New Holland Discbine®
Disc Mower-Conditioner Specifications
H7220 H7320 H7230 H7330
Page 1of 4
MODEL H7220 H7320 H7230 H7330
MOWMA ™ CUTTERBAR WITH SHOCKPRO™ HUBS
umber of discs 7788
umber of knives 14 (2 per disc) 14 (2 per disc) 16 (2 per disc) 16 (2 per disc)
Speed, rpm 3000 3000 3000 3000
Cutting width, ft. in. (mm) 9' 2" (2800) 9' 2" (2800) 10' 4" (3160) 10' 4" (3160)
Cutting angle .......2 to 10 degrees, mechanical or hydraulic control....... ........................2 to 10 degrees hydraulic control ...........................
Cutting height, in. (mm) ...........................................................................0.95 to 3.2 (24 to 81) with standard skid shoes......................................................................................
Ground clearance with header
fully raised, in. (mm) 17 (432) 17 (432) 18 (457) 17 (432)
Flotation............................................................................................................Vertical and lateral, adjustable springs .............................................................................................
MATERIAL DISCHARGE
Swath, ft. (mm) 6 (1829) 6 (1829) 7 (2134) 7 (2134)
Windrow, ft. (mm) ................Adjustable from 3 to 6 (914 to 1829)................ .....................Adjustable from 3 to 7 (914 to 2134) ........................
HYDRAULICS
Hydraulic swing....................................................................................................Standard (double-acting cylinder).................................................................................................
Hydraulic lift ................................................................................Standard (operated by two single-acting cylinders; master/slave)........................................................................
Hydraulic tilt .......Optional (operated by single-acting cylinder and....... ...........Standard (operated by single-acting cylinder and...............
incorporated into the lift system) incorporated into the lift system)
CONDITIONER
Type Chevron-design intermeshing Flail rotor with 90 tapered flails Chevron-design intermeshing Flail system with 102 tapered
molded rubber rolls and optional textured hood liner molded rubber rolls flails and optional textured
hood liner
Length, in. (mm) 90 (2286) 90 (2286) 102 (2591) 102 (2591)
Diameter, in. (mm) 10.4 (264) 22 (560) 10.4 (264) 22 (560)
Drive 4 HB V-belt and enclosed gears 4 HB V-belt 4 HB V-belt and enclosed gears 4 HB V-belt
Speed, rpm 647 1016 std. or optional 730 635 1000 std. or optional 718
Conditioner adjustment Single crank adjustable roll Adjustable rotor hood with Single crank adjustable roll Adjustable rotor hood with
pressure and two stop bolts to replaceable smooth liner pressure and two stop bolts to replaceable smooth liner
adjust roll gap adjust roll gap
SPEEDS
Operating, mph (kph) 0 to 9 (0 to 14.5) 0 to 9 (0 to 14.5) 0 to 9 (0 to 14.5) 0 to 9 (0 to 14.5)
Transport, mph (kph) 20 (32) 20 (32) 20 (32) 20 (32)
TUBELESS AG RIB IMPLEMENT TIRES
Size 9.5L x 14 6PR 9.5L x 14 6PR 11L x 15 6PR 9.5L x 14 6PR

New Holland Discbine®
Disc Mower-Conditioner Specifications
H7220 H7320 H7230 H7330
Page 2 of 4
MODEL H7220 H7320 H7230 H7330
DIMENSIONS
Height, transport, ft. in. (m) 5' 8" (1.7) 5' 8" (1.7) 5' 8" (1.7) 5' 8" (1.7)
Height, operating, ft. in. (m) 4' 5" (1.3) 4' 5" (1.3) 4' 5" (1.3) 4' 5" (1.3)
Width, transport, ft. in. (m) ..............9' 11" (3.0) with standard drawbar hitch ............. ..................11' 3" (3.4) with standard drawbar hitch......................
Width, operating, ft. in. (m) ............14' 10" (4.52) with standard drawbar hitch ........... ..................16' 0" (4.6) with standard drawbar hitch......................
Length, transport, ft. in. (m) ..............17' 7" (5.3) with standard drawbar hitch ............. ..................17' 7" (5.3) with standard drawbar hitch......................
Length, operating, ft. in. (m) 17' 2" (5.2) with standard 17' 2" (5.2) with standard 17' 2" (5.2) with standard 17' 8" (5.4) ) with standard
drawbar hitch drawbar hitch drawbar hitch drawbar hitch
Weight, operating lbs. (kg) 3,690 (1674) 3,740 (1696) 4,165 (1889) 4,065 (1844)
OTE: Rear curtain up for transport position on flail units. Windrow shields out for field and transport positions on flail and roll units.
DRIVE ........540 rpm PTO, enclosed gears and four HB belt........ ......540 or 1000 rpm PTO, enclosed gears and four HB belt..........
DRIVE PROTECTION...........................................................................................Slip clutch and over-running clutch................................................................................................
TRACTOR REQUIREMENT
.........65 PTO hp (48 kW) or greater with standard.......... .............. 80 PTO hp (60 kW) or greater with standard..................
ASAE Category II and III drawbar. ASAE Category II and III drawbar.
......................All models require two remote hydraulic valves capable of 1500 psi (10343 kPa), 7-pin SAE J560 connector for transport lights .....................

