Newer Technology MAXPower User manual

eSATA 6G PCIe 2.0 Controller Card
User Manual

Page 2
Table of Contents
Part 1: Introduction Page 3
a. What is eSATA 6Gb/s? Page 3
b. MAXPower eSATA 6G PCIe 2.0 Controller Card Page 3
c. MAXPower eSATA 6G Features Page 3
d. Maximum Interface Speed Comparison Page 3
Part 2: System Requirements & Installation Pages 4-6
a. System Requirements Page 4
b. Hardware Installation Page 4
c. Verifying Installation on AHCI Systems Page 5
d. Installation on Non-AHCI Systems Page 6
Part 3: Troubleshooting & FAQ Page 7
Part 4: Contact Information Page 7
Package Contents
• MAXPower eSATA 6G PCIe 2.0 Controller Card
• User Manual
• Driver Installation Disc for Windows 2000/XP/2003
• Low Prole Bracket
NewerTechnology MAXPower eSATA 6G PCIe 2.0
Images and descriptions may vary slightly between this manual and the unit shipped.
Please visit the product webpage for the most recent specications.

Part 1: Introduction
What is eSATA 6Gb/s?
eSATA stands for External Serial Advanced Technology Attachment. eSATA 6Gb/s (revision 3.0) is the latest
SATA standard and provides data transfer rates up to 6Gb/s (600MB/s) for external storage devices.
MAXPower eSATA 6G PCIe 2.0 Controller Card
Utilizing the latest eSATA 6Gb/s technology and true Plug-n-Play driverless install, the MAXPower eSATA 6G
card is the ideal choice for high speed, ecient, low cost connectivity for the Mac or PC.
MAXPower eSATA 6G Features:
• PCIe 2.0 x1 (500MB/s bandwidth)
• Compatible with PCIe 1.0 (250MB/s bandwidth)
• Two eSATA 6Gb/s ports (600MB/s per port*)
• eSATA Hot Plug Support
• Plug-n-Play Ready Industry Standard AHCI Compliance
• Out-of-the-Box Ready Driverless Install for:
• Mac OS X 10.5 & 10.6
• Windows Vista & Windows 7
• Any Linux versions with built-in AHCI support
(Windows 2000/XP/2003 requires driver install)
• Compatible with SATA based hard disk drives and solid state drives
• 3 year warranty
NewerTechnology MAXPower eSATA 6G PCIe 2.0
Maximum Interface Transfer Speeds
Page 3
*SATA 6Gb/s speeds (600MB/s) will be limited by the PCIe x1 bandwidth (500MB/s total for x1 PCIe 2.0 or 250MB/s total for x1 PCIe 1.0)

Part 2: System Requirements & Installation
System Requirements
Mac
Hardware: Intel-based Mac with available PCIe 2.0 or 1.0 slot
Operating System: Mac OS X 10.5 and later
PC
Hardware: Any computer with available PCIe 2.0 or 1.0 slot
Operating System: Windows 2000/XP/2003 and later
Hardware Installation
Before Installing the MAXPower eSATA 6G card...
• Make sure computer is turned o and unplugged from its power source
• Take appropriate electrostatic discharge precautions:
Step 1 Open the computer systems chassis and locate an unused PCIe 2.0 or 1.0 slot (x1, x4,
x8, or x16).
Step 2 Remove the PCI slot cover.
Step 3 Gently insert the MAXPower card into the PCIe slot and secure the bracket to the
computer chassis.
Step 4 After installing the MAXPower card attach any eSATA storage devices to the card and
start your computer.
Step 5
(Windows 2000/
XP/2003 only)
Windows 2000/XP/2003 versions do not have built-in AHCI support and therefore re-
quire driver installation* for the MAXPower eSATA 6G card to function. Use Windows’
New Hardware Install Wizard to install the drivers located on the included Driver
Installation CD.
*See the “Installation on Non-AHCI Systems” section for more details.
NewerTechnology MAXPower eSATA 6G PCIe 2.0
Page 4
Your computer is a static-sensitive device. It is susceptible to invisible damage
if not protected during installation.
We recommend proper grounding by using a grounding strap. Make sure to
work in a clean and static-free area, and avoid wearing clothing that retains
static charges.
For more information, please visit:
http://www.newertech.com/static

