Nexcom NSA 7136 User manual

NEXCOM International Co., Ltd.
NEXCOM International Co., Ltd.
Published November 2017 www.nexcom.com
Network and Communication Solutions
Network Security Appliance
NSA 7136
User Manual

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. ii NSA 7136 User Manual
Content
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Safety Information ................................................................................viii
Installation Recommendations...............................................................viii
Safety Precautions.................................................................................. ix
Technical Support and Assistance............................................................ x
Conventions Used in this Manual............................................................ x
Global Service Contact Information........................................................ xi
Package Contents.................................................................................xiii
Ordering Information ............................................................................xiv
Chapter 1: Product Introduction
Overview ................................................................................................1
Key Features ...........................................................................................1
Hardware Specifications..........................................................................2
Knowing Your NSA 7136 ........................................................................3
Front Panel ..........................................................................................3
Rear Panel ...........................................................................................4
Chapter 2: Jumpers and Connectors
Before You Begin ....................................................................................5
Precautions ............................................................................................5
Jumper Settings ......................................................................................6
Locations of the Jumpers and Connectors...............................................7
Jumpers..................................................................................................8
TPM Select ..........................................................................................8
RTC Clear............................................................................................8
ME Firmware Update ..........................................................................9
Password Clear ...................................................................................9
BIOS Recovery ..................................................................................10
Watchdog Setting ............................................................................10
Console Type Selection (RTS/CTS) ......................................................11
Console Type Selection (RTS/CTS) ......................................................11
Connector Pin Definitions .....................................................................12
External Connectors ..........................................................................12
System Reset Button ......................................................................12
RJ45 Console Port..........................................................................12
Internal Connectors...........................................................................13
VGA Connector .............................................................................13
SATA Connectors ...........................................................................13
LCM Header...................................................................................14
USB Headers ..................................................................................14
Fan Headers...................................................................................15
ATX Connector ..............................................................................15
ATX Connector ..............................................................................16

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. iii NSA 7136 User Manual
Content
PCIe Slots.......................................................................................17
Block Diagram ......................................................................................19
Chapter 3: System Setup
Removing the Chassis Cover .................................................................20
Installing an External SATA Hard Drive...................................................21
Installing a LAN Module........................................................................23
Installing the Rackmount Rails...............................................................25
Chapter 4: BIOS Setup
About BIOS Setup.................................................................................27
When to Configure the BIOS.................................................................27
Default Configuration...........................................................................28
Entering Setup......................................................................................28
Legends................................................................................................28
BIOS Setup Utility..................................................................................30
Main .................................................................................................30
Advanced .........................................................................................31
Intel RC Setup ..................................................................................39
Security ............................................................................................50
Boot..................................................................................................50
Save & Exit ........................................................................................51

