Box Spreader Specifications
130 145 155 165 185 195
Page 1 of 1
MODELS 130 145 155 165 185 195
CAPACITIES
Heaped, single beater, cu. ft (m3) 140 (3.97) 180 (5.10) 216 (6.10) 256 (7.25) 280 (7.90) 348 (9.85)
Heaped, double beater, cu. ft. (m3) 161 (4.56) 215 (6.10) 260 (7.36) 311 (8.81) 340 (9.60) 440 (12.46)
Struck level, cu. ft. (m3) 82 (2.32) 104 (2.95) 125 (3.54) 148 (4.19) 162 (4.60) 272 (7.70)
Struck level, slurry sides, cu. ft. (m3) 100 (2.83) 125 (3.54) 150 (4.25) 187 (4.19) 204 (5.79) —
Bushels 141 177 217 263 287 410
DIMENSIONS
Inside width of bed, inches (m) 47.4 (1.20) 60.9 (1.55) 60.9 (1.55) 60.9 (1.55) 60.9 (1.55) 72 (1.83)
verall width, inches (m)
(w/11.00x22.5 tires) 81.3 (2.07) 92.5 (2.35) 92.5 (2.35)** 101 (2.56)* 97 (2.46)** 111 (2.81)**
Inside bed depth, top of flare, inches (m) 22.6 (0.58) 22.6 (0.58) 22.6 (0.58) 22.6 (0.58) 22.6 (0.58) 32 (0.81)
Inside bed length, inches (m) 128.3 (3.26) 128.3 (3.26) 154.3 (3.92) 176 (4.47) 192 (4.48) 192 (4.88)
verall length, inches (m) 196.4 (4.99) 196.4 (4.99) 224.4 (5.70) 251.8 (6.39) 268.1 (6.81) 308 (7.82)
Loading height, inches (m) 47.8 (1.21) 47.8 (1.21) 47.8 (1.21) 47.8 (1.21) 46.8 (1.19) 57.5 (1.46)
Height to top of upper beater, inches (m) 63.8 (1.62) 63.8 (1.62) 63.8 (1.62) 62.8 (1.59) 62.8 (1.59) 69.8 (1.77)
Wheel tread, inches (m)
(w/11.00x22.5 tires) 69.5 (1.77) 80.5 (2.05) 80.5 (2.05) 85 (2.16) 85 (2.16) 98.8 (2.51)
PTO SPEEDS, RPM 540 540/1,000 ++ 540/1,000 ++ 540/1,000 ++ 540/1,000 ++ 540/1,000 ++
NUMBER OF APRON SPEEDS
Mechanical drive ..........................................................................................................2 (plus 1 slow-speed option) ..............................................................................................
Hydraulic drive NA NA NA NA 88
NUMBER OF BEATER PADDLES 9 12 12 12 12 12
WEIGHT
Hubs only, pounds (kg)+ 1,255 (556) 1,648 (749) 1,902 (865) 2,300 (1,043) 2,670 (1,214) 3,920 (1,778)
RECOMMENDED TRACTOR
PT hp (kW) 35 (26) & up 40 (30) & up 50 (37) & up 55 (41) & up 60 (45) & up 100 (75) & up
APRON CHAIN AVAILABILIT
T-Rod Standard Standard Standard Standard Standard NA
Pintle NA ption ption ption ption Standard
* Add 8.0 inches (200 mm), if 19Lx16.1 high-flotation tires are used.
**Add 10 inches (255mm) for 16.5 x 16.1 flotation tires.
+ For level or gently rolling land, the tractor weight should be at least 50% of the gross spreader weight; for hilly land, high-speed road travel, or other adverse conditions, the tractor weight
should be equal to the gross spreader weight (e.g., Model 130 should have a 7,000-lb. tractor, minimum).
++Easily converted by changing belt sleave and PT yoke.
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
