Nexa NC-1200 User manual

- 1 -
NC-1200
BARCODE SCANNER
Configuration Guide

- 2 -
Table of Contents
Chapter 1 System Information
1.1 About this manual 3
1.2 How to set up the parameter-I 3
1.3 How to set up the parameter –II 4
1.4 Resetting the standard product default 4
Chapter 2 System Setup
2.1 Interface selection
2.1.1 Keyboard emulation parameters setting 6
2.1.2 RS-232 communication setting 11
2.2 Scanning mode selection 16
2.3 Beeper tone selection 17
2.4 String Options (Prefix & Suffix) 18
2. Setup Insertion 19
Chapter 3 BarCode parameters setting
3.1 UPC-A 23
3.2 UPC-E 26
3.3 EAN-13 29
3.4 EAN-8 31
3. Code39 33
3.6 Codabar 36
3.7 Code93 40
3.8 Code128 42
3.9 Interleaved2 of 4
3.10 Industrial 2of 47
3.11 Matrix 2 of 49
3.12 China Postage 1
3.13 MSI/Plessey 3
3.14 Code 32
3.1 Code 11 7
3.16 Telepen 9
3.17 Function Key Emulation &
Function Code & Appendix 61

- 3 -
Chapter 1 - System Information
1.1 About this manual
This User's Guide provides detailed programming instructions. Barcode
scanners are factory programmed for the most common communication
setting. If you need to change these settings, programming is accomplished
by scanning the bar codes in this guide.
1.2 How to set up the parameter
Step 1: Scan the start configuration barcode
Start Configuration
Step 2: Scan necessary label for parameters that meet your application
Step 3: Scan end configuration to save the changes
End Configuration

- 4 -
1.3 How to set up the parameter – II
Most of time the scanner only requests one read of parameters when
changing to new values. You will hear two beeps when you successfully
set to the new values. But for some special parameters, multiple reads are
needed to complete the configuration. When use these special parameters.
In some cases, you might need to read one or more barcodes, such as:
Hexadecimal barcodes. For example: prefix, suffix, etc.
Numeric barcodes. For example: inter-character delay, max/min length
To complete the change of setting you will need to read the “Confirm”
barcode after you read the parameter. Below is the flow chart to explain
two different configurations.
1.4 Resetting the standard product default
If you aren’t sure what programming options are in your
scanner, or you’ve changed some options and want the
factory settings restored, scan the Standard Product
Default Settings bar code below.
Standard Product Defaults Setting

- 5 -
Chapter 2 - System setup
2.1 Interface selection
The scanner is designed to switch easily from interfaces.
Remember to reset the interface before changing to PS/2 or RS232 cable.
No presetting is requested for USB interface. Scanning USB bar code after
the cable is changed and activating the scanner by plugging the USB cable
again. USB interface complies with HID keyboard which means the setting
of USB scanner is exactly the same like the default setting from keyboard.
Start configuration End configuration
ITEM OPTION
Interface Selection
* KEYBOARD
RS-232
USB

- 6 -
2.1.1 Keyboard emulation parameters setting
Start configuration End configuration
ITEM OPTION
Device Selection for keyboard
Interface
*IBM AT
IBM XT
IBM PS/2 30-80
IBM 0
PS/2 2 ，30
NEC 9801
Reserved 1
Reserved 2

- 7 -
Start configuration End configuration
ITEM OPTION
Language for Keyboard Interface
* USA
ITALIAN
SPANISH
FRENCH
GERMAN
JAPANESE
Multi-Language Support
Reserved 1

- 8 -
Start configuration End configuration
ITEM OPTION
Function Key
* Disable
Enable
Emulate External Keyboard
* Disable
Enable
ALT Mode
* Disable
Enable
NOTE : Emulate External Keyboard
Scan the barcode below if you do not have an external keyboard.
After scanning the Emulate External Keyboard bar code, you must
power cycle your computer.

