Nightowl Stage Lighting RGBW4IN1 LED User manual

LED blinder light
LED Matrix 25X10W COB BLINDER
RGBW4IN1 LED
USER MANUAL
Ver1.0

Table of contents
Foreword ............................................................1
1. Before you operating ·················· ···············2
1.1 Packing list ························· ···············2
1.2Unpacking instructions ···················· 2
1.3 AC Power ························· ·············· 2
1.4 Safety instructions··············· ················ 2
2. Introduction ··············································3
2.1 Features ···························· ·············· 3
2.2 DMX channel··································· 3
3. Setup ······································ ···············8
3.1Fuse replacement································· 8
3.2 Fixt ure link ing ··································· 8
4. Operating instructions················· ················ 9
4.1 Menu configure ··································9
4.2 Menu function map········· ·············· 10
4.3 User configurations········· ·············· 10
4.4 LED rangement·············· ·············· 19
5. Technical specifications·············· ···············19
5.1 Technical specifications ········ ·············19
5.2 Warranty······································· 20

Warning! Confirm the voltage to select switch which can be matched the circuit
with the light. If it is different from the supply power and light, it will damage the
light! All the light must be connected the earth, not all the lights have the switch
to be selected.
Please connect the correct voltage!
Thank you for purchasing a Nightowl 25 LEDs Blinder.These Blinder light will provide you will years of trouble free service and allow you
to be far more flexible and innovative due to their color mixing capabilities, low power consumption, and the variety of control options.
To optimize the performance of this product, please read these operating instructions carefully to familiarize yourself with its basic
operations. These instructions contain important safety information regarding the use and maintenance of this unit. Please keep this
manual for future reference.
Safety and Proper Use
0 When unpacking and before disposing of the carton check there’s no transportation damage before using the projector. Should
there be any damage caused by transportation, consult your dealer and do not use the apparatus.
0 The projector is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain and moisture, excessive heat,
humidity and dust. Do not allow contact with water or any other liquids.
0 DO NOT mount the projector directly onto in ammable surface
0 The projector is only intended for installation, operation and maintenance by qualited personnel.
0 The projector must be installed in a location with adequate ventilation, at least 50cm from adjacent wall surfaces. Be sure that
no ventilation slots are blocked.
0 Do not project the beam onto in ammable surfaces, minimum distance is 5m
0 Avoid direct exposure to the light from the lamp. The light is harmful to the eye. Do not attempt to dismantle and/or modify the
projector in any way.
0 Electrical connection must only be carried out by qualited personnel.
0 Before installation, ensure that the voltage and frequency of power supply match the power requirements of the projector. It is
essential that each projector is correctly earthed and that electrical installation conforms to all relevant standards.
0 Keep a projector’s optical system clean. Do not touch LED lens with bare hands.
0 The projector should always be installed with a secondary safety. A safety cord is supplied for this; it should be attached as
shown in “installing the projector” section.
0 Shields and lens shall be changed if they have become visibly damaged to such an extent than their effectiveness is impaired
1. Before you operating
1.1 Packing list
Product name
Quantity
LED Matrix Light
1 pcs
Power cable
1pcs
User manual
1pcs
1. 2 Un p a c k i n g i n s t ru c t i o n s
When you get this product, please take it from carton carefully to make sure whether all the accessories are in and damaged or not
When you find that there are any parts or wrong sign with the carton, or non-operation, please inform us and to keep the carton and shipping
bill completely.
1.3 AC P o w e r
Please check the manual book before you operate the light. The rating current of the light listed which shows the average current-consume
under the normal circumstances.
All the lights must be offered shoot-through circuit, it could not be connected dimmer circuit, although the dimmer channels are completely for
1-100% switch.
Before the light’s working, please confirm the correct voltage.