New Holland Discbine®
Disc Mower-Conditioner Specifications
H7450 H7550 H7460 H7560
Page 3of 4
MODEL H7450 H7550 H7460 H7560
MOWMA ™ CUTTERBAR WITH SHOCKPRO™ HUBS
umber of discs 10 10 12 12
umber of knives 20 (2 per disc) 20 (2 per disc) 24 (2 per disc) 24 (2 per disc)
Speed, rpm 3000 3000 3000 3000
Cutting width, ft. in. (mm) 13 (3960) 13 (3960) 15' 7" (4795) 15' 7" (4795)
Cutting angle........................................................................................................2 to 10 degrees, hydraulic control.................................................................................................
Cutting height, in. (mm) ...........................................................................0.95 to 3.2 (24 to 81) with standard skid shoes......................................................................................
Ground clearance with header
fully raised, in. (mm) 18 (457) 18 (457) 18 (457) 18 (457)
Flotation............................................................................................................Vertical and lateral, adjustable springs .............................................................................................
MATERIAL DISCHARGE
Swath, ft. (mm) 8 (2438) 8 (2438) 8 (2438) 8 (2438)
Windrow, ft. (mm).............................................................................................Adjustable from 3 to 8 (914 to 2438)..............................................................................................
HYDRAULICS
Hydraulic swing....................................................................................................Standard (double-acting cylinder).................................................................................................
Hydraulic lift ................................................................................Standard (operated by two single-acting cylinders; master/slave)........................................................................
Hydraulic tilt..................................................................Standard (operated by single-acting cylinder and incorporated into the lift system)..........................................................
CONDITIONER
Type Chevron-design intermeshing Flail system with 102 tapered Chevron-design intermeshing Flail system with 102 tapered
molded rubber rolls hood liner flails and optional textured molded rubber rolls flails and optional textured
hood liner
Length, in. (mm) 102 (2591) 102 (2591) 102 (2591) 102 (2591)
Diameter, in. (mm) 10.4 (264) 22 (560) 10.4 (264) 22 (560)
Diameter, in. (mm) 4 HB V-belt and enclosed gears 4 HB V-belt 4 HB V-belt and enclosed gears 4 HB V-belt
Speed, rpm 740 1011 std. or optional 726 740 1000 std. or optional 726
Conditioner adjustment Single crank adjustable roll Adjustable rotor hood with Single crank adjustable roll Adjustable rotor hood with
pressure and two stop bolts to replaceable smooth liner pressure and two stop bolts to replaceable smooth liner
adjust roll gap adjust roll gap
SPEEDS
Operating, mph (kph) 0 to 9 (0 to 14.5) 0 to 9 (0 to 14.5) 0 to 9 (0 to 14.5) 0 to 9 (0 to 14.5)
Transport, mph (kph) 20 (32) 20 (32) 20 (32) 20 (32)
TUBELESS AG RIB IMPLEMENT TIRES
Size 31 x 13.5-15 31 x 13.5-15 31 x 13.5-15 31 x 13.5-15

New Holland Discbine®
Disc Mower-Conditioner Specifications
H7450 H7550 H7460 H7560
Page 4of 4
MODEL H7450 H7550 H7460 H7560
DIMENSIONS
Height, transport, ft. in. (m) 6' 8" (2.6) 6' 8" (2.6) 6' 8" (2.6) 6' 8" (2.6)
Height, operating, ft. in. (m) 5' 8" (1.7) 5' 8" (1.7) 5' 8" (1.7) 5' 8" (1.7)
Width, transport, ft. in. (m) .........13' 2" (4.0) with standard drawbar hitch, 2-pt ........ ....15' 9" (4.8) with 2-pt swivel hitch or drawbar swivel hitch........
swivel hitch or drawbar swivel hitch
Width, operating, ft. in. (m) ..............19' 5" (5.9) with standard drawbar hitch ............. .......................24' 11" (7.6) with 2-pt swivel hitch ..........................
...................21' 3" (6.5) with 2-pt swivel hitch................... ....................23' 3" (7.1) with drawbar swivel hitch........................
................19' 7" (5.9) with drawbar swivel hitch ...............
Length, transport, ft. in. (m) ..............24' 7" (7.2) with standard drawbar hitch ............. ........................30' 5" (9.3) with 2-pt swivel hitch ...........................
...................26' 5" (8.1) with 2-pt swivel hitch................... ..................29' 5 in. (8.7) with drawbar swivel hitch......................
................25' 5" (7.4) with drawbar swivel hitch ...............
20' 2" (5.8) 20' 8" (6.3) ........................25' 2" (7.7) with 2-pt swivel hitch...........................
w/std drawbar hitch w/std drawbar hitch
22' 1" (6.7) 22' 7" (6.9) ....................24' 2" (7.4) with drawbar swivel hitch........................
w/2-pt swivel hitch w/2-pt swivel hitch
21' 1" (6.1) 21' 7" (6.6)
w/drawbar swivel hitch w/drawbar swivel hitch
Weight, operating lbs. (kg) 5,800 (2631) 5,680 (2576) 6,500 (2948) 6,380 (2894)
OTE: Rear curtain up for transport position on flail units. Windrow shields out for field and transport positions on flail and roll units.
DRIVE.......................................................................................................1000 rpm PTO, enclosed gears and four HB belt......................................................................................
DRIVE PROTECTION...........................................................................................Slip clutch and over-running clutch................................................................................................
TRACTOR REQUIREMENT
.....90 PTO hp (67 kW) or greater with standard Category II ..... ..........100 PTO hp (74.5 kW) or greater with Category III..............
and III drawbar or Category III 3-point hitch. drawbar or Category III 3-point hitch.
......................All models require two remote hydraulic valves capable of 1500 psi (10343 kPa), 7-pin SAE J560 connector for transport lights .....................
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
© 2008 CNH America LLC
New H lland is a registered trademark f CNH America LLC.
Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).