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. iv NSA 7136 User Manual
Preface
PrefaCe
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NEXCOM
International Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NEXCOM International Co., Ltd. However,
users may update their knowledge of any product in use by constantly checking
its manual posted on our website: http://www.nexcom.com. NEXCOM shall
not be liable for direct, indirect, special, incidental, or consequential damages
arising out of the use of any product, nor for any infringements upon the rights
of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed.
Acknowledgements
NSA 7136 is a trademark of NEXCOM International Co., Ltd. All other
product names mentioned herein are registered trademarks of their
respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class A devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. vNSA 7136 User Manual
Preface
RoHS Compliance
NEXCOM RoHS Environmental Policy and Status
Update
NEXCOM is a global citizen for building the digital
infrastructure. We are committed to providing green
products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in
Electronic Equipment) directive 2011/65/EU, to be your trusted green
partner and to protect our environment.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg)
< 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent
Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) <
0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or
1,000ppm.
In order to meet the RoHS compliant directives, NEXCOM has established an
engineering and manufacturing task force in to implement the introduction
of green products. The task force will ensure that we follow the standard
NEXCOM development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NEXCOM are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NEXCOM RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2013 will be RoHS compliant.
They will use the usual NEXCOM naming convention.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. vi NSA 7136 User Manual
Preface
Warranty and RMA
NEXCOM Warranty Period
NEXCOM manufactures products that are new or equivalent to new in
accordance with industry standard. NEXCOM warrants that products will
be free from defect in material and workmanship for 2 years, beginning on
the date of invoice by NEXCOM. HCP series products (Blade Server) which
are manufactured by NEXCOM are covered by a three year warranty period.
NEXCOM Return Merchandise Authorization (RMA)
▪Customers shall enclose the “NEXCOM RMA Service Form” with the
returned packages.
▪Customers must collect all the information about the problems
encountered and note anything abnormal or, print out any on-screen
messages, and describe the problems on the “NEXCOM RMA Service
Form” for the RMA number apply process.
▪Customers can send back the faulty products with or without accessories
(manuals, cable, etc.) and any components from the card, such as CPU
and RAM. If the components were suspected as part of the problems,
please note clearly which components are included. Otherwise, NEXCOM
is not responsible for the devices/parts.
▪Customers are responsible for the safe packaging of defective products,
making sure it is durable enough to be resistant against further damage
and deterioration during transportation. In case of damages occurred
during transportation, the repair is treated as “Out of Warranty.”
▪Any products returned by NEXCOM to other locations besides the
customers’ site will bear an extra charge and will be billed to the customer.
Repair Service Charges for Out-of-Warranty Products
NEXCOM will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
Repair Service Charges for Out-of-Warranty Products
NEXCOM will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
System Level
▪Component fee: NEXCOM will only charge for main components such as
SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistor, capacitor.
▪Items will be replaced with NEXCOM products if the original one cannot
be repaired. Ex: motherboard, power supply, etc.
▪Replace with 3rd party products if needed.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.
Board Level
▪Component fee: NEXCOM will only charge for main components, such
as SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistors, capacitors.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. vii NSA 7136 User Manual
Preface
Warnings
Read and adhere to all warnings, cautions, and notices in this guide and
the documentation supplied with the chassis, power supply, and accessory
modules. If the instructions for the chassis and power supply are inconsistent
with these instructions or the instructions for accessory modules, contact
the supplier to find out how you can ensure that your computer meets
safety and regulatory requirements.
Cautions
Electrostatic discharge (ESD) can damage system components. Do the
described procedures only at an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an antistatic
wrist strap and attaching it to a metal part of the computer chassis.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. viii NSA 7136 User Manual
Preface
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.
▪The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. ix NSA 7136 User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. Do not place heavy objects on the equipment.
16. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. xNSA 7136 User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NEXCOM products, visit NEXCOM’s
website at www.nexcom.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. xi NSA 7136 User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
9F, No. 920, Chung-Cheng Rd.,
ZhongHe District, New Taipei City, 23586,
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com
America
USA
NEXCOM USA
2883 Bayview Drive,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com
Asia
Taiwan
NEXCOM Intelligent Systems
Taipei Office
13F, No.920, Chung-Cheng Rd.,
ZhongHe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
NEXCOM Intelligent Systems
Taichung Office
16F, No.250, Sec. 2, Chongde Rd.,
Beitun Dist.,
Taichung City 406, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
Japan
NEXCOM Japan
9F, Tamachi Hara Bldg.,
4-11-5, Shiba Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
China
NEXCOM China
Floor 5, No.4, No.7 fengxian middle Rd.,
(Beike Industrial Park), Haidian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. xii NSA 7136 User Manual
Preface
Europe
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu
Italy
NEXCOM ITALIA S.r.l
Via Lanino 42,
21047 Saronno (VA), Italia
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomitalia.it
NEXCOM Shanghai
Room 603/604, Huiyinmingzun Plaza Bldg., 1,
No.609, Yunlin East Rd.,
Shanghai, 200333, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM Surveillance Technology Corp.
Room202, Building B,
the GuangMing Industrial Zone Zhonghua Rd.,
Minzhi Street, Longhua District,
Shenzhen 518131, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM United System Service
Hui Yin Ming Zun Building Room 1108,
Building No. 11, 599 Yunling Road, Putuo District,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. xiii NSA 7136 User Manual
Preface
Package Contents
Before continuing, verify that the NSA 7136 package that you received is
complete. Your package should have all the items listed in the following
table.
Item Part Number Name Description Qty
1 19S00713600X0 NSA 7136 1
2 50311F0095X00 Flat Head Screw Long Fei:F6#32Tx5 Nylok NIGP F6#32Tx5 NI Nylok 4
3 50311F0100X00 Round Head Screw w/Spring+Flat Washer Long Fei:P3x6L P3x6 iso/SW6x0.5 NI 1
4 50311F0162X00 Round Head Screw w/Washer Long Fei P4x8 iso/w NI 1
5 50311F0512X00 F Head Screw Long Fei:F2.5x6L ISO Black+Nylok F2.5x6L ISO Black+Nylok 8
6 5040150001X00 NSA 7135 AL Handle VER:A Panadvance 78x58x8mm 1
7 5044440031X00 Rubber Foot Kang Yang:RF20-5-4P 19.8x18x5.0mm 4
8 6012200052X00 PE Zipper Bag #8 170x240mm, w/China RoHS Symbol 1
9 6012200053X00 PE Zipper Bag #3 100x70mm, w/China RoHS Symbol 1
10 6023309081X00 Cable EDI: 232091081804-RS COM Port. DB9 Female to RJ45 8P8C L:1800mm 1

