Newfeellight TR1650 User manual

I
TR1650 Laser Moving Head Beam Bar Light
User Manual

II
Thank you very much for buying the full-color animation series laser performer. For your personal
safety and better use of the product, please read this manual carefully before use and strictly abide by
the warning and operation instructions stated in this manual, so as to avoid personal safety and lamp
damage caused by misuse.
● Instructions for use:
After opening the packing case, carefully check whether the lamp is damaged due to
transportation, such as whether the screw is loose, whether the lens is broken, etc.Please check before
powering on.Check whether the lamp position is correct and stable, check whether the power supply
voltage is the same as the product.This device is a level 1 protection device. Therefore, the ground
cable of the power supply must be grounded by professionals.Check the power supply voltage before
use.
● Technical parameter table:
Function mode setting:
Display panel
MENU Switch the main menu to
UP Parameter adjustment
DOWN Parameter Adjustment
ENTER determine
The
serial
number
The rated
voltage
AC110V /240V ± 10% /50Hz to 60Hz
1
Rated
power
60W
2
Laser
power
Green: 60-80MW, wavelength 515nm,
Red: 100-500mw wavelength 638nm
Blue: 200-800mw wavelength at 450nm
3
Laser color
Green or red or blue
4
The LED
color
Yellow or white light
5
The work
environme
nt
indoor
6
The
control
mode
DMX512 mode, automatic mode, voice
mode
7
The
control
channel
7.9.19.24 CH
MENU UP DOWN ENTER

III
● Menu function
Addre
001-512.
512 Address Settings
Chnd
07CH
7 Channel Settings
09CH
9 Channel Settings
18CH
18 Channel Settings
24CH
24 channel Settings
Slnd
Auto
Automatic mode
Soun
Voice control mode
Slve 1
Console mode
Slve 2
Vice machine model
Shnd
Sh 0-9
Effect 0- Effect 9
Auto Speed
0-100.
Self-running speed adjustment
Sound Sense
0-100.
Acoustic sensitivity adjustment
Nodmx Set
Blac
None 512 signal returns to zero
Auto
None 512 signal self-routing
Sound
None 512 signal voice control
LED
OFF
Open out the screen
ON
Shut out the screen
Disp
Yes
Turn off reverse display
ON
Enable reverse display
RPan
OFF
X motor running forward
ON
X motor reversal
Rest
YES
The system reset
●Channel functions:
The laser show adopts standard DMX-512 signal, divided into 7 channel and 9 channel, 18 channel, 24 channel control mode.
7 channel mode
channel
function
instructions
1
0-255.
X motor operation
2
0-255.
X motor speed
3
0-255.
0-255 Overall brightness adjustment
4
0-127.
LED self-walking built-in effect (0-9)
128-255.
LED voice control built-in effect (0-9)
5
0-127.
Self-propelled Built-in effects (0-9)
128-255.
Built-in voice control effect (0-9)
6
0-255.
Speed/voice sensitivity
7
250-255.
reset
9 channel mode
channel
function
instructions
1
0-255.
X motor operation
2
0-255.
X motor speed
3
0-255.
0-255 Overall brightness adjustment
4
0-255.
Adjust stroboscopic speed
5
0-255.
Laser self-propelled effect
6
0-255.
Laser self-travel speed
7
0-255.
LED self-walking effect

IV
8
0-255.
LED self-going speed
9
250-255.
reset
18 channel mode
1
0-255.
X motor operation
2
0-255.
X motor speed
3
0-255.
BAR1 brightness adjustment
4
0-255.
BAR2 brightness adjustment
5
0-255.
BAR3 brightness adjustment
6
0-255.
BAR4 brightness adjustment
7
0-255.
BAR5 brightness adjustment
8
0-255.
BAR6 brightness adjustment
9
0-255.
BAR7 brightness adjustment
10
0-255.
BAR8 brightness adjustment
11
0-255.
The first group was bright white
12
0-255.
The second group was bright white
13
0-255.
The third group was bright white
14
0-255.
The fourth group was bright white
15
0-255.
The fifth group was bright white
16
0-255.
The sixth group is bright white
17
0-255.
Group 7 is bright white
18
0-255.
Group 8 is bright white
24-channel mode
channel
function
instructions
1
0-255.
X motor operation
2
0-255.
X motor speed
3
0-255.
0-255 Overall brightness adjustment
4
0-255.
BAR1 brightness adjustment
5
0-255.
BAR2 brightness adjustment
6
0-255.
BAR3 brightness adjustment
7
0-255.
BAR4 brightness adjustment
8
0-255.
BAR5 brightness adjustment
9
0-255.
BAR6 brightness adjustment
10
0-255.
BAR7 brightness adjustment
11
0-255.
BAR8 brightness adjustment
12
0-255.
The first group was bright white
13
0-255.
The second group was bright white
14
0-255.
The third group was bright white
15
0-255.
The fourth group was bright white
16
0-255.
The fifth group was bright white
17
0-255.
The sixth group is bright white
18
0-255.
Group 7 is bright white
19
0-255.
Group 8 is bright white
20
0-255.
Adjust stroboscopic speed
21
0-127.
LED self-walking built-in effect (0-9)
128-255.
LED voice control built-in effect (0-9)
22
0-127.
Self-propelled Built-in effects (0-9)
128-255.
Built-in voice control effect (0-9)
23
0-255.
Speed/voice sensitivity
24
250-255.
reset
H000
000-255.
Motor fine-tuning

V
P000
20-250.
Motor trip
Warning!!!!!!
Do not look directly at the light source when the light is on.Make sure the power supply
is switched off before any installation or maintenance work.
Low maintenance:
1, as far as possible to eliminate dust, dirt and smoke laying and even into the lamp body, the use of
the environment as far as possible to keep the laser show clean;
2, please use professional glass cleaning agent and flannelette cleaning mirror every month to ensure
the maximum laser brightness output and can prolong the service life of the light source, pay attention
to do not use wet cloth or other chemical solvents to wipe the lens, cleaning times depending on the
operation frequency of the lamp and the use of the surrounding environment;Cleaning is
recommended every 15 days.
Warranty Rules:
1. During the warranty period, if the fault occurs when the product is used under normal
conditions, you can show the warranty card and the purchased ticket sample (copy) according
to the content of this warranty regulation, and enjoy free maintenance service in the designated
service center or the factory.
2. During the warranty period, the following conditions will be paid repair service.
(1) No valid warranty card can be issued;
(2) There is omission, alteration and no sales name on the warranty card;
(3) Failure or damage caused by irresistability;
(4) Failure or damage caused in transportation or unloading;
(5) Failure or damage caused by failure to follow the instructions;
(6) Failure or damage caused by disassembly, repair or modification of the product without the
authorization of the manufacturer or non-professional personnel.
(7) Failure caused by the use of control system not approved by the factory or not matched by the
factory.
(8) Consumables (light source)
3. Please keep this warranty card properly and it will not be replaced if lost.
Low statement:
1、When this product leaves the factory, the performance is intact, the package is complete.All
users should strictly abide by the above stated warning and operation instructions, any damage caused
by misuse is not covered by our warranty, and the manufacturer is not responsible for the failure and
problems caused by ignoring the operation manual.
2、The company reserves the right to interpret the relevant matters stated in this manual.