Please read these instructions carefully, it includes important information about
the light’s installation, usage and maintenance of this product.
1.4 Safety instructions
Please confirm the same voltage to the light.
The light could not be water-proof, it only allow to be used in door. Don’t expand the light in wet or rain day, to avoid fire or damaged light.
Please confirm there is no flammable material around the light.
The light must be set up the ventilating place. The distance is≥51cm around approach material. To check the air passage is OK at any time.
The Maximum temperature is ≤40℃(104℉).
When the lights has problems, please stop to use to contact the supplier. Don’t repair it by yourself!
Don’t connect by a dimmer.
To confirm the power wire is straight and non-damaged. Don’t pull it directly.
Don’t look at the bulb when the light is working to avoid any hurt.
2. Introduction
2.1 Features
9/30/105DMX channels.
RGBW 4-in-1 COB LED light source
life long is 50000-10000 hours.
Variable electronic dimmer(0-100%).
Control mode:Auto,sound,DMX512 mode
Cool: temperature protector
2. 2 DM X c h a n n e l
9 CH s
30 CHs
CH
Function
Description
1
Dimmer
R, G, B, W Dimmer, Linear Dimmer, Dark to Bright
2
Strobe
R, G, B Strobe, Slow to Fast
3
Function 1
0-13 DMX 9Channels Controlling;
14-21 Choice color;
22-29 Color jumping to change;
30-37 Color gradually change;
38-45 Patterns Run 1;
46-53 Patterns R u n 2 ;
.........................................
239-246 Patterns R u n 2 4 ;
247-255 Sound activation.
4
Function 2
0-5 DMX 9Channels Controlling
6-130 126pcs Patterns ch o i c e .
5
Function Speed 1
Function speed, from slow to fast.
Function Speed 2
0-31 Fixed Patterns direction 1;
32-63 Fixed Patterns direction 2;
64-95 Fixed Patterns direction 3;
9--126 Fixed Patterns direction 4;
127-195 Patterns clockwise rotation from slow to
fast;
196-255 Patterns Anticlockwise rotation from slow
to fast.
6
Red
R, Linear Dimmer, Dark to Bright
7
Green
G, Linear Dimmer, Dark to Bright
8
Blue
B, Linear Dimmer, Dark to Bright
9
White
W, Linear Dimmer, Dark to Bright
CH
Function
Description
1
Dimmer
R, G, B, W Dimmer, Linear Dimmer, Dark to Bright
2
Strobe
R, G, B Strobe, Slow to Fast
3
Function 1
0-13 DMX 30 Channels Controlling;

105 CHs
14-21 Choice color;
22-29 Color jumping to change;
30-37 Color gradually change;
38-45 Patterns Run 1;
46-53 Patterns R u n 2 ;
.........................................
239-246 Patterns R u n 2 4 ;
247-255 Sound activation.
4
Function 2
0-5 DMX 30 Channels Controlling
6-130 126pcs Patterns ch o i c e .
5
Function Speed 1
Function speed, from slow to fast.
Function
Speed 2
0-31 Fixed Patterns direction 1;
32-63 Fixed Patterns direction 2;
64-95 Fixed Patterns direction 3;
9--126 Fixed Patterns direction 4;
127-195 Patterns clockwise rotation from slow to
fast;
196-255 Patterns Anticlockwise rotation from slow
to fast.
6
1
R, G, B, W Linear Dimmer
7
2
R, G, B, W Linear Dimmer
8
3
R, G, B, W Linear Dimmer
9
4
R, G, B, W Linear Dimmer
......
.......
........
30
25
R, G, B, W Linear Dimmer
CH
Function
Description
1
Dimmer
R, G, B, W Dimmer, Linear Dimmer, Dark to Bright
2
Strobe
R, G, B Strobe, Slow to Fast
3
Function 1
0-13 DMX 105 Channels Controlling;
14-21 Choice color;
22-29 Color jumping to change;
30-37 Color gradually change;
38-45 Patterns Run 1;
46-53 Patterns R u n 2 ;
.........................................
239-246 Patterns R u n 2 4 ;
247-255 Sound activation.
4
Function 2
0-5 DMX 105 Channels Controlling
6-130 126pcs Patterns ch o i c e .
5
Function Speed 1
Function speed, from slow to fast.
Function
Speed 2
0-31 Fixed Patterns direction 1;
32-63 Fixed Patterns direction 2;
64-95 Fixed Patterns direction 3;
9--126 Fixed Patterns direction 4;
127-195 Patterns clockwise rotation from slow to
fast;
196-255 Patterns Anticlockwise rotation from slow
to fast.
6
R1
R1 Linear Dimmer
7
G1
G1 Linear Dimmer
8
B1
B1 Linear Dimmer
9
W1
W1 Linear Dimmer
10
R2
R2 Linear Dimmer
11
G2
G2 Linear Dimmer
12
B2
B2 Linear Dimmer
13
W2
W2 Linear Dimmer
...
.......
.........
105
W25
W25 Linear Dimmer

