Night Watcher NW16TSP User manual

1
Protect yourself. Please read these instructions carefully prior to installation and retain them for
future reference.
Failure to follow any of these instructions could void product warranties.
0345 900 6764
www.nightwatcher.co.uk/support-centre
NW16TSP

2
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts,
cuts/abrasions and other hazards read all warnings and instructions included with and on the fixture box and all
fixture labels.
Before installing, servicing or performing routine maintenance upon this equipment, follow these general
precautions.
For Commercial Installation: Service and maintenance of this fixture should be performed by a qualified licensed
electrician.
For Residential Installation: If you are unsure about the installation or maintenance of this fixture, consult a
qualified, licensed electrician.
Do not mount the unit against flammable surfaces.
The motion detector will not operate correctly if it is installed:
oNear the outlet of a central heating boiler
oNear an air conditioning unit
oPointing directly at moving vehicles
oWithin sight of reflection from moving water
oWhere other lamps could shine on the detector
Fixtures can NOT be used with a dimmer switch, motion or occupancy sensor and other electronic switching
devices unless otherwise designated. LED fixtures must be powered directly off a switch circuit.
Do not install more than one motion sensor light on one wall switch.
This fixture should not be used in areas with limited ventilation or high ambient temperatures.
This fixture is intended to be connected to a properly installed and grounded.
These instructions do not claim to cover all details or variations in equipment or provide every possible
contingency to meet in connection with the installation, operation or maintenance. Should further information be
needed, you may contact Customer Service at : 0345 900 6764
WARNING: RISK OF ELECTRICAL SHOCK
Turn off electrical power at fuse or circuit breaker box before wiring fixture to the power supply.
Verify that the supply voltage is correct. Connect fixture to a 240volt, 50/60 Hz power source.
Make sure all electrical and grounded connections are in accordance with the National Electrical Code and any
applicable local code requirements.
All wiring connections must be proper isolated between wire connectors.
CAUTION: RISK OF PRODUCT DAMAGE
Never connect components under load.
Do not mount or support these fixtures in a manner that can cut the outer jacket or damage wire insulation.
Avoid covering LED fixtures with insulation, foam, or other material that will prevent convection or conduction
cooling.
Never connect an LED product directly to dimmer packs, occupancy sensors, timing devices or other related
control device, unless individual product specifications deem otherwise.
Unless individual product deems otherwise: do not exceed fixtures maximum ambient temperatures.
LED products are Polarity Sensitive. Ensure proper polarity before installation.
Electrostatic Discharge (ESD) can cause damage to LED fixtures. Personal grounding equipment must be worn
during all installation or servicing of the unit.
Do not touch the individual electronic components, it may cause ESD, shorten lamp life or alter performance.
CAUTION: RISK OF INJURY
Wear gloves and safety glasses at all times when removing fixture from carton, installing, servicing or performing
maintenance.
Avoid direct eye exposure to the light source while it is on. LED LAMPS ARE EXTREMELY BRIGHT. UNDER NO
CIRCUMSTANCES SHOULD YOU STARE INTO AN LED BEAM, THIS MAY CAUSE IRREPARABLE DAMAGE TO THE
EYE.
Account for small parts and destroy packaging materials, as these may be hazardous to children
WARNING: RISK OF BURN
Allow fixture to cool before handling. Do not touch enclosure of light source.
Do not exceed the maximum wattage marked on the label.
Keep combustible and other materials that can burn away from the luminaries, fixture and lamp/lens.

3
PRE-INSTALLATION
Before beginning assembly of the product, make sure all parts are present. Compare parts with package contents list and
hardware contents. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Installation time: 30 minutes.
Note: Fixture should be installed by persons with experience
in household wiring or by a qualified electrician. The
electrical system and the method of electrically connecting
this fixture to must be in accordance with the National
Electrical Code and local building codes.
Install the motion sensor 6.5 ft / 1.9 m - 10 ft / 3 m above the
ground. Motion sensor is less sensitive above 10 ft / 3 m.
Mount motion sensor so motion moves across detection
zone.
Mount sensor away from heat producing sources to
prevent false triggering. Also be very careful not to
include objects such as windows, white walls and water
in the detection zone.
Mount fixture away from moving objects such as trees
and street traffic.
Do not install more than one motion sensor light on one
wall switch.
Suitable for covered wall or eave mounting.
MOUNTING LOCATIONS
Determine the mounting location – a wall or under an eave.
Position the lamphead in the general direction of the
desired light coverage.
Note: Do not mount this light fixture on the ground.

