CP307
3U CompactPCI Processor Board based on
the Intel® Core™ Duo Processor and
User Guide
the Intel® 945GM Express Chipset
Doc. ID: 34424, Rev. 3.0
December 17, 2008
the Intel® Core™2 Duo Processor with
P R E L I M I N A R Y
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Preface CP307
Page ii ID 34424, Rev. 3.0
P R E L I M I N A R Y
Revision History
Imprint
Kontron Modular Computers GmbH may be contacted via the following:
MAILING ADDRESS TELEPHONE AND E-MAIL
Kontron Modular Computers GmbH +49 (0) 800-SALESKONTRON
Sudetenstraße 7 [email protected]
D - 87600 Kaufbeuren Germany
For further information about other Kontron products, please visit our Internet web site:
www.kontron.com.
Disclaimer
Copyright © 2006 Kontron AG. All rights reserved. All data is for information purposes only and
not guaranteed for legal purposes. Information has been carefully checked and is believed to
be accurate; however, no responsibility is assumed for inaccuracies. Kontron and the Kontron
logo and all other trademarks or registered trademarks are the property of their respective own-
ers and are recognized. Specifications are subject to change without notice.
Publication Title:
CP307: 3U CompactPCI Processor Board based on the Intel®
Core™ Duo Processor and the Intel® Core™2 Duo Processor
with the Intel® 945GM Express Chipset
Doc. ID: 34424
Rev. Brief Description of Changes Date of Issue
1.0 Initial issue 24-Nov-2006
2.0 General update 10-Aug-2007
3.0 General update, addition of a thermal characteristics graph for the
CP307 with the Intel® Core™ Duo processor, 2.0 GHz
17-Dec-2008