3. Setup
3.1 F ix t u r e li n k i n g
When you control the light’s master/slave or DMX 512 signal agreement, the lights can be connected by signal wire which the distance is ≤
500m,The maximum connect lights are 32pcs more or less, and adapt DMX light pair to segregate the signal zoom equipment, in order to
protect the light’s signal won’t be interrupted by other signal. Moreover, it won’t affect by the signal wire’s length
Da t a co n n e c t
Data cable is connected by DMX data wire, and XLR. Please use hi-quality data cable signal wire, it won’t be interrupted by magnetic.
Ch a r a c t e r i s t i c s of D M X d a t a ca b l e
2 conductors’ double tree lace and shield.
The maximum capacitance of the conductors-30 pF/ft.
The maximum capacitance of the conductor and shield -55 pF/ft.
The maximum resistance is 20 ohms/1000ft.
The nominal impedance 100-140 ohms.
DMX opt coupler segregate signal zoom equipment’s 3 pin(5 pin) XLR plug.
3.2 Setting up a DMX signal connect
As following pictures show, please connect the first light to the signal cable which is with XLR by DMX controller, then, connect light in
series.
The light must be set up the ventilating place. To confirm there is nothing to hinder the heat dissipation place. When the light is hanged,
please choose a safety wire.
4. Operating instructions
4.1 Menu configurations
Access control panel functions using the four panel buttons located directly under near the the LCD Display.
LCD display board
When a menu function is selected, the display will show immediately the first available option for the selected menu function. To select a
menu item, press<ENTER>.
Press the <MENU> button repeatedly until you reach the desired menu function. Use the <UP> and <DOWN> buttons to navigate the menu
options. Press the <ENTER> button to select the menu function currently displayed, or to enable a menu option. To return to the previous
option or menu without changing the value, press the <MENU> button.
No alternative worth that return re-option or menu, press (MENU) button
Button
Function
MENU
Used to access the menu or return to a previous
menu option.
DOWN
Scrolls through menu options in descending
order.
UP
Scrolls through menu options in ascending
order.
ENTER
Used to select and store the current menu or
option within a menu.
MENU
UP
DOWN
ENTER

4. 2 Me n u fu n c t i o n m a p
4. 3 U s e r co n f i g u r a t i o n s
Set-up 1pcs light`s menu mode (Auto-running)
.Press the MENU, such as the picture 4.2 shows the menu function
.Use the UP/DOWN buttons to choose the right one to confirm.
Set-up Master-slave mode
Press the MENU, same as picture 4.2 shows the menu function
Master: Set any one of lights to auto、sound or strobe control mode
Slave: Set them to DMX mode and their address code to1.
Notes ：Each Master-slave group can be one and only light in master, ensure lights under this group without connection with any DMX
controller.
Set-up DM X m o d e
The light can connect to the DMX controller to receive its signal indication, which control by DMX controller. DMX value is referenced by “
4. 5 L E D R a n g e m e n t :
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
5. Technical Specifications
5.1 Technical Specifications
No.
Display
Function
1
A001
9CH DMX Starting Address (001-512)
2
H001
30CH DMX Starting Address (001-512)
3
h001
105CH DMX Starting Address (001-512)
4
CC00
Jump Change 8 Color Chase (Speed 1-99)
5
Ed00
Gradual Change 8 Color Chase (Speed 1-99)
6
Er00
Pulse Change 8 Color Chase (Speed 1-99)
7
Tr00
Patterns Run Change (Speed 00-24),
Change Patterns by UP, BOWN Button.
8
Tu00
Run Change (Speed 00-99),
Change Speed by UP, BOWN Button.
9
BEB1
Sound Patterns Run Change (Speed 00-24), Change
Sound control Patterns by UP, BOWN Button.
10
R200
Red Preset (Level 0-255)
11
G200
Green Preset (Level 0-255)
12
B200
Blue Preset (Level 0-255)
13
W200
White Preset (Level 0-255)
14
OPRT
Master-slave mode
15
RST
Reset
Input Voltage
AC100V -240V, 50Hz/60Hz
Lamp resource
25 x 10W RGBW COB LED

5.2 Warranty
One (1) Year Limited Warranty
Subject to the limitations set forth below, Nightowl Stage Lighting hereby represents and warrants that the components of this
product shall be free from defects in workmanship and materials, including implied warranties of merchantability or fitness for a
particular purpose, subject to normal use and service, for one (1) year the original owner from the date of purchase.
Retailer and manufacturer shall not be liable for damages based upon inconvenience, loss of use of product, loss of time, interrupted
operation or commercial loss or any other incidental or consequential damages including but not limited to lost profits, downtime,
goodwill, damage to or replacement of equipment and property, and any costs of recovering, reprogramming, or reproducing any
program or data stored in equipment that is used with our products. This guarantee gives you specific legal rights. You may have other
legal rights which vary from country to state. Some country do not allow limitations on how long an implied warranty lasts, so the
above limitation may not apply to you.
Returns
Returned merchandise must be sent prepaid and in the original packing. Package must be clearly labeled with a Return Merchandise
Authorization Number (RMA #).
For repair and warrantee service contact contact Nightowl Stage Lighting at NightowlStageLighting.com for an RMA number and
shipping instructions. Include a phone number in case we need to speak to you in person. Our website contains all up to date contact
information.
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore, the damage must be reported to the carrier upon receipt of
merchandise. It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is damaged due
to shipping. Any other claim for items such as missing component/part, damage not related to shipping, and concealed damage, must
be made within seven (7) days of receiving merchandise. We will be happy to assist you with your shipping claim should there be an
issue.
Control model
Auto, sound, DMX512 signal
Max temperature
104°F(40°C)
Outside size
460 x 460 x 230mm
N.W
17kg
