New Air AF-1000 Series User manual

Manual v1.2
Evaporative Cooler
AF-1000 Series
OWNER’S MANUAL
Read and save these instrucons.

2
http://www.NewAir.com
A Name You Can Trust
Trust should be earned and we will earn yours. Customer happiness is the focus
of our business.
From the factory to the warehouse, from the sales floor to your home, the
whole NewAir family promises to provide you with innovative products,
exceptional service, and support when you need it the most.
Count on NewAir.
As a proud NewAir owner, welcome to our family. There are no robots here,
real people shipped your product and real people are here to help you.
Contact Us:
For questions regarding your product, please contact us at:
Call:
1-855-963-9247
Email:
[e-mail]
Online:
www.newair.com
Connect with Us:
Facebook.com/newairusa Instagram.com/newairusa
YouTube.com/newairusa Twitter.com/newairusa

3
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Register Your Product Online............................................................................... 4
Safety Information & Warnings ........................................................................... 5
Parts List............................................................................................................... 6
Assembly & Installation ....................................................................................... 6
Installing FIlters.................................................................................................... 7
Cleaning & Maintenance...................................................................................... 8
Troubleshooting................................................................................................... 9
Limited Manufacturer’s Warranty ..................................................................... 10
SPECIFICATIONS
MODEL NO.
AF-1000
VOLTAGE:
120/60Hz
CURRENT:
160W
F
REQUENCY
:
20 Liters

4
http://www.NewAir.com
REGISTER YOUR PRODUCT ONLINE
Register Your NewAir Product Online Today!
Take advantage of all the benefits product registration has to offer:
Service and Support
Diagnose troubleshooting and service issues faster and more
accurately
Recall Notifications
Stay up to date for safety, system updates and recall notifications
Special Promotions
Opt-in for NewAir promotions and offers
Registering your product information online is safe & secure and takes less
than 2 minutes to complete:
Alternatively, we recommend you attach a copy of your sales receipt below and
record the following information, located on the manufacturer’s nameplate on
the rear of the unit. You will need this information if it becomes necessary to
contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________________
Serial Number: ____________________________________________
Model Number: ____________________________________________
Register.NewAir.com

5
SAFETY INFORMATION & WARNINGS
When using any electrical appliance, basic safety precau ons
must be followed in order to reduce the risk of fire, electrical
shock and/or injury to persons or property. Be sure to read all
instruc ons before using this appliance and observe the
following safety tips:
•Carefully read all instruc ons before use.
•Check the condi on of the unit a er taking it out of the box. Ensure that all parts
are in good condi on.
•Before using the unit, verify that the cooler’s voltage requirements correspond
with your power outlet.
•Do not use any appliance with a damaged cord or plug. If the cord is damaged,
please contact an authorized service center.
•Do n empt to repair, adjust, or replace parts in the unit. Any repairs must be
made by an authorized technician.
•Do not place the unit near gas or electric stoves.
•Cau on should be taken when the cooler is used near children. The unit should
not be le un ended for any extended period of me whie in operaon.
•This appliance should not be used by persons (including children) with reduced
physical, sensory, or mental capabili es, or lack of experience and knowledge,
unless they have been given supervision or instruc on concerning its use by a
person responsible for their safety.
•This unit is intended for household indoor use. Do not operate this evaporave
cooler in bathrooms or in any other wet or damp loca ons.
•Do not insert objects into the air louvers.
•Use the “Power” bu n to turn the unit on or off. Do not control operaon by
pulling the plug from the power outlet.
•To prevent the risk of electric shock, do not operate the unit with wet hands.
•Save this instruc on manual for future reference.
WARNING: TO Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With Any
Solid-State Speed Control Device.
WARNING：
The cells shall be disposed of properly, including keeping them away from children, even used
cells may cause injury.

6
http://www.NewAir.com
PARTS LIST
ASSEMBLY & INSTALLATION
1. POWER: Connect the cord to a power outlet. An indicator light will
turn on, indicating that the power source is connected. Press the
“On/Speed” button to turn the unit on. When it turns on, the cooler
will start at medium speed (number 2) and then drop to the low speed
setting (number 1) after a few seconds.
2. SPEED: To adjust the fan speed, press the “On/Speed” button
repeatedly until the desires speed appears on the display.
1. Control Panel
2. Air Louvers
3. Carrying Handles
4. Cord Wrap
5. Honeycomb Filter
6. Partition
7. Carbon Filter
8. Dust Filter & Rear
Screen
9. Water Level
Indicator
10. Casters
11. Water Tank
12. Drain Hole
13. Remote Control

