMPLE SETTINGS

1980
mix depth
tone blend
tune
←
Ambient
mix depth
tone blend
shim
Airy
mix depth
tone blend
shim
Synth Pad
mix depth
tone blend
shim
EXAMPLE SETTINGS

SPECIFICATIONS
Electrical
Nominal input level -10 dBV (instrument / consumer line level)
Max input level 7 dBV using 9 V power supply
Input impedance 1.175 MΩ (mono), 2.35 MΩ (stereo)
Output impedance 500 Ω (mono), 1 kΩ (stereo)
Gain, enabled vs. bypass unity
Frequency response 20 Hz—20 kHz, +/-0.5 dB, dry signal or bypassed
Total harmonic distortion < 0.005 % @ 1 kHz, dry signal or bypassed,
-10 dBV input, 22 Hz—22 kHz bandwidth
Signal-to-noise ratio 110 dBA mono / 107 dBA stereo,
enabled @ 50% Mix or trails bypass
120 dBA, normal bypass
Power
Input 9-12 V DC, 80 mA
Connector center-negative, 5.5 mm OD x 2.1 mm ID
Physical
Dimensions 2.9” W, 4.6” L, 2.0” H / 73 mm W, 117 mm L, 51 mm H
Weight 8.84 oz / 251 g
*Specifications subject to change without notice.

This product contains no user-serviceable parts.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
California Proposition 65 Warning: This product may contain chemicals known to the State of California
to cause cancer, birth defects or other reproductive harm. While we believe our products are not harmful
when used as designed, we provide this warning to comply with Proposition 65.
© 2018 Neunaber Technology LLC. All rights reserved. Neunaber logo, Immerse™ and W3T™ are
trademarks of Neunaber Technology, LLC. US Patent #8204240 & China Patent #CN101689840B.