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. xiv NSA 7136 User Manual
Preface
Ordering Information
The following information below provides ordering information for NSA 7136.
Barebone
NSA 7136 (P/N: 10S00713600X0)
2U Intel®Xeon®E5-2600 v4/v3 PCH C612, with LCM, 1 swappable 3.5” HDD
tray, 3 swappable system fans, 8 LAN module (NI/NX series) bays, 700W PSU
LAN Modules
Model P/N Interface Type Port Number Bypass/Segment Expansion Slot Location Slot
NX 140F 10S20140F01X0 XL710-AM1 PCIe x8 4 SFP+ None None All Slot
NX 142F 10S20142F01X0 XL710-AM1 PCIe x8 4 SFP+ 2 bypass None All Slot
NX 142F-LR 10S20142F03X0 XL710-BM1 PCIe x8 4 SFP+ 2 bypass None All Slot
NX 120F 10S20120F00X0 X710-BM2 PCIe x8 2 SFP+ None None All Slot
NI 140F 10SK000NI02X0 i350AM4x1 PCIe x8 4 SFP None None All Slot
NI 180F 10S10180F01X0 i350AM4x2 PCIe x8 8 SFP None None All Slot
NI 142C 10SK000NI03X0 i350AM4x1 PCIe x8 4 Copper 2 bypass None All Slot
NI 180C 10S10180C01X0 i350AM4x2 PCIe x8 8 Copper None None All Slot
NI 184C 10S10184C01X0 i350AM4x2 PCIe x8 8 Copper 4 bypass None All Slot
NI 142F 10S10142F01X0 i350AM4x1 PCIe x8 4 SFP 2 bypass None All Slot
NI 121F 10S10121F01X0 i350AM2x1 PCIe x8 2 SFP 1 bypass None All Slot
NI 140C 10S10140C01X0 i350AM4x1 PCIe x8 4 Copper None None All Slot
NV 120F 10S50120F01X0 XXV710-AM2 PCIe x8 2 QSFP None None All Slot
NC220Q28M 10S30022002X0 MT27708A0-FDCF-CE PCIe x16 2 QSFP28 None None 1,2/ 3,4/ 5,6/ 7,8

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. 1NSA 7136 User Manual
Chapter 1: Product Introduction
ChaPter 1: ProduCt IntroduCtIon
Key Features
▪Dual Intel®Xeon®processor E5-2600 v4/v3 product family
▪Support DDR4 1866/2133/2400 ECC & REG, up to 512GB
▪Modular design supports 8 LAN module slots
Overview
▪Support swappable 3.5” SATA/SAS HDD
▪Support CRPS (1 + 1) redundant power supply
▪Support LCD module

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. 2NSA 7136 User Manual
Chapter 1: Product Introduction
Hardware Specifications
Main Board
▪NSB 7136
▪Dual Intel®Xeon®processor E5-2600 v4/v3 product family
▪Support 9.6 GT/s QPI speed
▪Intel®C612
▪One PCIe x8 expansion slot (Internal)
LAN Features
▪Swappable LAN modules
▪Support Intel®i350/ Intel®XL710 Copper/Fiber ports
▪Support 10/100/1000/10G link speed
▪LAN Bypass: ** please see LAN module list information
I/O Interface-Front
▪Support 2 x 20 characters LCD module, SIO interface
▪Power status/ HDD status/ GPIO status/ system failure status LEDs
▪1 x 3.5” HDD swappable bays
▪8 x LAN module bays
▪2 x USB 2.0 ports
▪1 x RJ45 type console port
▪1 x Reset button
▪2 x Management LAN ports
I/O Interface-Rear
▪3 x Swappable system FANs
▪1 x Power button switch
▪1 x VGA Port
▪2 x USB 2.0 ports
Main Memory
▪16 x 284-pin DDR4 1866/2133/2400 DIMM sockets, up to 512GB ECC
& REG SDRAM
Devices
▪1 x on-board CFast socket
Power Input
▪700W 1+1 CRPS redundant power supply
Chassis Dimensions
▪Chassis dimension: 432 mm x 550 mm x 88 mm
▪Carton dimension: 774 mm x 636 mm x 293 mm
Weight
▪Without packing: 19kg
▪With packing: 25kg
Environment
▪Operating temperature: 0°C~40°C
▪Storage temperature: -20°C~75°C
▪Relative humidity: 10%~90% non-condensing
Certifications
▪CE approval
▪FCC Class A
▪UL