4
PRE-INSTALLATION (Continued)
FIXTURE PACKING LIST
Part
Description
Quantity
A
Screw Hole Silicon cover
1
B
M4 X 56mm Center Screw
1
C
Drywall screw
2
D
Light Back Cover Plate
1
E
Plastic Masonry Plug
2
User Manual
1
Mounting Hardware included.
Tools Required for Installation (Not included):

5
INSTALLATION
Step 1. Installing the Mounting Bracket
Line up the holes of the light back cover plate Dwith the holes on your wall. Using
the two Drywall Screws Cand fix it tightly in ide the wall using the Plastic Masonry Plug E.
WARNING: Risk of electric shock. Disconnect power at fuse or circuit breaker
before installing or servicing.
CAUTION: Do not cut any wires with factory installed wire connectors or
remove the wire connectors.
Step 2: Wiring the Light Fixture
Connect the light wires inside the connection block .The mains wire should pass through the
Plastic Cover Bracket (D)
Neutral (Blue) to Neutral (Blue)
Earth (Green) to Earth ( Green/Yellow}
Live ( Brown) to Live (Brown )
Note: Make sure the polarity is correct.

6
INSTALLATION (Continued)
Step 3. Mounting the Light Fixture
Install the Light Fixture BODY to the wall Mounting cover Bracket (D) with affixed Center Screws (B).
Cover the hole of the Light Fixture screw hole with (A) the Decorative Silicon Cover .
Note: Make sure all the wires are properly connected inside the connection block before attaching the light to the
wall.
Step 4. Caulking Around the Light Fixture
Caulking Around the Light Fixture: For additional protection, caulk around the joint between the light fixture and
mounting bracket using a silicon sealant. (not included)

7
OPERATION
Adjusting the Lamp heads
1Adjusting the lamp heads; Adjust the lamp head direction by moving up and down within a range of 15 degrees. You
may also adjust the light position from side to side to select the required lamp direction.
Adjust the lamp head direction by moving up and
down
Note: LED LAMPS ARE NON-REPLACEABLE. Do not attempt to access / maintain the LEDs; they are non replaceable
and any contact may damage the LEDs and will void the warranty.
2The Motion Sensor Detector
Detection Range: 49.2 ft. / 15 M * 220 degrees on an optimum installation height of 2.5 meters
Note: When you first install your security light, ensure the PIR detector cover the desired area.

8
PIR Sensor Adjustment
Time Setting:
You can set the time span at a minimum of around 5 seconds by turning the TIME setting counter-clockwise or
set it at maximum around 7 minutes by turning the TIME setting fully clockwise. The security light will stay on
as long as motion is detected and will go off after the time span you set after no motion is detected.
Sensitivity Setting:
Adjust the SENS setting to adjust range of Passive Infrared Motion Sensor (2M – 15M)
Dusk Level/Ambient Light (LUX) Setting
This setting is used to control the ambient light level for the motion security light to turn on. You can set the
light to turn on only in the darkness by turning the LUX setting to counter-clockwise position. Or allow
the security light to trigger even during daylight by turning the LUX setting to full clockwise or at ambient
light level in between.
NB: LED LAMPS ARE NON-REPLACEABLE: Do not attempt to access / maintain the LED’s they are
non-replaceable and any contact may damage the LED’s.
Red LED sensor indicator:
The Red LED light will flash twice when triggered to indicate the PIR sensor is functioning correctly

9
Manual Override Function:
When powered on, the PIR sensor enters a “warm-up” period for about 20 seconds (the red LED sensor
indicator will light on), then automatically switches into AUTO MODE.
During AUTO MODE, by switching the mains switch OFF – ON – OFF – ON in about 2 seconds, the PIR sensor
will automatically change into MANUAL MODE, the lights will remain ON, and with NOT be controlled by time
duration or ambient light (LUX) levels, The MANUAL MODE will change to AUTO MODE in 6 hours
automatically.
During MANUAL MODE, by switching the main switch OFF then back ON again, the PIR sensor will reset the
“warm-up” period and then AUTO MODE.
SPECIFICATIONS
1. Detection Method: Passive Infrared Sensor (PIR)
2. Sensor Range: 2M - 15M x 220 degree spread (approx.)
3. Time Adjustment: 5 seconds to 7 minutes (approx.)
4. Power Source: 220-240VAC/50Hz
5. With AC COB LED Chip: 2 pcs * 18W
6. Load Rating: No extra Lights should be added to this unit
