ASSEMBLY INSTRUCTIONS
DOMINGO COLLECTION
B5902-310
B5902-330 5/0-4/6 Q/F Headboard 5/0 Queen Footboard And Rails
All images shown are for illustration purposes only. The actual product may vary due to product enhancement.
Thank you for being our valued customer. Be sure to check all packing materials carefully for small parts which may have
come loose inside the carton during shipment. Identify and count all items and compare them with the parts list and
hardware list below.
CAUTION: Read the instructions carefully before assembly.
1. We recommend that you assemble this product with the assistance of another person to eliminate damage to the
product during assembly.
2. Do not over-tighten the screws and bolts as they may damage the threads.
3. Keep all hardware parts out of reach of children.
4. When you want to reposition the product, please always “LIFT & MOVE”.
PARTS LIST
NO. DESCRIPTION SKETCH QTY
AHeadboard 1PC
BHeadboard Leg 2PCS
CFootboard 1PC
DBed Rail 2PCS
ESlat 4PCS
FSupport Leg 4PCS
1 of 2
HARDWARE LIST
NO. DESCRIPTION SKETCH QTY
1Bolt 1/4” x 1 1/2” 10PCS
2Bolt 1/4” x 3 1/4” 4PCS
3Bolt 1/4” x 4 3/4” 4PCS
4Chipboard Screw 8PCS
5Allen Wrench 2PCS
Step 2
Turn the nished headboard around.
Step 1
Attach Headboard Leg (B) to
Headboard (A) by using Bolt (1).
1
1
1
1
1
1
5
A
B

ASSEMBLY INSTRUCTIONS
DOMINGO COLLECTION
B5902-310
B5902-330 5/0-4/6 Q/F Headboard 5/0 Queen Footboard And Rails
All images shown are for illustration purposes only. The actual product may vary due to product enhancement.
Step 3
Attach Bed Rail (D) to Footboard (C) by
using Bolt (2).
Step 4
Attach nished headboard to Bed
Rails (D) by using Bolt(3).
Step 5
Attach Support Leg (F) to Slat (E) by
using Bolt (1).
2 of 2
2
2
2
2
C
D
D
33
3
3
F
1
15
Step 6
Attach Slats (E) to Bed Rails (D) by
using Bolt (4).
E
E
D
4444
4
4
4
4
Congratulations!
Now your product is ready for you to enjoy.
