REA VeriCube Operating Manual Version 2.16 –11/2020 Page 1 of 119

REA VeriCube

Verifier for Matrix Codes and

Barcodes

Operating Manual

Document Version 2.16

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 2 of 119

Credits

Version: 2.1.6 English

Any reproduction of these Operation Instructions either in part or as a whole, including

electronic processing, reproduction, or dissemination, without written permission from REA

Elektronik GmbH is prohibited.

Although this document has been prepared with utmost care and caution, there is always a

possibility that it may nonetheless contain erroneous figures and inaccuracies. REA Elektronik

is not liable for any damages which may arise from inaccuracies in the document.

REA Elektronik constantly strives to improve its products and therefore reserves the right to

make changes to the figures and data contained in this document on an ongoing basis

without prior notice.

REA Elektronik GmbH

Teichwiesenstraße 1

D-64367 Mühltal

Tel.: +49 (0)6154-638-0

Fax.: +49 (0)6154-638-195

E-Mail: r[email protected]

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 3 of 119

Document history

Version

date

description

author

2.01

2018-02-09

Table with tolerances for calibration

S.Liebler

2.10

2018-02-16

Safety instructions, license conditions

S.Liebler

2.11

2018-05-11

Terms of guarantee, datasheet, accessories,

temporary IP address

S.Liebler

2.12

2019-05-13

Revision adjustment and calibration,

adjustment with Dnom=0.75, device

maintenance/cleaning, report radiation

emission

S.Liebler

2.13

2019-08-20

EU declaration of conformity, 11.10 View of

the reports, 12.1 Evaluation, Techn.data

camera modules

S.Liebler

2.14

2019-11-26

Screenshots for adjustment changed 9.1, new

icons for mirror live image and manual

brightness of live image (CD9.09)

S.Liebler

2.15

2020-08-16

Contact in 13, Technical data, system

requirements, part-no. calibration card, new

functions automatic measurement +

behaviour with screensaver from CD9.15

S.Liebler

2.16

2020-11-03

New calibration function from CD9.17

VeriCube-UV, IR added

S.Liebler

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 4 of 119

Table of contents

1Introduction ...............................................................................................7

2Delivery scope............................................................................................7

2.1 Basic configuration ................................................................................7

2.2 VeriCube variations ...............................................................................8

2.3 Optional accessories ..............................................................................8

2.4 Software options ................................................................................. 11

3Transport, storage and operating conditions................................................. 12

4Safety Instructions.................................................................................... 13

4.1 General safety .................................................................................... 13

4.2 Additional safety instructions for REA VeriCube UV .................................. 15

4.3 Electrical hazards ................................................................................ 16

5REA VeriCube Version................................................................................ 17

5.1 REA VeriCube Standard........................................................................ 17

5.2 REA VeriCube Pharma.......................................................................... 17

5.3 REA VeriCube UV ................................................................................ 18

5.4 REA VeriCube IR ................................................................................. 20

6Commissioning ......................................................................................... 20

6.1 Power supply ...................................................................................... 20

6.2 System requirements .......................................................................... 21

6.3 Temperature change ........................................................................... 21

6.4 Connecting ......................................................................................... 22

6.4.1 Own Ethernet port ......................................................................... 23

6.4.2 Network operation ......................................................................... 24

6.4.3 PoE in switch................................................................................. 24

6.4.4 MAC addresses.............................................................................. 24

6.4.5 Firewall and network type............................................................... 24

6.4.6 Firewall and Network ports ............................................................. 25

6.4.7 Using a gateway ............................................................................ 25

6.4.8 Fixed IP Addresses......................................................................... 25

6.5 Software ............................................................................................ 26

6.5.1 Software installation ...................................................................... 26

6.5.2 Software and device options ........................................................... 28

6.6 Mounting and exchanging the camera lens module .................................. 34

7Correct handling ....................................................................................... 35

7.1 General considerations......................................................................... 35

7.2 Checklist for measuring........................................................................ 36

8Operating the device ................................................................................. 38

9Adjustment and Calibration of the REA VeriCube........................................... 40