7
•Low Speed
•Medium Speed
•High Speed
3. OSCILLATION: To turn on the oscillation feature, press the “OSC”
button once. The indicator will appear on the display. Press the “OSC”
button again to turn off the oscillation feature.
4. TIMER: The unit comes with a 10-hour timer (max. 10 hours). To set
the timer, press the “Timer” button. Each time the “Timer” button is
pressed, 0.5 hour of operation time is added. To have the unit run
continuously, make sure the timer is off.
•Press once – 0.5 hour
•Press twice – 1 hour
•Press 3 times – 1.5 hours
•Up to 10 hours
5. COOLING: Fill the tank with water and press the “COOL” button. The
indicator light will turn on. To stop the unit from cooling, press the
button again.
6. ADDING WATER TO THE TANK: Follow these steps to add water to the
water tank:
•Pull off the water tank’s cover.
•Carefully pour water into the water tank.
•Do not exceed the “maximum” water line on the water level
indicator.
•For enhanced cooling, add ice to the tank.
INSTALLING FILTERS
1. Remove the two included filters from their packaging.
2. Unscrew the rear screen and install the two filters so that they are
nearest to the rear screen, not the front of the unit. The order the
filters are installed does not matter.
3. Close the rear screen and screw it back in.
4. Add water as mentioned in the previous section and your evaporative
cooler is now ready to use.

8
hp://www.NewAir.com
CLEANING & MAINTENANCE
1. Before disassembling the unit, unplug the unit from the power outlet
and drain all ofthe water from the tank by removing the drain cap.
2. Use a clean, damp clothto wipe away any dust or dirt from the unit’s
exterior. Also wipe down the air louvers.
3. CLEANING THE DUST FILTER: Clean the dust filter by unscrewing
/pulling out the dust filter and washing the dust filter with running
water.
4. CLEANING THE HONEYCOMB FILTER AND TANK: Clean the
honeycomb filter and tank by following these steps:
•Unscrew and pull out the dust filter.
•Clean the honeycomb filter by using a vacuumor brush.
•Use a damp cloth with soapto clean and remove any residue
from the water tank.
•Rinse and drain the water tank.
•Replace the honeycomb and dust filters back into the unit.
Make sure the filters are properly inserted before ghtening
the screws.
NOTE: We recommend cleaning the unit every 3 months with regular use.
However, if you have hard water with a high mineral content, we recommend
cleaning the unit once a month to prevent residue buildup

9
TROUBLESHOOTING
Problem
Possible Causes
Solution
The unit produces
no air.
The unit is not plugged
in.
Check to make sure the plug
is plugged into an outlet.
The unit should beep twice
once the power supply is
connected.
The water tank is not
locked into the unit.
Make sure the water tank is
locked into the back of the
unit.
The unit does not
cool.
There is insufficient
water in the tank.
Check the water level in the
tank and make sure there is
enough water.
The cooler/humidifier
button was not
pressed.
Press the COOLER/
HUMIDIFER button.
The pump is defective.
Contact customer service if
there is an issue with the
water pump.
The unit does not
cool on high
speed.
The cooling pad is not
sufficiently saturated
with water.
If speed 3 is selected when
in cooling mode, the unit will
automatically revert to
speed 2 for 5 minutes to
allow the pad to be fully
soaked. The cooler will
automatically turn to speed
3 when the pad is soaked.
Water is coming
out of the vents.
The cooling pad may be
clogged with debris.
Clean the cooling pad by
rinsing it in water and
allowing it to thoroughly dry.
You can also clean it with a
water and vinegar solution.
If the problem persists,
contact customer service.

10
http://www.NewAir.com
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year
from the original date of purchase, the manufacturer will repair or replace any
parts of this appliance that prove to be defective in materials and
workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective
due to materials or workmanship will be repaired or replaced, at the
manufacturer’s discretion, at no charge to the original purchaser. The
purchaser will be responsible for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply such as low voltage, defective household
wiring or inadequate fuses
•Accident, alteration, misuse or abuse of the appliance such as using
non-approved accessories, inadequate air circulation in the room or
abnormal operating conditions (extreme temperatures)
•Use in commercial or industrial applications
•Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.
•Use of force or damage caused by external influences
•Partially or completely dismantled appliances
•Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with
the purchase date available. Once confirmed that your appliance is eligible for
warranty service, all repairs will be performed by a NewAir™ authorized repair
facility. The purchaser will be responsible for any removal or transportation
costs. Replacement parts and/or units will be new, re-manufactured or
refurbished and is subject to the manufacturer’s discretion. For technical
support and warranty service, please email [e-mail].