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. 3NSA 7136 User Manual
Chapter 1: Product Introduction
Knowing Your NSA 7136
LCD
Front Panel
Reset
button
USB
ports
RJ45 type
console port
Management LAN
HDD bay LAN modules
LCD
2x20 characters LCD module, SIO interface.
HDD Bay
One 3.5” HDD swappable bay for installing a HDD.
LAN Modules
Eight LAN module bays.
Reset Button
Press to restart the system.
USB Ports
Used to connect USB 2.0/1.1 devices.
Console Port
Used to connect RJ45 type console port.
Management LAN Ports
Two LAN ports used for managing the system.
LED Indicators
Indicates the power, hard drive and GPIO activity of the system.
LED indicators
GPIO Power LED
HDD LEDSystem Failure
LED Color
Power Green
HDD Yellow
System Failure Red
GPIO Yellow

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. 4NSA 7136 User Manual
Chapter 1: Product Introduction
Rear Panel
Power
switch
VGA USB
ports
AC power
sockets
Power Switch
Press to power-on or power-off the system.
VGA
Used to connect an analog VGA monitor.
USB Ports
Used to connect USB 2.0/1.1 devices.
AC Power Sockets
Dual redundant power supply sockets, plug an AC power cord here before
turning on the system.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. 5NSA 7136 User Manual
Chapter 2: Jumpers and Connectors
ChaPter 2: JumPers and ConneCtors
This chapter describes how to set the jumpers and connectors on the
NSA 7136 motherboard.
Before You Begin
▪Ensure you have a stable, clean working environment. Dust and dirt can
get into components and cause a malfunction. Use containers to keep
small components separated.
▪Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
– A Philips screwdriver
– A flat-tipped screwdriver
– A set of jewelers screwdrivers
– A grounding strap
– An anti-static pad
▪Using your fingers can disconnect most of the connections. It is
recommended that you do not use needle-nosed pliers to disconnect
connections as these can damage the soft metal or plastic parts of the
connectors.
▪Before working on internal components, make sure that the power is off.
Ground yourself before touching any internal components, by touching
a metal object. Static electricity can damage many of the electronic
components. Humid environments tend to have less static electricity than
dry environments. A grounding strap is warranted whenever danger of
static electricity exists.
Precautions
Computer components and electronic circuit boards can be damaged by
discharges of static electricity. Working on computers that are still connected
to a power supply can be extremely dangerous.
Follow the guidelines below to avoid damage to your computer or yourself:
▪Always disconnect the unit from the power outlet whenever you are
working inside the case.
▪If possible, wear a grounded wrist strap when you are working inside the
computer case. Alternatively, discharge any static electricity by touching
the bare metal chassis of the unit case, or the bare metal body of any
other grounded appliance.
▪Hold electronic circuit boards by the edges only. Do not touch the
components on the board unless it is necessary to do so. Don’t flex or
stress the circuit board.
▪Leave all components inside the static-proof packaging that they shipped
with until they are ready for installation.
▪Use correct screws and do not over tighten screws.

Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved. 6NSA 7136 User Manual
Chapter 2: Jumpers and Connectors
Jumper Settings
A jumper is the simplest kind of electric switch. It consists of two metal
pins and a cap. When setting the jumpers, ensure that the jumper caps are
placed on the correct pins. When the jumper cap is placed on both pins, the
jumper is short. If you remove the jumper cap, or place the jumper cap on
just one pin, the jumper is open.
Refer to the illustrations below for examples of what the 2-pin and 3-pin
jumpers look like when they are short (on) and open (off).
Two-Pin Jumpers: Open (Left) and Short (Right)
Three-Pin Jumpers: Pins 1 and 2 are Short
1
2
3
1
2
3