9.1 Adjustment of REA VeriCube................................................................. 42

9.1.1 Level correction............................................................................. 47

9.1.2 Reflectance adjustment .................................................................. 50

9.1.3 Scale adjustment........................................................................... 51

9.2 REA VeriCube calibration ...................................................................... 52

9.2.1 Admissible device tolerances for calibration with red light ................... 52

9.2.2 Calibration for white light ............................................................... 54

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 5 of 119

9.2.3 Calibration with REA calibration card ................................................ 55

9.2.4 Calibration with extended calibration cards ....................................... 60

10 Synthetic aperture / measuring opening ................................................... 62

11 Execution of the measurements ............................................................... 63

11.1 Positioning of the device.................................................................... 63

11.1.1 Camera downwards..................................................................... 63

11.1.2 Camera upwards......................................................................... 64

11.1.3 Camera sideways........................................................................ 65

11.1.4 Turning the keyboard .................................................................. 66

11.1.5 Testing 3D parts ......................................................................... 66

11.2 Measuring process using the Windows software.................................... 67

11.3 Automatic measurement mode........................................................... 69

11.4 Automatic ROI ................................................................................. 70

11.5 Mirror live image .............................................................................. 70

11.6 Setting the brightness of the live image .............................................. 71

11.7 Recording the image ......................................................................... 71

11.8 Opening the image file ...................................................................... 71

11.9 Saving the image file ........................................................................ 72

11.10 Static reflection measurement............................................................ 72

11.11 Preset the measurement image size ................................................... 73

11.12 Rotating the image ........................................................................... 73

11.13 Behaviour of the software TransWin32 when locking the PC................... 74

11.14 View of the Reports .......................................................................... 74

11.15 Details in the test reports .................................................................. 78

12 Configuring the evaluation and symbologies .............................................. 80

12.1 Evaluation ....................................................................................... 81

12.2 Symbology selection ......................................................................... 82

12.3 Lighting and aperture........................................................................ 84

12.4 Profile management.......................................................................... 86

12.5 File Saving Options ........................................................................... 87

12.6 Device data ..................................................................................... 89

12.7 User management ............................................................................ 90

12.7.1 Simple user name ....................................................................... 90

12.7.2 Simple password ........................................................................ 90

12.7.3 Setting up the user management.................................................. 91

12.7.4 User management during operation .............................................. 94

12.7.5 Transwin32 configuration protection.............................................. 96

13 Trouble shooting .................................................................................... 97

14 Maintenance and cleaning ..................................................................... 102

15 Intellectual property reserve ................................................................. 102

16 Software update .................................................................................. 103

17 Protected trademarks ........................................................................... 104

18 License conditions ................................................................................ 105

18.1 License Agreement ......................................................................... 106

18.2 Limited support and fault / error rectifications.................................... 106

18.3 Export limitations ........................................................................... 107

18.4 Maintenance .................................................................................. 107

18.5 Liability ......................................................................................... 107

19 Certificate of conformity for REA VeriCube............................................... 108

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 6 of 119

20 Certificate of conformity for the REA calibration cards............................... 109

21 EU declaration of conformity for the REA VeriCube ................................... 110

22 Technical data ..................................................................................... 111

23 Measurement Report radiation emission.................................................. 114

24 Terms of guarantee.............................................................................. 114

25 Attachment ......................................................................................... 116

25.1 General symbols used in this manual ................................................ 116

25.2 Abbreviations used ......................................................................... 117

25.3 Handling ....................................................................................... 117

25.4 Manager’s Obligations ..................................................................... 118

25.5 Obligation of the user ..................................................................... 118

25.6 Intended use ................................................................................. 118

25.7 Recycling....................................................................................... 119

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 7 of 119

1Introduction

The REA VeriCube is a measurement device for the quality control of printed 2D

matrix codes and 1D barcodes. This is a stationary device, which has to be connected

to a PC via an Ethernet network. The application software along with the device

driver and the display of the test reports run on a computer running Microsoft

Windows.

In contrast to a scanner for barcodes and matrix codes, REA VeriCube is an optically

operating measurement device. Measurement devices are subject to a regular

adjustment and calibration (monitoring of testing equipment). Adjustment and

calibration (monitoring of testing equipment) can be performed by the operator and

as long as calibration is successful, there is no need to return the unit to the

manufacturer.

