New-Flow OF100 Series User manual

Instruction Manual
MANUFACTURE OF FLOW SWITCH AND INDICATOR
OF100 SERIES

New-Flow Metal Tube Flow Meter Instruction Manual
page 1
a
b c d
a
b
c
d
Multimeter
"+" Driver
"–" Driver
1.5mm Hexagon
Key Wrench Set
Necessary Tools
Acting Principle
2. The revolving cam activates the
1. The micro switch provides SPDT function and offer NO.NC.COM contact for usage.
micro switch to control the flow rate.
Micro Switch
OF100 Assemblies
a
1.
2.
3.
4.
5.
6.
7.
1.
2.
3.
4.
5.
6.
7.
Inside Outside
Cam
Terminal Block
Scale Palte
Flow Pointer
Zero Adjustable Screw
Alarm Pointer
The Setting Step
1. If the flow range needs to be reseted, please open an upper cover at first and relax the
revolvable cam(2) with the hexangular key wrench(d). (as diagram B)
(Diagram A) (Diagram B)
Revolvable Cam
2. Turn the flow pointer(5) to the requested alarm set point with hand and hold the hand
at the position (as diagram C). Let the revolvable cam touch the micro switch(1) to cause NO, COM
short-circuited. When the multimeter displays zero (as diagram D), lock the cam tightly in place.
INSTALLATION OF OF100

New-Flow Metal Tube Flow Meter Instruction Manual
page 2
(Diagram C) (Diagram D) (Diagram E) (Diagram F)
INSTALLATION OF OF100
3. Revolve the flow pointer(5) by hand and confirm the alarm setting whether it is correct by multimeter(a) once again.
4. If the alarm set point still incorrect, please repeat 1,2,3 steps until reach the alarm set point that you need.
5. Finally, move the alarm pointer to the alarm of new setting point and lock tightly by "+" driver with hand.
6. If the pointer didn't return zero (as diagrm E), when there are not fluid through inside this flow meter.
zero adjustable screw. (as diagram F, )
First, we have to keep the flow pointer(5) in zero and adjust the flow pointer in zero with "–" driver to revolve
Zero Adjustable Screw
Decrease Increase
Notice
1. Please watch for the flow direction when you install.
2. After setting completon, please indeed lock the upper cover tightly, and have to a cable gland in
entrance fixed cable to make sure water tightly.
3. If the fluid is dirty water or waste water, please installing filter at inlet to avoid fluid jamp.
5
0
2
10
15
20
NEW-FLOW
F28C1799
1/2NPT
kg/ h
OF-100
LHHL
RL LR
Dimensions Flow Direction Type
OUT
IN
FLOW
53
Ø100.5
½" NPT
Electronic
Connection

New-Flow Flow Switch And Indicator Instruction Manual
page 1
LOAD
Vs
Power Supply: 24V DC
Output: Linear 4~20 mA (2 wires system)
Accuracy: ±2% F.S.
Tool: Multimeter, Program Communicator (GTP01), Power Supply (24V DC), “−” Driver
* NOTE:
1. Please keep flow pointer in zero match to 4mA.
2. BF300-GT don’t need to calibration in user side at moment.
3. GTP01 needs to purchase in addition.
NEW-FLOW
+ –
+
–2 wires
4~20 mA
+
–
+ –
24V DC
(Fig. A)
Main Parts List
Program Steps Method
Step 1. The junction terminal of program communicator with the circuit board as Fig. A. Then proceed to under steps.
Step 2. Press and hold down the RESET button for 5 seconds, the LED lamp will light. Then release press and to
keep indicating pointer on “0” point of scale. Then press SET button to start proceed another step. LED
lamp will become dark.
Terminals
Program Communicator (GTP01)
Connect junction terminal
with circuit board.
LED
SET
NORM
RESET

New-Flow Flow Switch And Indicator Instruction Manual
page 2
Step 3. To move indicating pointer to 10% of full scale, LED will flashing once on intermittence.
Then, press SET button and start another steps.
Step 4. To move indicating pointer to 20% of full scale, LED will flashing twice on intermittence.
Then, press SET button and start another steps.
LED Flashing Once LED Flashing Twice
LED Flashing Three Times LED Flashing Four Times
Step 5. To move indicating pointer to 40% of full scale, LED will flashing three times on intermittence.
Then, press SET button and start another steps.
Step 6. To move indicating pointer to 60% of full scale, LED will flashing four times on intermittence.
Then, press SET button and start another steps.
LED Flashing Five Times LED Flashing Six Times
Step 7. To move indicating pointer to 80% of full scale, LED will flashing five times on intermittence.
Then, press SET button and start another steps.
Step 8. To move indicating pointer to 100% of full scale, LED will flashing six times on intermittence.
Then press SET button, LED will become dark. At the meantime, the proceedure of program sets
are finished.

New-Flow Flow Switch And Indicator Instruction Manual
page 3
Step 9. After completion the above-mentioned steps, plesae check of the flow rate 0~100% compare with the output signal
4~20mA or not. If output signal can’t match to the flow indicator as under flow table of step 10, it should be re-set
again according to
Program Steps Method.
0% 50% 100%
mA
%%%%%
LPM
4 0 0
5.6 10 1.5
7.2 20 3
10.4 40 6
13.6 60 9
16.8 80 12
20 100 15
Step 10. Flow table and Output signal (example: flow range 0~2000 L/H)
LED
Off
Flash once
Flash twice
Flash three times
Flash four times
Flash fivetimes
Flash six times
Note
1. Above all, please confirm the input power supply and the wiring mode that are correct.
2. After setting completion, please indeed lock the upper cover tightly, and have to a cable gland in entrance
fixed cable to make sure water tightly.
3. If the process of program set is error, please press and hold down the SET button until the LED lamp turns off.
Then re-set it again according to
Program Steps Method.
4. Moves the indicator by manual and test run directly after the flow meter completion of installed, all of they are workable.
5. The flow meter has completed program before shipping, therefore it doesn’t need to program once more.