- 9 -
Start configuration End configuration
ITEM OPTION
Caps Lock
* Disable
Enable
Num Lock
* Disable
Enable
Inter Character Delay
(Default：00)
Ref: Appendix（00—64H）

- 10 -
Start configuration End configuration
ITEM OPTION
Terminator
None
* CR
Tab
ESC
CR + LF
Block transmission delay
(Default：00)
Ref: Appendix（00—0AH）
Keyboard Speed
(Default 00: high clock rate)
Ref: Appendix（00—08H）

- 11 -
2.1.2 RS-232 communication setting
Start configuration End configuration
ITEM OPTION
Baud Rate
1200bps
2400bps
4800bps
* 9600bps
19200bps
38400bps
Data Bits
7 Bits
* 8 Bits

- 12 -
Start configuration End configuration
ITEM OPTION
Stop Bits
* 1 Stop Bits
2 Stop Bits
Parity
* NONE
ODD
EVEN
Mark
Space

- 13 -
Start configuration End configuration
ITEM OPTION
Inter-character delay
(Default：00)
Ref: Appendix（00—64H）
Block transmission delay
(Default：00)
Ref: Appendix (00-0AH)
Response delay
(Default：00)
Ref: Appendix (00-0AH)
HANSHAKING
* None
RTS/CTS
ACK/NAK
Xon/Xoff

- 14 -
Start configuration End configuration
ITEM OPTION
Terminator
For RS-232
None
* CR+LF
CR
LF
Tab
STX/ETX
EOT

- 15 -
Start configuration End configuration
ITEM OPTION
Handshaking
* None
RTS/CTS
ACK/NAK
Xon/Xoff

- 16 -
2.2 Scanning mode selection
Start configuration End configuration
ITEM OPTION
Reading Mode
* Trigger On/Good Read Off
Trigger On/Off
Continuous/Trigger Off
Continuous/Testing
Continuous/Trigger on
Continuous /Auto power on
Flash
Flash / Auto Power On

- 17 -
2.3 Beeper tone selection
Start configuration End configuration
ITEM OPTION
Beep Tone
(Default：09H)
Ref: Appendix (00-10H)
Beep Sound Duration
(Default：0 H)
Ref: Appendix (00-10H)
Power On Beeper
* Enable
Disable
Beeper
* ON
OFF

- 18 -
2.4 String Options (Prefix & Suffix)
This section describes the alterations which can be made to the format of
the transmitted data string. A prefix and suffix of maximum 10 direct
input may be included in front and at the end of scanned barcode.
Format
{Prefix} {Code ID} {Bar Code} {Suffix}
How to set up a prefi ?
To configure “## “as prefix
(1) Scan Start Configuration barcode
(2) Scan Preamble bar code
(3) Scan ‘#” twice from FULL ASCII table
(4) Scan Confirm configuration barcode
( ) Scan End Configuration barcode.
How to set up a suffi ?
To configure “$$” as suffix
(1) Start configuration barcode
(2) Scan Postamble barcode
(3) Scan ‘$” twice from FULL ASCII table
(4) Scan Confirm configuration barcode
( ) Scan End configuration barcode.

- 19 -
2. Setup Insertion
This section describes how to setup the insertion of output.
NOTE :
♦Max. 10 charters can be inserted each time
♦Max. Insertion group is only two.
♦Insertion group (01) or (02) can be used in different kinds of
barcodes at the same time

- 20 -
E ample:
:
To insert character “A” before the third digit(3)
Make the decoded data: 12A34 6789
How to set up a character you want to insert
(1) Scan Start Configuration barcode
(2) Scan “G1 Insertion character”
(3) Scan “4” and “1” from FULL ASCII Table
(4) Scan Confirm configuration barcode
( ) Scan End configuration barcode
How to set up position you wish to place the character
(6) Scan Start Configuration barcode
(7) Scan “G1 Character Position”
(8) Scan “0” and “3” from FULL ASCII Table (which presents the position)
(9) Scan Confirm configuration barcode
(10) Scan End configuration barcode
How to set up insertion for code 39
Go to chapter 3. (code 39)
(11) Scan Start Configuration barcode
(12) Scan “Insert group selection” bar code
(13) scan “0” and “1” from FULL ASCII Table
(which presents the group- 01 you just set up previously)
(14) Scan Confirm configuration bar code
(1 ) Scan End configuration barcode