An overview of all Verifier variants and brochures can be found on our website:

https://www.rea-verifier.com

2Delivery scope

The REA VeriCube in its basic configuration is delivered in cardboard packaging and

fitting foam padding with the following parts:

2.1 Basic configuration

1 REA VeriCube, test unit with operating unit as per delivery note (see following

chapter for available types)

1 optic module, exchangeable, according to the delivery note (built into the unit)

1 Plexiglas dust-protection cover –built-in in transport (must be replaced with a

glass plate during commissioning)

1 anti-reflective glass plate (08316280) (separately packaged)

1 GigaBit PoE power supply unit (100–240V, 30W) (06113003)

1 power cable for the ordered plug standard (Euro, UK, US)

2 network cables, highly flexible, RJ45 CAT7 (08316608)

1 printed operating manual (this document)

1 USB stick with software and documentation (08316300)

1 calibration card, serialized, in a protective envelope (90031702)

1 test report of the reference code of the calibration card, created with the delivered

VeriCube for documenting the delivery status

1 test report of the reference code (req. for test equipment monitoring)

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 8 of 119

1 white level correction calibration card (protected in new condition with blue

protection foil) in a protective envelope (90031703) (can be cleaned with 3M Novec

71IPA)

1 field of view cover as a black PVC plate (07601403)

1 field of view cover as a black cloth (07799084)

2.2 VeriCube variations

VeriCube

Type

description

Artikel-Nr.

Standard

with threaded mounting holes for mounting customer-

specific devices or stops

030.035.000

Pharma

as standard, but with closed plate without holes

030.035.001

Inline

as standard, but with PLC interface with 24V digital I/O

030.035.004

Diffuse

Standard

as standard, but with diffuse lighting

030.035.050

Diffuse

Pharma

as pharma, but with diffuse lighting

030.035.051

DPM

as pharma, but with dome lighting

030.035.061

as pharma, but with lighting 660/365nm

030.035.011

IR 945 nm

as pharma, but with lighting 660/945nm

030.035.141

IR 855 nm

as pharma, but with lighting 660/855nm

030.035.131

2.3 Optional accessories

Optional parts are only included if they have been ordered and are listed separately

on the delivery note. License keys are not necessary. In devices that are already in

operation, optional functions can be activated later by means of license keys.

Camera modules

There is a variety of different camera modules available. Depending on the range of

codesizes and module sizes that have to be measured, the appropriate camera

module must be selected. For UV and IR, a camera module set up for this purpose

must be used, because with this lighting option the focus position shifts relative to

that for red and white light.

At least one camera module must be specified when ordering.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 9 of 119

Camera modules for red and white lighting:

Measuring plane 0mm (on the glass pane):

030.037.100

Camera module for matrix codes typical>= 0.44 mm

(focal length 8 mm, field of view 114 x 71 mm)

030.037.101

Camera module for matrix codes typical >= 0.31 mm

(focal length 12 mm, field of view 80 x 60 mm)

030.037.102

Camera module for matrix codes typical >= 0.25 mm

(focal length 16 mm, field of view 64 x 47 mm)

030.037.103

Camera module for matrix codes typical >= 0.14 mm

(focal length 25 mm, field of view 37 x 27 mm)

030.037.104

Camera module for matrix codes typical >= 0.042 mm

(focal length 50 mm, field of view 9 x 6 mm)

Measuring plane +15mm (Inline application or with stand):

030.037.112

Camera module for matrix codes typical >= 0,27 mm

(focal length 16 mm, field of view 68 x 51 mm)

030.037.113

Camera module for matrix codes typical >= 0,16 mm

(focal length 25 mm, field of view 40 x 30 mm)

030.037.114

Camera module for matrix codes typical >= 0,05 mm

(focal length 50 mm, field of view 10 x 7 mm)

Measuring plane +45mm (Inline application or with stand):

030.037.123

Camera module for matrix codes typical >= 0,2 mm

(focal length 25 mm, field of view 47 x 25 mm)

Camera module for UV lighting:

Measuring plane 0mm (on the glass pane):

030.037.202

Camera module for UV - matrix codes typical >= 0,27 mm

(focal length 16 mm, field of view 68 x 51 mm)

Camera module for IR lighting:

Measuring plane 0mm (on the glass pane):

030.037.301

Camera module for IR 855nm - matrix codes typical >= 0.31 mm

(focal length 12 mm, field of view 80 x 60 mm)

030.037.302

Camera module for IR 855nm - matrix codes typical >= 0.25 mm

(focal length 16 mm, field of view 64 x 47 mm)

030.037.401

Camera module for IR 945nm - matrix codes typical >= 0.31 mm

(focal length 12 mm, field of view 80 x 60 mm)