Verifying Installation on AHCI Systems
The MAXPower eSATA 6G card has built-in AHCI support on the following Operating Systems:
• Max OS X 10.5.x
• Mac OS X 10.6.x
• Windows Vista
• Windows 7
• Any Linux based OS with built-in AHCI support
Mac
PC In Windows Device Manager, the MAXPower eSATA 6G card will be recognized as a
Standard AHCI 1.0 Serial ATA Controller card.
Upon computer startup, the MAXPower eSATA 6G card will be recognized by the BIOS as
a “Marvell 88SE91xx Adapter” which is the chip utilized for the eSATA 6G technology and
control.
After installation, the MAXPower eSATA 6G card will be visible in Apple System Proler in
the “PCI Cards”section as an “AHCI Controller” with drivers installed.
NewerTechnology MAXPower eSATA 6G PCIe 2.0
Page 5

Installation on Non-AHCI Systems
The following Operating Systems do not have AHCI support and require a two-part driver install:
• Windows 2000
• Windows XP
• Windows 2003
Use the Windows Found New Hardware Install
Wizard to install the drivers located on the included
Driver Installation CD. Make sure the CD is inserted
into your computer before beginning.
Windows will locate the drivers on the Driver
Installation CD at which point click on “Next” to
continue installation.
Upon successful installation, click“Finish” to
complete the rst driver installation. Repeat the
same steps for the second part of driver installation.
After completion, restart your computer.
Windows will present a dialog box stating
information about the Windows Logo program.
Click on “Continue Anyway” to continue the
installation.
NewerTechnology MAXPower eSATA 6G PCIe 2.0
Page 6

Part 3: Troubleshooting & FAQ
Troubleshooting Tips
If a connected storage device is not recognized after connecting it:
First try unplugging the eSATA cable from the MAXPower eSATA 6G card and then plugging it back in. If the
device is still not recognized, keep the storage device turned on and connected via eSATA to the MAXPower
eSATA 6G card and restart your machine. Please contact Technical Support for further assistance.
If the MAXPower e SATA 6G card is not being recognized by the computer:
First make sure the card is seated completely in the PCIe slot by reviewing the Hardware Installation steps.
If the card is still not recognized, try installing the card into a dierent PCIe slot. If the card is still not
recognized, please contact Technical Support for assistance.
FAQ
Does the MAXPower eSATA 6G card support port multiplier enclosures?
The MAXPower eSATA 6G does not have support for port multiplier enclosures.
Does the MAXPower eSATA 6G card support booting?
Booting from the MAXPower eSATA 6G card is not currently supported for Mac. On PC’s running Windows 7
or Vista, boot support can be enabled by enabling AHCI mode in the BIOS.
Part 4: Contact Information
Telephone
[phone]
8AM - 10PM CT Monday - Friday
9AM - 4PM CT Saturday
Live Chat
Available 24 hours a day, 7 days a week through NewerTech’s distributor, OWC.
For more information, visit:
http://www.newertech.com/support
Email
Submit your email at:
http://www.newertech.com/support
NewerTechnology MAXPower eSATA 6G PCIe 2.0
Page 7

FCC Certication Information
FCC Part 15 Class B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•Reorientorrelocatethereceivingantenna
•Increasetheseparationbetweentheequipmentandreceiver
•Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiveris
connected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Modications not expressly approved by the manufacturer could void the user’s authority to operate the
equipment under FCC rules.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
European Union Compliance Statement This Information Technologies Equipment has been tested and
found to comply with the following European directives:
•EuropeanStandardEN55022(1998)ClassB
•EuropeanStandardEN55024(1998)
NewerTechnology MAXPower eSATA 6G PCIe 2.0
Page 8 Revision 3 - 3/29/10 CH