030.037.402

Camera module for IR 945nm - matrix codes typical >= 0.25 mm

(focal length 16 mm, field of view 64 x 47 mm)

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 10 of 119

98031601 REA VeriCube compact case

09930162 REA VeriCube High quality aluminium case incl. packaging

Optional test cards for extended monitoring of the testing equipment

90031705 (replaces 98320009) Calibrated test card with EAN/UPC codes (AI)

90031704 (replaces 98320008) Calibrated test card Data Matrix Codes (AI)

90031706 Calibration card GS1-128 (AI)

90031707 Kalibrierkarte GS1-Databar EAN/UPC (AI)

08316223 Focal distance tool 15mm & 45mm

99031621 Spacer 15mm (only required for 15mm distance between optics, please

order separately)

98031600 30+45mm spacer set Accessories for spacer 99031621

99031640 Adjustable positioning stop VeriCube

08316222 Protective Cover VeriCube

030.037.200 Measuring table –one measuring table as a table for parts / cans which

can neither be left on the REA VeriCube for measuring nor placed on the REA

VeriCube.

99031620 Stand –REA VeriCube can be mounted into our height-adjustable stand

and used with the camera modules with focus position +15mm. This combination is

mainly used for checking codes on components/products (circuit boards, brake discs,

hoses, surgical instruments, etc.

08250330 USB Gigabit Ethernet Adapter

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 11 of 119

2.4 Software options

030.207.101

Optional symbologies (internal software option)

08300920

ScanLink –testing the structured code content (additional installation)

030.207.160

Comparator function (internal software option)

030.207.170

Article database32 (additional installation)

030.035.180

Code analysis (internal software option) Software extension for client-

specific analysis of data structures using a definition table

030.035.181

DPM -ISO/IEC TR 29158 (AIM DPM Guideline 2006) (internal software

option) Measurement evaluation for direct part marking, limited to

45° illumination

030.035.183

Audit Trail software option (new installation necessary)

When ordering internal software options, these are activated by entering an

activation code. If a software option is purchased subsequently, it is supplied with an

activation key only, which must be entered in TranWin32.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 12 of 119

3Transport, storage and operating conditions

The REA VeriCube can only be transported in the supplied

case or transport packaging.

Transport: The REA VeriCube is delivered in a case or in a cardboard

box with adequate foam padding. This package should be preserved

for possible transportation. The REA VeriCube should only be

transported in its original packaging, especially with parcel services

and similar means. In case, it is shipped without the original

packaging though, it should be packaged with good padding, so that

the device cannot move in the cardboard shipment box.

The glass pane must always be removed for transport and the plastic

pane must then be used as a protection. The glass cover must always be removed

prior to the transportation and then the plastic cover must be used as protection.

After transportation, the device must be warmed up to room temperature because

the optical parts can be fogged by the temperature change.

Storage: The device should always be stored in dry, dust-free rooms and at room

temperature. When not in use, the device should be covered or stored in the

transport packaging to protect it from dust deposits. For storage, remove the glass

pane and insert the plastic pane.

Dust on the optically effective surfaces leads to misalignment of the optical

measuring paths. This leads to incorrect measurement results.

Operation: Humidity, cold, heat and mechanical impacts incurred when the

equipment is dropped, can lead to a situation where the measuring chamber cover as

well as the mechanical and electronic parts can be damaged or destroyed.

If the device still provides measurement results with these damages, there is a high

risk that these results are incorrect or deviate too far from the correct values.

The device is delivered with a plastic cover and a top plate, which protect the

measuring chamber. The plastic cover serves as dust protection during the storage

and transportation of the REA VeriCube. The glass plate serves as a top plate in the

event that the codes to be measured need to be placed on the surface. The glass top

plate must always be removed prior to the transportation and the plastic cover used

as protection.

ATTENTION

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 13 of 119

4Safety Instructions

4.1 General safety

Before setting up the REA product and using it, please read and strictly observe

these operating instructions very carefully, especially the safety instructions.

Supplementary notes can be found in Annex 24. Symbols are described in 24.1.

The REA Verifier tester REA VeriCube is built according to state of the art and

recognized safety regulations. Nevertheless, its use risks to life and limb of the user

or others, or damage to the REA VeriCube or other property may arise.

The REA VeriCube is

to use in accordance with the intended use.

to put into operation in absolutely perfect condition.

Disorders that may affect safety must be rectified immediately.

(See chapter "Intended Use, Chapter 24.6").

In case of breakdown, the REA VeriCube must shut down immediately and must only

be taken back into operation after proper repair!

Warning:

Commissioning, operation and any subsequent applicable

service may only be performed by trained personnel.

Warning:

Before maintenance work or other interventions, it is

obligatory to turn off the verifier and unplug the power

cord. Otherwise there is a risk of damage on the device or

even personal injury because of electrical voltage.

Warning:

Don’t cover the power supply (PoE injector). Risk of

overheating and danger of fire.

Warning LED lighting:

In the REA VeriCube, LEDs with red light 660nm and white

light 4000K are used. It is essential to avoid looking directly

into the LEDs, otherwise the eyes might be damaged.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 14 of 119

Warning:

Be careful with the glass cover. When the VeriCube is tilted,

it could slip out and fall down. Caution, danger of injury.

Warning:

Be careful with the glass cover. After a glass breakage, be

careful with possible glass splinters, danger of cutting.

Warning:

Caution when handling the VeriCube: Cutting danger of injury at

the corners and edges of the device.

Cleaning

If necessary, clean the housing with a damp (not wet) cloth.

Clean glass cover with a damp cloth (e.g. microfiber as attached with

shipment).

If necessary, clean the lense of the camera module and the mirror only

with special auxiliary means for optical lenses.

Attention: cleaning with solvents will destroy the device

Dust may only be removed with compressed air, if it is completely free of

oils and other contaminants. In dusty environments, it is recommended

to protect the device and cover it if possible.

Electrostatic sensitive parts

Electrostatic discharges should be avoided as they can destroy the device.

Functional test

It is recommended to do a monthly review (calibration) of the accuracy of

the verifier by measuring the supplied test code.(See Section 11 Calibration)

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 15 of 119

4.2 Additional safety instructions for REA VeriCube UV

In addition to the safety instructions in chapter 4.1General safety the following must

be observed when operating the REA VeriCube UV:

Attention! The device works with UV radiation. It must only be used with

appropriate protective measures in accordance with EU Directive 2006/25/EC

In countries outside the EU, it is obligatory to comply with the occupational

safety regulations that are in force in that country.

The warning sign "UV radiation”

must not be removed from the device or concealed or made

unrecognisable in any other way.

UV protective glasses are supplied with the unit. It is recommended that these

glasses be put on before the installation or commissioning process and before each

power-up.

The unit switches on the UV-LED's during continuous operation. The unit should

therefore only be installed in a room where it is not possible to enter without taking

protective measures (wearing UV glasses).

With REA VeriCube UV the irradiation values according to EN 62471:2008 for the skin

directly on the device are exceeded. For longer-term work at the radiation source it is

therefore recommended to wear opaque clothing and gloves. During operation,

please always cover the field of view with the black plate or black cover cloth after

the object has been positioned.

The use of the device is the sole responsibility of the user. The

manufacturer REA Elektronik GmbH is not liable for any damages

caused by the use of the device. This exclusion of liability is only limited

by legal regulations that apply to contracts or transactions between

companies (BtB).

The manufacturer REA Elektronik GmbH has designed this product, REA

VeriCube with UV LED's 365nm, exclusively for commercial use with

appropriate protective devices. Use in private areas and / or without

protective equipment is NOT intended use. The liability for damage

resulting from such improper use, lies exclusively with the user.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 16 of 119

4.3 Electrical hazards

Warning:

When mains plug is unplugged or a main switch is switched off

during cleaning, maintenance or repair work, appropriate measures

must be taken to prevent unauthorized re-establishment of the mains

connection. This applies to the power supply. The verifier itself falls

under the category of Low Voltage.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 17 of 119

5REA VeriCube Version

5.1 REA VeriCube Standard

The REA VeriCube, in the standard design, has 13 screws on the upper side. With the

exception of any two screws, all the others can be removed.

The plate is either in blue or silver in color. The screws have Torx T10 heads.

The screws are there to close the threaded holes. The threaded holes are provided

for fastening the used fixtures when, for example, auxiliaries and other measurement

aids must be affixed to the device. The advantage of this is that frequently made

measurements of identical products can be performed by the device without the

positioning aided by the live image function.

5.2 REA VeriCube Pharma

The REA VeriCube in the Pharma design has a closed plate at the top without screw

holes.

This design is intended for use in areas in which it must be possible to clean the

surface easily and quickly.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 18 of 119

5.3 REA VeriCube UV

The REA VeriCube UV has an ultraviolet illumination as an alternative to the red light

illumination with 660 nm. For this alternative illumination there are arranged 16 UV-

LEDs with a wavelength of 365 nm in the unit.

This applies to VeriCube devices with UV illumination

Devices can be identified by a warning sign:

Please read this manual completely before you start using the device!

Please pay particular attention to the safety instructions for the REA

VeriCube UV in chapter 4.1General safety + 4.2Additional safety

instructions for REA VeriCube UV

With REA VeriCube UV the irradiation values according to EN 62471:2008 for the skin

directly on the device are exceeded. For longer-term work at the radiation source it is

therefore recommended to wear opaque clothing and gloves. During operation,

please always cover the field of view with the black plate or black cover cloth after

the object has been positioned.

The Level correction when adjusting this type of test instrument differs from the

standard procedure. The greyscale card must be used here instead of the luminance

card. Please refer to the note in chapter Level adjustment procedure for this type of

verifier.

Attention should be paid to the fact, that upon UV illumination, dirt will get visible,

that was invisible with natural light before, like for example thin layers of fat,

fingerprints etc. Extremely precise attention to cleanliness is a prerequisite

for reproducible measurements.

It is recommended to always wear gloves (e.g. Monochrom article no.: 5241L) when

handling the device in order to avoid contamination of the verifier, the calibration /

adjustment cards and the measuring objects.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 19 of 119

For the reflectance adjustment the blue component of the UV-LED light is used,

which is within the sensitivity range of the camera. An absolute reference to national

standards is not established in this case, but only a reference to the reflectance

values measured with red light as a reference. This adjustment is used to obtain

repeatable, stable measurement results that refer to a defined standard.

The typical measurement objects are markings with dyes / inks / printing colors that

are invisible or completely transparent in visible light. In UV light, these markings

generate fluorescence in the visible range of the light spectrum. This light, which is

generated by fluorescence is evaluated as if it were a reflected light from the surface.

Due to the adjustment, described above, the UV light source has an always identical

intensity. Thus, the fluorescence is evaluated with stable lighting values. The

evaluation must be in accordance with ISO/IEC TR 29158 (DPM).

Attention:

The focusing plane of the camera module in UV is shifted in relation to

that in red light. If the REA VeriCube UV is to be used for measurements

with red light, it is essential that a suitable camera module is then used

for red light.

REA VeriCube Operating Manual Version 2.16 –11/2020 Page 20 of 119

5.4 REA VeriCube IR

The REA VeriCube IR has an infrared illumination as an alternative to the red light

illumination with 660 nm.

REA has two different versions for infrared lighting in its portfolio.

The REA VeriCube IR can be purchased as a variant with 855 nm or with 945 nm.

With these types of device, IR is always the alternative lighting to red light. For this

alternative lighting, the device contains 16 IR LEDs with a wavelength of 855 nm or

945 nm.

Handling, adjustment and calibration are the same with the REA VeriCube IR as with

the standard device. However, it should be noted that due to unavoidable reflections

through the glass pane, a warning appears during Level correction: "Level correction

finished with a warning. Warning: the calibration card seems dirty. Please clean it.

However, on this occasion the adjustment result has been accepted. [0x20081285].“

This warning can be noted in this case, but work can still continue normally.

The reflections can only be prevented if both the adjustment and the measurements

afterwards are performed without the glass pane. This is also permitted. However, it

must be taken into account that the mirror in the device and the camera lens will

then become contaminated by dust more quickly and therefore have to be cleaned

regularly. As long as the device is not in operation it should be protected against

dust.

Attention:

The focusing plane of the camera module with IR lighting is shifted in

relation to that in red light. If the REA VeriCube IR is to be used for

measurements with red light, it is essential that a suitable camera module

is then used for red light.

6Commissioning

6.1 Power supply

The power for the VeriCube is supplied via a network cable connected to the device.

This type of power supply is designated as Power over Ethernet (PoE) (power supply

over a network cable). The delivered power supply unit provides power to a

connected device only when the device is designed for a power over Ethernet supply.

It is not recommended to connect a non PoE-enabled power supply device to the OUT

connection of the power supply unit. A second cable or additional separate power

supply unit is not necessary. The delivered network cables are, apart from the

increased flexibility, standard off-the-shelf network cables.
